- Page 1 LED Projector "Pocket" MODEL PK10 User Manual This User Manual is important to you. Please read it before using your projector. EN-1 Downloaded From projector-manual.com Mitsubishi Manuals...
- Page 2 EN-2 Downloaded From projector-manual.com Mitsubishi Manuals...
- Page 3 WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS AC ADAPTER’S PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET. NOTE: WHEN USING THE AC ADAPTER, THE SOCKET-OUTLET SHALL BE INSTALLED NEAR THE EQUIPMENT AND The lightning flash with arrowhead symbol within SHALL BE EASILY ACCESSIBLE.
- Page 4 Your MITSUBISHI ELECTRIC product WARNING is designed and manufactured with high Only use the attached specified AC adapter and power quality materials and components which cord. If you use another AC adapter and power cord, it can be recycled and reused.
-
Page 5: Table Of Contents
Contents Declaration of Conformity Model Number : PK10 Important safeguards............6 Trade Name : MITSUBISHI ELECTRIC Responsible party : Mitsubishi Digital Electronics Overview................10 America, Inc. Power supply..............11 9351 Jeronimo Road, Irvine, CA Remote control (optional accessory)......13 92618 U.S.A Installation..............15 Telephone number : +1-(949) 465-6000 Basic connections............16... -
Page 6: Important Safeguards
Important safeguards 8. Accessories Do not place this projector on an unstable cart, stand, tripod, bracket or table. Use only with a cart, stand, Please read all these instructions regarding your projector tripod bracket, or table recommended by the and retain them for future reference. Follow all warnings manufacturer or sold with the projector. - Page 7 11. Power-cord protection (d) If the projector does not operate normally after Power-supply cord should be routed so that it is not you follow the operating instructions. Adjust only likely to be walked on or pinched by items placed upon those controls that are covered by the operating or against it.
- Page 8 WARNING: Do not place the projector on uneven surface. Place the projector on a level and stable surface only. Unplug the power cord or remove the battery Do not look into the lens when the projector is immediately if there is something wrong with your operating.
- Page 9 Place of installation COMPLIANCE NOTICE OF FCC This equipment has been tested and found to comply with For safety’s sake, do not use the projector at any place the limits for a Class B digital device, pursuant to Part 15 of subjected to high temperature and high humidity.
-
Page 10: Overview
Control panel Overview 1 LAMP indicator 2 POWER indicator 3 CHARGE indicator 4 Four directional buttons : AUTO POSITION AUTO POSITION button COMPUTER VIDEO : VIDEO button : COMPUTER button 5 ENTER button 6 POWER button 7 MENU button Terminal board 1 S-VIDEO terminal 2 VIDEO terminal 1 Focus ring... -
Page 11: Power Supply
Power supply the battery before using the projector for the first time use. Using the projector for charging the battery. You may also use the projector when charging the battery. Using the provided AC adapter (02550-0112-00 ) or an optional Lithium-ion rechargeable battery . For battery charging Warning: 1. - Page 12 For battery removal 4. Insert the plug from the AC adapter into the DC IN terminal. Slide the battery lock switches on the two sides to remove 5. Insert the appropriate end of the power cord into the the battery from the projector. AC adapter.
-
Page 13: Remote Control (Optional Accessory)
Remote control For the first time use: (optional accessory) Catch Remove the transparent insulation tape by pulling it Battery holder before use. 1 Power button 2 Four directional buttons For battery change: 3 Enter button 1. Push the catch to the right 4 Menu button and remove the battery 5 Keystone... -
Page 14: Operating Range
Operating Range Remote Control Precautions The infrared signal operates by line-of-sight up to a Handle the remote control carefully. distance of approximately 16.4 feet (5 m) and within a 40- Do not use the remote control if it got wet. Remove the degree angle of the remote sensor. -
Page 15: Installation
Installation Screen Distance Diagonal size Width : W Height : H Layout of the projector inch inch inch inch 0.31 0.24 0.18 15.4 Image size varies depending on the distance between the 0.51 16.0 0.41 12.0 0.31 26.0 0.66 screen and the projector. 0.76 24.0 0.61... -
Page 16: Basic Connections
Basic connections Projector + AV device This projector can be connected with various devices such as a VCR, video camera, videodisc player, or VIDEO IN personal computer that have analog RGB output connectors. S-VIDEO IN Important: Make sure that the connected device is turned off before starting connection. -
Page 17: For Macintosh
Projector + DVD player or HDTV Projector + Computer For computer with D-SUB Some DVD players have an output connector for 3-line fitting (Y, C ). When connecting such DVD player with this projector, use the VGA IN terminal. VGA IN VGA IN to monitor port Desktop type... -
Page 18: Preparation
Preparation Caution: Plug in the power cord firmly. When unplugging, hold and pull the power plug, not the power cord. Preparation for projection Do not plug in or out the power cord with your hand 1. Attach the provided AC adapter to the projector. wet. - Page 19 Important: When the keystone adjustment is carried out, the adjustment value is indicated. Note that this value doesn’t mean a projection angle. The allowable range of the adjustment value in the keystone adjustment varies depending on the installation conditions. When the keystone adjustment takes effect, the resolution decreases. In addition, stripes may appear or straight lines may bend in images with complicated patterns.
