Allied Data Technologies Tornado WebJet 128 User Manual

External isdn terminal adapter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Tornado WebJet 128
External ISDN Te rminal A d a p t e r
Users Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tornado WebJet 128 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Allied Data Technologies Tornado WebJet 128

Summary of Contents for Allied Data Technologies Tornado WebJet 128

  • Page 1 Tornado WebJet 128 External ISDN Te rminal A d a p t e r Users Manual...
  • Page 2 The information is not to be copied, translated, reproduced or transferred or stored on any electronic medium or other machine, neither wholly nor partly, without prior permission in writing from ALLIED DATA TECHNOLOGIES. The sale and use of software is subject to the ALLIED DATA TECHNOLOGIES General Terms of Delivery and Payment as well as its License Terms.

  • Page 3: Table Of Contents

    Allied Data Technologies Bulletin Board & Website ........

  • Page 4: Introduction

    How is the manual set up? The first chapter examines data communication in general. The second chapter describes the Tornado WebJet 128, the installation and bringing into use of the Terminal Adapter. Chapters 3 and 4 explain the commands and the S registers.

  • Page 5: Isdn, Data Communication, The Internet

    Setting up a data connection through the ISDN network is almost the same as doing so by modem. Once a protocol has been selected, a number can be dialed using the ATD command. The Tornado WebJet 128 will now establish a connection through the D channel.

  • Page 6: The Function Of The Tornado Webjet 128

    The Tornado WebJet 128 holds a number of standard protocols for exchanging data. In most cases, PPP (Point to Point Protocol) is used to gain Internet access through an Internet Provider. The V.110 or V.120 protocols are used to contact BBSs.
  • Page 7 Possible port speeds are: 300, 1200, 2400, 4800, 9600, 19200, 38400, 57600 and 115200 bps If data bits, control bits and speed are set at the computer end, the Tornado WebJet 128 will adapt automatically as soon as an AT command is sent.

  • Page 8: Getting Started With The Tornado Webjet 128

    The top of the terminal adapter shows four LEDS. Three of them reflect the status of the ISDN connection and the serial port. The fourth one indicates whether there is power on the Tornado WebJet 128. Figure 4: Tornado WebJet 128: Top...

  • Page 9: The Back Of The Terminal Adapter

    2. Take the ISDN cable and click the RJ45 connector into the terminal adapter (S0 connection). 3. Plug the Tornado WebJet 128 Power adapter into the electrical outlet. 4. Plug the Power adapter connector into the power connection at the back of the Tornado WebJet 128. The green power LED is now on.

  • Page 10: Protocols

    TRANSPARENT asyn-sync Remote control. The above list is an example. It is possible that your Tornado WebJet 128 will produce another outline due to software changes. A protocol is selected by using the AT&O<n> command. To select the corresponding protocol, the number found in the left column has to be entered for <n>.

  • Page 11: Establishing A Data Connection

    S119:000 S120:000 S121:253 S122:254 S123:000 S124:001 S126:000 S131:000 S133:080 S153:000 S154:000 S161:000 When the Tornado WebJet 128 is used in Windows, it isn’t necessary to select protocols by using the AT commands. Selecting the correct driver will do, the setting will be done automatically.
  • Page 12 TORNADO WEBJET 128 b. If the connection fails, one of the following messages will appear: ERROR You have made a typing error. NO DIALTONE The terminal adapter is not -- or not properly -- connected to the ISDN connection (S0). For this reason, it isn’t possible to call.

  • Page 13: At Command Set And S Registers

    TORNADO WEBJET 128 AT command set and S registers 3.1 The AT command set This chapter discusses the terminal adapter commands. Most terminal adapters and communication programs use the AT command set. In order to support new equipment like terminal adapters with AT commands as well, manufacturers have added commands of their own to the AT command set.
  • Page 14 TORNADO WEBJET 128 The Terminal Adapter recognizes the terminal baud rate and parity from the initial letters AT in the command line. The Terminal Adapter gears itself to it. Automatically recognized speeds are 300, 1200, 2400, 4800, 9600, 19200, 38400, 57600 and 115200 bps.

  • Page 15: At Commands At A Glance

    TORNADO WEBJET 128 3.1.3 AT commands at a glance The Terminal Adapter responds to the commands listed below. After this, a detailed description stating the accompanying parameters is given. A Answer an incoming call ........16 D Dial a number..

  • Page 16: List Of S Registers

    TORNADO WEBJET 128 3.2.2 List of S registers Register: Description: S000 Number of ringing signals for auto answer......16 S001 Number of non-replied ringing signals .

  • Page 17: Description Of At Commands And S Registers

    TORNADO WEBJET 128 3.3 Description of AT commands and S registers In the following sections, meaning and contents of AT commands and S registers are discussed. A great number of S registers have specific technical meanings. It is therefore not advisable to change an S register setting if you are not sure of the consequences.
  • Page 18 TORNADO WEBJET 128 Also refer to: &D (DTR behavior), X (show result of code selection and data detection), W (return messages), S95 (return messages), S112 (detailed indications). Allied Data Technologies...

  • Page 19: Dialing An Isdn Number

    TORNADO WEBJET 128 3.5.1 Dialing an ISDN number When dialing an ISDN number, the D command is followed by the number and, if necessary, a subaddress (preceded by an asterisk '*'). The dial command looks like this: ATDisdn_nb*sub_addr : : dte_channel_id in which: isdn_nb*sub_addr is an ISDN number, followed, if necessary, by a subaddress.

