Exmark Metro 21 Operator's Manual page 14

For Exmark Mower Parts Call 606-678-9623 or 606-561-4983
3.1.2 Blade Control Bail:
3.1.3 Self-Propel Drive Bail (For Self-Propelled units only):
3.1.4 Throttle-Choke Control:
Located on the upper handle as shown in Figure 1. When the blade control bail
is depressed, the system senses that the operator is in the normal operator's
position.
For units with a Blade Brake Clutch: When the blade control bail is released, the
system senses that the operator has moved from the normal operating position
and will stop the blade.
For units without a Blade Brake Clutch: When the blade control bail is released,
the system senses that the operator has moved from the normal operating position
and will kill the engine.
Located on the upper handle as shown in Figure 1. When the self-propel drive
bail is squeezed, the unit will move forward at the speed set on the speed control
lever. When this bail is released the unit will stop moving.
The throttle-choke control is located on the left side of the handles as shown in
Figure 2. The lever is used to control engine speed. Moving the lever to the full
forward (Choke) position will place the lever in the choke position. The choke
aids in starting a cold engine. Moving the throttle control forward will increase
engine speed and moving it to the rear will decrease engine speed.
For units with a Blade Brake Control: The throttle-choke control also includes an
engine kill position. Moving the lever into the full rearward
the engine.
www.mymowerparts.com
Figure 1
Figure 2
- 9 -
(Off) position will kill
