RESIDENT PROGRAMMING QUICK REFERENCE

Some of the programming PPN's may be commonly used by the
resident. Following are quick references to the keystrokes required.
✦ NOTE: The "###" is the default command prefi x. The following example
assumes that the default has not been changed.
To Enter Programming Mode
Press: Master Code
Master Code = the current 6-digit Master Programming Code
To Exit Programming Mode & Save Changes
Press:
Re-entering a Command After a Mistake
If an incorrect entry, or an incorrect key is pressed during programming, to
clear the keypad:
Press:
Adding a Entry Code
Press: Code Code
Code = The new entry code: 1-999999, depending on code length
Relay = Relay output entry code will activate:
1 = Relay #1 2 = Relay #2 3 = Both Relays
4 = Relay #1 as priority user (no access restrictions)
Time Zone = 0 = no time zone; 1-7 to restrict access per time zone 1-7
Adding a Temporary Entry code
Press: Code Code
Valid From Valid Thru
Code = The new entry code: 1-999999, depending on code length
Relay = Relay output entry code will activate:
1 = Relay #1 2 = Relay #2 3 = Both Relays
Time Zone = 0 = no time zone; 1-7 to restrict access per time zone 1-7
Number = Number of times (1-255) that the entry code is allowed access
Valid From = First date (MMDDYY) that the entry code is valid
Valid Thru = Last date (MMDDYY) the entry code is valid.
Removing a Single Entry Code
Press: Code Code
Code = The entry code to remove.
Suspend or Activate a Single Transmitter
Press: Facility ID
Facility = Facility code 1-16 of transmitter (0 = no facility code)
ID = 5-digit ID number of transmitter
Action: 0 = Suspend transmitter; 1 = Re-activate transmitter
22
Relay Time Zone
Relay Time Zone Number
Action
Maximum Number of Visitor Rings
Press: Rings
Rings = 1-15 Rings maximum
Visitor Talk Time Limit
Press: Limit
Limit = 15-255 Seconds allowed
Call Waiting Feature On/Off
Press: Call Waiting
Call Waiting: 1 = ON; 2 = OFF
Call Forwarding
Press: Forwarding
Extension Delay
Forwarding: 0 = Call forwarding feature OFF
1 = Call forwarding feature ON at all times
2 = Call forwarding feature ON (scheduled by Time Zone)
Time Zone = 1-7 (Call forwarding feature active during this Time Zone)
Telephone Number = Up to 11-digit telephone number
Extension = Up to 4-digit telephone extension number
Delay = 1-25 seconds (delay between telephone number and extension)
"Do Not Disturb" Privacy Feature On/Off
Press: Privacy Time Zone
Privacy: 0 = Privacy feature OFF
1 = Privacy feature ON (scheduled by Time Zone)
2 = Privacy feature ON at all times
Time Zone = 1-7 (Privacy feature active during this Time Zone)
Automatic Door/Gate Open Time
Press: Relay 1st Time Zone
Relay: 1 = Relay #1
2 = Relay #2
1st Time Zone = Time Zone 1-7
2nd Time Zone = Time Zone 1-7 (enter "0" if the 2nd time zone is not used)
Setting Time Zones
Press: Time Zone Number
Start Minute AM/PM End Hour
Time Zone Number = 1-7
Active Days (Enter up to 8 digits):
1 = Sun; 2 = Mon; 3 = Tue; 4 = Wed; 5 = Thu; 6 = Fri; 7 = Sat; 8 = Holidays
Start Hour = 1-12 Start Minute = 0-59 AM/PM: 0 = AM; 1 = PM
End Hour = 1-12 End Minute = 0-59 AM/PM: 0 = AM; 1 = PM
Setting the Holiday Days
Press: Holiday Number
Holiday Number = 1-10
Month = 1-12
Day = 1-31
Time Zone Telephone Number
2nd Time Zone
Active Days Start Hour
End Minute AM/PM
Month Day
