INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions regarding installation, operation or service.
NOTICE: DO NOT DISCARD THIS MANUAL
MT. VERNON E2 PELLET STOVE
Model(s):
MTV-E2-CSB
MTV-E2-PFT
MTV-E2-PBK
Please read this entire manual before installation and use of this
pellet fuel-burning room heater. Failure to follow these instructions
could result in property damage, bodily injury or even death
CAUTION
Tested and approved for wood pellets and shelled
corn only. Burning of any other type of fuel voids your
warranty.
A 2:1 mix of pellets to corn is approved, but may require the
fi repot to be cleaned more frequently.
To obtain a French translation of this manual, please contact
your dealer or visit www.quadrafi re.com
Pour obtenir une traduction française de ce manuel, s'il vous
00
plaît contacter votre revendeur ou visitez www.quadrafi re.com
1
Owner's Manual
Operation & Care
MTV-E2-MBK
MTV-E2-PDB
MTV-E2-PMH
Tested and
O-T L
Listed by
C
OMNI-Test Laboratories, Inc.
061-S-83-2
NOTE
NOTE
Please read this entire manual
before use of this pellet fuel-burning
room heater. Failure to follow these
instructions could result in property
damage, bodily injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do NOT burn garbage or fl ammable fl uids
such as gasoline, naphtha, or engine oil in
room heater.
• Do not overfi re - If heater or chimney con-
nector glows, you are overfi ring. Overfi ring
will void your warranty.
• Comply with all minimum clearances to
combustibles as specifi ed. Failure to
comply may cause house fi re.
Portland
Oregon USA
US
Hot glass will cause burns.
•
Do not touch glass until it is cooled
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
fi replace.
•
Alert children and adults to hazards of high temperatures
•
High temperatures may ignite clothing or other
fl ammable materials.
•
Keep clothing, furniture, draperies and other fl ammable
materials away.
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and na-
tional codes and regulations.
• Consult local building, fi re offi cials or authorities having juris-
diction about restrictions, installation inspection, and permits.
7080-132J
WARNING
WARNING
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down.
CAUTION
January 8, 2016
