User Manuals: Avalue Technology OFT-10W02 Frame Tablet

User Manuals: Avalue Technology OFT-10W02 Frame Tablet

Manuals and User Guides for Avalue Technology OFT-10W02 Frame Tablet. We have 1 Avalue Technology OFT-10W02 Frame Tablet manual available for free PDF download: Quick Reference Manual

Avalue Technology OFT-10W02 Quick Reference Manual

Avalue Technology OFT-10W02 Quick Reference Manual (48 pages)

10.1" Open Frame Tablet

Brand: Avalue Technology | Category: Tablet | Size: 2 MB

Table of Contents

Table of Contents
6
1 Getting Started

7
- Safety Precautions
  7
- Packing List
  7
- System Specifications
  8
- System Overview
  11
  - Right View
    11
  - Left View
    11
- System Dimensions
  12
- Flush Mounting Concept
  15
- Panel Mounting
  16
- Wall Mounting Concept
  24
- Wall Mounting
  25
2 Hardware Configuration

33
- Architecture Overview-Block Diagram
  34
- Motherboard Overviews
  35
- Motherboard Connector List
  37
- Motherboard Connectors Settings
  39
  - Touch Button Board Connector (JTB1)
    39
  - General Purpose I/O Connector (JDIO1)
    39
  - RS-232 Connector (J232-1)
    40
  - RS-485 Connector (J485-1)
    40
  - USB Connector (JCAM1)
    41
  - Amplifier_L (Jamp_L)
    41
  - Amplifier_R (Jamp_R)
    42
  - A-MIC Connector (JAMIC1)
    42
  - I2C Connector (JSEN1)
    43
  - DC Power-In Connector (JDCIN3)
    43
- Fcc
  44
- Android Rotate Setting
  46
