Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury, death and/or
property damage! Retain instructions for future reference.
Table of Contents
OPERATOR'S RESPONSIBILITY:
The tool operator is responsible for:
General Safety . . . . . . . . . . . . .1-3
• Reading and understanding tool
Specifications . . . . . . . . . . . . . . .2
labels and manual.
Operating The Nailer . . . . . . .3-5 • Selecting an appropriate tool actua-
tion system, taking into considera-
Operational Mode . . . . . . . . . . .4
tion the work application for which
Troubleshooting . . . . . . . . . . . . .7
the tool is used.
Warranty . . . . . . . . . . . . . . . . . . .8 • The safe use of the tool.
• Ensuring that the
tool is used only
Description
when the operator
This nailer is designed for decorative
and all other person-
trim, molding, window casings, furni-
nel in the work area
ture trim and picture frame assembly.
are wearing ANSI Z87 eye protec-
Features include: convenient rear load-
tion equipment, and when
ing magazine which holds up to 100
required, other appropriate protec-
nails, no-mar tip, adjustable exhaust,
tion equipment such as head, hear-
single cycle trigger, quick clear nose,
ing and foot protection equipment.
and an adjustable depth of drive mech-
Serious eye or permanent hearing
anism.
loss could result.
• Assuring that the tool is kept in safe
working order as described in this
General Safety
manual.
Information
EMPLOYER'S RESPONSIBILITY:
CALIFORNIA PROPOSITION 65
• Selecting an appropriate tool actua-
You
DANGER
!
tion system, taking into considera-
can cre-
tion the work application for which
ate dust when you cut,
sand, drill or grind materi-
the tool is used.
als such as wood, paint,
• Ensuring that this manual is avail-
metal, concrete, cement, or other
able to operators and personnel
masonry. This dust often contains
performing maintenance.
chemicals known to cause cancer, birth
defects, or other reproductive harm. • The safe use of the tool.
Wear protective gear.
• Enforcing that the
tool is used only
This manual contains safety, opera-
when the operator
tional and maintenance information.
and all other person-
Contact your Maxus representative if
nel in the work area
you have any questions.
are wearing ANSI Z87 eye protec-
tion equipment, and when
required, other appropriate protec-
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
Maxus Nailers meet or exceed Industries'
Standards as set forth by the American
National Standard Institute/International
Staple, Nail and Tool Association in ANSI/ISAN-
TA SNT-101-2002.
© 2004
Model MXN064
Finishing
Nailer
Model MXN064
Locate model number on decal, date
code on body and record below:
Model No. ________________________
Date Code ________________
Retain these numbers for
future reference.
tion equipment such as head, hear-
ing and foot protection equipment.
Serious eye or permanent hearing
loss could result.
• Assuring that the tool is kept in
safe working order as described in
this manual.
• Assuring the proper maintenance
of all tools in employer's possession.
• Ensuring that tools which require
repair are not further used before
repair. Tags and physical segrega-
tion are recommended means of
control.
Danger indicates
DANGER
!
an imminently haz-
ardous situation which, if not avoided,
WILL result in death or serious injury.
IN277100AV 4/04
