INSTALLATION, OPERATION & SERVICE MANUAL
IMPORTANT NOTICES:
This reverse osmosis system contains replaceable treatment components critical for effective performance. It is the user's responsibility to, and
the manufacturer strongly recommends that the user, periodically test the product water to verify the system is performing satisfactorily. See the
test kit(s) for sampling instructions.
This system is acceptable for treatment of influent concentrations of no more than 27 mg/L nitrate and 3 mg/L nitrite in combination measured
as N and is certified for nitrate/nitrite reduction only for water supplies with a pressure of 280 kPa (40 psig) or greater.
This system conforms to NSF/ANSI 58 for pentavalent arsenic reduction. See Performance Data Sheet and Arsenic Facts section for an
explanation of reduction performance.
DO NOT USE WITH WATER THAT IS MICROBIOLOGICALLY UNSAFE OR OF UNKNOWN QUALITY, WITHOUT
ADEQUATE DISINFECTION BEFORE OR AFTER THE SYSTEM. Systems certified for cyst reduction may be used on disinfected
water that may contain filterable cysts.
M I C R O L I N E
DRINKING WATER SYSTEM
.
MODEL T.F.C. - 435
Tested and Certified by NSF International against
NSF/ANSI Standard 58 for the reduction of the
claims specified on the Performance Data Sheet.
Drink With Confidence!
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T.F.C. - 435 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Microline T.F.C. - 435

Summary of Contents for Microline T.F.C. - 435

  • Page 1 ® M I C R O L I N E DRINKING WATER SYSTEM MODEL T.F.C. - 435 INSTALLATION, OPERATION & SERVICE MANUAL Tested and Certified by NSF International against NSF/ANSI Standard 58 for the reduction of the claims specified on the Performance Data Sheet.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Page SECTION I. INTRODUCTION ................... 3 SECTION II. SPECIFICATIONS ..................5 SECTION III. PREPARATION ....................6 A. Major System Components ............... 6 B. Tools Recommended for Installation ............6 C. Site Selection For Major System Components ......... 6 SECTION IV.

  • Page 3: Section I. Introduction

    SECTION I. INTRODUCTION aromatic polyamide film and is classified as a Thin Your new Reverse Osmosis (R.O.) Drinking Water Film Composite (T.F.C.). System uses a combination of filtration technologies The spiral wound construction of the R.O. to reduce unwanted contaminants in a water supply. Membrane provides maximum surface area for The following steps combine to give you the best in water production and is less susceptible to fouling...
  • Page 4 OPTIONAL T.F.C.–435 BASEMENT INSTALLATION DIAGRAM DISPENSING FAUCET DISPENSING DISPENSING FAUCET FAUCET NOTE: FOR REFRIGERATOR WATER DISPENSER OR ICE MAKER HOOKUP, TEE INTO NOTE: FOR REFRIDGERATOR 3/8" BLUE TUBING TO NOTE: FOR BEST FLOW RA PRODUCT WATER DISPENSER OR ICE DISPENSING FAUCET (3/8"...

  • Page 5: Section Ii. Specifications

    the system cover for instant monitoring at the the Water Quality Monitor was designed to touch of a button. The monitor compares the level operate best while the system is making water, of the total dissolved solids in the incoming (feed) a false reading may occur if tested when your water versus the product water and calculates R.O.

  • Page 6: Section Iii. Preparation

    SECTION III. PREPARATION " metal drill bit. 10. Phillips head and flat blade screwdrivers. A. Major System Components 11. ½", " and " open end wrenches. The following components comprise the R.O. 12. 10" Crescent wrench with jaws taped to hold Drinking Water System.

  • Page 7: Section Iv. Installation Steps

    a high pressure drop. Remember, these tanks body and should be mounted so that the “CL” line can weigh up to 30 pounds when full of water; is at least one (1) inch (26mm) above the flood a firm, level area is required. level rim of the sink.

  • Page 8: Feed Water Saddle Valve Installation

    LONG REACH AIR GAP FAUCET FEED WATER SADDLE VALVE WITH 3/8" CONNECTOR Cold Water Line Saddle Reversible Back Plate Spout Valve Plastic Shipping Handle Plug (Remove) Air Gap Window Tightening Screw Critical Level 7/16" Stud Line Insert Reject Outlet For Drain Clamp Line Reject Inlet For Manifold Drain Line...

  • Page 9: Drain Clamp Installation

    •Drill a " hole in the supply line; (do not drill a " hole through the wall of the drain drill through the opposite wall). pipe. Do NOT penetrate the opposite side of the pipe. •Turn the handle to expose the lance no more than "...

  • Page 10: Manifold Assembly Installation

    D. R.O. Manifold Assembly Installation and insert the tubing. Locate the site per Sec. III, C.3, page 7. Various 5. Locate the " Blue Product Water Tubing. installation sites will require different types of Firmly press one end into the tee and the other mounting fasteners;...

  • Page 11: Start Up

    F. Start Up In–Out ports), empty, and install the Activated Carbon Post Filter. Firmly tighten At time of start up and each time the filters are the Housing hand tight only. changed the system should be sanitized (also see Operation and Maintenance Sec. V, B.1–4, page 2.

  • Page 12: Changing Filters

    operation is to let the Holding Tank fill with 3. Wash the inside of the Housings using a mild water and then draw water as needed. When detergent and a soft cloth. Do not use abrasive the pressure in the Holding Tank falls to a cleaners or pads.

  • Page 13: Changing The In-Line Activated Carbon Post Filter

    Dispensing Faucet, in the following order, close the Faucet and then open the Holding Tank Valve. •Do not open the Faucet for at least 8 hours. •Discard the first three full tanks of water produced, they will contain chlorine. C. Changing the In–Line Activated Carbon Post Filter 1.

  • Page 14: Section Vi. Trouble Shooting Guide

    SECTION VI. TROUBLE SHOOTING GUIDE Problem Possible Cause Solution Low quantity of Product Water Feed Water Saddle Valve is plugged or Open Valve or unclog. from Holding Tank closed. Clogged Sediment/Carbon Prefilter or Replace filters. Activated Carbon Post Filter. Low water pressure. Feed Water pressure must be above 40 psig.
  • Page 15 Problem Possible Cause Solution The Product Water and Drain Water Correct plumbing. High Total Dissolved Solids (TDS) lines are reversed. in the Product Water No drain flow, Drain Restrictor is Clear or replace Drain Restrictor. (continued) clogged. No drain flow, the drain orifice in Clear or replace Air Gap Faucet..

  • Page 16: Exploded View And Parts List

    EXPLODED VIEW & PARTS LIST 19A ..Water Quality Test Kit 23 ..Nitrate/Nitrite Test Kit ���� �� ���� MADE IN USA...
  • Page 17 IN–LINE ACTIVATED CARBON POST FILTER DRAWING NO. PART NO. DESCRIPTION 1...... S2009 ........Self Tapping Screw 2...... S2005 ........ASO Cap 3...... S2013 ........ASO Cap O–Ring 4...... S2011 ........ASO Diaphragm – Large 5...... S2007 ........ASO Piston 6...... S2006 ........
  • Page 18 NOTES:...
  • Page 19 NOTES:...
  • Page 20 This warranty does not cover the disposable sediment and carbon filters whose service life depends on feed water conditions. In addition, the membrane is only warranted if the required feed water conditions are met. The above warranty will also not apply to any part of the Microline R.O. Drinking Water System that is dam- ®...
