LED LCD TV

SERVICE MANUAL

CHASSIS : LD12D
MODEL: 42LV770S
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
P/NO : MFL67002349 (1107-REV00)
North/Latin America
Europe/Africa
Asia/Oceania
42LV770S-ZA
Internal Use Only
http://aic.lgservice.com
http://eic.lgservice.com
http://biz.lgservice.com
Printed in Korea

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 42LV770S and is the answer not in the manual?

Questions and answers

Related Manuals for LG 42LV770S

Summary of Contents for LG 42LV770S

  • Page 1: Service Manual

    Internal Use Only North/Latin America http://aic.lgservice.com Europe/Africa http://eic.lgservice.com Asia/Oceania http://biz.lgservice.com LED LCD TV SERVICE MANUAL CHASSIS : LD12D MODEL: 42LV770S 42LV770S-ZA CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. P/NO : MFL67002349 (1107-REV00) Printed in Korea...
  • Page 2 PRODUCT SAFETY ................. 3 SPECIFICATION ..................4 ADJUSTMENT INSTRUCTION ............... 8 EXPLODED VIEW .................. 15 SCHEMATIC CIRCUIT DIAGRAM .............. Copyright © 2011 LG Electronics. Inc. All rights reserved. - 2 - LGE Internal Use Only Only for training and service purposes...

  • Page 3: Safety Precautions

    An other abnormality exists that must be corrected before the receiver is returned to the customer. Copyright © 2011 LG Electronics. Inc. All rights reserved. - 3 - LGE Internal Use Only Only for training and service purposes...
  • Page 4 3) PAL-I/I’ 4) SECAM L/L’, DK, BG, I 5) DVB-T 6) DVB-C 7) DVB-T2 8) DVB-S DVB-S :Satellite Copyright © 2011 LG Electronics. Inc. All rights reserved. - 4 - LGE Internal Use Only Only for training and service purposes...
  • Page 5 L/R Input SDPIF out (1EA) SPDIF out USB (2EA) EMF, DivX HD, For SVC(download) JPEG, MP3, DivX HD Copyright © 2011 LG Electronics. Inc. All rights reserved. - 5 - LGE Internal Use Only Only for training and service purposes...
  • Page 6 VESA 1024*768 48.363 60.00 65.00 VESA(XGA) 1360*768 47.72 59.8 84.75 WXGA 1920*1080 66.587 59.93 138.625 WUXGA FHD model Copyright © 2011 LG Electronics. Inc. All rights reserved. - 6 - LGE Internal Use Only Only for training and service purposes...

  • Page 7: Hdmi Input

    48.363 60.00 65.00 VESA(XGA) HDCP 1360*768 47.72 59.8 84.75 WXGA HDCP 1280*1024 63.595 60.0 108.875 SXGA HDCP/FHD model Copyright © 2011 LG Electronics. Inc. All rights reserved. - 7 - LGE Internal Use Only Only for training and service purposes...

  • Page 8: Adjustment Instruction

    - Pattern : Horizontal 100% Color Bar Pattern - Pattern level : 0.7 ± 0.1 Vp-p - Image Copyright © 2011 LG Electronics. Inc. All rights reserved. - 8 - LGE Internal Use Only Only for training and service purposes...
  • Page 9 2) Connect each other LAN Port Jack. 3) Play Test (F9) button and confirm OK Message. 4) Remove LAN cable. Copyright © 2011 LG Electronics. Inc. All rights reserved. - 9 - LGE Internal Use Only Only for training and service purposes...
  • Page 10 0x03 90 (2) Check the menu on in-start 0x04 45 0x05 40 ⓓ 0x06 3E 0x07 ⓓ ⓔ3 Copyright © 2011 LG Electronics. Inc. All rights reserved. - 10 - LGE Internal Use Only Only for training and service purposes...

  • Page 11: White Balance Adjustment

    -> Only when internal pattern is not available G-Cut B-Cut Color Analyzer Matrix should be calibrated using CS-1000 Warm R-Gain G-Gain B-Gain R-Cut G-Cut Copyright © 2011 LG Electronics. Inc. All rights reserved. - 11 - LGE Internal Use Only Only for training and service purposes...
  • Page 12 Fig . 3 Connect the Dongle WARM 0.313 0.329 6500 K 0.0000 ( Do ng le Co nnec t io n Disp lay) Copyright © 2011 LG Electronics. Inc. All rights reserved. - 12 - LGE Internal Use Only Only for training and service purposes...
  • Page 13 ‘OK’ key on the controller. 3) You must remove the pairing with the TV Set by select ‘Vol+(STOP)’ key on the controller. Copyright © 2011 LG Electronics. Inc. All rights reserved. - 13 - LGE Internal Use Only Only for training and service purposes...
  • Page 14 1. RF input: Mono, 1 KHz sine wave signal, 100 % Modulation 2. CVBS, Component: 1 KHz sine wave signal 0.4 Vrms 3. RGB PC: 1 KHz sine wave signal 0.7 Vrms Copyright © 2011 LG Electronics. Inc. All rights reserved. - 14 - LGE Internal Use Only...

