• System Power LED Lead (3-pin PLED)
This 3-pin connector connects to the system power LED. The LED
lights up when you turn on the system power, and blinks when the
system is in sleep mode.
• System Warning Speaker Lead (4-pin SPEAKER)
This 4-pin connector connects to the case-mounted speaker and
allows you to hear system beeps and warnings.
• Reset Switch Lead (2-pin RESET)
This 2-pin connector connects to the case-mounted reset switch for
rebooting the system without turning off the system power.
• ATX Power Switch / Soft-Off Switch Lead (2-pin PWRSW )
This connector connects a switch that controls the system power
Pressing the power switch turns the system between ON and SLEEP, or
ON and SOFT OFF, depending on the BIOS or OS settings. Pressing the
power switch while in the ON mode for more than 4 seconds turns the
system OFF.
• Hard disk activity LED (2-pin IDE_LED)
This connector supplies power to the hard disk activity LED. Any read
or write activity of an IDE device cause this LED to light up.
ASUS M2S-X 1-29
