JVC KD-ADV7380J Service Manual page 2

KD-ADV7380/KD-DV7300
Power Output
Signal to Noise Ratio
Load Impedance
Equalizer Control Range
Audio Output Level
Subwoofer-out Level/Impedance
Color system
Video Output (composite)
Other Terminal
Frequency Range
FM Tuner
AM Tuner
Signal Detection System
Number of Channels
Frequency Response
Dynamic Range
Signal-to-Noise Ratio
Wow and Flutter
DivX/MPEG Video
MP3
WMA
AAC
1-2 (No.MA312)
SPECIFICATION
AUDIO AMPLIFIER SECTION
Frequencies
Level
Digital (DIGITAL OUT: Optical)
Line-Out Level/Impedance
Output Impedance
FM
AM
Usable Sensitivity
50 dB Quieting Sensitivity
Alternate Channel Selectivity (400 kHz)
Frequency Response
Stereo Separation
Sensitivity
Selectivity
DVD/CD PLAYER SECTION
DVD, fs=48 kHz/96 kHz
CD, fs=44.1 kHz
Video Max. Resolution
Audio Bit Rate
Sampling Frequency: DivX
Sampling Frequency: MPEG Video 32 kHz, 44.1 kHz, 48 kHz
Bit Rate
Sampling Frequency
Bit Rate
Sampling Frequency
Bit Rate
Sampling Frequency
20 W RMS × 4 Channels at 4 Ω and [< or =] 1% THD+N
80 dBA (reference: 1 W into 4 Ω)
4 Ω (4 Ω to 8 Ω allowance)
60 Hz, 150 Hz, 400 Hz, 1 kHz, 2.5 kHz, 6.3 kHz, 15 kHz
±10 dB
Signal wave length: 660 nm
Output level: -21 dBm to -15 dBm
KD-ADV7380: 5.0 V/20 kΩ load (full scale)
KD-DV7300: 2.5 V/20 kΩ load (full scale)
1 kΩ
2.5 V/20 kΩ load (full scale)
NTSC
1 Vp-p/75 Ω
CD changer, Steering wheel remote input (for KD-ADV7380), LINE IN, 2nd AU-
DIO OUT
TUNER SECTION
87.5 MHz to 107.9 MHz (with channel interval set to 100 kHz or 200 kHz)
87.5 MHz to 108.0 MHz (with channel interval set to 50 kHz)
530 kHz to 1 710 kHz (with channel interval set to 10 kHz)
531 kHz to 1 602 kHz (with channel interval set to 9 kHz)
11.3 dBf (1.0 µV/75 Ω)
16.3 dBf (1.8 µV/75 Ω)
65 dB
40 Hz to 15 000 Hz
30 dB
20 µV
35 dB
Non-contact optical pickup (semiconductor laser)
2 channels (stereo)
16 Hz to 22 000 Hz
16 Hz to 20 000 Hz
96 dB
98 dB
Less than measurable limit
720 × 480 pixels (30 fps)
720 × 576 pixels (25 fps)
DivX: 32 kbps - 320 kbps
MPEG Video: 32 kbps - 320 kbps
MPEG-1: 32 kHz, 44.1 kHz, 48 kHz
MPEG-2: 16 kHz, 22.05 kHz, 24 kHz
32 kbps - 320 kbps
MPEG-1: 32 kHz, 44.1 kHz, 48 kHz
MPEG-2: 16 kHz, 22.05 kHz, 24 kHz
32 kbps - 320 kbps
22.05 kHz, 32 kHz, 44.1 kHz, 48 kHz
16 kbps - 320 kbps
44.1 kHz, 48 kHz
