Page 1
DRINKING WATER SYSTEM MODEL T.F.C.-300 INSTALLATION, OPERATION & SERVICE MANUAL IMPORTANT NOTICES: This reverse osmosis system contains replaceable treatment components critical for effective performance. It is the user's responsibility to, and the manufacturer strongly recommends that the user, periodically test the product water to verify the system is performing satisfactorily.
TAblE Of CONTENTS Page SECTION I. INTRODuCTION ................3 SECTION II. SPECIfICATIONS ................5 SECTION III. INSTAllATION STEPS ...............6 A. Faucet Installation ..................6 B. Feed Water Saddle Valve Installation ............8 C. Drain Clamp Installation ................8 D. R.O. Manifold Assembly Installation ............9 Position the Drinking Water Holding Tank and Make the Final Hose Connections .............
SECTION I. INTRODuCTION the incoming water (Feed Water) to produce the Your new Reverse Osmosis (R.O.) Drinking Water product water (the Permeate). The excess minerals System uses a combination of filtration technologies are rinsed to drain (the Reject Water). to reduce unwanted contaminants in a water supply. The membrane is specially constructed, fully The following steps combine to give you the best in aromatic polyamide film and is classified as a Thin...
Page 4
OPTIONAl T.f.C.–300 bASEMENT INSTAllATION DIAgRAM DISPENSINg FAUCET NOTE: FOR BEST FlOW RATE, KEEP TUBINg FROM R.O. MANIFOlD TO DISPENSINg FAUCET AS SHORT AS PRODUCT POSSIBlE (3/8” Blue) HOlDINg TANK SHUTOFF VAlVE (Open Position) FlOOR TANK (3/8” Yellow) NOTE: FOR BEST FlOW RATE, KEEP TUBINg FROM HOlDINg TANK TO R.O.
SECTION II. SPECIfICATIONS TAblE A – quAlIfIED SySTEM PERfORMANCE Because the performance of an R.O. Membrane is highly dependent upon pressure, temperature, pH and TDS, the following should be used for comparison purposes only. u.S. Metric Membrane Production 40-60 gpd 151-227 lpd Membrane TDS Reduction 93% minimum...
SECTION III. INSTAllATION STEPS 2c. Drilling a counter top: All plumbing should be done in accordance with state NOTE: The counter top must be less than 1¼" and local plumbing codes. thick. Treat ceramic tile as porcelain until the NOTE: Some codes may require installation by a tile is penetrated, then use the carbide tipped licensed plumber;...
Page 7
4. Place the Base Assembly through the mounting hole on the sink or counter top. Drop the handle of the Wrench through the Faucet Base opening. This will separate and orient the Toggle Wings. Position the Faucet Base so that the arrows are 6.
b. feed water Saddle Valve Installation 2b. To install on (hard) Steel or Brass Tubing supply line. Decide on location. Do NOT connect to a hot water feed line. If you are not sure of the supply, •The supply line should now be drained. Use a run the hot water and feel the supply piping.
3. locate the " Black Drain Tubing which is 3. locate the ¼" Black Drain Tubing attached attached to the faucet. to the faucet. Remove the black plug from the fitting labelled “Drain” on the manifold and NOTE: When cutting the polytubing make insert the tubing.
f. Start up 2. Installing the R.O. Membrane: At time of start up and each time the filters are •Remove the R.O. Membrane Housing, (the changed the system should be sanitized (also see middle one), and empty. Operation and Maintenance Sec. IV, B.1–4). •Insert the Membrane up into the manifold.
The more water that is used (up to the capacity •Use a good quality unscented 5¼% liquid of the system) the better the R.O. system will chlorine household bleach. function. Other uses for the water are flowers, •Add one capful of bleach (this is 2 tsp. or 10 pets and rinsing glassware.
SECTION V. TROublE ShOOTINg guIDE Problem Possible Cause Solution low quantity of Product water Feed Water Saddle Valve is plugged or Open Valve or unclog. from holding Tank closed. Clogged Sediment/Carbon Prefilter or Replace filters. Activated Carbon Post Filter. low water pressure Feed Water pressure must be above 40 psig.
Page 13
Problem Possible Cause Solution high Total Dissolved Solids (TDS) The Product Water and Drain Water Correct plumbing. in the Product water lines are reversed. (continued) No drain flow, Drain Restrictor is Clear or replace Drain Restrictor. clogged. No drain flow, the drain orifice in Clear or replace Dispensing Faucet.
EXPlODED VIEw & PARTS lIST ���� �� ���� MADE IN USA...
Page 15
DRAwINg NO. PART NO. DESCRIPTION 1...... S2009 ........Self Tapping Screw 2...... S2005-01 ........ ASO Cap 3...... S2013 ........ASO Cap O–Ring 4...... S2011 ........ASO Diaphragm – large 5...... S2007-01 ........ ASO Piston 6...... S2006-01 ........ ASO Piston Ring 7......
Page 16
R.O. DRINkINg wATER SySTEM FIVE/ONE YEAR lIMITED WARRANTY What Does This Warranty Cover? This warranty covers any defects in materials and workmanship of the R.O. Drinking Water System when installed and operated within recommended parameters, with the exceptions stated below. How Long Does The Coverage Last? The manufacturer will warrant its R.O.
