- Page 1 Mobile Digital Video Recorder CMDVR-0402 User Manual - 1 -...
-
Page 2: Important Safety Instructions
MPORTANT SAFETY INSTRUCTIONS FCC Compliance Statement This equipment has been tested and found to comply with the limits for a Class A digital NOTE : device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: Table Of Contents
ONTENTS IMPORTANT SAFETY INSTRUCTIONS……………………………………………..……… INDEX……………………………………………………………………….……………………… 1. INTRODUCTION Package Contents……………………………………………………………………..…… Front Panel…………………………………………………………………………………… Rear Panel……………………………………………………………………………….……. Remote Controller……………………………………………………...………………..… 2. INSTALLATION Hard Drive..………….………..………………………………….…….………………….. Connections..………………..………………………………………….…………..……… Starting the DVR………………………………………………………………….………… Log In & Log Out…………………………………………………………………….……… 3. CONFIGURATION System Setup………...……….………………..………………………..…………..Camera Setup…………………………………………………..………………………….. Motion Detection……………………..…………………………………………….. Record Setup…………………………………………..…………..………….……….. Record Scheduler……………………………………………………………………………..16 Sensor Setup……………………..…………………………….……………………………... -
Page 4: Introduction
1. I NTRODUCTION The CMDVR0402 is a compact sized multiplexer digital video recorder developed specifically for mobile transportations such as vehicles, buses, trains, etc. Unlike outdated time-lapse VCRs, the CMDVR0402 provides extremely long recording capabilities with advanced recording and convenient search functions. Package Contents Check the package and contents for visible damage. -
Page 5: Front Panel
Introduction Front Panel REMOTE MENU PREV NEXT (ENTER) (PTZ) (PTZ) (PTZ) (PTZ) HDD LOCK 1 REMOTE SENSOR Return to previous mode 2 MENU(ENTER) 10 CH Enter MENU, Select, Apply values Change channels during monitoring or (PTZ) playback. Move, increase values, PTZ control(Tilt) 11 HDD POWER /OPERATION LED (PTZ) 12 HDD KEY LOCK... -
Page 6: Rear Panel
Introduction Rear Panel A/IN1 A/OUT1 A/OUT2 V/OUT V/IN1 V/IN2 V/IN3 V/IN4 REMOTE TXT/IN A/IN2 DC8V ~36V 12 13 Audio In 2 1 Audio In 1 10 Text In 2 Audio Out 1 11 USB Port 3 Audio Out 2 12 Remote Eye 4 Video Out 13 Power Cord 5 Video In 1... -
Page 7: Remote Controller
Introduction Remote Controller OSD On/Off. AUDIO Select Audio Channel. Return to previous mode. AUDIO Move Up, PTZ Control(Tilt), Increase value. Set ID of remote controller. AUDIO JITTER (While pressing ID button, press 2 digits from MENU the number buttons and release the ID button). Identical ID must be applied for the DVR and ENTER NEXT... -
Page 8: Installation
2. I NSTALLATION Hard Drive Removable HDD Tray Screws HDD Bracket 2.5” HDD HDD Bracket Screws 1. Detach the Removable HDD Tray 2. Detach the HDD Bracket from the from the DVR. Tray and attach the 2.5” HDD onto the Bracket with the supplied screws. -
Page 9: Connections
Installation Connections Audio Out Video Out Video In A/IN1 A/OUT1 A/OUT2 V/OUT2 V/IN1 V/IN2 V/IN3 V/IN4 TXT/IN REMOTE A/IN2 DC8V ~36V Power RS485 Audio In Text In Remote Controller Connecting to RS485 - 9 -... -
Page 10: Starting The Dvr
Installation Starting The DVR After installing the hard disk, connect the power cord to start the DVR. ※ The HDD Lock in the front panel must be in the lock position before turning on the DVR power. When starting the DVR for the first time, formatting of the hard disk will commence automatically and the DVR will be initialized as follows. -
Page 11: Log In & Log Out