  • Page 15: Exploded View

    X-RADIATION, Shock, Fire, or other Hazards. Do not modify the original design without permission of manufacturer. Copyright LG Electronics. Inc. All rights reserved. - 15 - LGE Internal Use Only Only for training and service purposes...
  • Page 16 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. MAIN & NAND FLASH Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 17 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. MAIN POWER Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 18 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR MAIN AUDIO/VIDEO THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 19 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR MAIN DDR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...

  • Page 20: Gnd

    BCM35230 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. MICOM Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 21 BCM35230 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. HDMI Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 22 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR COMMON JACK THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 23 BCM35230 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR IR/KEY THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 24 BCM35230 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR WIRELESS THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 25 BCM35230 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR COMP/AV THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...

  • Page 26: Gnd

    ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR USB + WIFI THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 27 BCM35230 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR M_REMOCON THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 28 BCM35230 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR ETHERNET THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 29 FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR LVDS THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 30 FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR L_DIMMING THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 31 BCM35230 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. AUDIO[NEO] Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 32 2010.11.11 BCM35230 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 33 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR TUNER SINGLE THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...

  • Page 34: 35V

    FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 35 BCM35230 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR SCART THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 36 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR NON CHB THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 37 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR CHINA HOTEL THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 38 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR NON URSA THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 39 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR SMD GASKET THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 40 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR TUNER SMD GASKET THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 41 BCM35230 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR POWER THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 43 LCD TV Repair Guide `11 years New Models < Applicable Model > LV770S/T/W/G-ZA Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 44 (MAX9668B) (MAX9668B) I2C_SDA I2C_SDA (MAX9668B) (MAX9668B) (0xE8) (0xE8) (0xEA) (0xEA) (0xE8) (0xEA) Z_OUT 80P mini-LVDS Output 80P mini-LVDS Output RIGHT LEFT Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 45 Soft touch +IR HDMI switch (4:1) Motion assy Audio AMP (10W+10W) Tuner type can be changed by the model name. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 46 Wireless Ready PC-RGB RGB,H/V side L/R In PC-AUDIO OPTIC SPDIF OUT M-Remote Module UART (built in) Ethernet Only LW950X/770X A/V1 Rear RS-232C Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 47 LED BLU control Vsync RF Emitter Active Type Display * For more information about 3D system, refer to the page 1 ~6 Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 48 Main / Module LVDS cable 51PIN LED driver / PSU T-CON to Module 80pin FFC Multi-cable: IR+MOTION +SPK WOOFER SPK CABLE Local dimming cable 8pin Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 49 RF MOTION ASSY (15pin ) (12pin) SPK unit Control key (4pin) IR Key PCB RF MOTION ASSY (15pin) (12pin) To Main Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 50 Circuit noise, mechanical noise F. Exterior error Exterior defect First of all, Check whether there is SVC Bulletin in GCSC System for these model. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 51 Always check & record S/W Version and White Replace Main Board Re-enter White Balance value Balance value before replacing the Main Board Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 52 Check and No Video/ Normal Board replace No audio voltage? ( 3.5V,12V,20V or MAIN B/D 24V…) Replace Power Board and repair parts Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 53 Check Normal Contact with signal distributor Tuner soldering Picture? or broadcaster (Cable or Air) Normal Picture? Replace Main B/D Close Close Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 54 Change satellite setting signal distributor Normal (match with installed ANT) or broadcaster Picture? (Cable or Air) Normal Picture? Close Close Close Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 55 Request Repair for external device/cable RGB/ Check external External HDMI/DVI device and device/Cable Replace Main B/D error cable normal Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 56 Screen Replace screen? External Input, Component, normal? Main B/D RGB and HDMI/DVI by HDMI/ connecting Jig, pattern Generator ,Set-top Box etc. