QUICK START GUIDE
Model: SS2520-C6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SS2520-C6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VISIO SS2520-C6

Summary of Contents for VISIO SS2520-C6

  • Page 1 VIZIO QUICK START GUIDE Model: SS2520-C6...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Your Unit is designed and manufactured to operate within defined design limits, and misuse may result in electric shock or fire. To prevent function abnormally. Unplug the power cord immediately and contact your dealer for repair. Continued use of your Unit may cause your Unit from being damaged, the following rules should be observed for its installation, use, and maintenance.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Package Contents ..............4 Controls & Connections ............5 First-Time Setup..............8 Using the Remote ..............14 LED Indicators ................. 15 Bluetooth Pairing ..............16 Using Bluetooth mode ............17 Advanced Setup ..............18 Using Button Combinations ..........19 Connecting a Subwoofer ............

  • Page 4: Package Contents

    PACKAGE CONTENTS 2.1 Sound Stand Remote Control with 2 x Quick Start Guides Stereo RCA to 3.5mm Digital Optical Audio Cable Cable 2 x AAA Batteries (1 English, 1 French/Spanish) Power Cable Coaxial Audio Cable...

  • Page 5: Controls & Connections

    CONTROLS & CONNECTIONS Front of Sound Stand LED Indicators 12 LED indicators will give visual feedback when you press buttons on the remote control.
  • Page 6 Back of Sound Stand Power Port SUB Out Subwoofer Out DIGITAL (3) AUX (1) Coaxial In Analog Audio In OPTICAL (4) Service*/USB Port Digital Optical Audio In Service Port/USB In AUX (2) Analog Audio In...
  • Page 7 Side of Sound Stand Power Input Bluetooth Input (Hold to force pair, See Bluetooth Pairing for more information) Volume + / -...

  • Page 8: First-Time Setup

    FIRST-TIME SETUP Important: The Sound Stand is designed to hold TVs up to 55” in size with a weight of up to 60lbs. The TV base should not be larger than 12.5” by 14”. Place the Sound Stand on a flat, stable level surface. VIZIO recommends that you first place your TV alongside the Sound Stand so that the connection ports are easy to access.
  • Page 9 Back of Sound Stand GOOD GOOD BETTER BETTER 3.5MM TO 3.5MM TO DIGITAL OPTICAL DIGITAL COAXIAL RCA CABLE RCA CABLE CABLE* CABLE* CHOOSE ONE CABLE: GOOD BETTER AND CONNECT IT TO YOUR TV Note: Not all TVs have the audio outputs shown above. To connect the Sound Stand directly to your * When using either of the Digital Inputs, if there is no audio: (A) try setting the TV output to PCM or (B) other devices (Blu-ray player, game system, etc) see your device’s user manual.
  • Page 10 Connect the power cable to the Sound Stand. Plug the power cable into a power outlet. Back of Sound Stand...
  • Page 11 Center your TV on top of the Sound Stand. If your TV has seperate stands like the one shown above, be sure the TV does not come into contact Be sure that your TV’s base fits completely on top of with the top of the Sound Stand.
  • Page 12 Remove the battery cover by gently sliding Insert the included batteries and gently it away from the remote. slide the battery cover back into place.
  • Page 13 Turn your TV on, the Sound Stand will automatically turn on and begin searching for an active input. The LED indicators on the front of the Sound Stand will begin cycling in pairs through inputs until an audio source is detected.* Tip: Pressing the INPUT button will stop the auto detect function.

  • Page 14: Using The Remote

    USING THE REMOTE Bluetooth Press to enter Bluetooth input. (To enter force pair mode, press and hold for 5 seconds) Input Press to change input source. Power (Press and hold for 5 seconds to enable auto input detection function) Press to turn on or off. Play/Pause Volume +/- Press to select an option.

  • Page 15: Led Indicators

    LED INDICATORS LED Indicators are located here. The LED Indicators give visual feedback when you press buttons on the remote control. Function LED Behavior Description Analog Audio In - AUX (1) Press the INPUT button on the remote to cycle through each available input: Analog Audio In - AUX (2) •...

