LCD PROJECTOR
MODEL
XL5U
SL4SU
User Manual
X L 5
S L 4 S
EN – 1

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi SL4SU

Summary of Contents for Mitsubishi SL4SU

  • Page 1 LCD PROJECTOR MODEL XL5U SL4SU User Manual X L 5 S L 4 S EN – 1...
  • Page 2 CAUTION: NO USER-SERVICEABLE PARTS INSIDE The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the litera- ture accompanying the appliance.

  • Page 3: Table Of Contents

    Maintenance ... 25 Troubleshooting ... 26 Indicators ... 29 Specifications ... 30 Declaration of Conformity Model Number : XL5U / SL4SU Trade Name : MITSUBISHI ELECTRIC Responsible party : Mitsubishi Digital Electronics America, Inc. 9351 Jeronimo Road, Irvine, CA 92618 U.S.A...

  • Page 4: Important Safeguards

    Important safeguards Please read all these instructions regarding your LCD projector and retain them for future reference. Follow all warnings and instructions marked on the LCD projector. Read instructions All the safety and operating instructions should be read before the appliance is operated. Retain instructions The safety and operating instructions should be retained for future reference.
  • Page 5 WARNING: Unplug immediately if there is something wrong with your projector. Do not operate if smoke, strange noise or odor comes out of your projector. It may cause fire or electric shock. In this case, unplug immediately and contact your dealer. Never remove the cabinet.

  • Page 6: Overview

    Overview Control panel POWER POWER STATUS STATUS AUTO POSITION AUTO POSITION COMPUTER COMPUTER KEYSTONE KEYSTONE VIDEO VIDEO ENTER ENTER MENU MENU Terminal panel EN – 6 1 Remote control sensor (Front) 2 Control panel 3 Speaker 4 Terminal panel 5 Air outlet grille 6 Kensington Security Lock Standard connector 7 Foot adjustment button...
  • Page 7 Bottom side Remote control POWER PAGE DOWN AUTO SOURCE KEYSTONE POSITION STILL MUTE ENTER MENU VOLUME EXPAND 1 Lamp cover 2 Air inlet grille / Filter cover 3 Adjustment foot (Left/Right) Caution: Do not replace the lamp immediately after using the projector because the lamp would be extremely hot and it may cause burns.

  • Page 8: Remote Control

    Remote control Battery loading First Loading: When you use the remote control for the first time, pull out the insulation sheet. Replacement of the battery: Lock Battery holder 1. Turn the remote control upside down. 2. Push the lock inward and pull out the battery holder. 3.

  • Page 9: Installation

    Installation Layout of the projector Image size varies depending on the distance between the screen and the projector. Front projection Screen Diagonal size Width : W Height : H inch inch inch • The above figures are approximate and may be slightly different from the actual measurements. Front projection, ceiling mounting For ceiling mounting, you need the ceiling mount kit designed for this projector.

  • Page 10: Basic Connections

    Basic connections This projector can be connected with various devices such as a VCR, video camera, videodisc player, and personal computer that have analog RGB output connectors. Important: • Make sure that the connected device is turned off before starting connection. •...
  • Page 11 Projector + Computer COMPUTER/COMPONENT VIDEO IN COMPUTER/ AUDIO IN COMPONENT VIDEO OUT PC audio cable (option) Necessary when outputting to both a PC monitor and the projector. Important: • When you use a longer RGB cable instead of the provided cable, the image quality may deteriorate. •...

  • Page 12: Preparation

    Preparation Preparation for projection 1. Attach the provided power cord to the projector. 2. Plug the power cord in the wall outlet. 3. Remove the lens cap. Warning: • Do not look into the lens directly when the projector is on. •...

  • Page 13: Basic Operation

    Basic operation POWER 3, 1, 2 COMPUTER MENU Power-on 1. Turn on the device connected to the projector first. 2. Plug the power cord in the wall outlet. • The POWER indicator lights up. • If the power cord is unplugged from the wall outlet before the projector is cooled down completely after use, the fans may start rotating when the power cord is plugged in...
  • Page 14 Basic operation (continued) Power-off Use the following procedure to turn off the projector. Do not turn off the projector by unplugging the power cord while the lamp is on. Unplugging while the lamp is on degrades the lamp’s performance and causes failure in the projector.

  • Page 15: Menu Operation

    Menu operation IMAGE CONTRAST BRIGHTNESS sRGB COLOR MATRIX COLOR TEMP. COLOR TINT SHARPNESS GAMMA MODE INSTALLATION AUTO POWER ON AUTO POWER OFF IMAGE CAPTURE SETUP SPLASH SCREEN BACK COLOR MUTE MODE LAMP MODE IMAGE REVERSE FEATURE MENU POSITION EXPAND MODE AUDIO MODE CINEMA MODE VIDEO SIGNAL...
  • Page 16 Menu operation (continued) 1 IMAGE CONTRAST ... Use to adjust the image contrast. The contrast becomes higher as the value increases. BRIGHTNESS ... Use to adjust the image brightness. The image becomes brighter as the value increases. sRGB ... Choose ON for projection emphasizing on the color reproducibility.
  • Page 17 3 FEATURE MENU POSITION ... Use to select the position of the menu on the screen, 1. (upper left) or 2. EXPAND MODE .. Choose the mode for enlarging the image. See page 20. AUDIO MODE ... Select COMPUTER to output the audio that is input to the AUDIO IN terminal when COMPUTER is chosen as the source.