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 57 Measure voltage of each output of Power B/D Normal? Normal Replace Main B/D voltage? Close Normal Check ST-BY 3.5V voltage? ☞A18 Replace Power B/D Replace Power Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 58 Power off by unknown status except listed case "POWEROFF_ABNORMAL1" Power off by abnormal status except CPU trouble Abnormal "POWEROFF_CPUABNORMAL" Power off by CPU Abnormal Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 59 Speaker off Board Cancel OFF Replace Power Board and repair parts Check Speaker Disconnection Replace MAIN disconnectio Board Replace Speaker Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 60 External Input Connect and Normal signal error) check other audio? external device Check and fix external device Check and fix external device Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 61 (Power B/D don’t have problem) If R/C operate, Normal Close Explain the customer operating? cause is interference from light in room. Replace R/C Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 62 - S/W Version error Check and fix RGB,HDMI Fix in external device/cable /DVI, Optical Replace Main B/D accordance with Recognition technical error information Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 63 “Part related to nose” in the Owner’s then proceed as shown in the solution manual Manual. (For models without any fix information, provide the description) Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 64 Replace module Adjust VCOM exterior damage ☞A28 damage Cabinet Replace cabinet damage Remote controller Replace remote controller damage Stand Replace stand dent Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 65 Exchange LED driver Board (PSU) A-3/5 Inverter/ Module Exchange Module itself (1) A-4/5 Exchange Module itself (2) A-5/5 Continue to the next page Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 66 D. Function error_ No response in Remote controller operation checking remote controller, key error method D. VCOM Adjustment Sequence of the Vcom adjustment Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 67 Check the DC 24V, 12V, 3.5V and Inverter on ALEF LED P202 P203 6~10 6~10 Error Error Inverter ON Inverter ON A-dim A-dim P-dim P-dim Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 68 3. After recording the R, G, B (GAIN, Cut) value of Color Temp (Cool/Medium/Warm), re-enter the value after replacing the MAIN BOARD. (Cool/Medium/Warm), re-enter the value after replacing the MAIN BOARD. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 69 3.5V Inverter On/off Lamp : A-Dim LED : N.C PWM Dim #1 Error-out • Lamp SCANNING Model : PWM Dim #2 Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 70 MENU - Set up support - signal test select channel When the signal is strong, use the attenuator (-10dB, -15dB, -20dB etc.) Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 71 <ALL MODELS> 1. Checking method for remote controller for adjustment Version Press the IN-START with the remote controller for adjustment Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 72 LCD TV connection diagram (1) date <ALL MODELS> As the part connecting to the external input, check the screen condition by signal Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 73 Checking item : 1. Defective pixel 2. Residual image 3. MODULE error (ADD-BAR,SCAN BAR..) 4.Video error (Classification of MODULE or Main-B/D!) Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 74 Solder defect, CNT Broken Solder defect, CNT Broken T-Con Defect, CNT Broken Abnormal Power Section Solder defect, Short/Crack Solder defect, Short/Crack A - 1/5 Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 75 Abnormal Power Section Solder defect, Short/Crack Abnormal Display Fuse Open, Abnormal power section Solder defect, Short/Crack Noise GRADATION GRADATION A - 2/5 Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 76 Appendix : Exchange PSU(LED driver) No Light Dim Light Dim Light Dim Light No picture/Sound Ok A - 3/5 Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 77 Panel Mura, Light leakage Press damage Crosstalk Press damage Crosstalk Un-repairable Cases In this case please exchange the module. Press damage A - 4/5 Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 78 Un-repairable Cases In this case please exchange the module. Horizontal Block Gate TAB IC Defect Gate TAB IC Defect A - 5/5 Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 79 Check front display LED date Front LED control : Menu Option Power Indicator Standby light ON ST-BY condition: Red Power ON condition: white Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 80 Edge LED Inverter On/off Lamp : A-Dim LED : N.C PWM Dim #1 Error-out • Lamp SCANNING Model : PWM Dim #2 Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...

  • Page 81: Lamp Scanning Model : Pwm Dim #2

    Edge LED Inverter On/off Lamp : A-Dim LED : N.C PWM Dim #1 Error-out • Lamp SCANNING Model : PWM Dim #2 Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 82 Entry method 1. Press the IN-START button of the remote controller for adjustment 2. Check the entry into adjustment item 3 Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 83 1. Press the MENU button on the remote controller. 2. Select the AUDIO function of the Menu. 3. Select TV Speaker from Off to On. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...

  • Page 84: Table Of Contents

    ③ Connect the tester RX1 to the speaker terminal and if you hear the Chik Chik sound when you touch the GND and output terminal, the speaker is normal. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only...
  • Page 85 4. When checking the Pre-Amp when the power is in ON condition, it is normal when the Analog Tester needle moves slowly, and defective when it does not move at all. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only...
  • Page 86 ■ Push the OK key to store the value. Then the message “Saving OK” is pop. ■ Press the exit key to finish V-COM adjustment. Copyright © 2011 LG Electronics. Inc. All rights reserved. LGE Internal Use Only Only for training and service purposes...
