b-1
ACCUSPLIT, Inc.
6120 Stoneridge Mall Rd., Suite 210
Pleasanton, CA 94588 USA
800-965-2008 • 925-226-0888 • FAX 925-463-0147
www.ACCUSPLIT.com • support@ACCUSPLIT.com
2-3
IMPORTANT NOTE
This stopwatch can store up to 500 split/lap times.
However please note when there are 5 free mem-
ories left, the icon "FULL " will blink to remind you
of the nearly full situation. Whenever the storage
is full, extra split/lap times will NOT be stored into
memory even though you reset your stopwatch
and start a new event. Extra split/lap times will
only be shown on the display but not recorded.
In order for the stopwatch to record the lap/split
times again, you must delete the data in the DATA
memory. Please refer to the "Data Mode" section
in the instruction manual for how to delete the
memory.
2
ACCUSPLIT®
E X C L U S I V E
AX602M500
AX602M500DEC
DIGITAL QUARTZ
STOPWATCHES
OPERATING
INSTRUCTIONS
980-314
Introduction
You are about to enjoy an advanced Cumula-
tive and Lap memory professional digital quartz
stopwatch with advanced timing features. Models
AX602M500 & AX602M500DEC Stopwatches
include Time of day, Daily Alarm, Chronograph
stopwatch, 500 memory, Data register, Count-
down timer, Stroke Measurement timer, and Pacer
(from 5 to 240 beats per minute).
Model AX602M500DEC Decimal Stopwatch
includes Decimal timing (1/100 of a sec,
1/1000 of a minute, 1/100,000 of an hour).
Model AX602M500 Speed Stopwatch includes
Speed Measurement.
INSTRUCTIONS
3
Advertisement
Table of Contents
Related Manuals for Accusplit AX602M500
Summary of Contents for Accusplit AX602M500
- Page 1 Stroke Measurement timer, and Pacer (from 5 to 240 beats per minute). Model AX602M500DEC Decimal Stopwatch includes Decimal timing (1/100 of a sec, 1/1000 of a minute, 1/100,000 of an hour). Model AX602M500 Speed Stopwatch includes Speed Measurement.
- Page 2 General Features • ACCUSPLIT X case with ergonomic design and no-fail buttons • 4 button operation • Large LCD display with contrast adjustment • 12/24 hour display • Time of day and chime • Daily alarm • Full 1/100 second chronograph with working range from 0 to 19 hr.
-
Page 3: Time Of Day Mode
[MODE] button is pressed again. 10-11 ACCUSPLIT products use a common setting procedure known as S1-S2-S3-S4. S1 (2 sec) - Enter set function OR S1 (4 sec) - Enter set function & clear the current settings S2 –... - Page 4 12-13 date-month (d-m), Sound ON or OFF , Contrast (darkness of the digits - default is 9), then back to Second, and recycles again. Note: when the second is to be set, press [START • SPLIT] to reset the second digits to zero. At the end of setting, press [RECALL] (S4) or [MODE] to exit from the setting mode and back to Time of Day Display.
- Page 5 16-17 Chronograph and Recall Mode Press [MODE] until you enter the Chrono mode. The stopwatch can measure up to 19 hours, 59 minutes, 59.99 seconds. When you enter the Chronograph mode, the display format is as below. 18-19 To take a current split or lap time, press [START • SPLIT].
- Page 6 20-21 When there are 5 free memories left, the icon “FULL ” will blink to remind you of the nearly full situation. Whenever the storage is full, extra split/lap times will not be stored into memory but will still be shown on the display. Any fastest and slowest laps will not be stored.
- Page 7 24-25 Please note that if the stopwatch is running, no selection for chronograph operating modes can be made until the stopwatch has been stopped and reset. Segmented run memory for lap/split time storage. A header consisting of the date/time stamp is attached to each segment to indicate the moment when you began recording the particular timing segment.
- Page 8 28-29 [RECALL] Note: watch is still running [RECALL] so run time continues to advance. [RECALL] 30-31 Recall indicator turns off when watch returns to regular Chronograph mode. [RECALL] During memory recall, you can press either [START • SPLIT] or [STOP • RESET] to exit from chrono recall mode and jump to the chrono start/stop or lap state respectively.
- Page 9 32-33 The header consisting of the date/time stamp will be shown. The number of laps in the segment will appear in the upper left while the segment num- ber is displayed in the middle left. If the segment shown is not your desired segment, press [START •...
-
Page 10: Timer Mode
36-37 Note: You cannot delete all segments while the stopwatch is running. If nothing happens when you push and hold [STOP • RESET] check to make sure the stopwatch is stopped. 38-39 Number of cycles Time in Countdown Repeat mode The upper line shows the programmable timer value (initially set at 0:00:00:0) while the middle line displays the current timer counting. - Page 11 40-41 How to set the timer Press and hold [RECALL] (S1) for 2 seconds to activate timer setting. Timer setting starts with second digits, which are shown blinking. You can press [START • SPLIT] (S3) to advance the fl ashing digits.
- Page 12 During the 1st second, 180.0 will be shown and fl ashing as below. 46-47 Speed Mode (AX602M500 Model only) Press [MODE] until you enter the Speed mode. The display will be as follows. Distance indicator (only used in speed mode °...
- Page 13 48-49 Press [START • SPLIT] (S3) to toggle between KM and MILE. To select the following digits, press [STOP • RESET] (S2). The far right digit will blink and you can set the distance from the least signifi cant digit to the most signifi cant digit. The distance can be set in the range 0.000 to 1999.999 km (or ML) using [START •...
- Page 14 During Data recall, the fastest speed will be reviewed fi rst, then the slow- est speed and average speed. Please register your new stopwatch at www.ACCUSPLIT.com/support or send this form to address on the back cover of this instruction booklet Email (preferred)