-
Page 20: Basic Operation
Basic operation Power-on 1. Turn on the device connected to the projector first. On the control panel 2. Plug the AC adapter in both the projector and the wall outlet. The POWER indicator lights up. The CHARGE indicator lights up when the projector connects with a not fully charged battery. - Page 21 Power-off Important: Images may not be projected with good quality in an Use the following procedure to turn off the projector. Do not extremely hot or cold environment. (This is not a turn off the projector by unplugging the power cord while the product malfunction.) lamp is on.
-
Page 22: On The Remote Control
On the remote control BLANK button The screen is temporarily cut off when this button is KEYSTONE button pressed. To cancel blanking, press this button again. Press the KEYSTONE or KEYSTONE to adjust image distortion caused by tilting the projector. 4:3/16:9 button Important: Toggle the 4:3/16:9 button to change the aspect ratio. -
Page 23: Menu Operation
Menu operation OFF, ON IMAGE CONTRAST -30 - +30 BRIGHTNESS -30 - +30 FEATURE MENU POSITION STANDARD OFF, ON ANAMORPHIC -30 - +30 COLOR TEMP LANGUAGE -30 - +30 HIGH -30 - +30 USER RESET ALL COLOR -30 - +30 TINT -30 - +30 SHARPNESS... - Page 24 1 IMAGE GAMMA MODE..Select STANDARD for computer sources. Select THEATER for HIGH BRIGHTNESS MODE..........film sources. For normal use, ........Select ON for high brightness mode. select AUTO. When AUTO is CONTRAST ....Use to adjust the image contrast. selected, the appropriate gamma The contrast becomes higher as the mode is automatically selected value increases.
- Page 25 3 FEATURE MENU POSITION..Use to select the position of the menu on the screen, 1. (upper left) or 2. (lower right). ANAMORPHIC...Select ON when playing DVD discs containing data of widescreen images. LANGUAGE....Use to select the language used in the menu. ( , English, Español, Deutsch, Français, Italiano, , Português).
-
Page 26: Image Adjustment
Image adjustment Image adjustment Adjustment of the image from the computer You can adjust the image using the IMAGE menu. This projector adjusts the format of the video signal To control the white-to-black level of the image: supplied from the computer. However, sometimes images Adjust CONTRAST in the IMAGE menu. - Page 27 Simple adjustment method 1. Select HORIZ. POSITION in the SIGNAL menu. 2. Press the button to adjust the horizontal start position (or the left side of the image). 3. Select TRACKING in the SIGNAL menu. 4. Press the button to adjust the horizontal end position (or the right edge of the image). 5.
-
Page 28: Troubleshooting
Troubleshooting The following offers solutions to some of the common problems you may encounter. We suggest that you consult this chart before contacting your dealer. Images aren’t projected on the screen. Problem Cause and solution Check the states of the indicators. Power isn’t turned on. - Page 29 Problem Cause and solution Turn on the power of the connected device, or check whether there is something wrong No source found. with the connected device. Check whether the external device outputs signals. (Check this especially when the external device is a notebook computer.) Check that the cable connected to the external device isn’t defective.
- Page 30 Cause and solution Problem Rainbow blurprojected images. This is due to color breaking noise that occurs in a DLP system and is not a malfunction. It occurs because of interference with the screen and isn’t a product malfunction. Fine streak pattern appears in projected images. Change the screen or readjust the focus of the projector.
- Page 31 Others Problem Cause and solution Hot air is emitted from the air outlet grilles. This air comes out as a result of cooling the inside of the projector. This isn’t a product malfunction. The microcomputers inside the projector may be wrongly operating because The menu can’t be used.
