Nitto QA-4000 Instruction Manual

PORTABLE MAGNETIC DRILL
READ ALL INSTRUCTIONS BEFORE OPERATING THIS MACHINE TOOL
ATRA ACE
PROFESSIONAL TOOL
Model
Power Source (Single Phase)
Rated Power Consumption
Drill Motor Rated Ampere
No-load Speed
Magnet Power Consumption
Jetbroach One-touch Type
Hole
Capacity Hibroach One-touch Type
Magnet Holding Power
Magnet Dimensions
Weight
The specifications and design may be changed for improvement without prior notice. The specifications and design may be changed for improvement without prior notice. The specifications and design may be changed for improvement without prior notice.
Keep the manual handy - so you can use it whenever necessary.
Model QA-4000, QA-6500
For One-touch Type Annular Cutter Only
(Side Lock Type Annular Cutter Cannot Be Fitted)
QA-4000

Specifications

QA-4000
220-240V∼
680W
3A
750min (rpm)
-1
50W
φ 17.5 ∼φ 40mm
Plate thickness 35mm
φ 14・φ 15mm
Plate thickness 12mm
φ 16 ∼φ 18mm
Plate thickness 25mm
6664N (680kgf)
82mm × 172mm
18.5kg
Manufactured by:
NITTO KOHKI Co., Ltd.
2-9-4, Nakaikegami, Ohta-ku,
Tokyo 146-8555, Japan
TEL : (81)-3-3755-1111
FAX : (81)-3-3753-8791
E-mail : overseas@nitto-kohki.co.jp
URL : www.nitto-kohki.co.jp
QA-6500
QA-6500
220-240V∼
1010W
4.5A
400/750min (rpm)
-1
75W
φ 17.5 ∼φ 40mm
Plate thickness 35mm
φ 17.5 ∼φ 65mm
Plate thickness 50mm
φ 18 ∼φ 35mm
Plate thickness 25mm
9800N (1000kgf)
100mm × 200mm
26kg