  • Page 18: Image Adjustment

    Image adjustment Image adjustment You can adjust the image using the IMAGE menu. opt. XGA60 IMAGE CONTRAST BRIGHTNESS sRGB COLOR MATRIX COMPUTER COLOR TEMP. STANDARD COLOR TINT SHARPNESS GAMMA MODE To control the white-to-black level of the image : Adjust CONTRAST in the IMAGE menu. Press the % button to increase the contrast and the $ button to reduce it.

  • Page 19: Adjustment Of The Image From The Computer

    Adjustment of the image from the computer This projector adjusts the format of the video signal supplied from the computer. However, sometimes images are not projected correctly owing to the type of the computer used. When the image from the computer isn’t projected correctly, press the AUTO POSITION button.

  • Page 20: Advanced Features

    Advanced features Expand By pressing the EXPAND button on the remote control, you can magnify the image to view the details. You can view the image in its original size in the REAL mode. • The EXPAND mode doesn't work with video or S-video signal.
  • Page 21 Setting of the image displayed during startup or muting You can display your desired image as the startup screen (or splash screen). Using the menu, you can also use such image as a background that is displayed while the video is muted or no signal is supplied. Important: •...
  • Page 22 Advanced features (continued) Page-up and page-down You can control the computer to page-up and page-down the presentation data using the remote control. Switch the pages using the PAGE UP or DOWN button on the remote control. Connection To control the computer using the remote control, connect the projector with the computer as shown below. •...
  • Page 23 Password function This projector is equipped with the password func- tion that is designed for prevention of theft and wrong operation by children and restriction on operation by other than specified users. The pass- word function has three modes as follows. DISPLAY INPUT ...

  • Page 24: Lamp Replacement

    Lamp replacement The lamp is designed to project the image on the LCD panels. When the lamp no longer functions, replace it with a new one. Caution: • Do not remove the lamp immediately after using the projector. You may get burned because the lamp is very hot after use.

  • Page 25: Maintenance

    Maintenance Caution: Be sure to turn off the lamp and unplug the power cord from the wall outlet before you perform any maintenance on the projector. Cleaning of the air-filter Clean the air-filter fre- quently (about once a month). If the filter or ventilation grilles become clogged with dirt or dust, the temperature inside...

  • Page 26: Troubleshooting

    Troubleshooting The following offers solutions to some of the common problems you may encounter. We suggest that you consult this chart before contacting your dealer. Images aren't projected on the screen. Problem Cause and solution Power isn't turned on. • Check the states of the indicators. POWER Steady red Blinking...

  • Page 27: Images Aren't Projected Correctly

    Images aren't projected correctly. Problem Cause and solution Projected images are • Check that the cable connected to the external device isn't intermittent. shaking. • Connect the cable's plug with the external device's connector firmly. Projected images are • Press the AUTO POSITION button. displaced.
  • Page 28 Troubleshooting (continued) Others Cause and solution Problem • This air comes out as a result of cooling the inside of the projector. This isn't a product Hot air is emitted from malfunction. the air outlet grilles. No audio is output. •...

  • Page 29: Indicators

    Indicators This projector has two indicators, each of which shows the operation condition of the projector. The following offer solutions to possible problems. If these problem persist, turn the projector off and consult your dealer. Normal condition POWER STATUS CONDITION Stand-by Steady Lamp stand-by (about 1 minute)

  • Page 30: Specifications

    San Mateo, CA 94403, U.S.A. Phone : +1- (650)572-2700 Fax : +1- (650)572-9675 EN – 30 640 x 400 (Expand) - 800 x 600 (Real) - 1,024 x 768 (Compress) (SL4SU) ) : Y:1.0 Vp-p (negative sync.) P Total 2,359,296 pixels (XL5U)

  • Page 31: Replacement Part

    DDC Clock 246C483-10 1 Remote control (with battery) 246C383-20 1 Quick reference card 246C381-10 1 Safety manual 246C507-10 1 CD-ROM 246C508-10 1 Carrying case 499B040-10 Spare lamp (for SL4SU) (VLT-XL5LP) Pin No. Spec. R(RED)/C G(GREEN)/Y B(BLUE)/C – – – – HD/CS –...
  • Page 32 Specifications (continued) Specification of RGB signals in each computer mode of the projector (For XL5U) Signal mode resolution (H x V) TV60, 480i(525i) – TV50, 576i(625i) – 1080i 60 (1125i 60) – 1080i 50 (1125i 50) – 1080i 50a (1250i 50) –...
  • Page 33 Specification of RGB signals in each computer mode of the projector (For SL4SU) Signal mode resolution (H x V) TV60, 480i(525i) – TV50, 576i(625i) – 1080i 60 (1125i 60) – 1080i 50 (1125i 50) – 1080i 50a (1250i 50) –...
  • Page 34 MITSUBISHI Projector Contact Information North America MESCA (Mitsubishi Electric Sales Canada Inc.) http://www.mitsubishielectric.ca Information Technologies Group, 4299 14th Avenue, Markham, Ontario L3R 0J2, Canada Sales Phone :+1-(905) 475-7728 :+1-(905) 475-7958 E-mail :projectors@mitsubishielectric.ca Technical Phone :+1-(905) 475-7728 :+1-(905) 475-7958 Customer Care E-mail :support@mitsubishielectric.ca MDEA (Mitsubishi Digital Electronics America, Inc.)
