- Page 1 Digital Video Recorder CDVR-0402U User Manual - 1 -...
-
Page 2: Fcc Compliance Statement
WARNING FCC Compliance Statement NOTE : This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: Important Safety Instructions
MPORTANT SAFETY INSTRUCTIONS 1. Read Instructions All the safety and operating instructions should be read before the product is operated. 2. Retain Instruction Manuals The safety and operating instructions should be retained for future reference. 3. Heed Warnings All warnings on the product and in the operating instructions should be adhered to. 4. - Page 4 Important Safety Instructions 14. Damage Requiring Service Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: a) When the power-supply cord or plug is damaged. b) If liquid has been spilled, or objects have fallen into the product. c) If the product has been exposed to rain or water.
-
Page 5: Table Of Contents
ONTENTS FCC COMPLIANCE STATEMENT................... IMPORTANT SAFETY INSTRUCTIONS................INDEX..........................1. INTRODUCTION AND INSTALLATION DVR Components......................Front Panel........................Rear Panel........................Remote Controller..................... 2. INSTALLATION Installation of Hard Disk Drives................... Starting the DVR......................Log In & Log Out......................USB Flash Drive......................3. CONFIGURATION System Setup........................ -
Page 6: Dvr Components
1. I NTRODUCTION The CDVR-0402 is a compact sized multiplexer digital video recorder developed to provides extremely long recording capabilities with advanced recording and convenient search functions. 1.1. DVR Components Check the package and contents for visible damage. If any components are damaged or missing, do not attempt to use the unit, contact the supplier immediately. -
Page 7: Front Panel
Introduction 1.2. Product Description 1.2.1. Front Panel ① ② ③ ⑧ ⑨ ⑤ ⑥ ⑦ ④ ⑩ ① POWER : Power On/Off ② PANIC : Recording On/Off of all channels at highest speed and quality. ③ Channel Indicator : Indicates which channels are operating ④... -
Page 8: Rear Panel
Introduction 1.2.2. Rear Panel ① ③ ④ ⑤ ② ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ① Power Cable Connection. ( Does not support 110V~220V Free Volt) ② Power Switch. - Select the correct voltage for your region. ③ Video Input Connectors - Input connectors for video signals. -
Page 9: Remote Controller
Introduction 1.2.3. Remote Controller OSD On/Off during Monitoring/Full-screen Playback. PANIC Panic Recording On/Off. Numeral Keys Select channel or type in characters. CAPTURE Capture video clip/image to external memory. Remove image distortion during frame by frame advance. PREVIOUS Move to previous category. NEXT Move to next category. -
Page 10: Installation
2. I NSTALLATION 2.1. Installation of Hard Disk Drives ※ Compatible Hard Disk Drives : Samsung, Maxtor, Fujitsu, Western Digital, Seagate Maximum of 2 Hard Disk Drives may be installed in the DVR. Installation order. Insert the HDD into the bracket(Bottom side up) and secure the HDD onto the bracket using 4 screws and connect the Power Plug and IDE Cable into the HDD connectors. -
Page 11: Starting The Dvr
Starting The DVR 2.2. Starting The DVR After installing the hard disk, set the DIP switch to the NTSC or PAL position to match your equipment and select the correct power voltage(located at the rear panel) of your region before turning on the power of the DVR. -
Page 12: Log In & Log Out
Starting The DVR 2.3. Log In & Log Out The USER will be required to Log In(Type in the PASSWORD) in order to enter Setup, Search(Playback), PTZ Control, and Log Search. “0000” Default PASSWORD is set at ※ 1) Using the Remote Controller press the [ENTER] button and use the Number buttons to type in the password. -
Page 13: Usb Flash Drive
Starting The DVR 2.4. USB Flash Drive This DVR supports Hi-Speed USB 2.0 Flash Drives. • - Use of Full Speed USB 2.0 Flash Drives may result in slow backup speed or capture speed. • Please note that the USB must be formatted using the DVR Formatting function. Please follow the formatting instructions provided in CONFIGURATION –... -
Page 14: Configuration
3. C ONFIGURATION Before starting your DVR for the first time, you should establish the initial settings. This includes categories such as time and date, display language, camera, audio, record mode, network and password. Press the [SETUP] button on the Remote Controller to enter SETUP . The selected category will be highlighted with a blue background as shown in the above picture. -
Page 15: System Setup
Configuration 3.1. System Setup CATEGORY DEFAULT ADJUSTMENT Change the OSD LANGUAGE. [Up, Down][Left, Right]: ENGLISH KOREAN CHINESE LANGUAGE ENGLISH [ENTER] : Apply new LANGUAGE. [PREV][NEXT] : Move to previous/next category. Set the ID(Identification no.) of DVR. Input Range : 0~255 [Left, Down] : Decrease number [Right, Up] : Increase number Select [ADMIN] or [USER] and press [ENTER] to change the PASSWORD. - Page 16 Configuration CATEGORY DEFAULT ADJUSTMENT Upgrade the Firmware of the System. Copy the Firmware file “/DVRSYS/FW/FDVR0402.BIN” to a USB memory stick SYSTEM and connect the USB memory stick to the DVR.. UPGRADE The DVR will reboot in order to initialize the UPGRADE. [ENTER] : Perform UPGRADE.
