Owners & ™ Regency Bellavista B41XTCE Installation Manual Gas Fireplace MODELS: B41XTCE-NG10 B41XTCE-LP10 www.regency-fire.com Bellavista B41XTCE Video WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
Page 2
To the New Owner: Congratulations! You are the owner of a state-of-the-art Gas Fireplace by REGENCY . The Bellavista™ ® B41XTCE has been designed to provide you with all the warmth and charm of a wood fireplace at the flick of a switch. The Bellavista™ B41XTCE has been approved by Warnock Hersey/Intertek for both safety and efficiency.
This appliance can only be used with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases. Ensure that structural members are not cut or weakened during installation. Bellavista Bellavista B36XT B41XTCE Video Gas Fireplace Benefits Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Accent Light Bulb Replacement ........56 Horizontal terminations ..........29 Valve Replacement ............57 Two (2) 90 Elbows (Rigid Pipe 5" x 8") ....29 Installing Valve .............57 Horizontal terminations ..........29 Main Assembly ............58 Burner Assembly ............59 The Warranty: Limited Lifetime ........63 Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Page 5
The State of Massachusetts requires the installation of a carbon monoxide alarm in accordance with NFPA 720 and a CO alarm with battery back up in the same room where the gas appliance is installed. Regency Bellavista™ B41XTCE-10 Gas Fireplace...
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipm ent, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. Regency Bellavista™ B41XTCE-10 Gas Fireplace...
2) The appliance when installed, must be electrically grounded in accordance with local codes, or in the absence of local codes with the current National Electrical Code, ANSI/ NFPA 70 or CSA C22.1 Canadian Electrical Code. Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Log Set Installation e. Standard Flush Door f. Remote Control g. Fan Installation (Optional) h. Light Installation (Optional) 7) Final check. Diagram 1 Flat on Wall Flat on Wall Corner Recessed into Wall/Alcove Corner Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Front to Back Wall (Maximum) Notes: 0" No Hearth Required Close to Ceiling Minimum Vent Clearances to Combustibles Horizontal Top 3" (76mm) Horizontal Side 2 " (51mm) Horizontal Bottom 2" (51mm) Vertical Vent 2" (51mm) Alcove 10 | Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Mantel Clearances Combustible Non-combustible Header (steel stud) 1" on edge Non-combustible Standoff Inches Top of Fireplace Opening To Floor Mantel Clearances B41XTCE From Top of 32-11/16" 25-13/16" 22-1/16" 17-9/16" Fireplace Opening (830mm) (656mm) (560mm) (446mm) Regency Bellavista™ B41XTCE-10 Gas Fireplace...
IN THIS AREA 3-9/16" [91mm] 38-7/16" 976mm 4-1/8" [105mm] NOTE: The 6" x 46-11/16" supplied with the unit is secured directly above the unit as shown above. **All other non-combustible material is supplied by others. 12 | Regency Bellavista™ B41XTCE-10 Gas Fireplace...
** Important: Framing height requires consideration of the hearth depth. Dimension N = N + the thickness of the installed hearth. Non-Combustible Drywall Header (or other (steel stud) facing) on edge Non-Combustible Header (steel stud) on edge Non-Combustible Facing 11" (279mm) dia. Hole through wall Vent. Opening for gas connection Regency Bellavista™ B41XTCE-10 Gas Fireplace...
NOTE: The 6" x 46-11/16" non combustible material supplied with this unit can be replaced if trying to achieve a clean finish. A large piece of non combustible material (ie. 4' x 8' x 1/2" can be used to eliminate taped seams on or near unit. 14 | Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Page 15
To maintain a clean finished edge - facing material edges may be finished with a J-style trim or metal cornerbead (both materials available at your local building or hardware store). IMPORTANT: Materials used must be NON-COMBUSTIBLE. Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Nailing strip for Clean Finish (set flush with unit) Nailing strip for Tile Finish (set Nailing strip for back 1/2") Tile Finish (set back 1/2") Nailing strip for Clean Finish (set flush with unit) 16 | Regency Bellavista™ B41XTCE-10 Gas Fireplace...
