Miller Electric Invision 350MPa Specifications

Invision
Heavy Industrial Applications
Invision 350 MPa
Railroad
Quick
Truck/Trailer Manufacturing
Light Gauge and Tube
Specs
Lawn and Garden Equipment
Recreational Vehicles
S-74 MPa
Heavy/Light Manufacturing
Metal Fabrication
The Power of Blue
Dynamic Pulsed MIG — highly-engineered
pulse programs default to give a tight
productive pulse arc. The operator can
fine tune the arc if desired.
Auto-Line Power Management
™
Technology allows for any input voltage
hook-up (208 – 575 V) with no manual
linking required, providing convenience
in any job setting. Ideal solution for dirty
or unreliable input power.
Fan-On-Demand ™ cooling system
operates only when needed, reducing
noise, energy use and the amount of
contaminants pulled through machine.
Large, dual digital meters are easy to
view and are presettable to ease setting
weld output.
Inverter arc control technology provides
greater puddle control for outstanding MIG
weld performance.
Line voltage compensation keeps welding
output constant even if input power varies
by +/-10%. Invision 350 MPa models
further expand line voltage compensation
on 460 VAC to an amazing +37%, -59%.
350 MPa System
™
Processes
Invision 350 MPa
MIG (GMAW)/Pulsed MIG (GMAW-P)
Flux Cored (FCAW)
Air Carbon Arc Cutting and Gouging
(CAC-A) (1/4 in carbons max.)
S-74 MPa
MIG (GMAW)
Flux Cored (FCAW)
Pulsed MIG (GMAW-P)
.
®
Power source is warranted for 3 years, parts and labor.
Original main power rectified parts are warranted for 5 years.
Gun warranted for 90 days, parts and labor.
Miller Electric Mfg. Co.
An Illinois Tool Works Company
1635 West Spencer Street
Appleton, WI 54914 USA
Invision 350 MPa
Input Power
Rated Output
Weight
S-74 MPa
Input Power
Electrode Wire Dia. Capacity
Wire Speed
Weight
Equipment Sales US and Canada
Phone: 866-931-9730
FAX: 800-637-2315
International Phone: 920-735-4554
International FAX: 920-735-4125
Issued March 2009 • Index No. DC/23.5
MIG Welding
Power Source
Requires 3- or 1-Phase Power, 50/60 Hz
10 – 38 V, 5 – 425 A
Net: 80 lb (36.3 kg) Ship: 89.1 lb (40.4 kg)
24 VAC, 10 A, 50/60 Hz
.023 –5/64 in (0.6–2 mm)
50–780 IPM (1.3–19.8 m/min)
Net: 58 lb (26 kg)
Invision 350 MPa System
Add the new S-74 MPa feeder for a
package that gives you the benefit of
Synergic-Pulsed MIG. As you increase/
decrease the wire feed speed, the pulse
parameters increase/decrease matching
the right amount of power output to
the wire speed.
SharpArc technology changes welding arc
™
characteristics in Pulsed MIG welding mode.
Lightweight, aerospace-grade aluminum
case offers protection with the benefit of
reduced weight.
Easy setup for MIG and Pulsed MIG
applications.
