IKEGAMI
The CTS Series
CTS-2
CTS-8
CLS-4
CTS-4
CTS-16
CLS-8
CLTS-4
Instruction Manual
Thank you very much for purchasing one of our products. Please read
this manual before using the this product. When using this product,
always follow the instructions contained in this manual, and pay close
attention to the safety information.
37 Brook Avenue Maywood, NJ 07607
TEL: (201)368-9171
Fax: (201)569-1626
Web: www.ikegami.com
Advertisement
Table of Contents
Related Manuals for Ikegami CTS-2
Summary of Contents for Ikegami CTS-2
- Page 1 IKEGAMI The CTS Series CTS-2 CTS-8 CLS-4 CTS-4 CTS-16 CLS-8 CLTS-4 CLTS-8 Instruction Manual Thank you very much for purchasing one of our products. Please read this manual before using the this product. When using this product, always follow the instructions contained in this manual, and pay close attention to the safety information.
- Page 2 To reduce the risk of electric shock, do not remove the cover. No parts inside the product can be serviced by the user. If your product needs service contact Ikegami Electronics at (201) 368-9171. Usage Environment Avoid using or storing this product in areas such as those listed below. Doing so could damage the product or cause it to malfunction.
- Page 3 5) HOME; Will freeze the scan to the selected position. If more than one position is selected, the higher number will be activated. CTS-2: 2x1 Terminating Video only sequential switcher CTS-4: 4x1 Terminating Video only sequential switcher CLS-4: 4x1 Looping Video only sequential switcher...
- Page 4 Each input has it's own resistor and must be cut if the looping feature is to be used on that input. Cut here violet, green, black 37 Brook Avenue Maywood, NJ 07607 TEL: (201)368-9171 Fax: (201)569-1626 Web: www.ikegami.com...
- Page 5 2) Cut the 75 ohm resistor on both sides and remove it. If more than one input is to be unterminated cut the additional resistors out. 3) Re-install the cover and replace the screws. 4) Reconnect the power supply. 37 Brook Avenue Maywood, NJ 07607 TEL: (201)368-9171 Fax: (201)569-1626 Web: www.ikegami.com...
-
Page 6: Limited Warranty
Limited Warranty: Ikegami warrants this product and all accessories provided with it to be free of defects in material and workmanship for a period of 5 years after the original date of purchase. This warranty does not cover damage to the product resulting from accident, misuse or modification.
