JVC KD-ADV7380J Service Manual page 6

KD-DV7306/KD-DV7305
Maximum Power Output
Continuous Power Output (RMS) Front/Rear
Load Impedance
Equalizer Control Range
Signal to Noise Ratio
Audio Output Level
Subwoofer-out Level/Impedance
Color system
Video Output (composite)
Other Terminal
Frequency Range
FM Tuner
AM Tuner
Signal Detection System
Number of Channels
Frequency Response
Dynamic Range
Signal-to-Noise Ratio
Wow and Flutter
DivX/MPEG Video
MP3
WMA
WAV
USB Standard
Data Transfer Rate
1-6 (No.MA312)
AUDIO AMPLIFIER SECTION
Front/Rear
Frequencies
Level
Digital (DIGITAL OUT: Optical)
Line-Out Level/Impedance
Output Impedance
FM
AM
Usable Sensitivity
50 dB Quieting Sensitivity
Alternate Channel Selectivity (400 kHz)
Frequency Response
Stereo Separation
Sensitivity/Selectivity
DVD/CD PLAYER SECTION
DVD, fs=48 kHz/96 kHz
CD, fs=44.1 kHz
Video Max. Resolution
Audio Bit Rate
Sampling Frequency: DivX
Sampling Frequency: MPEG Video 32 kHz, 44.1 kHz, 48 kHz
Bit Rate
Sampling Frequency
Bit Rate
Sampling Frequency
Quantization Bit Rate
Sampling Frequency
Full Speed
Low Speed
50 W per channel
19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total har-
monic distortion
4 Ω (4 Ω to 8 Ω allowance)
60 Hz, 150 Hz, 400 Hz, 1 kHz, 2.5 kHz, 6.3 kHz, 15 kHz
±10 dB
70 dB
Signal wave length: 660 nm
Output level: -21 dBm to -15 dBm
2.5 V/20 kΩ load (full scale)
1 kΩ
2.5 V/20 kΩ load (full scale)
PAL/NTSC
1 Vp-p/75 Ω
CD changer, LINE IN, 2nd AUDIO OUT
TUNER SECTION
87.5 MHz to 108.0 MHz
531 kHz to 1 602 kHz
11.3 dBf (1.0 µV/75 Ω)
16.3 dBf (1.8 µV/75 Ω)
65 dB
40 Hz to 15 000 Hz
30 dB
20 µV/35 dB
Non-contact optical pickup (semiconductor laser)
2 channels (stereo)
16 Hz to 22 000 Hz
16 Hz to 20 000 Hz
96 dB
98 dB
Less than measurable limit
720 × 480 pixels (30 fps)
720 × 576 pixels (25 fps)
DivX: 32 kbps - 320 kbps
MPEG Video: 32 kbps - 320 kbps
MPEG-1: 32 kHz, 44.1 kHz, 48 kHz
MPEG-2: 16 kHz, 22.05 kHz, 24 kHz
32 kbps - 320 kbps
MPEG-1: 32 kHz, 44.1 kHz, 48 kHz
MPEG-2: 16 kHz, 22.05 kHz, 24 kHz
32 kbps - 320 kbps
22.05 kHz, 32 kHz, 44.1 kHz, 48 kHz
16 bit
44.1 kHz
USB SECTION
USB 1.1/USB 2.0
Max. 12 Mbps
Max. 1.5 Mbps
