Page 1: User Guide
USER GUIDE IMPRESSION 860 Not the actual front page 801.318 USG/860/AE-A 30.09.96... - Page 2 USER GUIDE IMPRESSION 860...
- Page 3 USER GUIDE LCD PROJECTOR...
-
Page 4: Table Of Contents
USER GUIDE TABLE OF CONTENTS 1 SYMBOL DESCRIPTIONS ... 5 2 SAFETY INSTRUCTIONS ... 5 3 INTRODUCTION... 9 4 MAIN FEATURES ... 10 5 SUPPLIED MATERIAL ... 11 5.1 WHEN YOU OPEN THE LCD PROJECTOR PACKAGE... 11 5.2 OPTIONAL MATERIAL ... 11 5.3 GLOSSARY ... - Page 5 USER GUIDE 11.3 POWER SUPPLY ... 37 11.4 REMOTE CONTROL ... 38 11.5 COMPATIBILITY... 38 11.6 CONNECTORS ON THE SUPPLIED CABLES ... 39 12 CONNECTORS... 40 12.1 SOURCE 1/2/3... 40 12.2 MOUSE ... 41 13 ENVIRONMENTAL STATEMENT ... 42 14 FCC STATEMENT... 43 15 SERVICE INFORMATION ...
-
Page 6: Symbol Descriptions
USER GUIDE SYMBOL DESCRIPTIONS DANGEROUS VOLTAGE This symbol is intended to alert the user to the presence of uninsulated “ dangerous voltages” within the product housing that may be of sufficient magnitude to constitute a risk of electric shock to persons. WARNING This symbol is used on the product to alert the user of important operating and maintenance (servicing) - Page 7 USER GUIDE The normal operating life for the lamp is 750 hours. High-pressure lamp may explode if improperly used. Refer all servicing to authorized personnel only. 1. Water and Moisture - The projector is designed for indoor use only and should not be used near water and moisture. 2.
- Page 8 USER GUIDE 8. Non-use Periods - The power cord of the projector should be unplugged from the outlet when left unused for a long period of time. 9. Damage Requiring Service - The projector should be serviced only by authorized service personnel when; the power supply cord or the plug has been damaged, objects have fallen, or liquid spilled, into the projector, the projector has been exposed to water or condense,...
- Page 9 USER GUIDE careful when lifting and carrying the unit as it is heavy. 16. Lamp Beam - Do not look directly into the projector or lens when operating the projector. The lamp emits rays which may cause eye injury and/or sunburns. 17.
-
Page 10: Introduction
USER GUIDE LCD PROJECTOR INTRODUCTION Congratulations on purchasing this state-of-the-art, high resolution LCD projector. This projector can be connected to most computer sources, and video sources indirectly, for the best projection results and maximum compatibility. The projector displays bright vivid images in 16.7 million colors simultaneously, at SVGA resolution, making it the ideal choice for presenting computer generated text and graphics. -
Page 11: Main Features
USER GUIDE MAIN FEATURES The unit employs the following important features that in total provide you with a highly functional and powerful projector: High brightness 575 Watt illumination system 640 x 480 to 1152 x 870 image resolution 3 x RGB input/output connectors 16.7 million colors Infrared remote mouse On screen display (OSD) -
Page 12: Supplied Material
USER GUIDE SUPPLIED MATERIAL WHEN YOU OPEN THE LCD PROJECTOR PACKAGE A complete set includes the following components : 1. LCD Projector 2. VGA Cable with Y-split 3. MAC monitor adapter 4. MAC computer adapter 5. Mouse Cable OPTIONAL MATERIAL Optional cables, adapters and accessories are available. -
Page 13: Glossary
USER GUIDE GLOSSARY The following terms are used throughout this user guide to identify the different parts of the LCD projector, or to refer to certain ancilliary items. TOP PANEL KEYBOARD POWER STATUS INDICATOR PROJECTION LENS LENS CAP FOCUSING RING HEIGHT ADJUSTMENT RING DESKTOP MOUSE VENTILATION SLATS... -
Page 14: Setting Up The Lcd Projector
USER GUIDE SETTING UP THE LCD PROJECTOR SAFETY PRECAUTIONS Switch off all equipment before connecting together the various items. Be aware of static electricity that may build up, especially in the dry season and when operating on synthetic carpets. Discharge any static electricity by touching a metallic surface before you start. -
Page 15: Arrangements In The Projection Room
USER GUIDE ARRANGEMENTS IN THE PROJECTION ROOM The LCD projector should be placed on a table, or other stable hard surface, at the distance required to give the desired size of projected image on the wall. 4.8m / 187" 4.0m / 156" 3.0m / 117"... -
Page 16: Selecting Additional Adapters And Cables
USER GUIDE SELECTING ADDITIONAL ADAPTERS AND CABLES 6.3.1 FOR YOUR COMPUTER SOURCE(S) You may have a computer source which requires an additional adapter to connect between the source and the VGA cable with Y-split. A set of two MAC adapters is supplied in your delivery package. COMPUTER MAC II and PowerMAC 6.3.2... -
Page 17: Making The Cable Connections
USER GUIDE MAKING THE CABLE CONNECTIONS 1. Place the projector on a stable, hard surface, at the desired distance from the projection screen. 2. Connect the source equipment to the connector ports of the LCD projector, preferentially into the Source 1 connector port (This is the default source connector port): - PC: Insert the end of the VGA cable marked ‘... - Page 18 USER GUIDE - MAC: Insert the end of the VGA cable marked ‘ LCD’ into Source 1 connector port or the next available source port. Connect the MAC-Monitor adapter onto the short cable section and then attach your MAC monitor to it. Connect the MAC-Computer adapter onto the output port on your Macintosh computer unit, and then connect the VGA cable connector marked ‘...
