3M IP Camera Bullet
Quick Installation Guide
Thank you for purchasing this product!
Before you use this product, please check the package
contents. If any item is missing, contact your dealer of
purchase to claim for missing item(s).
Package Contents
Description
No.
1
Network IP Camera
2
DC power adapter
3
Sun Shield
4
Screw
5
Bracket
6
User manual CDROM
7
Quick installation guide
Q'ty
1
1
1
2
1
1
1
Advertisement
Table of Contents
Related Manuals for SMAX Technology SIU7117
Summary of Contents for SMAX Technology SIU7117
-
Page 1: Quick Installation Guide
3M IP Camera Bullet Quick Installation Guide Thank you for purchasing this product! Before you use this product, please check the package contents. If any item is missing, contact your dealer of purchase to claim for missing item(s). Package Contents Description Q’ty Network IP Camera... - Page 2 Familiar with the IP Camera [DI/DO Pin assignment] Description - : RS485- + : RS485+ 1 : DO 2 : GND 3 : DI DC12Volt/2A input Reset Button Audio output Audio input Network, RJ45 connector (support POE 802.3af) 2 LED indicator, orange: power, green: network TV output, BNC connector Please check the I/O cable attached index before insert or ※...
- Page 3 [Front site] Description IR-LED: Used for illumination assistance under night mode Day/night sensor: Used for day/night detection and IR-LED ON/OFF control Lens: Fixed focal length. Hardware verification 1. Connect Ethernet cable to LAN port. 2. Connect DC power cable to IP Camera’s DC power connector. 3.
- Page 4 Disassembly the case to insert SD card 1. Hereunder shows the sequence of bullet case disassembly. 2. It is recommended that release the case with a hexagonal socket, such as the socket spanner ① pictured above. Attach the socket spanner to the cable gland ②, and twist anti-clockwise to loosen it.
- Page 5 3. Please note the front side of the cable, which is covered with heat shrink tube, should be inserted in to the PVC tube cap completely. It is very important for weatherproof function working properly. Accessories’ assembly 1. Find the screws in the package, use screwdriver to fix the sun shield on the device’s main body.
- Page 6 Search the camera on the network This camera offers web UI management interface. Currently the viewing system required as below: ˙OS: Microsoft Windows XP / Vista / Win7 / Win8 ˙Browser: IE8 / IE9 / IE10 ˙Cell phone: 3GPP player ˙Quick Time: 7.0 or above 1.
- Page 7 Access camera’s Web UI and Install ActiveX Plugin 1. This IP camera is a DHCP client. It can get IP address from DHCP server automatically. 2. The default IP address is 192.168.1.99. Use IPFinder to search the camera and assign an IP address resided in the same sub-network of the managed computer.
- Page 8 6. If the window pop up this ‘Windows Firewall has blocked some features of this program’ Click ‘Allow access’, otherwise the UI image will not be able to function properly. 7. When Internet Explorer plugin is installed, you may also be prompted that ‘Do you want to allow changes to be made to your computer?’: Click ‘Yes’...
