71-1729
INSTRUCTIONS
APPLICATIONS
2008-2009 Honda Accord
24 WAY CONNECTOR
in
Color
Function
P
1
Yellow
12V Battery/Memory
2
White
Left Front (+) Speaker
3
White/Black
Left Front (-) Speaker
4
Blue/Red
Ground Shield for Amplified Sound System
5
Blue/Black
Ground Shield for Amplified Sound System
6
Gray
Right Front (+) Speaker
7
Gray/Black
Right Front (-) Speaker
8
Blue/White
Amplifier Turn On
9
Black/Yellow
Audio Remote Switch
10
Black/Green
Open
11
Red
12 Volt Switched/Accessory
12
Orange/White
Dimmer
13
Black
Ground
14
Green
Left Rear (+) Speaker
15
Green/Black
Left Rear (-) Speaker
16
Red/White
Ground Shield for Amplified Sound System
17
Gray/Red
Ground Shield for Amplified Sound System
18
Purple
Right Rear (+) Speaker
19
Purple/Black
Right Rear (-) Speaker
20
Green/White
Audio Remote Switch Ground
21
Green/Red
Passenger's MICU
22
Brown/White
Data Link Connector (K-Line)
23
Brown/Red
Open
24
Orange
Illumination
Rev. 04/07/09
1-800-221-0932
© COPYRIGHT 2008-2009 METRA ELECTRONICS CORPORATION
71-1729
INSTRUCTIONS
APPLICATIONS
2008-2009 Honda Accord
24 WAY CONNECTOR
in
Color
Function
P
1
Yellow
12V Battery/Memory
2
White
Left Front (+) Speaker
3
White/Black
Left Front (-) Speaker
4
Blue/Red
Ground Shield for Amplified Sound System
5
Blue/Black
Ground Shield for Amplified Sound System
6
Gray
Right Front (+) Speaker
7
Gray/Black
Right Front (-) Speaker
8
Blue/White
Amplifier Turn On
9
Black/Yellow
Audio Remote Switch
10
Black/Green
Open
11
Red
12 Volt Switched/Accessory
12
Orange/White
Dimmer
13
Black
Ground
14
Green
Left Rear (+) Speaker
15
Green/Black
Left Rear (-) Speaker
16
Red/White
Ground Shield for Amplified Sound System
17
Gray/Red
Ground Shield for Amplified Sound System
18
Purple
Right Rear (+) Speaker
19
Purple/Black
Right Rear (-) Speaker
20
Green/White
Audio Remote Switch Ground
21
Green/Red
Passenger's MICU
22
Brown/White
Data Link Connector (K-Line)
23
Brown/Red
Open
24
Orange
Illumination
Rev. 04/07/09
1-800-221-0932
© COPYRIGHT 2008-2009 METRA ELECTRONICS CORPORATION
INST71-1729
www.metraonline.com
INST71-1729
www.metraonline.com
71-1729
INSTRUCTIONS
APPLICATIONS
2008-2009 Honda Accord
24 WAY CONNECTOR
in
Color
Function
P
1
Yellow
12V Battery/Memory
2
White
Left Front (+) Speaker
3
White/Black
Left Front (-) Speaker
4
Blue/Red
Ground Shield for Amplified Sound System
5
Blue/Black
Ground Shield for Amplified Sound System
6
Gray
Right Front (+) Speaker
7
Gray/Black
Right Front (-) Speaker
8
Blue/White
Amplifier Turn On
9
Black/Yellow
Audio Remote Switch
10
Black/Green
Open
11
Red
12 Volt Switched/Accessory
12
Orange/White
Dimmer
13
Black
Ground
14
Green
Left Rear (+) Speaker
15
Green/Black
Left Rear (-) Speaker
16
Red/White
Ground Shield for Amplified Sound System
17
Gray/Red
Ground Shield for Amplified Sound System
18
Purple
Right Rear (+) Speaker
19
Purple/Black
Right Rear (-) Speaker
20
Green/White
Audio Remote Switch Ground
21
Green/Red
Passenger's MICU
22
Brown/White
Data Link Connector (K-Line)
23
Brown/Red
Open
24
Orange
Illumination
Rev. 04/07/09
1-800-221-0932
© COPYRIGHT 2008-2009 METRA ELECTRONICS CORPORATION
71-1729
INSTRUCTIONS
APPLICATIONS
2008-2009 Honda Accord
24 WAY CONNECTOR
in
Color
Function
P
1
Yellow
12V Battery/Memory
2
White
Left Front (+) Speaker
3
White/Black
Left Front (-) Speaker
4
Blue/Red
Ground Shield for Amplified Sound System
5
Blue/Black
Ground Shield for Amplified Sound System
6
Gray
Right Front (+) Speaker
7
Gray/Black
Right Front (-) Speaker
8
Blue/White
Amplifier Turn On
9
Black/Yellow
Audio Remote Switch
10
Black/Green
Open
11
Red
12 Volt Switched/Accessory
12
Orange/White
Dimmer
13
Black
Ground
14
Green
Left Rear (+) Speaker
15
Green/Black
Left Rear (-) Speaker
16
Red/White
Ground Shield for Amplified Sound System
17
Gray/Red
Ground Shield for Amplified Sound System
18
Purple
Right Rear (+) Speaker
19
Purple/Black
Right Rear (-) Speaker
20
Green/White
Audio Remote Switch Ground
21
Green/Red
Passenger's MICU
22
Brown/White
Data Link Connector (K-Line)
23
Brown/Red
Open
24
Orange
Illumination
Rev. 04/07/09
1-800-221-0932
© COPYRIGHT 2008-2009 METRA ELECTRONICS CORPORATION
INST71-1729
www.metraonline.com
INST71-1729
www.metraonline.com
