- Page 1 Owner’s Manual and Service Guide C-Series: AC48-2-AC-UB-L-D and AC48-2-AC-UB-S-D February 2015...
-
Page 2: Table Of Contents
Table of Contents Introduction Vehicle Specifications Important Labels Operation System Operational Process Rules for Safe Operation Maintenance Storage Troubleshooting... -
Page 3: Introduction
Introduction Thanks for purchasing a STAR EV C-Series. For your better use, please read through this manual before operate the C-Series to avoid any possible damage due to improper operation, and keep it after reading for future reference. Important Information: Important information is showed in following way in this manual to arouse your attention:... -
Page 4: Vehicle Specifications
Vehicle Specifications Passengers C-Series Standard C-Series Long Battery group 8 x 6V, Trojan T105 8 x 6V, Trojan T105 Motor 7 HP 7 HP Controller Power (amps) 450 Amp, AC Curtis 450 Amp, AC Curtis Maximum speed (mph) 19.5 (20-25 LSV) 19.5 (20-25 LSV) Cargo capacity (lbs) 1100... -
Page 5: Important Labels
Important Labels Please read the following labels carefully before operating the vehicle, and promptly replace any labels which become unreadable or removed. “Security Warning” label under the dashboard: WARNING “Warning” label under the dashboard: “Warning” label besides the parking-brake handle:... -
Page 6: Operation System
Operation System Schematic Figure of Operation System Turn Signal Switch Functions of Operating System Controls the power supply of the whole vehicle. When the key is inserted and turned clockwise, it will switch on lights, horn and the control system; when the key is turned back, the power will be switched off. Power Key:... - Page 7 Controls the speed. It should be depressed slowly. The vehicle speeds up with the gradual depressing, and reaches full speed when the pedal is stepped down completely. The vehicle slows down when the Acceleration Pedal: pedal being released gradually. When the pedal is fully released, electric brake works. Decelerates and stops the vehicle.
-
Page 8: Operational Process
Operational Process Starting the vehicle Select F for Forward or R for Reverse from F&R Switch. • Switch on Power Key. • Release the Parking Brake lever. • Step down on the Acceleration Pedal smoothly. • WARNING If you switch on Power Key first before selecting Forward or Reverse on F&R switch, the vehicle will not run. - Page 9 Charging the batteries CAUTION There are two different kinds of charger for you to choose: an exterior charger and a built in (on-board) charger. Before you use the charger, please read the charger operation manual. • Explosive hydrogen gas is produced while the batteries are charged. Only charge in well-ventilated areas. •...
- Page 10 o Turn off the charger(s) when the batteries are fully charged, and disconnect the charger(s) with AC power.
-
Page 11: Rules For Safe Operation
Rules for Safe Operation The driver should have a good knowledge of the operation system of the vehicle and its features. Follow the rules for safe operation. WARNING Drive the vehicle off road unless it is a street legal vehicle (NEV/LSV). •... -
Page 12: Maintenance
Maintenance Users should perform regular maintenance as follows. Battery Maintenance WARNING Battery electrolyte is poisonous and dangerous, and may cause severe burns, injury, etc. Always wear protective clothing, gloves, and goggles when handling batteries, electrolyte, and charging your battery. KEEP IT OUT OF REACH OF CHILDREN. Cleaning The exterior of the battery, connection wires and bolts should always be kept clean and dry. - Page 13 Foreign matter Do not place any objects on the battery and do not connect the positive pole to the negative pole. This may cause a short circuit, dangerous sparking or damage to the battery or injury to your body. Recharging As long as you use the vehicle, regardless of how long you have used it, the battery should be recharged fully on the same day.
- Page 14 Watering Flooded batteries need water. More importantly, watering must be done at the right time and in the right amount or else the battery's performance and longevity suffers. Water should always be added after fully charging the battery. Prior to charging, there should be enough water to cover the plates. If the battery has been discharged partially or fully, the water level should also be above the plates.