Installation Log In & Log Out The USER will be required to Log In(Type in the PASSWORD) in order to enter Setup, Search(Playback), PTZ Control, and Log Search. ※ Default PASSWORD is set at “0000” 1) Using the Remote Controller press the [ENTER] button and use the Number buttons to type in the password. -
Page 12: Configuration
3. C ONFIGURATION Before starting your DVR for the first time, you should establish the initial settings. This includes categories such as time and date, display language, camera, audio, remote control, record mode, network and password. Press the [MENU] button on the Remote Controller or the DVR front panel to enter the MAIN MENU and select [SETUP]. -
Page 13: Configuration System Setup
Configuration System Setup CATEGORY DEFAULT ADJUSTMENT Change the OSD LANGUAGE. [Up, Down][Left, Right]: ENGLISH CHINESE KOREAN JAPANESE LANGUAGE ENGLISH [ENTER] : Apply new LANGUAGE. Set the ID(Identification no.) of DVR.(Limit : 0~255) [Left, Down] : Decrease number [Right, Up] : Increase number Select [ADMIN] and press [ENTER] to change the PASSWORD. -
Page 14: Camera Setup
Configuration CATEGORY DEFAULT ADJUSTMENT The date of the DVR Firmware Version will be indicated. All setting values will return to its’ initial FACTORY DEFAULT values. FACTORY [Up, Down][Left, Right]: Toggle between YES RESET [ENTER] : Apply/Not Apply the initial DEFAULT Values. Password input will be required. -
Page 15: Motion Detection
Configuration CATEGORY DEFAULT ADJUSTMENT Select the PTZ Driver. [Up, Down, Right, Left] : Select the PTZ Driver < Compatible PTZ DRIVER List > PTZ DRIVER NONE Pelco_D, Pelco_P, Panasonic, PT_A100L, DOME1, DOME2, HSDN_251N, WPT_101, SJ_2819, SK_2162D, DSC_230, GROOM_D106, CAZ1723, VC_C4, SCC_C4201, CRR1600T, SRX_100B, VVK_3000, ORX_1000, NK97CH, PIH717, PIH718, Vicon, Hangang, Gateway, E_DSO, Ateye, GRX_1000A, AD, JO308ACU, Sensormatic, Smartscan, Sungjin... -
Page 16: Recording Setup
Configuration Recording Setup CATEGORY DEFAULT ADJUSTMENT Set the recording resolution level. Even if QUAD recording is selected, only 1 channel will be recorded if the NTSC resolution is set at 720x480. Therefore, when 720x480 is set, designate which channel to be recorded. 352X240 4 channels can only be recorded if the resolution is set at 352x240. -
Page 17: Record Schedule
Configuration Record Schedule The recording time can be set according to Channels, Weekday, and Time. CATEGORY DEFAULT ADJUSTMENTS Select the WEEKDAY Scheduling. WEEKDAY [Up, Down] : Change WEEKDAY Set the Recording method. C : Continuous M : Motion D : Dual Mode (Motion + Sensor) S : Sensor SCHEDULE TABLE X : No recording... -
Page 18: Sensor Setup
Configuration Sensor Setup CATEGORY DEFAULT ADJUSTMENT Set the SENSOR Number. SENSOR [Left, Down] : Decrease Number [Right, Up] : Increase Number SENSOR Select the SENSOR TYPE TYPE [Up, Down, Left, Right] : Select NO or NC Select the CAMERA that is to be connected to the SENSOR CAMERA [Left, Down, Right, Up] : Move between channels LINK... -
Page 19: Network Setup
Configuration Network Setup CATEGORY DEFAULT ADJUSTMENT Set the DVR NAME. Use the Numeral/Letter/Symbol buttons or the [Up, Down] buttons to input the Name. NAME [Left, Right] : Move to previous, next space [Up, Down] : Select letter, number, symbol Select IP Type. TYPE FIXED [Up, Down][Left, Right]: Select AUTO... - Page 20 Configuration CATEGORY DEFAULT ADJUSTMENT Set the PPPOE ID for internet connection when using ADSL modems. [Up, Down] : Select letter, number, symbol. PPPOE ID [Left, Right] : Move to next space Numeral/Letter/Symbol keys can also be used to change the ID Limit: 16 characters(Combination of numbers and letters).