  • Page 20: Result Codes

    TORNADO WEBJET 128 Syntax Value Def. Meaning 19 of 192 : 19200 bps : 28800 bps : 38400 bps : 57600 bps : 115200 bps : select internal clock (asynchronous clock information is derived from the S0 bus) : select external clock...
  • Page 21 TORNADO WEBJET 128 Syntax Value Def. Meaning &D2 &Q0, &Q5 : DTR going off: break connection &Q1: DTR going off: break connection, DTR has to be on within time in S25 for a CONNECT. No Auto Answer if DTR is not on.

  • Page 22: Other Messages

    TORNADO WEBJET 128 3.6.2 Other messages 3.6.2.1 Extended (protocol) messages The messages listed below are given at protocol negotiations. The messages are switched on through S95. Chiffre Texte Signification CARRIER 300 Line speed 300 bps CARRIER 1200 Line speed 1200 bps...

  • Page 23: Profiles And Identification

    Euro-ISDN software version &V Show settings Show settings Software reset using stored settings Caution! This command completely resets the Tornado WebJet 128, all possible connections will be broken See also S122 &F Software reset using factory settings See also S121 &W...

  • Page 24: Sundries

    The above commands store the settings in the nonvolatile memory, but do not become automatically active. They are activated by using the AT#Z command or by switching the Tornado WebJet 128 off and on again. AT&F activates the factory settings.

  • Page 25: Special Applications

    5.1 Dial-in configuration The Tornado WebJet 128 can be set to link a telephone number to a protocol. When this number is called, the Tornado WebJet 128 will establish a connection according to the set protocol. When this number is called, this call is always passed on to the analog connection.

  • Page 26: Msn Numbers

    TORNADO WEBJET 128 5.1.2 MSN numbers Having an ISDN connection, it is possible for you to apply to your provider (e.g. PTT Telecom) for more than one telephone number (with a maximum of eight). As a standard, you will be given one main number and an option on three extra numbers.

  • Page 27: Remote Configuration

    WebJet 128 using the V.120/RC protocol. In this protocol, the data path isn’t passed on to the serial port but is sent back to the ISDN connection. The remote Tornado WebJet 128 can be set in the same way as is done through the serial port by using « AT » commands.

  • Page 28: Appendix A: Technical Specifications

    TORNADO WEBJET 128 Appendix A: Technical Specifications General: Protocols: * V.110, 1 x B channel synchronous/asynchronous * V.120, 1 x B channel, 64000 bps * V.120, 2 x B channel, 128000 bps * PPP, 1 x B channel, 64000 bps * Multi Link PPP (ML-PPP), 2 x B channel, 128000 bps (BACP) Data Compression: V.42bis, MNP5...

  • Page 29: Appendix B: Allied Data Technologies Bulletin Board & Website

    Allied Data Technologies Bulletin Board & Website In order to support the users of its data communication equipment, Allied Data Technologies has set up a Bulletin Board System (BBS): the ALLIED DATA BBS. Here you can place and/or find messages, questions and other information.

  • Page 30: Appendix C: Rs232C Connector

    TORNADO WEBJET 128 Appendix C: RS232C Connector CCITT DBF9F Richting Naam Verkort Data carrier detect (CD) Received Data (RxD) Transmitted Data (TxD) Data terminal ready (DTR) Signal Ground (GND) Data set ready (DSR) Request to send (RTS) Clear to send...

  • Page 31: Appendix D: Call Clearing Causes

    CLEARED: message. The messages are given in hexadecimal and decimal values respectively. The below messages are for an ETSI ISDN network (Euro-ISDN). Messages with a value larger than 80 hexadecimal are generated by the Tornado WebJet 128. The messages are produced by the Tornado WebJet 128 by using the AT*D/<number> command at dial-up. Decimal Description...
  • Page 32 Exemples de messages détaillés. Examples of extended messages. We start from a Tornado WebJet 128 which has the following settings: protocol 6 is for voice (S111 is 1). Protocol 11 is for PAD (S111 is 7). S112=35 (maximum information and automatic PAD VC).

  • Page 33: Appendix E: Ascii Table

    TORNADO WEBJET 128 Appendix E: ASCII Table Meaning of ASCII codes Null, or all zeros Device Control 1 Shift In Start of Heading Device Control 2 Shift Out Start of Text Device Control 3 Sync. End of Text Device Control 4 Linefeed End of Transm.
  • Page 34 TORNADO WEBJET 128 CTRL CODE CODE CODE < > " & Allied Data Technologies...

  • Page 35: Appendix F: Suggested Further Reading

    TORNADO WEBJET 128 Appendix F: Suggested further reading A lot of literature has been published on the workings of the Terminal Adapter, ISDN, modems and other facets of data communication. Books, but also computer magazine articles appear on a regular basis. In addition, there are specific data communication magazines.

  • Page 36: Index

    TORNADO WEBJET 128 Index Internet, 3 Internet Configuration, 3 ISDN, 1 ASCII Table, 35 ISDN2, 1 asynchronous communication, 3 ISP, 2 Asynchronous format, 3 AT command set, 11 AT commands outline, 13 Led, 5 Auto Answer indicator, 5 Manual B channels, 1...
  • Page 37 TORNADO WEBJET 128 Head office Allied Data Technologies bv Allied Data Technologies UK Pascalweg 1, Spijkenisse 4 Lake End Court P.O.box 788, Taplow 3200 AS Spijkenisse Maiden Head the Netherlands Berkshire SL6 0JQ Tel. +31 (0)181-611 5 22 United Kingdom Fax +31 (0)181-614 8 40 Tel.
