HP Integrity BL860c i2 Installation Manual page 22

2. Transfer the duplicate part/serial numbers label from the processor module to the processor's
heatsink.
a. Remove the duplicate yellow tear-away label that lists the part and serial numbers from
the processor module.
b. Place the label on the top of the heatsink.
3. Install the processor over the load posts.
NOTE:
the pin 1 marker on the processor module, the chamfered corner of its attached voltage
regulator heatsink.
4. Remove the heatsink cover.
22 Installing the server blade into the enclosure
Ensure pin 1, indicated on the empty socket with an embossed triangle, matches
