Hyundai GENESIS Quick Reference Manual

WALK THE CUSTOMER THROUGH EACH OF
THE FOLLOWING KEY DELIVERY FEATURES
CLIMATE CONTROL – pages 14-15
☐
- Explain the different air modes to customer
☐ TIRE PRESSURE MONITORING SYSTEM
(TPMS) – page 31
Low tire pressure indicator
Low tire pressure location indiator
TPMS malfunction indicator
CLOCK ADJUSTMENT – page 31
☐
Hour
1
Minute
Push and hold Reset to toggle
2
Reset
between 12 or 24 hours.
3
VEHICLE SETTINGS – pages 12-13
☐
- Demonstrate vehicle settings
in instrument cluster
- Demonstrate navigation use,
enter dealer address
- Show radio presets
BLUETOOTH – pages 20-21
☐
- Demonstrate phone pairing
Refer to www.hyundaiusa.com/bluetooth
- Demonstrate QR code
BLUE LINK – pages 22-23 (if applicable)
☐
- Assist with creating MyHyundai.com account
- Assist with Blue Link enrollment
Show Blue Link Users Manual & tear out Voice
Commands/Quick Tip Card
- Encourage customers to press the Blue link button
after enrollment to initiate Welcome Call
MAINTENANCE
Scheduled Maintenance
Engine Oil And Filter
Tire Rotation
Air Cleaner Filter
Fuel Tank Air Filter
Vacuum Hose
Fuel Lines, Fuel Hoses And Connections
Power Steering Fluid
Vapor Hose & Fuel Filler Cap
Climate Control Air Filter
(For Evaporator And Blower Unit)
Air Conditioning Refrigerant
Brake Hoses & Lines
Drive Shafts & Boots
Electronic Throttle Control
Exhaust Pipe & Muffler
Front Disc Brake/Pads, Calipers
Rear Brake Disc/Pads
Steering Gear Box, Linkage & Boots/
Lower Arm Ball Joint, Upper Arm Ball Joint
Suspension Mounting Bolts
1 2 3
Power Steering Pump, Belt & Hoses
Propeller Shaft
Brake Fluid
Parking Brake
Rear Differential Oil
Fuel Filter
Valve Clearance (3.8L)
Drive Belt
Spark Plugs (Iridium Coated)
Coolant
Automatic Transmission Fluid
*See Owner's Manual for details.
Looking For more detailed information?
Manual, If you require additional information or are unsure of a specific issue, you should always refer to the vehicle's
Owner's Manual or contact your authorized Hyundai dealer.
The information contained in this Quick Reference Guide was correct at the time of printing; however, specifications
and equipment can change without notice. No warranty or guarantee is being extended in this Quick Reference
Guide, and Hyundai reserves the right to change product specifications and equipment at any time without incurring
obligations. Some vehicles are shown with optional equipment. Specifications apply to U.S. vehicles only. Please
contact your Hyundai dealer for current vehicle specifications.
Normal Usage Severe Usage*
Replace 7,500 or 12 mos. Replace 3,750 or 6 mos.
Perform 7,500 Perform 7,500
Inspect 7,500 Inspect Same As Normal
Replace 30,000 Replace More Frequently
Inspect 7,500 Inspect Same As Normal
Replace 30,000 Replace More Frequently
Inspect 7,500 Inspect Same As Normal
Inspect 7,500 Inspect Same As Normal
Inspect 7,500 Inspect Same As Normal
Inspect 7,500 Inspect Same As Normal
Replace 15,000 Replace More Frequently
Inspect 15,000 Inspect Same As Normal
Inspect 15,000 Inspect Same As Normal
Inspect 15,000 Inspect 7,500 or 6 mos.
Inspect 15,000 Inspect Same As Normal
Inspect 15,000 Inspect Same As Normal
Inspect 15,000 Inspect More Frequently
Inspect 15,000 Inspect More Frequently
Inspect 15,000 Inspect More Frequently
Inspect 15,000 Inspect Same As Normal
Inspect 15,000 Inspect Same As Normal
Inspect 15,000 Inspect 7,500 or 6 mos.
Inspect 30,000 Inspect Same As Normal
Inspect 30,000 Inspect More Frequently
Inspect 37,500 Replace 80,000
Replace 37,500 Replace More Frequently
Inspect 60,000 Inspect Same As Normal
1st Inspect 60,000 or 72 mos.
Inspect Same As Normal
Add'l Inspect 15,000 or 24 mos.
Replace 100,000 or 10 yrs Replace More Frequently
1st Replace 120,000 or 120 mos.
Replace Same As Normal
Add'l Replace 30,000 or 24 mos.
Replace 60,000
This Quick Reference Guide does not replace your vehicle's Owner's
NP150-G2014-A
(Rev 10/23/13)
Printing 10/24/13
