Summary of Contents for Mitsubishi XL1U
- Page 1 X L 1 Projector User Manual XL1U MODEL EN – 1...
- Page 2 CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. NOTE: SINCE THIS PROJECTOR IS PLUGGABLE EQUIPMENT, THE SOCKET-OUTLET SHALL BE IN- STALLED NEAR THE EQUIPMENT AND SHALL BE EASILY ACCESSIBLE. WARNING Use the attached specified power supply cord. If you use another power-supply cord, it may cause interfer- ence with radio and television reception.
-
Page 3: Table Of Contents
What’s included in the box ... 27 Replacement part ... 27 Specification of RGB signals in each computer mode of the projector ... 28 Trademark, Registered trademark Windows 98 and Windows 95 are registered trademarks of Microsoft in the U.S. and other countries. -
Page 4: Important Safeguards
Water and moisture Do not use this projector near water or in con- tact with water. Accessories Do not place this projector on an unstable cart, stand, tripod, bracket or table. - Page 5 Air outlet grille. The heated Air outlet grille and Bottom plate may cause injury or damage to other equipment. Also, do not set the projector on the desk which is easily affected by heat. Clean the air-filter once a month.
-
Page 6: Overview
Overview Control panel AUTO COMPUTER POSITION LAMP VOLUME SOURCE VIDEO TEMP MENU Terminal board RS-232C COMPUTER IN AUDIO IN VIDEO IN COMPUTER OUT EN – 6 Front height adjuster buttons Air outlet grille (Front) Air inlet grille (Side-Front) Terminal board Air inlet grille (Side-Rear) Control panel IRIS sensor... -
Page 7: Bottom Side
AVOID EXPOSURE - RADIATION IS EMITTED FROM THIS APERTURE. Lamp cover Adjustment foot Caution: Do not replace the lamp right after using the projector. The lamp is very hot. Transmitter indicator Power button COMPUTER button Mouse button Right click button (For mouse) -
Page 8: Using The Remote Control
The range for operation is about 10 m (33 feet) when the remote control points to the projector. The distance to the screen back to the projector must be less than 6 m (20 feet). Depending on the type of the screen, the distance is different. -
Page 9: Installation
Installation Orientation of the projector Picture size can be set by changing the distance between the screen and the projector. Front projection Screen (between the screen and the head of the projector) Screen Diagonal size Height Width (inch) (inch) (inch) 30 "... -
Page 10: Basic Connections
Basic connections This projector can be connected to equipment such as PC, VCRs, video cameras and DVD players. Important: • Make sure that your equipment is turned off before connection. • Plug in firmly and unplug by holding the plug, not by pulling the AC power cord. -
Page 11: Projector + Personal Computer
Please contact your dealer. • The audio input for this projector is a stereo pin jack. (Speaker output is mono.) Please check the available cable for the audio input terminal of the PC. Some personal computer may not have the audio output terminal. -
Page 12: Preparing The Projector For Operation
2. Connect the power cord to the wall power outlet. 3. Remove the lens cap. Warning: • Do not look directly into the lens when projector is “ON”. • The lens cap is for protecting the lens. If you leave the power on with the cap on, the cap may be warped. -
Page 13: To Operate Projector Power On
VIDEO TEMP 1. Turn on the equipment connected to the projector. 2. Put the projector into standby mode by pressing the main power switch. The POWER indicator lights up red. 3. Turn the projector on by pressing the POWER but- ton. - Page 14 • After the lamp is turned off, the lamp cannot be switched on again for 60 seconds as a precaution- ary measure. If you wish to turn on the projector again, wait until the indicator is off then press the POWER button.
-
Page 15: Menu Operation
Menu operation IMAGE INSTALLATION AUTO POWER OFF FEATURE SIGNAL * 1: The item can not be selected when the sRGB is set to ON. * 2: The item can not be selected with certain signals. * 3: Setting range is different with certain signals. * 4: The item can not be selected when the source is selected VIDEO or S-VIDEO. - Page 16 • The projector will be in the stand-by mode when the lamp is off. Use the remote control to turn on the lamp. AUTO POWER OFF ... Set the time elapsed before the projector enters into the stand-by mode when there is no signal inputted from the selected source.
