T6627SH(EN).fm Page 1 Thursday, January 22, 2004 1:27 PM
TV-Video Combi
TVC5044
Owner's Manual

Table of Contents

Safety Information..............................................................................................................................................2
Before Using This Product ................................................................................................................................2
Installation .........................................................................................................................................................5
TV Functions......................................................................................................................................................9
Playback ..........................................................................................................................................................10
Manual Recording............................................................................................................................................11
Timer Recording ..............................................................................................................................................12
Other Functions ...............................................................................................................................................13
Maintenance ....................................................................................................................................................14
Troubleshooting Guide ....................................................................................................................................15
Specifications ..................................................................................................................................................15
Declaration of Conformity ...............................................................................................................................16
Features
• Automatic Operations
• On Screen Display
• Teletext Reception
• Sleep Timer
• Auto Repeat Playback
Supplied Accessories
• Owner's manual
• Remote control
• Two R6 batteries
Important Copyright Information
Unauthorised recording or use of broadcast television
programming, video tape, film or other copyrighted material
may violate applicable copyright laws. We do not take
responsibility for the unauthorised duplication, use, or other
acts which infringe upon the rights of copyright owners.
A Note About Recycling
This product's packaging materials are recyclable and can be
reused. Please dispose of any materials in accordance with your
local recycling regulations.
Printed in Malaysia
PAL
• One Touch Recording
• Timer Recording
• Auto Head Cleaner
• NTSC Playback
Batteries should never be thrown away or incinerated but
disposed of in accordance with your local regulations
concerning chemical wastes.
Model/Serial Number
This appliance has a serial number located on the rear panel.
Please note down the model number and serial number and
retain the information for your records.
Model number:
Serial number:
0EMN02509
T6627SH*****
EN

Advertisement

Table of Contents
loading

Related Manuals for UNITED TVC5044

Summary of Contents for UNITED TVC5044

  • Page 1: Table Of Contents

    T6627SH(EN).fm Page 1 Thursday, January 22, 2004 1:27 PM TV-Video Combi TVC5044 Owner’s Manual Table of Contents Safety Information..............................2 Before Using This Product ..........................2 Installation .................................5 TV Functions..............................9 Playback ................................10 Manual Recording............................11 Timer Recording ..............................12 Other Functions ...............................13 Maintenance ..............................14 Troubleshooting Guide ............................15...

  • Page 2: Safety Information

    T6627SH(EN).fm Page 2 Thursday, January 22, 2004 1:27 PM Safety Information WARNING: • Avoid installation in enclosed spaces such as bookcases unless proper ventilation is provided. • Live parts inside. Do not remove any screws. • Keep the unit away from radiators and other heat sources. •...
  • Page 3 T6627SH(EN).fm Page 3 Thursday, January 22, 2004 1:27 PM Controls and Connections All the buttons mentioned in this manual without specific notice are ones on the remote control. Front Panel 7 8 9 10 11 12 13 14 15 VIDEO AUDIO STANDBY-ON PROG...
  • Page 4 T6627SH(EN).fm Page 4 Thursday, January 22, 2004 1:27 PM Remote Control 1. STANDBY-ON/y button 2. number buttons 3. SLEEP button 4. RECORD button 5. PAUSE button button STANDBY-ON MUTE STATUS 7. STOP /p button button 9. PLAY button 10. CLEAR button PROG 11.

  • Page 5: Installation

    T6627SH(EN).fm Page 5 Thursday, January 22, 2004 1:27 PM Installation Connecting the TV-Video Combi Connecting Additional Devices You can connect an additional device such as decoder, satellite Connecting the Cable receiver, camcorder, etc. to the EXT1/AV1 scart socket. The scart socket to be connected is usually marked 'AV' or 'TV' on the decoder or satellite receiver.

  • Page 6: Important Notes For Operation

    T6627SH(EN).fm Page 6 Thursday, January 22, 2004 1:27 PM Important Notes for Operation 5) Press MENU to exit. Get Ready MENU INITIAL Press the main power switch to power on the unit. Then the TIMER CH TUNING PICTURE CLOCK little red STANDBY indicator on the front panel comes SET UP LANGUAGE INITIAL...
  • Page 7 T6627SH(EN).fm Page 7 Thursday, January 22, 2004 1:27 PM Setting the Clock Decoder Allocation This unit incorporates a 24-hour clock. The clock must be set Some TV channels transmit encoded TV signals which can for the Timer Recording function to operate correctly. only be viewed with a purchased or hired decoder.
  • Page 8 T6627SH(EN).fm Page 8 Thursday, January 22, 2004 1:27 PM •If this is the channel you want, press Channel Plan MENU INITIAL CH Indication TV Channel TIMER CH TUNING 02 – 12 E2 – E12 PICTURE CLOCK SET UP LANGUAGE 13 – 20 A –...

  • Page 9: Tv Functions

    T6627SH(EN).fm Page 9 Thursday, January 22, 2004 1:27 PM TV Functions To Select a Desired Channel Teletext Reception You can select a desired channel by using PROG +/- , or directly Many TV channels transmit Teletext information along with pressing the number buttons on the remote control.

  • Page 10: Playback

    T6627SH(EN).fm Page 10 Thursday, January 22, 2004 1:27 PM Playback Basic Playback <Note for “Speed Search” and “Still Picture”> • Usually there will be video “noise” lines (black and white Your unit can record on and play standard VHS cassettes. streaks or dots) on the screen.

  • Page 11: Manual Recording

    T6627SH(EN).fm Page 11 Thursday, January 22, 2004 1:27 PM Manual Recording or LP) Recording Selecting the Recording Speed (SP LP allows to double the recording duration on tape (for 1) Insert a cassette tape with its erase-prevention tab in place. example 6 hours instead of 3 hours on a E180 cassette).

  • Page 12: Timer Recording

    T6627SH(EN).fm Page 12 Thursday, January 22, 2004 1:27 PM Timer Recording Timer Recording To Stop a Timer Recording Which Has Already Started You may program the unit to start and end a recording while (STOP EJECT) Press on the unit. you are away.

  • Page 13: Other Functions

    T6627SH(EN).fm Page 13 Thursday, January 22, 2004 1:27 PM Other Functions Auto Repeat Playback Real Time Tape Counter This function can be used to play a cassette over and over • This shows the elapsed recording or playback time in again.

  • Page 14: Maintenance

    T6627SH(EN).fm Page 14 Thursday, January 22, 2004 1:27 PM Maintenance Cabinet Cleaning • Wipe the front panel and other exterior surfaces of the unit with a soft cloth that has been immersed in lukewarm water and wrung dry. • Never use a solvent or alcohol. Do not spray insecticide liquid near the unit.

  • Page 15: Troubleshooting Guide

    • Spent batteries do not belong in the dustbin. • You can dispose of them at a collection point for spent batteries or special waste. Contact your council for details. Specifications TVC5044 Voltage 220-240V/50Hz Power consumption less than 5W (Standby)

  • Page 16: Declaration Of Conformity

    Low Voltage Directive: 73 / 23 / EEC We: Funai Electric Trading (Europe) GmbH Bluecherstrasse 11 22767 Hamburg/Germany declare that the TV-Video Combi TVC5044 are in compliance with following norms: EN 55013: 2001 EN 55020: 2002 EN 61000-3-2: 2000 EN 61000-3-3: 1995 + A1: 2001 EN 60065: 1998 ©...