-
Page 21: Display Setup
Configuration Display Setup CATEGORY DEFAULT ADJUSTMENT OSD(On Screen Display) Designate which information to be shown on the monitoring screen. [Left, Up] : Move to upper information [Right, Down] : Move to lower information [ENTER] : Toggle to Apply/Disable Set the BORDER COLOR of screen BORDER [Left, Up] : Move to upper category. -
Page 22: Backup & Format
Configuration Backup & Format CATEGORY ADJUSTMENT Set the START-END TIME of a recorded video for Backup [Left, Right] : Move between Year/Month/Day/Time BACKUP [Up, Down] : Increase/Decrease number Number keys can also be used to change date & time Select the backup memory device. Move to START and press [ENTER]. -
Page 23: Operation
4. O PERATION Monitoring Monitoring Screen The video signals received by the CMDVR0402 can be viewed on Multi-Screens or the image can be viewed in the Pause and Zoom mode. Date, Time, Camera Number, Recording Status, HDD Capacity Usage are displayed on the screen. Information displayed on the screen(OSD) can be Changed by pressing the [OSD] button. -
Page 24: Sequence Display
Operation SEQUENCE DISPLAY Single screen sequence display is possible by pressing the [SEQUENCE] button. The Sequence Dwell Time can be set in the [SETUP] – [DISPLAY] menu. icon will appear on the screen during the sequence display mode. PTZ Control This is a mode to control Camera Direction/Focus/Zoom/Preset/Swing/Pattern/Group during the Monitoring Mode. -
Page 25: Search(Playback)
Operation SEARCH (Playback) You may search the recorded contents of the DVR by using the Time Search Mode. Enter the [SEARCH] menu and the following screen will appear. Select either “DVR” or “USB”(Highlighted with yellow stripe when selected) with the [Up, Down] buttons and press [ENTER]. - Page 26 Operation SEARCH PROCEDURE By selecting the [SEARCH] menu, information of the first file recorded on the current day will appear on the screen. And the search procedure will start from the “Day” indication field. 1) Select the Year and Month. On the calendar, days containing recorded data will be highlighted in yellow.
- Page 27 Operation Move to the relevant Day and the recording information for the corresponding Day will be indicated on the Hour/Channel indication table. Button Function Up, Down, Left, Move to the desired Day Right ENTER Move to the Hour/Channel indication table PREV : Move to “Year-Month”...
- Page 28 Operation 4) Select the relevant Time Range and press [Enter] button to play the recording. Button Function Up, Down Move from file to file(Time range) ENTER Start playback PREV : Move to Hour/Channel indication table PREV, NEXT NEXT : Move to “Year-Month” indicator FULL SCREEN DISPLAY The playback screen can be changed to the full screen mode by pressing the [FULL SCR] button.
-
Page 29: Usb Memory Search
Operation USB Search Data saved on a USB Memory Stick may be played back by following the USB Search procedure. Select the [SEARCH] menu and move to “USB” by using the [Up, Down] buttons. Then press the [ENTER] button to enter the USB Time Search Mode. SEARCH PROCEDURE The following display will appear on the screen. - Page 30 Operation ① SORT Selection of LOG types. Type Explanations POWER Power On/Off SENSOR Sensor Input RECORD Record Start/Stop CAMERA Camera Input Signal data NETWORK Network connections BACKUP Start Backup SETUP Setup Enter/Exit/Save CLOCK Date/Time adjustments ② LOG LIST List of SORT categories of the selected date. SEARCH PROCEDURE 1) Select the relevant “Year, Month”.
- Page 31 Operation 2) Select the desired Day. Move to the desired Day, then the corresponding log records of the selected Day will appear in the LOG List at the bottom of the screen Button Function Up, Down, Move to relevant Day Left, Right ENTER Move to LOG List...
-
Page 32: Video Clip Copy
Operation Button Function Select the SORT category. Up, Down (Select among ALL, POWER, SENSOR, RECORD, CAMERA, LAN, BACKUP, SETUP, TIME.) ENTER Move to LOG List(If log records exist for the selected date.) PREV : Move to Day indication field PREV, NEXT NEXT : Move to LOG List(If log records exist for the selected date.) 4) Event Playback Video recordings activated by Alarm Inputs are listed in the LOG List(SENSOR) and the... -
Page 33: Appendix : Technical Specification
Appendix Technical Specification Category Specification Operating System Embedded Proprietary OS Compression Algorithm MPEG4(VIDEO) , ADPCM(SOUND) Multi-Screen Display 1/4/Sequence Video Input 4 BNC Monitor Output 1 Composite Display Speed 120fps Recording Resolution 352x240, 720x480(NTSC), 352x288, 720x576(PAL) Recording Speed(CIF) Max 120fps(NTSC), Max 100fps(PAL) Recording Mode Continuous, Timelapse, Schedule, Event Audio...