-
Page 17: User Memory For Signal Setting
HORIZ. POSITION ... Use to adjust the horizontal position of the image. VERT. POSITION ... Use to adjust the vertical position of the image. FINE SYNC..Use to synchronize the projector with PC input signals so that the image is not blurred. -
Page 18: Picture Adjustment
The white, which temperature is low, becomes raddish white. When the color temperature is higher, the white becomes more bluish. This projector sets this color temperature by changing the numbers of contrast blue and red. -
Page 19: Adjustment From Personal Computer
Adjustment from personal computer Although this projector sets proper signal systems automatically for the image signal from personal computers, it cannot be applied to some of personal computers. In this case, press the AUTO POSITION button. If the images are still not projected correctly, use the MENU display to adjust the projected im- ages. -
Page 20: Advanced Feature For Presentation
Advanced features for presentation Expand By pressing the EXPAND button on the remote con- trol, you can magnify the detailed image of the picture. Using the Expand mode 1. Press the EXPAND button. • You can magnify different areas of the active pic- ture by pressing the {, }, $, % button. -
Page 21: Mouse Remote Control
Mini DIN 6P • Turn off PC and the projector before connecting with PS/2 port. When connecting the PC with the projector when the personal computer is on, the remote control does not work as a mouse. In that case, turn the projec- tor on, then restart the personal computer. -
Page 22: Lamp Replacement
• Be sure that the projector guide is firmly inserted between the right and left lamp guides. Important: • The projector will not turn on if you do not secure the lamp lid. • You must reset the operation time meter after you replace the lamp. -
Page 23: Maintenance
Maintenance Caution: Be sure to turn off the projector and unplug the power cord from the wall outlet before you perform any main- tenance on the projector. Cleaning the air-filter Clean the air-filter frequently. If the filter or ventilation grille become clogged with dirt or dust, the temperature inside the projector may rise and shut off the power (the TEMP indicator starts to blink red). -
Page 24: Troubleshooting
(In this case, the TEMP indicator does not light up.) The image is • The projector is not at a right angle to the screen. distorted. The image is dark. • Brightness, tint and color are not adjusted correctly. -
Page 25: Indicators
Indicators The projector has three LED Indicators which shows the working condition of the projector. The following offers solutions to possible problems. If a problem persists, turn the projector off and consult your dealer. POWER indicator LAMP indicator TEMP indicator... -
Page 26: Specifications
(performance guarantee) Kensington Lock This projector has a Kensington Security Standard connector for use with a Kensington MicroSaver Security System. Refer to the information that came with the Kensington System for instructions on how to use it to secure the projector. Please contact to Kensington Technology Group as shown below. -
Page 27: Connectors
Replacement part (Option / Not included in the box) Spare Mercury lamp RS-232C input Use to control the projector with the personal computer, or control the personal computer with remote con- trol. Use the provided RS-232C cable (Mini DIN 8P-D-SUB 9P) for the connection. -
Page 28: Specification Of Rgb Signals In Each Computer Mode Of The Projector
Specifications (continued) Specification of RGB signals in each computer mode of the projector Signal mode resolution (H x V) TV60 – TV50 – 1080i – 720p – PC98 640 x 400 CGA70 640 x 400 CGA84 640 x 400 CGA85... - Page 29 Manufactured by Mitsubishi Electric Corporation 1 Zusho Baba, Nagaokakyo-City, Kyoto Japan 871D341A50 Printed in Japan...
- Page 30 • Turn on the projector after the computer is started up. (If you do not follow this order, the Comport may not function.) • Adapters may be necessary depending on the PC connected to this projector. Contact your dealer for details. 1) Interface...
- Page 31 (1) Send the command from a personal computer to the projector. (The commands must be sent at least 400ms apart.) (2) The projector will send a return command 400ms* after it has received an end code. If the command is not received correctly, the projector will not send the return command.
- Page 32 INPUT VIDEO INPUT S-VIDEO When a personal computer sends the command, data code will not be attached. On the other hand, the projector which has received a command will attach the recent operating status and then send. [Example ] Input was Video when the operating status of the input terminal was confirmed.
- Page 33 000 - 510 (000 - 398 for SL1U) 000 - 510 (000 - 398 for SL1U) 0 (MUTE OFF), 1 (MUTE ON) Status code from projector 30 30 41 50 4F 4E 31 0D '0' '0' 'A' 'P' 'O' 'N' '1' ' Status code from...