-
Page 17: Camera Setup
Configuration 3.2. Camera Setup CATEGORY DEFAULT ADJUSTMENT Set whether to hide the selected channel or channels from the live COVERT monitoring screen while continuing to record the channels. [ENTER] : Toggle to Apply/Not Apply. Select the channel that is to be configured. CHANNEL [Up, Down][Left, Right] : Change channels [CH] and Numeral keys can also be used to change the channel. -
Page 18: Motion Detection
Configuration CATEGORY DEFAULT ADJUSTMENT Set the PTZ ID. Input Range : 0~255 PTZ ID [Left, Down] : Decrease number [Right, Up] : Increase number Number keys can also be used to change the PTZ ID. Select the PTZ Driver. [Up, Down, Right, Left] : Select the PTZ Driver <... -
Page 19: Record Setup
Configuration 3.3. Record Setup CATEGORY DEFAULT ADJUSTMENT Set the recording resolution level. Even if QUAD recording is selected, only 1 channel will be recorded if the NTSC resolution is set at 720x480. Therefore, when 720x480 is set, designate which 352X240 channel to be recorded. - Page 20 Configuration CATEGORY DEFAULT ADJUSTMENT Set the FPS(frame per second). NTSC(fps) : 0, 1, 2, 3, 4, 5, 6, 7, 10, 15, 30 NTSC: 15 PAL(fps) : 0, 1, 2, 3, 4, 5, 6, 8, 12, 25 PAL : 12 [Left, Down] : Decrease FPS level [Right, Up] : Increase FPS level Set video recording QUALITY MIDDLE...
-
Page 21: Record Schedule
Configuration 3.4. Record Schedule The recording time can be set according to Channels, Weekday, and Time. CATEGORY DEFAULT ADJUSTMENTS Select the WEEKDAY Scheduling. WEEKDAY [Up, Down] : Change WEEKDAY Set the Recording method. C : Continuous M : Motion Detection D : Dual Mode (Motion + Sensor) SCHEDULE S : Sensor... -
Page 22: Sensor Setup
Configuration 3.5. Sensor Setup CATEGORY DEFAULT ADJUSTMENT Set the SENSOR Number. SENSOR [Left, Down] : Decrease Number [Right, Up] : Increase Number SENSOR Select the SENSOR TYPE TYPE [Up, Down, Left, Right] : Select NO or NC Select the CAMERA that is to be connected to the SENSOR CAMERA [Left, Down, Right, Up] : Move between channels LINK... - Page 23 Configuration CATEGORY ADJUSTMENT DEFAULT Set the duration for which the Alarm(Output) will continue after the sensor is triggered. OUTPUT Input Range : 0~600(Second) DWELL TIME [Left, Down] : Decrease duration [Right, Up] : Increase duration Number keys can also be used to change the dwell time. Set whether to use the DVR Buzzer when a sensor is triggered.
-
Page 24: Network Setup
Configuration 3.6. Network Setup : Page 1 CATEGORY DEFAULT ADJUSTMENT Set the DVR NAME. Use the Numeral/Letter/Symbol buttons or the [Up, Down] buttons to input the Name. NAME [Left, Right] : Move to previous/ next space [Up, Down] : Select letter, number, symbol Select IP Type. - Page 25 Configuration CATEGORY DEFAULT ADJUSTMENT Set the SMTP Address. [Left, Right] : Move to next number field SMTP [Up, Down] : Increase/Decrease number Number keys can also be used to change the STMP address. Display the MAC Address of the DVR. MAC Address is pre-set during production and cannot be changed.
- Page 26 Configuration 3.6. Network Setup : Page 2 CATEGORY DEFAULT ADJUSTMENT Set whether E-Mail Login is required for E-MAIL notification when a sensor is E-MAIL triggered AUTHORITY [Up, Down, Left, Right] : Select YES or NO Set the E-Mail Login ID. [Up, Down] : Select letter, number, symbol.
