- Page 1 Professional Lighting Technology DMX Strobe ST7500DMX User Guide Please read these instructions carefully before use...
- Page 2 1. Introduction Congratulations on the purchase of your new strobe light. We are confident you will enjoy many trouble free hours with this unit. To assist with the care and use of the TABLE OF CONTENTS product we have prepared this short guide. 1.
- Page 3 Installation 5. Remote controller input: By connecting to the 1/4 “microphone jack to control The unit should be mounted via its screw holes on the bracket. Always ensure the unit for Stand by, Function and Mode. that the unit is firmly fixed to avoid vibration and slipping while operating. Make 6.
- Page 4 Chase pattern in 4-light show mode: 4. Take out the old lamp and Pattern 1 1234 Full on replace the new one to the Pattern 2 1-2-3-4 ― 4-3-2-1 fixture. Pattern 3 1-2-3-4-4-3-2-1 Pattern 4 12-34 ― 23-14 Pattern 5 1-12-123-1234-123-12-1-stop ―...
- Page 5 DMX512 Address Chart 8. DMX512 Connection Value Option • Examples: Channel 1 : dip / on : #1 ( =1 ) Channel 3 : dip / on : #1, #2 ( 1 + 2 = 3) Channel 5 : dip / on : #1, #3 ( 1 + 4 = 5 ) Channel 7 : dip / on : #1, #2, #3 ( 1 + 2 + 4 = 7 ) The DMX512 is widely used in intelligent lighting control, with a maximum of 512 7.
- Page 6 9. Troubleshooting • If the unit is not functioning well – check main power supply is ‘on’ and check fuses. • If the unit is functioning but lamp does not light - may require replacing lamp. • If the unit is not moving to the music, check the sound-activation adjustment (when applicable) •...