- Page 19 USER GUIDE 3. Connect an external video adapter and video sources if required. 4. Connect one end of the mouse cable marked ‘ LCD’ into the mouse port on the LCD projector and the other end marked ‘ MA’ (Mouse Adapter) into the appropriate mouse adapter, determined by which mouse type you are using.
-
Page 20: Image Adjustments
USER GUIDE 6. Apply mains power to the various items of source equipment. Your LCD projector is now fully connected up. Before use for your presentation, refer to the next section on Image Adjustments to attain the highest quality of projected image. IMAGE ADJUSTMENTS The infrared remote control is the main user interface by which the device settings are adjusted. - Page 21 USER GUIDE OPERATION FREQ With data from a source displayed on-screen, set the background to a chequered pattern 50% grey (direct mode 1:1 uncompressed). If the frequency is set wrongly, vertical unstable bands will be visible in the image (see illustration). Adjust with the frequency right/left keys to remove all the vertical bands (see illustration).
- Page 22 USER GUIDE OPERATION POSITION Select POSITION. Adjust using the cursor keys until the full image lies within the viewing area (see illustration). CONTR Adjust using the contrast up/down arrow keys for optimum image quality BRIGHT Adjust using the brightness up/down arrow keys for local lighting conditions.
-
Page 23: Using The Lcd Projector
USER GUIDE USING THE LCD PROJECTOR The LCD projector has a set of features and functions with which you need to be familiar with in order to operate the unit efficiently and to allow you to make a smooth, problem-free presentation. INFRARED REMOTE CONTROL The infrared remote control is the main user interface with the projector. - Page 24 USER GUIDE The MEM column indicates whether the function setting is memorized for the source apparatus for future use. FUNCTION CONTR Contrast is the ratio between light and dark colors. Low contrast is recommended for long-term viewing, while high contrast is used to enhance details.
- Page 25 USER GUIDE FUNCTION FREEZE Holds the image projected on the screen. This feature can be used to hide actions on the computer that the audience need not see, such as changes between software packages, or for returning the audience’ s attention back to the presenter! BLANK Turns the screen white.
- Page 26 USER GUIDE FUNCTION SCALE Selects direct 1:1 mapping or scaling of images. Allows panning within oversized images using the cursor keys. Use the cursor keys to show different areas of the image based on each of the four corners. Displays the On-Screen Display (OSD) information at the foot of the screen.
-
Page 27: Top Panel Keyboard
USER GUIDE LCD PROJECTOR TOP PANEL KEYBOARD The settings most likely to be adjusted during the set-up process are also accessible via a secondary keyboard panel on the top of the LCD projector, known as the Top Panel Keyboard. The Power ON/OFF Indicator is also located on this panel. -
Page 28: Special Features Of Your Lcd Projector
USER GUIDE SPECIAL FEATURES OF YOUR LCD PROJECTOR INTELLIGENT COOLING SYSTEM The fan operates as long as the LCD projector is switched on. Provided that the power cord is connected, the fan continues to run for 2 minutes even after the unit has been switched off. This ensures a continuous protection against high temperature inside the projector. -
Page 29: Reset
USER GUIDE RESET This feature enables standard settings of most controls. RESET will only reset the active mode. A fundamental master reset may be performed by pressing all four top panel keys simultaneously. All settings will return to factory defaults, so do not perform a master reset unless it is really required. -
Page 30: Trouble-Shooting
USER GUIDE TROUBLE-SHOOTING This is a checklist to help you pinpoint any problem that may arise. Check the symptoms carefully if you experience any problem. The cure may be at your fingertips! Always check that the OSD appears when the OSD key on the remote control is pressed. - Page 31 USER GUIDE SYMPTOM SOLUTION Some colors are unstable or flickering The whole image appears to be unstable or misplaced Cooling fan is not working The remote control mouse is not working The desktop mouse is not working Check first that there are no loose cable connections.
