Maxus MXN10400 Operating Instructions

Operating Instructions
Limited Warranty
1. DURATION: From the date of purchase by the original purchaser as follows: Campbell Hausfeld (Standard Duty and
Unannounced) – One (1) Year, (Serious Duty) – Two (2) Years, (Extreme Duty) – Three (3) Years; IronForce by Campbell
Hausfeld – One (1) Year; Farmhand – Three (3) Years; Maxus – Five (5) Years.
2. WHO GIVES THIS WARRANTY (WARRANTOR): Campbell Hausfeld / Scott Fetzer Company, 100 Production Drive,
Harrison, Ohio, 45030, Telephone: (800) 543-6400
3. WHO RECEIVES THIS WARRANTY (PURCHASER): The original purchaser (other than for purposes of resale) of the
Campbell Hausfeld product.
4. WHAT PRODUCTS ARE COVERED BY THIS WARRANTY: Any Campbell Hausfeld nailer, stapler, air tool, spray gun, infla-
tor or air accessory supplied or manufactured by Warrantor.
5. WHAT IS COVERED UNDER THIS WARRANTY: Substantial defects in material and workmanship which occur within the
duration of the warranty period.
6. WHAT IS NOT COVERED UNDER THIS WARRANTY:
A. Implied warranties, including those of merchantability and FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED
FROM THE DATE OF ORIGINAL PURCHASE AS STATED IN THE DURATION. If this product is used for commercial,
industrial or rental purposes, the warranty will apply for ninety (90) days from the date of purchase. Some States
do not allow limitation on how long an implied warranty lasts, so the above limitations may not apply to you.
B. ANY INCIDENTAL, INDIRECT, OR CONSEQUENTIAL LOSS, DAMAGE, OR EXPENSE THAT MAY RESULT FROM ANY
DEFECT, FAILURE, OR MALFUNCTION OF THE CAMPBELL HAUSFELD PRODUCT. Some States do not allow the exclu-
sion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to
you.
C. Any failure that results from an accident, purchaser's abuse, neglect or failure to operate products in accordance
with instructions provided in the owner's manual(s) supplied with product. Accident, purchaser's abuse, neglect or
failure to operate products in accordance with instructions shall also include the removal or alteration of any safety
devices. If such safety devices are removed or altered, this warranty is void.
D. Normal adjustments which are explained in the owner's manual(s) provided with the product.
E. Items or service that are normally required to maintain the product, i.e. o-rings, springs, bumpers, debris shields,
driver blades, fuses, batteries, gaskets, packings or seals, fluid nozzles, needles, sandblast nozzles, lubricants, mate-
rial hoses, filter elements, motor vanes, abrasives, blades, cut-off wheels, chisels, chisel retainers, cutters, collets,
chucks, rivet jaws, screw driver bits, sanding pads, back-up pads, impact mechanism, or any other expendable part
not specifically listed. These items will only be covered for ninety (90) days from date of original purchase.
Underlined items are warranted for defects in material and workmanship only.
F. Cosmetic defects that do not interfere with the product's function.
7. RESPONSIBILITIES OF WARRANTOR UNDER THIS WARRANTY: Repair or replace, at Warrantor's option, products or com-
ponents which are defective, have malfunctioned and/or failed to conform within duration of the warranty period.
8. RESPONSIBILITIES OF PURCHASER UNDER THIS WARRANTY:
A. Provide dated proof of purchase and maintenance records.
B. Deliver or ship the Campbell Hausfeld product or component to the nearest Campbell Hausfeld Authorized Service
Center. Freight costs, if any, must be borne by the purchaser.
C. Use reasonable care in the operation and maintenance of the products as described in the owner's manual(s).
9. WHEN WARRANTOR WILL PERFORM REPAIR OR REPLACEMENT UNDER THIS WARRANTY: Repair or replacement will be
scheduled and serviced according to the normal work flow at the servicing location, and depending on the availability
of replacement parts.
This Limited Warranty applies in the United States, Canada and Mexico only and gives you specific legal rights. You may
also have other rights which vary from state to state or country to country.
MXN10400
8
See Warranty on page 8 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury, death and/or
property damage! Retain instructions for future reference.
Table of Contents
OPERATOR'S RESPONSIBILITY:
The tool operator is responsible for:
General Safety . . . . . . . . . . . . .1-3
• Reading and understanding tool
Specifications . . . . . . . . . . . . . . .2
labels and manual.
Operating The Tool . . . . . . . . .3-5 • Selecting an appropriate tool actua-
tion system, taking into considera-
Troubleshooting . . . . . . . . . . . . .7
tion the work application for which
Warranty . . . . . . . . . . . . . . . . . . .8
the tool is used.
• The safe use of the tool.
Description
• Ensuring that the
tool is used only
This tool is designed for decorative
when the operator
trim, molding, window casings, furni-
and all other person-
ture trim, picture frame assembly, cabi-
nel in the work area
netry, casebacks, and crafts. Features
are wearing ANSI Z87 eye protec-
include: convenient top loading maga-
tion equipment, and when
zine which holds up to 100 brads or
required, other appropriate protec-
staples, adjustable depth control,
tion equipment such as head, hear-
adjustable exhaust, quick clear nose.
ing and foot protection equipment.
Serious eye or permanent hearing
General Safety
loss could result.
• Assuring that the tool is kept in safe
Information
working order as described in this
CALIFORNIA PROPOSITION 65
manual.
You
DANGER
!
EMPLOYER'S RESPONSIBILITY:
can
create dust when you cut,
• Selecting an appropriate tool actua-
sand, drill or grind materi-
tion system, taking into considera-
als such as wood, paint,
tion the work application for which
metal, concrete, cement, or
other masonry. This dust often contains the tool is used.
chemicals known to cause cancer, birth • Ensuring that this manual is avail-
defects, or other reproductive harm.
able to operators and personnel
Wear protective gear.
performing maintenance.
This manual contains safety, opera-
• The safe use of the tool.
tional and maintenance information.
• Enforcing that the
Contact your Campbell Hausfeld repre-
tool is used only
sentative if you have any questions.
when the operator
and all other person-
nel in the work area
are wearing ANSI Z87 eye protec-
tion equipment, and when
required, other appropriate protec-
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
Maxus Nailers meet or exceed Industries'
Standards as set forth by the American
National Standard Institute/International
Staple, Nail and Tool Association in ANSI/ISAN-
TA SNT-101-2002.
© 2004
MXN10400
2-in-1
Nailer/Stapler
Model MXN10400
Locate model and date code on tool
magazine and under nozzle shield,
and record below:
Model No. ________________________
Date Code ________________
Retain these numbers for
future reference.
tion equipment such as head, hear-
ing and foot protection equipment.
Serious eye or permanent hearing
loss could result.
• Assuring that the tool is kept in
safe working order as described in
this manual.
• Assuring the proper maintenance
of all tools in employer's possession.
• Ensuring that tools which require
repair are not further used before
repair. Tags and physical segrega-
tion are recommended means of
control.
IN701300AV 11/04
