INSTALLATION
MANUAL
R410A Split Series
Models
RXS50K2V1B
RXS60F4V1B
RXG50K3V1B
RX50G3V1B
RX60G3V1B
ARXS50G3V1B
RXS50L2V1B
RXS60L2V1B
RX60G4V1B
ARXS50L2V1B
Installationsanleitung
Split-Baureihe R410A
Manuel d'installation
R410A Split-systeem
Manual de instalación
Manuale d'installazione
Serie Multiambienti R410A
Εγχειρίδιο εγκατάστασης
∆ιαιρούμενης σειράς R410A
Manual de Instalação
Руководство по монтажу
Серия R410A с раздельной установкой
Installation manual
R410A Split series
Série split R410A
Montagehandleiding
Serie Split R410A
Série split R410A
Montaj kılavuzları
R410A Split serisi
English
Deutsch
Français
Nederlands
Español
Italiano
Ελληνικά
Portugues
Русский
Türkçe
Advertisement
Table of Contents
Related Manuals for Daikin RXS50K2V1B
Summary of Contents for Daikin RXS50K2V1B
-
Page 1: Installation Manual
MANUAL R410A Split Series Installation manual English R410A Split series Installationsanleitung Deutsch Split-Baureihe R410A Manuel d’installation Français Série split R410A Models Montagehandleiding RXS50K2V1B ARXS50G3V1B Nederlands R410A Split-systeem RXS60F4V1B RXS50L2V1B Manual de instalación RXG50K3V1B RXS60L2V1B Español Serie Split R410A RX50G3V1B RX60G4V1B... - Page 2 3P327445-13G...
- Page 3 3P327445-8D...
- Page 4 3P327445-17K...
-
Page 5: Safety Precautions
Safety Precautions • The precautions described herein are classified as WARNING and CAUTION. They both contain important information regarding safety. Be sure to observe all precautions without fail. • Meaning of WARNING and CAUTION notices WARNING..Failure to follow these instructions properly may result in personal injury or loss of life. CAUTION..Failure to observe these instructions properly may result in property damage or personal injury, which may be serious depending on the circumstances. -
Page 6: Precautions For Selecting The Location
• Make sure to provide for adequate measures in order to prevent that the outdoor unit be used as a shelter by small animals. Small animals making contact with electrical parts can cause malfunctions, smoke or fire. Please instruct the customer to keep the area around the unit clean. -
Page 7: Outdoor Unit Installation Drawings
Outdoor Unit Installation Drawings Max. allowable piping length Min. allowable piping length 1.5m Max. allowable piping height Additional refrigerant required for refrigerant 20g/m pipe exceeding 10m in length. Gas pipe O.D. 12.7mm Wrap the insulation pipe with the finishing Liquid pipe O.D. -
Page 8: Precautions On Installation
Installation Guidelines • Where a wall or other obstacle is in the path of outdoor unit’s inlet or outlet airflow, follow the installation guidelines below. • For any of the following installation patterns, the wall height on the outlet side should be 1200mm or less. Wall facing one side Wall facing two sides More than 100... -
Page 9: Refrigerant Piping
Outdoor Unit Installation Flaring the pipe end 1) Cut the pipe end with a pipe cutter. (Cut exactly at right angles.) Remove burrs. 2) Remove burrs with the cut surface facing downward so that the chips do not enter the pipe. Flaring Set exactly at the position shown below. -
Page 10: Purging Air And Checking Gas Leakage
Purging air and checking gas leakage • When piping work is completed, it is necessary to purge the air and check for gas leakage. WARNING • Do not mix any substance other than the specified refrigerant (R410A) into the refrigeration cycle. •... -
Page 11: Refrigerant Piping Work
Outdoor Unit Installation Refilling the refrigerant Check the type of refrigerant to be used on the machine nameplate. Precautions when adding R410A Fill from the gas pipe in liquid form. It is a mixed refrigerant, so adding it in gas form may cause the refrigerant composition to change, preventing normal operation. 1) Before filling, check whether the cylinder has a siphon attached or not. -
Page 12: Pump Down Operation
Pump Down Operation In order to protect the environment, be sure to pump down when relocating or disposing of the unit. 1) Remove the valve cap from liquid stop valve and gas stop valve. 2) Carry out forced cooling operation. Hexagonal wrench 3) After 5 to 10 minutes, close the liquid stop valve with a hexagonal wrench. -
Page 13: Facility Setting (Cooling At Low Outdoor Temperature)
Facility Setting (cooling at low outdoor temperature) This function is designed for facilities such as equipment or computer rooms. It is never to be used in a residence or office where people occupy the space. Cutting jumper 6 (J6) on the circuit board will expand the operation range down to –10°C. However it will stop if the outdoor temperature drops below –18°C and start back up once the temperature rises again. - Page 14 Service lid Power supply terminal block Shape wires so that the service lid and stop valve cover fit securely. Screw Observe the notes mentioned below when wiring to the power supply terminal block. Precautions to be taken for power supply wiring. CAUTION •...
-
Page 15: Wiring Diagram
Wiring diagram Terminal strip Field wiring Connector Relay connector Connection Terminal Black Orange Blue Brown White Green Yellow Notes Refer to the nameplate of the unit for power requirements. TO INDOOR UNIT To indoor unit POWER SUPPLY Power supply IN CASE OF COOLING ONLY TYPE In case of cooling only type OUTDOOR Outdoor... -
Page 16: Trial Operation And Testing
Trial Operation and Testing Trial operation and testing 1-1 Measure the supply voltage and make sure that it falls in the specified range. 1-2 Trial operation should be carried out in either cooling or heating mode. For heat pump •... - Page 20 3P360062-1C 2013.11...