-
Page 32: Maintenance
Maintenance Caution: Be sure to turn off the lamp and unplug the power cord from the wall outlet before you perform any maintenance on the projector. Cleaning of the projector and the ventilation slots Use a soft cloth to clean the projector and the ventilation grilles. When the grilles become dirty, wipe them with a soft cloth dampened with diluted mild detergent, and then wipe them with a dry cloth. -
Page 33: Indicators
Indicators This projector has three indicators, each of which shows the operation condition of the projector. The following offer solutions to possible problems. If these problem persist, turn the projector off and consult your appliance dealer. Normal condition (AC Adaptor only) LAMP (Green) POWER (Red) CONDITION... -
Page 34: Abnormal Condition
Normal condition (Battery only) CHARGE (Red) CONDITION LAMP (Green) POWER (Red) System ON System standby Low Battery (System turned off) Flashing x 10 Abnormal condition LAMP (Red) POWER (Red) CHARGE (Red) CONDITION Off x 1 (Flashing) System Failure Off x 3 (Flashing) Fan abnormal Off x 4 (Flashing) Over temperature... -
Page 35: Specifications
Specifications Type projector Model PK10 Rated input 15V, 2.0A Display technology Single 0.55” DLP panel Native resolution 800 x 600 pixels Colors 16.7 million Projection lens Fixed zoom with focus adjustment; F2.0 Light source RGB LED lamps Projection range Typical image size: 12" - 60"... -
Page 36: Kensington Lock
Kensington Lock This projector has a Kensington Security Standard connector for use with Kensington MicroSaver Security System. Refer to the information that came with the Kensington System for instructions on how to use it to secure the projector. Please contact Kensington Technology Group below. Kensington Technology Group 2855 Campus Drive San Mateo, CA 94403, U.S.A. -
Page 37: Optional Accessories
What’s included in the box 1 Soft Carrying Bag P6439-3000-00 1 CD ROM (User manual) P6439-A001-00 1 Quick Reference Guide P6439-4001-00 1 Composite Video Cable 02552-0075-00 1 AC Adaptor 02550-0112-00 1 Power Cord 02552-0078-00 02552-0083-00 02552-0079-00 It depends on different counties or areas, only 1 cord is included. Optional accessories 1 Remote Control RM-PK10C... - Page 38 Specification of RGB signals in each computermode of the projector Signal mode Resolution (H x V) Horizontal frequency (kHz) Vertical frequency (Hz) VGA 60 640 x 350 31.47 59.94 VGA 85 640 x 350 37.86 85.08 VGA mode3 640 x 480 31.47 59.94 640 x 480...
- Page 39 Specification of HDTV signals Horizontal frequency Vertical frequency Resolution Signal mode (kHz) (Hz) (H x V) 480i 720 x480 15.80 60.00 480p 720 x480 31.50 60.00 576i 720 x576 15.60 50.00 576p 720 x576 31.30 50.00 720p 60 1280 x720 45.00 60.00 720p 50...
- Page 40 Information Technologies Group, 4299 14th Avenue, Phone :+33 (0)1 55-68-56-42 Markham, Ontario L3R 0J2, Canada Fax :+33 (0)1 55-68-57-31 Sales & Technical Inquires MEU-GER (Mitsubishi Electric Europe B.V. German Branch) Phone :+1-(800) 450-6487 http://www.mitsubishi-evs.de/ Fax :+1-(905) 475-7958 Gothaer Strasse 8, 40880 Ratingen, Germany E-mail :projectors@mitsubishielectric.ca...
- Page 41 Phone :+34-93.586.27.51 Fax :+34-93.588.53.87 Fax :+39-(0)39-6053214 E-mail :mitsubishi.profesional@sp.mee.com E-mail :info.projector@it.mee.com MEU-SWE (Mitsubishi Electric Europe B.V Scandinavian MEU-NL (Mitsubishi Electric Europe B.V. Benelux Branch) Branch) http://www.mitsubishi.nl/LCD/ProdFrame.html Hammarbacken 14, Box 750, S-19127, Sollentuna,Sweden Nijverheidsweg 23A, 3641 RP Mijdrecht, The Netherlands Sales Inquiries...
- Page 42 E-mail :Peripherals@asia.meap.com Phone :+86(21) 5211-0882-3018 Technical Inquiries Fax :+86(21) 5211-0576 Phone :+65-6470-2666 HONG KONG (Mitsubishi Electric Ryoden Air-Conditioning Fax :+65-6475-9503 & Visual Information Systems (HongKong) Ltd.) INDONESIA (Mitsubishi Electric Asia Pte. Ltd.) 7th Floor, Manulife Tower, 169 Electric Road, North Point,...
- Page 43 11TH FL., 88 SEC. 6, CHUNG SHAN N. RD., TAIPEI, 111R. E-mail :projectorsales@bdt.co.nz Technical Inquiries O.C. Sales & Technical Inquires Phone :+64-(0)4-560-9100 Phone :+886-2-2832-8255 Fax :+64-(0)4-560-9133 Fax :+886-2-2833-9813 E-mail :service@bdt.co.nz MKY (Mitsubishi Electric Kang Yong Watana Co., Ltd. ) EN-43 Downloaded From projector-manual.com Mitsubishi Manuals...
- Page 44 Manufactured by Mitsubishi Electric Corporation 1 Zusho Baba, Nagaokakyo-City, Kyoto Japan MITSUBISHI ELECTRIC CORPORATION EN-44 Downloaded From projector-manual.com Mitsubishi Manuals...
