Exmark METRO 26 Setup Instructions

Loose Parts
Use the chart below to verify that all parts have been shipped. Part numbers not shown are available on the dealer
extranet.
Dealer Pack
Part #
—
Literature Pack
Part #
—
—
Removing the Unit from the Box
Remove the unit from the box.
Installing the Handle
1. Remove the hardware from the machine.
2. Mount the handle to the outside of the lawn mower
housing on each side as shown in Figure 1.
Note: You can adjust the handle height for
comfortable operation. Stand behind the handle to
determine the height. Loosen the lower mounting
bolt, adjust the handle height as desired, and
re-tighten lower bolts.
3. Move the cable ties on each side of the handle bar
into the locations shown and tighten (see Figure 1).
© 2011—Exmark Mfg. Co., Inc.
P.O. Box 808
Beatrice, NE 68310
Description
Warranty Registration Reminder
Description
Manual, Operator's
Manual, Engine Operator's
For Serial Nos. 312,000,000 & Higher
Qty.
Fill out the online warranty registration
form.
Qty.
1
Read before operating the machine.
1
Figure 1
1. 5/16-18 nyloc nut
2. 3/8-16 nyloc flange nut
3. Secure cable ties as
shown
4. 3/8-16 x 1 1/4 carriage bolt
METRO 26
®
Setup Instructions
Use
Use
5. 3/8 spring disc washer
6. 3/8-16 x 1 1/4 taptite screw
7. 5/16-18 x 1 1/4 hex flange
screw
Part No. 4500-937 Rev. A
Printed in the USA
All Rights Reserved