- Page 15 Testing Visual inspection alone is not sufficient to determine the overall health of the battery. Both open-circuit voltage and specific gravity readings can give a good indication of the battery's charge level, age, and health. Routine voltage and gravity checks will not only show the state of charge but also help spot signs of improper pro, such as undercharging and over-watering, and possibly even locate a bad or weak battery.
- Page 16 If any specific gravity reading still registers lower than the factory specification of 1.277+/- .007 then one or more of the following conditions may exist: 1. The battery is old and approaching the end of its life. 2. The battery was left in a state of discharge too long. 3.
- Page 17 State of charge as related to specific gravity and open circuit voltage Open-Circuit Voltage Specific Gravity Percentage of Corrected to Charge 80˚ F 1.277 6.37 8.49 12.73 25.46 38.20 50.93 1.258 6.31 8.41 12.62 25.24 37.85 50.47 1.238 6.25 8.33 12.50 25.00 37.49...
- Page 18 2. The friction plate should be changed periodically; the friction value on one side should not exceed 2 mm. 3. Adjust the flatness of the platen spring plate (feeling manually): first tighten the screws diagonally, use your hand to check the flatness of the spring plate. If not flat, tighten the screws for the non-flat part. 4.
- Page 19 colors and become broken. brush and commutators is too big; the mica between different commutators extrudes; the brush is made by wrong materials; the brush is wrong in type. Sparking. The motor is over-loaded; the commutators are not clean, not round or not smooth; mica or some commutators extrude;...
- Page 20 Check if the turn signal switch can be switched on and off properly. Check if all the connections between the motor, the battery, and the controller are in good condition. • • Please use the following cleaning procedure for routine maintenance: Turn the power key to OFF position.
- Page 21 Lubrication Notes To avoid any damage on the brake shoe, handbrake should be released before staring the vehicle. The lubricant for rear power assembly must be applied and changed as per user’s manual. • The brake system must be adjusted once every 3 months. •...
- Page 22 6. Check if the battery is charged fully by 3 ways: a) using the hydrometer; b) checking the battery power meter; 7. Clean the surface of battery Charger 8. Observe the charging status, check if the charger plug becomes hot.
- Page 23 22. Check if there is oil leaking on the gear box and the rear end. 23. Add the lubricant inside the wheel hub, steering system. 24. Adjust the toe-in of the front end. 25. Clean the body and seat. ...
-
Page 24: Storage
Storage Please follow the steps as below when the vehicle is stored. 1. Check the liquid level inside the battery; recharge it fully before storing the vehicle. WARNING: Charge the battery once a month if your vehicle will be stored more than one month. 2. -
Page 25: Troubleshooting
Trouble Shooting There is no settled mode to diagnose and eliminate the malfunction of electric shuttle buss. During maintaining and checking, we suggest you first listen, then look and feel. Below is the diagnoses and maintenance of some common malfunctions. 1. - Page 26 it starts Controller failure Repair, change Accelerator Failure Repair, change Controller Failure Check, change Normal at low speed, Motor Failure Check, change Weak power at high speed Accelerator Failure Check, change 3. Vehicle cannot change direction, only runs in one direction Vehicle can only run in F&R switch failure Change...
- Page 27 positions Gear inside transmission case wear Change Orientation pin loosen Change Check the pressure Pressure of front tire is deficient. and Inflate Screw plug of Redirector is too tight Adjust Lack of lube in redirector Maintain, add lube Toe-in abnormal Adjust Steering heavy Clearance of tension rod ball is too...
- Page 28 Brake of one wheel is too tight Adjust or Change Spring shock absorber is abnormal Change Front suspension loose Change Tire pressure is abnormal or tires Inflate or rotate need to be rotated Toe-in is improper Adjust Drum bearing loose Change U type Bolt of Leaf Spring loose Tighten...
- Page 29 Tire pressure is different Repair or Change One wheel cylinder’s piston blocks Adjust Wheel alignment improperly Adjust Brake drum becomes out of round Change Brake pedal has no free travel Adjust Clearance between brake shoe and drum is too small or releasing spring Adjust or Change is disable.