-
Page 27: Display Setup
Configuration 3.7. Display Setup CATEGORY DEFAULT ADJUSTMENT OSD(On Screen Display) Designate which information to be shown on the monitoring screen. [Left, Up] : Move to upper category [Right, Down] : Move to lower category [ENTER] : Toggle to Apply/Disable Set the BORDER COLOR of screen BORDER [Left, Up] : Move to upper category. -
Page 28: Backup & Format
Configuration 3.8. Backup & Format CATEGORY ADJUSTMENT Set the START-END TIME of a recorded video for Backup [Left, Right] : Move between Year/Month/Day/Time BACKUP [Up, Down] : Increase/Decrease number Number keys can also be used to change date & time Select the backup memory device(USB) and move to START . -
Page 29: Operation
4. O PERATION 4.1. Monitoring Monitoring Screen The video signals received by the DVR can be viewed on Multi-Screens or the image can be viewed in the Pause and Zoom mode. Date, Time, Camera Number, Recording Status, HDD Capacity Usage are displayed on the screen. Information displayed on the screen(OSD) can be changed by pressing the [OSD] button or the DVR front panel [ESC] button.. -
Page 30: Sequence Display
Operation SEQUENCE DISPLAY Single screen sequence display is possible by pressing the [SEQUENCE] button. The Sequence Dwell Time can be set in the [SETUP] – [DISPLAY] menu. icon will appear on the screen during the Sequence Display mode. 4.2. PTZ Control This is a mode to control Camera Direction/Focus/Zoom/Preset/Swing/Pattern/Group during the Monitoring Mode. -
Page 31: Recording
Operation 4.3. Recording The initial recording configuration for this DVR is set up as follows : CATEGORY DEFAULT VALUE RECORDING SPEED - NTSC 15FPS(Frames Per Second) - PAL 12FPS(Frames Per Second) RECORDING QUALITY MIDDLE RESOLUTION - NTSC 352x240(CIF) - PAL 352x288(CIF) RECORDING SCHEDULE CONTINUOUS... -
Page 32: Search(Playback)
Operation 4.4. Search (Playback) You may search the recorded video data of the DVR by using the Time Search Mode. Enter the [SEARCH] menu and select “DVR” using the [Up. Down] buttons and press [ENTER]. DVR Search : TIME & DATE SEARCH The following Time Search Mode will appear on the screen. -
Page 33: Button Function
Operation SEARCH PROCEDURE By selecting the [SEARCH] menu, information of the first file recorded on the current day will appear on the screen. And the search procedure will start from the “Day” indication field. 1) Select the Year and Month. On the calendar, days containing recorded data will be highlighted in yellow. - Page 34 Operation Button Function Up, Down, Left, Right Move to the desired Day ENTER, NEXT Move to the Hour/Channel indication table PREV PREV : Move to “Year-Month” indication field 3) Select the relevant Hour/Channel. The relevant recording file list will appear on the upper left corner of the screen for the selected Hour/Channel. Button Function Left, Right...
- Page 35 Operation Button Function Up, Down Move from file to file(Time range) ENTER Start playback PREV : Move to Hour/Channel indication table PREV , NEXT NEXT : Move to “Year-Month” indicator FULL SCREEN DISPLAY The playback screen can be changed to the full screen mode by pressing the [FULL SCR] button.
-
Page 36: Usb Search
Operation USB Search Data saved on a USB Memory Stick may be played back by following the USB SEARCH procedure. Select the [SEARCH] menu and move to “USB” by using the [Up, Down] buttons. Then press the [ENTER] button to enter the USB Time Search Mode. SEARCH PROCEDURE The following display will appear on the screen. -
Page 37: Log Search
Operation 4.4. Log Search All events that occur on the DVR are recorded in the Log List. Select the [LOG] Menu and the following LOG Time Search mode will appear. ① ② ① SORT Selection of LOG types. Type Explanations POWER Power On/Off SENSOR... - Page 38 Operation SEARCH PROCEDURE 1) Select the relevant “Year, Month”. On the calendar, days containing LOG records will be highlighted in yellow. Button Function Left, Right Toggle between Year Month Up, Down Select the relevant Year and Month ENTER Move to the Day indication field PREV : Move to LOG List(If log records exist for the selected date.) PREV , NEXT NEXT : Move to Day indication field...
- Page 39 Operation 3) SORT Select the desired type of log information of the selected Day. Button Function Select the SORT category. Up, Down (Select among ALL, POWER, SENSOR, RECORD, CAMERA, LAN, BACKUP , SETUP , TIME.) Display log list of the selected event selected. (If log records exist for the selected ENTER event.) PREV : Move to Day indication field...
-
Page 40: Video Clip Copy
Operation 4.5. Video Clip Copy Video Clip copies of recorded video datas can be made to a USB Memory Stick by taking the following steps. COPY PROCEDURE 1) Enter SEARCH(DVR). 2) Follow the procedure explained in DVR SEARCH to find the relevant video data and activate playback. 3) Find the Starting location of the video clip you wish to make a copy and press the [CAPTURE] button to designate the Starting location. -
Page 41: Appendix : Technical Specification
Appendix Technical Specification Category Specification Operating System Embedded Proprietary OS Compression Algorithm MPEG4(VIDEO) , ADPCM(SOUND) 1.5~6KByte/Frame @ 352x240(352x288) Byte Size per Frame 6~24KByte/Frame @ 720x480(720x576) Multi-Screen Display 1/4/Sequence Video Input 4 BNC Monitor Output 1 Composite, 1 VGA, 1 S-Video Display Speed 120fps NTSC : 352x240, 720x480...