-
Page 32: Maintenance
USER GUIDE 10 MAINTENANCE 10.1 GENERAL From time to time, the LCD projector unit and lens may be cleaned with a damp, non-abrasive cloth to remove dust and dirt spots. The lens should be cleaned with a mild dish-washing detergent solution, or with standard lens cleaning solutions available from a photographic dealer. -
Page 33: Lamp Replacement Messages
USER GUIDE 10.3 LAMP REPLACEMENT MESSAGES When the time is due to replace the lamp, the projector will give you one of the two following messages on the screen. Lamp has less than 50 hours left of recommended burning time Press any key to clear this message... - Page 34 USER GUIDE If the lamp timer is accidentally reset before the lamp has reached expected lifetime, or the lamp is changed before it is required and reset the timer, the warning below appears. This leaves you with two alternatives which are both described in the next paragraphs. The lamp change indicator has been activated, though the lamp has not reached expected lifetime.
-
Page 35: Fuse Replacement
USER GUIDE 10.4 FUSE REPLACEMENT The mains fuse is located at the mains input, as an integral part of the connector and switch assembly (See the figure). A defective fuse may indicate a permanent electrical failure. If a new fuse breaks immediately, please return the unit to you dealer for control. -
Page 36: Care Of The Remote Control
USER GUIDE LCD PROJECTOR 10.5 CARE OF THE REMOTE CONTROL The infrared remote control requires no maintenance, other than battery replacement when required. To change the batteries, open the battery holder on the rear of the handset. Remove the old batteries and dispose of carefully. -
Page 37: Technical Data
USER GUIDE 11 TECHNICAL DATA The technical data given in this section was correct at the time of going to print, but may change without prior notice in order to improve product performance. This LCD projector is designed for indoor use and should not be operated or stored in conditions outside the general environmental limits given in section below, as this may lead to permanent damage and will violate any warranties. -
Page 38: Lcd Projector Unit
USER GUIDE 11.2 LCD PROJECTOR UNIT PROJECTOR DIMENSIONS PROJECTOR WEIGHT PROJECTION LENS ANTI-KEYSTONE CORRECTION PROJECTION LAMP LIGHT OUTPUT LCD CELL COLOR RESOLUTION RESPONSE TIME CONTRAST RATIO PIXEL RESOLUTION LCD SCREEN DIAGONAL VIDEO FREQUENCY HORIZONTAL SYNC VERTICAL SYNC RGB INPUT DEFECTIVE PIXELS APPROVALS 11.3 POWER SUPPLY... -
Page 39: Remote Control
USER GUIDE 11.4 REMOTE CONTROL UNIT SIZE UNIT WEIGHT BATTERIES FUNCTIONAL RANGE COMPATIBILITY APPROVALS 11.5 COMPATIBILITY The LCD projector is compatible with the interfaces and resolutions shown below, some of which are predefined. However since different varieties of these exist, a frequency adjustment may be needed. MODE RESOLUTION Generic... -
Page 40: Connectors On The Supplied Cables
USER GUIDE 11.6 CONNECTORS ON THE SUPPLIED CABLES The connectors on the supplied cables are described below. CABLE PROJECTOR VGA 4m/13ft Y- 26 pin HDDSUB split cable male with fingerscrews Mouse cable 8 pin mini DIN male Mouse adapter 8 pin mini DIN cable (serial) female MAC mouse... -
Page 41: Connectors
USER GUIDE 12 CONNECTORS The connector ports for the source equipment on the LCD projector are located on the right hand-side (when facing) of the unit. The connector port for the mains power cord is located next to the fuse cabinet. The pinouts of all the connector ports is described in this section. -
Page 42: Mouse
USER GUIDE 12.2 MOUSE This port is used to exchange mouse messages between the projector and the computer. 8 PIN MINIDIN FEMALE (FRONT VIEW) LCD PROJECTOR MAC ADB RS232 RTS PS/2 CLOCK RS232 RXD PS/2 DATA RS232 CTS RS232 TXD... -
Page 43: Environmental Statement
USER GUIDE 13 ENVIRONMENTAL STATEMENT Care has been taken in the manufacture of this LCD projector that environmental stress and pollution has been minimized. Where possible, recyclable materials have been used to minimize the environmental impact. There are no special requirements for handling the product. Should the LCD module inside the projector become broken for any reason, resulting in a spillage of liquid and glass fragments from inside the unit, the following precausions should be taken:... -
Page 44: Fcc Statement
USER GUIDE 14 FCC STATEMENT This equipment has been certified to comply with the limits for a Class A computing device, pursuant to Subpart J of Part 15 of FCC rules. Only peripherals (computer input/output devices, terminals, printers, etc.) certified to comply with the Class A limits may be attached to a computer that complies with Class A limits. -
Page 45: Service Information
USER GUIDE 15 SERVICE INFORMATION This product contains no user serviceable parts, outside the scope of section Maintenance. Attempts to modify mechanics, electronics or optics inside the housing will violate any warranties, and may be hazardous. If for any reason the product fails to work properly, first check the section on Trouble-shooting.