3) From the inside of the firebox, remove the exhaust assembly by remov- ing the 10 screws. Before proceeding to Step 8, inspect condition of all gaskets. DO NOT install parts with damaged gaskets. Replace if necessary with spare gaskets supplied. Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Page 18
Leave loose - until rear screws installed. See Diagram 3. Baffle Plate Diagram 3 Note: Reuse existing screw holes - do not make new holes. Tighten screws. Diagram 2 18 | Regency Bellavista™ B41XTCE-10 Gas Fireplace...
6) From inside the firebox, install the baffle plate with 4 - 1/4" x 1/2 " AT 1-1/2 screws. Ensure all screws are tightly secure, but do not over tighten. Diagram 1 Baffle Plate Diagram 3 Regency Bellavista™ B41XTCE-10 Gas Fireplace...
* Clearance in accordance with local installation codes and the requirements of the gas supplier 3 feet (91cm) within a height of 15 feet (4.5m) above the meter / regulator assembly 3 feet (91cm) above - if within 10 feet (3m) horizontally 20 | Regency Bellavista™ B41XTCE-10 Gas Fireplace...
5” X 8” RIGID PIPE CROSS REFERENCE CHART Components from different Manufacturers may not be mixed. Not all Rigid Pipe components are available directly from FPI. Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Description...
Page 22
• A Vent Guard is required when the AstroCap is installed above grade at 7 feet or lower. • The Simpson Dura-Vent and Selkirk Direct Temp horizontal termination caps cannot be used in any applications. • Only the AstroCap XL and Snorkels are certifi ed for horizontal terminations. 22 | Regency Bellavista™ B41XTCE-10 Gas Fireplace...
FLEX VENT OR RIGID PIPE 5" X 8" The diagrams show all allowable combinations of vent runs with 5" x 8" venting using the Regency direct vent system or rigid vent system. A vent guard should be used whenever the termination is lower than the specified minimum or as per local codes.
Notes: 1) Liner sections should be continuous without any joints or seams. 2) Only Flex pipe purchased from Regency may be used for Flex installations. 3) Regency Direct Vent System (Flex) is only approved for horizontal terminations.
Direct Vent Pro, ICC Excel and Selkirk ® Direct-Temp. AstroCap XL is a proprietary trademark of FPI Fireplace Products International Ltd. Dura-Vent® and Direct Vent are registered and/or proprietary trademarks of Simpson Dura-Vent Co. Inc. Regency Bellavista™ B41XTCE-10 Gas Fireplace...
A wall thimble is mandatory for all horizontal terminations due to high temperatures. Horizontal (Feet) Restrictor 1-1/2 Open Set 3 Restrictor 2-1/2 Open Set 2 Restrictor 3-1/2 Open Set 1 47-1/2" (1207mm) Minimum Height Requirement 28 | Regency Bellavista™ B41XTCE-10 Gas Fireplace...
90 6' Min. 5' Max. 11' Min. 8' Max. elbows is required. 7' Min. 6" Max. 12' Min. 9' Max. No Vent Restrictor Installed Lengths do not include elbow indicated. Must use rigid pipe adaptor #770-994. Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Refer to the "Vent Restrictor Position" section for details on how to change the vent restrictor from the factory setting to 3-1/2" opening, 2-1/2"opening and to 1-1/2" opening. Note: Must use optional flue adapter when using Rigid Pipe (Part # 770-994). 30 | Regency Bellavista™ B41XTCE-10 Gas Fireplace...
5' Min. 8' Min. 6' Max. 6' Min. 9' Min. 7' Max. 7' Min 10' Min. 8' Max. No Vent Restrictor Installed Lengths do not include elbow indicated. Must use rigid pipe adaptor #770-994 Regency Bellavista™ B41XTCE-10 Gas Fireplace...
