Page 1: User Manual
USER MANUAL Model: CVG-10ARxl Video Audio Distribution Amplifier For maximum results, use Comprehensive Brand Premium High Resolution cables and connectors. -
Page 2: Table Of Contents
Figure 1: CVG-10ARxl Video Audio Distribution Amplifier Figure : Increasing the Outputs: Arranging a 1:30 Video Audio DA Tables Table 1: Front Panel CVG-10ARxl Video Audio Distribution Amplifier Features Table 2: Rear Panel CVG-10ARxl Video Audio Distribution Amplifier Features Table : Technical Specifications of the CVG-10ARxl... -
Page 3: Introduction
1 For example, you can connect 3 CVG-10ARxl units to make a 1:30 video audio distribution amplifier (see section 6.2) 2 Recommended for low signal transmission over long distances or in audio broadcasting studios for high quality signal recreation 3 The video outputs are arranged in two blocks of 5 outputs (outputs 1 to 5, and outputs 6 to 10). -
Page 4: Your Cvg-10Arxl Video Audio Distribution Amplifier
CVG-10ARxl away from moisture, excessive sunlight and dust Your CVG-10ARxl Video Audio Distribution Amplifier Figure 1 and Tables 1 and 2 define the CVG-10ARxl: Figure 1: CVG-10ARxl Video Audio Distribution Amplifier Table 1: Front Panel CVG-10ARxl Video Audio Distribution Amplifier Features... -
Page 5: Table 2: Rear Panel Cvg-10Arxl Video Audio Distribution Amplifier Features
Table 2: Rear Panel CVG-10ARxl Video Audio Distribution Amplifier Features Feature Function VIDEO IN BNC Connector Connects to the video source VIDEO LOOP BNC Connector For looping to increase output availability Term Button Pushing in selects 75 , releasing selects Hi-Z... -
Page 6: Installing On A Rack
Installing on a Rack This section describes what to do before installing on a rack and how to rack mount. -
Page 7: Using The Cvg-10Arxl Video Audio Distribution Amplifier
1 Switch OFF the power on each device before connecting it to your CVG-10ARxl. After connecting your CVG-10ARxl, switch on its power and then switch on the power on each device 2 As required. Up to 10 outputs can be connected on the CVG-10ARxl. Not all outputs need to be connected 3 For example, VCR units 4 Insert a screwdriver into the hole and carefully rotate it, to trim the level 5 The video outputs are arranged in two blocks of 5 outputs (outputs 1 to 5, and outputs 6 to 10). -
Page 8: Increasing The Outputs
1 Switch OFF the power on each device before connecting it to your CVG-10ARxl units. After connecting the CVG-10ARxl units, switch on their power and then switch on the power on each device... -
Page 9: Figure : Increasing The Outputs: Arranging A 1:30 Video Audio Da
compensation equalization level, if required If audio control adjustment is required for left and/or right gain, push in the Enable/Disable buttons, and then adjust the trimmer controls Figure : Increasing the Outputs: Arranging a 1:30 Video Audio DA 1 Insert a screwdriver into the hole and carefully rotate it, to trim the level... -
Page 10: Technical Specifications
Technical Specifications Table 3 includes the technical specifications: Table : Technical Specifications of the CVG-10ARxl INPUTS: 1 composite video, 1 looping, 1Vpp/75 with termination switch on BNC connectors 2 audio, stereo or balanced mono, 2 looping, on RCA connectors OUTPUTS:...