  • Page 16: Bluetooth Pairing

    BLUETOOTH PAIRING To pair the Sound Stand with a Bluetooth device: Press and hold the Bluetooth button on the Sound Stand or the Bluetooth button on the remote for five (5) seconds. When the Sound Stand is in Bluetooth Pairing Mode, the LED Indicators on the Display Panel on the front of the Sound Stand will light sequentially from left to right and back again.

  • Page 17: Using Bluetooth Mode

    USING BLUETOOTH MODE Maximizing Signal Your Sound Stand supports music streaming from smartphones, tablets, and computers with Bluetooth A Bluetooth signal has a range of up to 30 feet. Keep capability. Device compatibility will vary, see your in mind that Bluetooth is a compressed audio format, device’s documentation for more information.

  • Page 18: Advanced Setup

    ADVANCED SETUP Connect up to five (5) different devices to the Sound Stand (devices shown are examples you can use any device). Back of Sound Stand To listen to a device, change the input source on the Sound Stand. Optical, Coaxial, and 3.5mm cables transmit audio only.

  • Page 19: Using Button Combinations

    USING BUTTON COMBINATIONS There are 3 functions that are triggered by 3 different button combinations on the Sound Stand. Function LED Behavior Description Reset the Sound Stand to the factory default settings. To perform a Factory Reset, Press and Factory All 12 LEDs will flash 3 times: Hold the Bluetooth(...

  • Page 20: Connecting A Subwoofer

    CONNECTING A SUBWOOFER To connect a subwoofer: RCA Subwoofer Cable* Press the BASS button on the remote control to enter bass adjustment mode. Optional Subwoofer* Use the Previous/Next buttons to adjust the bass level to the center position. Power Off the Sound Stand and Subwoofer. Connect an RCA cable from the Sound Bar to the Subwoofer.
  • Page 21 VIZIO RECOMMENDS Simply Beautiful! Introducing the all-new VIZIO P-Series Ultra HD Full-Array LED Smart TV. With four times the detail of 1080p Full HD and best-in-class picture quality of Full-Array LED, 64 Active LED Zones™, and Clear Action 960, the P-Series is your crystal-clear window to an exhilarating world where picture is everything.
  • Page 22 VIZIO RECOMMENDS The all-new 2015 E-Series Full-Array LED Smart TV has arrived. Featuring a new modern design, brilliant picture quality, and faster, easier-to-use smart TV experience, VIZIO’s 2015 E-Series brings you premium HD entertainment at an incredible value. Full-Array LED backlighting and 5 Active LED Zones produce ™...
  • Page 23 Take A Moment To Register Your Product At VIZIO.COM/PRODUCT-REGISTRATION Why Register? Customized Support Get assistance quickly with your information on-hand. News & Offers Take advantage of the latest news and special offers from VIZIO. Safety & Satisfaction Stay up to date with important product updates and notifications. REGISTER YOUR VIZIO PRODUCT NOW...
  • Page 24 Do You Have Questions? Find Answers At SUPPORT.VIZIO.COM Find help with: • New Product Setup • Connecting Your Devices • Technical Problems • Product Updates • And More Live Chat Support Available You can also contact our award-winning support team at: Phone: (877) 878-4946 (TOLL-FREE) techsupport@VIZIO.com...

  • Page 25: Help & Troubleshooting

    HELP & TROUBLESHOOTING • Press the POWER button on the remote control or on the top of your Sound Stand. There is no power. • Ensure the power cord is securely connected. • Plug a different device into the electrical outlet to verify that the outlet is working correctly. •...

  • Page 26: One-Year Limited Warranty

    ONE-YEAR LIMITED WARRANTY ON PARTS AND LABOR Covers units purchased as new in United States and Puerto Rico Only VIZIO provides a warranty to the original purchaser of a new Product against defects in materials and workmanship for a period of one year of non-commercial usage and ninety (90) days of commercial use.

  • Page 27: Legal & Compliance

    LEGAL & COMPLIANCE FCC Class B Radio Interference Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 28 © 2015 VIZIO INC. ALL RIGHTS RESERVED. 150210OC-US-NC...
