Industrial Electronic Devices
User Manual
Revision 1.001
English
PROFINET / J1939 - Converter
(Order Code: HD67610-A1)
for Website information:
www.adfweb.com?Product=HD67610
for Price information:
www.adfweb.com?Price=HD67610-A1
Benefits and Main Features:
Very easy to configure
Electrical isolation
Two PROFINET ports
Temperature range: -40°C/85°C (-40°F/185°F)
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual PROFINET / J1939
Document code: MN67610_ENG
For others PROFINET products see also the following link:
Converter PROFINET to
www.adfweb.com?Product=HD67600
Other
www.adfweb.com?Product=HD67601
Products
www.adfweb.com?Product=HD67601
www.adfweb.com?Product=HD67602
www.adfweb.com?Product=HD67602
www.adfweb.com?Product=HD67603
www.adfweb.com?Product=HD67603
www.adfweb.com?Product=HD67604
www.adfweb.com?Product=HD67605
www.adfweb.com?Product=HD67606
www.adfweb.com?Product=HD67607
www.adfweb.com?Product=HD67608
www.adfweb.com?Product=HD67609
Do you have an your customer protocol?
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
Revision 1.001
Pagina 1 di 24
(NMEA2000)
(Serial RS232)
(Serial RS485)
(Modbus Master RS232)
(Modbus Master RS485)
(Modbus Slave RS232)
(Modbus Slave RS485)
(PROFIBUS Master)
(PROFIBUS Slave)
(CAN)
(CANopen)
(DeviceNet Master)
(DeviceNet Slave)
Phone +39.0438.30.91.31
Advertisement
Table of Contents
Related Manuals for ADF Wed PROFINET / J1939
Summary of Contents for ADF Wed PROFINET / J1939
-
Page 1: User Manual
User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 1 di 24 Industrial Electronic Devices User Manual Revision 1.001 English PROFINET / J1939 - Converter (Order Code: HD67610-A1) for Website information: www.adfweb.com?Product=HD67610 for Price information: www.adfweb.com?Price=HD67610-A1 Benefits and Main Features:... -
Page 2: Table Of Contents
User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 2 di 24 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is:... -
Page 3: Security Alert
User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 3 di 24 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for each individual application, legal and safety regulation. -
Page 4: Example Of Connection
User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 4 di 24 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 5: Connection Scheme
User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 5 di 24 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67610-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 6: Characteristics
Pagina 6 di 24 Industrial Electronic Devices CHARACTERISTICS: The HD67610-A1 is a PROFINET / J1939 Converter. It has the following characteristics: Up to 512 bytes in reading and 512 bytes in writing; Triple isolation between CAN - Power Supply, CAN - Ethernet, Power Supply - Ethernet. -
Page 7: Power Supply
User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 7 di 24 Industrial Electronic Devices POWER SUPPLY: The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax... -
Page 8: Function Modes
User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 8 di 24 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the ‘Dip2 of Dip-Switch A’: The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. -
Page 9: Leds
User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 9 di 24 Industrial Electronic Devices LEDS: The device has got six LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. -
Page 10: Profinet
User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 10 di 24 Industrial Electronic Devices PROFINET: The PROFINET connection must be made using Connector3 and/or Connector4 of HD67610-A1 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. -
Page 11: J1939
User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 11 di 24 Industrial Electronic Devices J1939: For terminate the J1939 line with a 120Ω resistor it is necessary that the Dip1 of ‘Dip-Switch B’ is at ON position. -
Page 12: Use Of Compositor Sw67610
A device configuration can also be imported or exported: To clone the configurations of a programmable “PROFINET / J1939 – Converter” in order to configure another device in the same manner, it is necessary to maintain the folder and all its contents;... -
Page 13: Set Communication
User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 13 di 24 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, PROFINET and J1939. By Pressing the “Set Communication” button from the main window for SW67610 (Fig. 2) the window “Set Communication”... -
Page 14: Receive Frames
User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 14 di 24 Industrial Electronic Devices RECEIVE FRAMES: By pressing the “Receive Frames” button from the main window for SW67610 (Fig. 2) the “Receive J1939 Frames” window appears (Fig. -
Page 15: Send Frames
User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 15 di 24 Industrial Electronic Devices SEND FRAMES: By pressing the “Send Frames” button from the main window for SW67610 (Fig. 2) the “Send J1939 frames” window appears (Fig. 5). -
Page 16: Update Device
User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 16 di 24 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button it is possible to load the created Configuration into the device; and also the Firmware, if is necessary. - Page 17 User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 17 di 24 Industrial Electronic Devices If you know the actual IP address of the device you have to use this procedure: Turn on the Device with the Ethernet cable inserted;...
-
Page 18: Mechanical Dimensions
User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 18 di 24 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 8: Mechanical dimensions scheme for HD67610-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 19: Ordering Informations
Connectors Type 1: Removable 5mm Screw Terminal Enclosure Type A: 1M, 35mm DIN Rail mounting Device Family HD67610: PROFINET / J1939 - Converter Order Code: HD67610-A1 PROFINET / J1939 - Converter ACCESSORIES: Order Code: AC34001 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V AC Order Code: AC34002 35mm Rail DIN - Power Supply 110V AC 50/60Hz –... -
Page 20: Plc Configuration
User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 20 di 24 Industrial Electronic Devices PLC CONFIGURATION: The configuration and commissioning of the PROFINET Converter as described on the following pages was accomplished with the help of the TIA Portal V11-software of Siemens. - Page 21 User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 21 di 24 Industrial Electronic Devices 2) Import the module in the network; connect the device to the PLC network and edit the parameters of IP, station name etc.
- Page 22 User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 22 di 24 Industrial Electronic Devices 3) Load the configuration into the PLC. ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
-
Page 23: Disclaimer
User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 23 di 24 Industrial Electronic Devices DISCLAIMER All technical content within this document can be modified without notice. The content of the document content is a recurring audit. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 24: Warranties And Technical Support
User Manual PROFINET / J1939 Document code: MN67610_ENG Revision 1.001 Pagina 24 di 24 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com...
