LZ600RG Red & Green Laser Burst User Manual
Thanks for purchasing
Please read this manual carefully and thoroughly, as it gives important information regarding safety
and operation instruction. Keep this manual in order to consult it in the future.
The quality of every set of the products is guaranteed in the factory before the shipment. Please
check the accessories as the packing list inside. If the carton appears to be damaged, please inspect
the fixture carefully. In case damage has been found or some parts are missing, please contact our
after service department before shipping back the product.
Safety Information：
1. Always ground the fixture electrically properly.
2. For indoor use only. Keep in cool and dry place with the ambient temperature of 10-35℃. Put the
fixture in steady place and do not shake.
3. Continuous operation of over 4 hours will shorten the life of the laser. Please always keep within
4 hours.
4. The lens at the aperture will be covered with dirt and dust that will decrease the power output.
Please clean it with the soft cloths or paper periodically.
5. Do not attempt to tear off the warranty paper. Such action will avoid the company's warranty.
6. Do not attempt to dismantle the fixture if problems happen. Please connect with our after service
department directly.
7. Do not throw away the packing material. If problems happen, please pack the product with the
material and send back to Neo-Laser after service department
Fuse Replacement
Note: Replace the fuse with the same specified. If not, the potential damage will be avoided of the
company's responsibility.
Replace the fuse：Disconnect the power, use the screwdriver to unscrew the fuse holder, take out
the fuse, place it with the good one of the same specified and finally screw the fuse tight.
LZ600RG Red & Green Laser Burst
.
1