4) Level the fireplace and fasten it to the framing using nails or screws through the top and side nailing strips. Diagram 7 Diagram 2 IMPORTANT Diagram 1 Must use Rear Venting Deflector packaged with unit in rear vent horizontal termination applications. 32 | Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Apply Mill Pac or high temperature silicone to the outer flex pipe and slip it over Wall Thimble the outer flue collar of the vent terminal at Screws least 1-3/8"(35mm) and fasten with the 3 screws. Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Diagram 2 vent height may solve the problem. Important: Always check for gas leaks with a soap and water solution or gas leak detector. Do not use open flame for leak testing. 34 | Regency Bellavista™ B41XTCE-10 Gas Fireplace...
4500 ft. follow current CAN/ CGA-B149.1. 885 S.I.T. VALVE DESCRIPTION 1) 6 Stage flame adjustment 2) Pilot adjustment 3) Inlet Pressure Tap 4) Outlet Pressure Tap 5) Pilot Outlet 6) Main Gas Outlet 7) Main Gas Inlet Regency Bellavista™ B41XTCE-10 Gas Fireplace...
fi rebox wall (left side shown). Position the left brick panel in place and secure with the brick panel clip and screw removed from the fi rebox as shown below. 36 | Regency Bellavista™ B41XTCE-10 Gas Fireplace 918-865a 11/09/09...
fi rebox. See diagram below. panel is centered when installed. Install the right side panel - secure with panel clip and 1 screw. See step 3. Top Panel Bracket Back Panel Right Side Panel Regency Bellavista™ B41XTCE-10 Gas Fireplace 05/29/12 918-866b...
Page 38
Top panel bracket shown installed with Stainless Steel Panels 5) Slide top panel under the top of the back and right side panels as shown below. 6) Install left side panel - repeat step 4. 38 | Regency Bellavista™ B41XTCE-10 Gas Fireplace 918-866a 11/09/09...
4) Place Log F on the right side of the burner, directly in front of Log A. Position Log F so it fi ts into the pin on the burner as shown below. Diagram 2 Vermiculite Diagram 4–Log F 05/29/15 918-863 Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Page 40
10) Slide the right side of Log G back until it touches the tab on the burner shown below. Tab on Burner Back of Log G Diagram 9 Diagram 6–Log G 40 | Regency Bellavista™ B41XTCE-10 Gas Fireplace 918-863 05/29/15...
Page 41
13) Position Log B on top of Log A. Log B fi ts into the pin in Log A. Ensure Log B sits upright 90 degrees with the left side of the log resting on the notch in Log E. See next 2 diagrams. Diagram 15 Diagram 12 Regency Bellavista™ B41XTCE-10 Gas Fireplace 05/29/15 918-863...
Page 42
19) Test fi re to ensure proper lighting (make sure fl ame fl ows smoothly from one end of the burner to the other). If there is any fl ame hesitation, check that area for any blockage of the burner ports. 42 | Regency Bellavista™ B41XTCE-10 Gas Fireplace 918-863 05/29/15...
2. Tuck any loose wires neatly underneath the firebox–inside the fireplace. Note: Ensure that wires do not touch the underside of the fire box (Keep wires away from heat as much as possible). AC adaptor Wire adaptor Regency Bellavista™ B41XTCE-10 Gas Fireplace...
CAUTION: Label all wires prior to disconnection Caution: Ensure that the wires do not touch any when servicing controls. Wiring errors can cause hot surfaces and are away from sharp edges. improper and dangerous operation. 1 of 10 44 | Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Connect the red wire into the grommet and push grommet into the Electrical fan assembly housing. Receptacle WHITE Push Fan down BLACK on mounting pins Ground Lug Plug fan power cord into receptacle. rear 8. Connect and secure fan ground cable to ground lug. 08/21/14 919-425 Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Page 46
46 | Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Caution: Ensure that the wires do not touch any hot surfaces and are away from sharp edges. CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Page 48
- see picture below. NOTE: When the remote receiver is set to ON position, the remote control transmitter and all of its features are now disabled. CAUTION Do not wire Thermostat wires to 120V wire. 48 | Regency Bellavista™ B41XTCE-10 Gas Fireplace...
fi rebox base. Left side shown, repeat for right side. Diagram 2: Slide burner assembly to the right and then remove. 7) Remove the 2 screws securing the rear log tray and lift out. Diagram 3 Diagram 3 Regency Bellavista™ B41XTCE-10 Gas Fireplace 08/12/14 918-864a...
