Industrial Electronic Devices
User Manual
Revision 2.011
English
PROFIBUS Master / Ethernet - Converter
(Order Code: HD67575-A1)
for Website information:
http://www.adfweb.com/?Product=HD67575
for Price information:
http://www.adfweb.com/?Price=HD67575-A1
Benefits and Main Features:
Very easy to configure
PROFIBUS up to 6Mbps
Free software for interfacing to the device
Commands available for develop your own
program
Temperature range:
-40°C / 85°C (-40°F / 185°F)
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual PROFIBUS Master / Ethernet
Document code: MN67575_ENG
For others PROFIBUS devices, see also the following links:
PROFIBUS Master from/to ...
www.adfweb.com?Product=HD67570
www.adfweb.com?Product=HD67577
www.adfweb.com?Product=HD67579
www.adfweb.com?Product=HD67580
www.adfweb.com?Product=HD67593
www.adfweb.com?Product=HD67604
PROFIBUS Slave from/to ...
www.adfweb.com?Product=HD67045
www.adfweb.com?Product=HD67053
www.adfweb.com?Product=HD67252
www.adfweb.com?Product=HD67551
www.adfweb.com?Product=HD67552
www.adfweb.com?Product=HD67553
www.adfweb.com?Product=HD67555
www.adfweb.com?Product=HD67561
www.adfweb.com?Product=HD67562
www.adfweb.com?Product=HD67563
www.adfweb.com?Product=HD67564
www.adfweb.com?Product=HD67565
www.adfweb.com?Product=HD67574
www.adfweb.com?Product=HD67576
Do you need to choose a device? do you want help?
Ask it to the following link:
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
Revision 2.011
Page 1 of 34
(... DeviceNet Slave)
(... CAN)
(... Modbus TCP Slave)
(... Modbus Slave)
(... EtherNet/IP)
(... PROFINET)
(... Serial)
(... M-Bus Master)
(... NMEA 2000)
(... CANopen)
(... CAN)
(... J1939)
(... DeviceNet Master)
(... Modbus Master)
(... Modbus Slave)
(... Ethernet Server)
(... Modbus TCP Client)
(... Modbus TCP Server)
(... DeviceNet Slave)
(... Ethernet Server)
Phone +39.0438.30.91.31
Advertisement
Table of Contents
Related Manuals for ADF Wed HD67575-A1
Summary of Contents for ADF Wed HD67575-A1
-
Page 1: User Manual
Page 1 of 34 Industrial Electronic Devices User Manual Revision 2.011 English PROFIBUS Master / Ethernet - Converter (Order Code: HD67575-A1) for Website information: http://www.adfweb.com/?Product=HD67575 For others PROFIBUS devices, see also the following links: for Price information: http://www.adfweb.com/?Price=HD67575-A1 PROFIBUS Master from/to …... -
Page 2: Table Of Contents
User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 2 of 34 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated;... -
Page 3: Security Alert
User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 3 of 34 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for each individual application, legal and safety regulation. -
Page 4: Example Of Connection
User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 4 of 34 Industrial Electronic Devices EXAMPLE OF CONNECTION: Used in pair with the HD67576-A1, allows to make a tunneling over Ethernet. In both cases you can also connect them to Internet. ADFweb.com Srl –... -
Page 5: Connection Scheme
User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 5 of 34 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD67575-A1 with c.s.: B153 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... - Page 6 User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 6 of 34 Industrial Electronic Devices Figure 1b: Connection scheme for HD67575-A1 with c.s.: B150 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
-
Page 7: Characteristics
User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 7 of 34 Industrial Electronic Devices CHARACTERISTICS: The configurable “PROFIBUS Master / Ethernet” converter allows the following characteristics: TCP/IP and UDP protocol at Ethernet side; Triple isolation between Ethernet /PROFIBUS, Ethernet /Power Supply, PROFIBUS/Power Supply. Mountable on 35mm Rail DIN;... -
Page 8: Power Supply
POWER SUPPLY: The device can be powered between a wide range of tensions. For more details see the two tables below. Vmin Vmax Vmin Vmax HD67575-A1 Consumption at 24V DC: Device W/VA HD67575-A1 Caution: Not reverse the polarity power HD67575-A1 ADFweb.com Srl –... -
Page 9: Function Modes
Revision 2.011 Page 9 of 34 Industrial Electronic Devices FUNCTION MODES: HD67575-A1 . B153 WITH C The device has got two functions mode depending of the position of the Dip2 of ‘Dip-Switch A’: The first, with Dip2 in Off position (factory setting), is used for the normal working of the device. -
Page 10: Leds
Industrial Electronic Devices LEDS: The device has got five LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. HD67575-A1 . B153 WITH C Normal Mode Boot Mode... - Page 11 User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 11 of 34 Industrial Electronic Devices HD67575-A1 . B150 WITH C Normal Mode Boot Mode Blinks quickly: Boot state 1: Ethernet comm (green) Blinks quickly when receive Ethernet commands Blinks very slowly (~0.5Hz): update in progress...