Page 50
Note: Glass is longer than diffuser for ease of removal. Note: Oils from hands will shorten the life of the bulbs, do not handle bulbs with bare hands. 18) Reverse steps 9 - 1. 50 | Regency Bellavista™ B41XTCE-10 Gas Fireplace 918-864a 08/12/14...
Page 51
Optional Accent Light Green Extension Cord NOTE: Lights can be turned ON and OFF using the remote control AUX function on the hand held transmitter. See Remote Control instructions for details. No switch is required. 06/16/15 918-864b Regency Bellavista™ B41XTCE-10 Gas Fireplace...
1. To remove the safety screen, grasp on both sides from the bottom. Lift up and out slightly to release from bottom magnets and to release hooks on mesh frame from brackets inside unit (see below). Hooks on mesh barrier frame 3. To reinstall–reverse steps. 52 | Regency Bellavista™ B41XTCE-10 Gas Fireplace...
The glass should be cleaned or the film will bake on and become very difficult to remove. Use a non-abrasive cleaner and NEVER clean the glass while it is hot. Regency Bellavista™ B41XTCE-10 Gas Fireplace...
(see Diagram 2). An audible beep should be heard from the receiver. 2. If service to be performed–you must shut off power and disconnect gas to the unit. ON/OFF Button Diagram 2 Remote shown in Manual Mode on Hi 54 | Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Utilisez l'interrupteur murale ON/OFF du Brûleur ou du contrôle à distance pour éteindre le brûleur. Si le service est effectuée–vous devez débrancher l'alimentation et coupez le gaz à l'unité. DO NOT REMOVE THIS INSTRUCTION PLATE 919-401a Regency Bellavista™ B41XTCE-10 Gas Fireplace...
5) The appliance and venting system must be purchase your replacement from an authorized inspected before use, and at least annually, Regency dealer only. Replacement glass (Part by a qualified field service person, to ensure #940-383/P) is shipped already installed into the...
Diagram 2: Slide burner assembly to the right and then remove. 10) Reverse steps 9 - 1. 7) Remove the 2 screws securing the rear log tray and lift out. Diagram 3 Diagram 3 Regency Bellavista™ B41XTCE-10 Gas Fireplace 918-864a 08/12/14...
Diagram 3 11) Remove the 14 screws securing the Diagram 3 valve tray assembly in place (Diagram and then lift the entire assembly out Also remove the valve gasket. Diagram 7 58 | Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Thermodisc Bracket 508-010 Calcium Silicate Board 911-012 Ignition Module 919-375 Manual 948-259 Spring Handle Lever * Not available as a replacement part. 948-025 Spring Door Extension 940-383/P Ceramic Glass 506-083 Door Frame Outer box Assembly Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Pilot Holder Extruded 911-006 Pilot Assembly - NG 911-007 Pilot Assembly - LP 911-037 Flame Sensor 911-038 Flame Electrode 910-100 Pilot Orifice NG 910-101 Pilot Orifice LP 911-137 Pilot Clip 911-039 Pilot Hood 60 | Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Page 61
Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Page 62
62 | Regency Bellavista™ B41XTCE-10 Gas Fireplace...
Fireplace Products are designed with reliability and simplicity in mind. In addition, our internal Quality Assurance Team carefully inspects each unit thoroughly ® before it leaves our facility. FPI Fireplace Products International Ltd. is pleased to extend this limited lifetime warranty to the original purchaser of a Regency Product. This ®...