-
Page 12: Profibus
ETHERNET: The Ethernet connection must be made using Connector2 of HD67575-A1 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended the use of a cross cable. -
Page 13: Use Of Compositor Sw67575
User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 13 of 34 Industrial Electronic Devices USE OF COMPOSITOR SW67575: To configure the Converter, use the available software that runs with Windows, called SW67575. downloadable site www.adfweb.com and its operation is described in this document. (This manual is referenced to the last version of the software present on our web site). -
Page 14: Set Communication
In the field “Port” insert the number of the port; In the field “COMPANION BOARD IP ADDRESS” insert the IP address of the Ethernet Client device that communicates with the HD67575-A1; In the field “COMPANION Port” insert the number of the port of the Ethernet Client device that communicates with the HD67575-A1. -
Page 15: Profibus Network
User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 15 of 34 Industrial Electronic Devices PROFIBUS NETWORK: By pressing the “PROFIBUS Network” button from the main window for SW67575 (Fig. 2) the window “PROFIBUS Network” (Fig. 4) appears. -
Page 16: Master Profibus Options
User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 16 of 34 Industrial Electronic Devices MASTER PROFIBUS OPTIONS: By pressing the “Master PROFIBUS Options” button from the “PROFIBUS Network” window (Fig. 4) the “PROFIBUS Master Options” window appears (Fig. 5). In this window is possible to set the WatchDog Time for the PROFIBUS Slaves. -
Page 17: Profibus Device
User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 17 of 34 Industrial Electronic Devices PROFIBUS DEVICE: By pressing the “Add Slave PROFIBUS” and “Modify Slave PROFIBUS” button (or double click above an existent PROFIBUS Slave) from the “PROFIBUS Network”... -
Page 18: M Odule S Election
User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 18 of 34 Industrial Electronic Devices ODULE ELECTION The section “Module Selection” is used to select which Modules are present in the Slave (Fig. 7). In this section is possible to: Check the list of the Modules selected (“Select Modules”) (Fig. - Page 19 User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 19 of 34 Industrial Electronic Devices By pressing the “Manual Module” button from the “PROFIBUS Device” window (Fig. 6) the “Add Module Manually” window appears (Fig. 8). In this window is possible to add a Module manually, i.e. writing the configuration of the module (in hexadecimal). The means of the fields are: In the field “Description of...
-
Page 20: U Ser P Arameters
User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 20 of 34 Industrial Electronic Devices ARAMETERS The section “User Parameters” is used to modify the parameters of the PROFIBUS slave (Fig. 9). In this section there are: The List of all Parameters available for the PROFIBUS device (“User Parameters”) (Fig. - Page 21 User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 21 of 34 Industrial Electronic Devices By pressing the “Modify User Parameters Manually” button from the “PROFIBUS Device” window (Fig. 6) the “Add Module Manually” window appears (Fig. 10). In this window is possible to add/modify the User and/or Modules Parameters manually, i.e.
-
Page 22: M Odule P Arameters
User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 22 of 34 Industrial Electronic Devices ODULE ARAMETERS The section “Module Parameters” is used to modify the parameters of the Modules (Fig. 11). In this section there are: The List of all Module selected in the GSD file (“Available modules”) (Fig. -
Page 23: C Apabilities
User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 23 of 34 Industrial Electronic Devices APABILITIES The section “Capabilities” is used only to show which features/baudrates available in the PROFIBUS device. The Green Icon indicate that capability/baudrate is available, the Red Icon indicate no compatibilities with that capability/baudrate (Fig. 12). Figure 12: “PROFIBUS Device –... -
Page 24: O Ptions
User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 24 of 34 Industrial Electronic Devices PTIONS The section “Options” is used to enable some option for each PROFIBUS device (Fig. 13). The means of the fields are: In the field “Enable Sync”... -
Page 25: Update Device
Device” button it is possible to load the created Configuration into the device; and also the Firmware, if is necessary. If you don’t know the actual IP address of the device you have to use this procedure: HD67575-A1 . B153 WITH C Turn off the Device;... - Page 26 At this point the configuration/firmware on the device is correctly update. Note: When you install a new version of the software it is better if the first time you do the update of the Firmware in the HD67575-A1 device. Warning: If the Fig.
-
Page 27: Ethernet Protocol
Converter, it uses both. Note: We provide a free software tool that can be used together with the HD67575-A1. Is possible to download it from here: www.adfweb.com/download/filefold/SW67575-Tool.zip. The manual of this software can be found here: www.adfweb.com/download/filefold/MNSW67575-Tool_ENG.pdf. - Page 28 User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 28 of 34 Industrial Electronic Devices The “Writing state” (Byte 3) can have these values: • 0x00: Writing not required; • 0x01: No error; • 0x02: Slave does not exist, or does not respond in time or is not connected to line; •...
- Page 29 User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 29 of 34 Industrial Electronic Devices Example2: Request to get data from address PROFIBUS 20, without writing nothing. Request: 14 00 00 Response: 03 14 00 0F F4 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00...
- Page 30 User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 30 of 34 Industrial Electronic Devices XTENDED The Extended Protocol is enabled by adding a +0x80 to Byte Number 1. The request include the following byte: Byte Number Description Address PROFIBUS Slave Starting Address Write...
- Page 31 User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 31 of 34 Industrial Electronic Devices The “Writing state” (Byte 3) can have these values: • 0x00: Writing not required; • 0x01: No error; • 0x02: Slave does not exist, or does not respond in time or is not connected to line; •...
-
Page 32: Mechanical Dimensions
Page 32 of 34 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 16: Mechanical dimensions scheme ORDER CODE: Order Code: HD67575-A1 PROFIBUS Master / Ethernet - Converter ACCESSORIES: Order Code: AC34001 Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V AC Order Code: AC34002 Rail DIN - Power Supply 110V AC 50/60Hz –... -
Page 33: Disclaimer
User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 33 of 34 Industrial Electronic Devices DISCLAIMER All technical content within this document can be modified without notice. The content of the document content is a recurring audit. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 34: Warranties And Technical Support
User Manual PROFIBUS Master / Ethernet Document code: MN67575_ENG Revision 2.011 Page 34 of 34 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: 1) Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.
