Page 1: User Guide
USER GUIDE IMPRESSION 960 Not the actual front page 801.230 USG/960/AE-C 18.09.96... - Page 2 USER GUIDE IMPRESSION 960...
-
Page 3: Lcd Projector
USER GUIDE LCD PROJECTOR... -
Page 4: Table Of Contents
USER GUIDE TABLE OF CONTENTS 1 SYMBOL DESCRIPTIONS ... 5 2 SAFETY INSTRUCTIONS... 5 3 INTRODUCTION... 9 4 MAIN FEATURES ... 10 5 SUPPLIED MATERIAL ... 11 6 OPTIONAL MATERIAL ... 11 7 SETTING UP THE LCD PROJECTOR ... 12 7.1 COMPUTER ... - Page 5 USER GUIDE LCD PROJECTOR...
-
Page 6: Symbol Descriptions
USER GUIDE SYMBOL DESCRIPTIONS DANGEROUS VOLTAGE This symbol is intended to alert the user to the presence of uninsulated “ dangerous voltages” within the product housing that may be of sufficient magnitude to constitute a risk of electric shock to persons. WARNING This symbol is used on the product to alert the user of important operating and maintenance (servicing) - Page 7 USER GUIDE The normal operating life for the lamp is 750 hours. High-pressure lamp may explode if improperly used. Refer all servicing to authorized personnel only. 1. Water and Moisture - The projector is designed for indoor use only and should not be used near water and moisture. 2.
- Page 8 USER GUIDE 7. Cleaning - The projector should be cleaned only as recommended, see the Maintenance section. Disconnect the power cord from the power outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. 8. Non-use Periods - The power cord of the projector should be unplugged from the outlet when left unused for a long period of time.
- Page 9 USER GUIDE 16. Lifting/moving - When the projector is to be moved, let the unit cool down completely, cover the lens, disconnect the power plug from the power outlet and disconnect all external cords and cables to prevent damage that may cause a fire, electric shock, etc. Be careful when lifting and carrying the unit as it is heavy.
-
Page 10: Introduction
USER GUIDE LCD PROJECTOR INTRODUCTION Congratulations on purchasing this state-of-the-art, high-resolution LCD projector. This projector can be connected to both computer and video sources for the best projection results and maximum compatibility. The ability to display a multitude of colors simultaneously as well as high resolution, makes it the ideal choice for presenting computer generated text and graphics. -
Page 11: Main Features
USER GUIDE MAIN FEATURES The unit employs the following important features that in total provide you with a highly functional and powerful projector : - High brightness illumination system - 640x480 to 1280x1024 image resolution - Built in RGB video interface - 3 x RGB input/output connectors - 16.7 million colors - BatMouse™... -
Page 12: Supplied Material
USER GUIDE SUPPLIED MATERIAL A complete set includes the following components : 1. LCD Projector 2. VGA/XGA V-Split Cable 3. BNC V-Split Cable 4. Mouse Cable 5. Mouse Adapter PC (Y-Split) OPTIONAL MATERIAL Optional cables and adapters are available for special computer sources such as 13W3, MAC etc. -
Page 13: Setting Up The Lcd Projector
USER GUIDE SETTING UP THE LCD PROJECTOR Switch off all equipment before connecting the projector. Be aware of static electricity that may build up, especially in the dry season and when operating on synthetic carpets. Discharge any static electricity by touching a metallic surface before you start. -
Page 14: Computer
USER GUIDE COMPUTER Switch off all equipment before you connect the LCD projector to the computer, mouse and video source as outlined in the following chapters. Then apply power first to the LCD projector, then to the computer and video source for correct operation. Connect the LCD projector, computer and monitor as shown in the rear foldout page (see Connection Layout). -
Page 15: Operation
USER GUIDE your monitor and re-connect with the shortest lead of the V-split (1B). Connect the longest lead of the V-split (1A) to the monitor BNC inputs. 7.1.4 ADAPTERS If you have a computer that requires adapters to physically connect, insert applicable adapter(s) onto the V-split of the PC compatible cable (2A,2B) as described in the table on page 10. -
Page 16: Mouse
USER GUIDE MOUSE See the rear foldout when setting up. Connect the mouse-cable to the LCD projector (3). Connect the appropriate adapter (4) to the end of the mouse-cable, labelled “ MA” . Then connect the adapter to the appropriate computer mouse port. For the computer to recognise the mouse, connect all cables and power on the projector before the computer is booted. -
Page 17: Step Operation
USER GUIDE USING THE BATMOUSE: STEP OPERATION Control mouse pointer directly with the cursor keys Press LEFT to activate (emulates the left mouse key) Press DRAG to tag an object, move it using the cursor keys, then press DRAG again (or wait 5 seconds) to release the object (Drag-and-Drop). -
Page 18: Using The Lcd Projector
USER GUIDE USING THE LCD PROJECTOR The LCD projector has a set of connectors and controls that you need to know in order to operate the device correctly. OPTICS The projection lens is mounted in the front of the projector. The optical system is designed with a 8 degree keystone correction so that the projected image is shifted upwards on the wall. -
Page 19: Remote Control
USER GUIDE LCD PROJECTOR REMOTE CONTROL The infrared BatMouse remote control (RC) is the main user interface to the projector. The RC is used to set the LCD projector correctly (to get the best possible viewing conditions) and to control the presentation. The figure shows the different keys on the remote control. - Page 20 USER GUIDE The 'MEM' column in the tables below indicates whether the setting is memorized for each source. For a detailed overview, see the Features section. BATMOUSE KEYS : CONTROL FUNCTION CONTR Contrast (ratio between light and dark colors) BRIGHT Brightness (whiteness) TUNE Adjusts the stability of the image...
-
Page 21: Control Panel
USER GUIDE CONTROL PANEL The control panel keyboard consists of a subset of the remote control keys. For a detailed overview, please see the Features section. CONTROL TUNE BRIGHT RESET ON/OFF MASTER RESET ON/OFF TUNE FUNCTION Adjusts the stability of the image Adjusts the brightness (whiteness) of the image Defaults to factory settings Activity indicator... -
Page 22: Connectors
USER GUIDE CONNECTORS All connectors are positioned on the left hand side of the LCD projector (seen from the rear). See the technical data section for pinouts of the various connectors. Do not connect any other devices with similar plugs to the connectors of the LCD projector, as this voids any warranty and may cause permanent damage to the device. -
Page 23: Features
USER GUIDE FEATURES The LCD projector has a variety of different features implemented. This chapter explains each feature in detail. 9.1.1 INTELLIGENT SAFECOOL SYSTEM The fan operates as long as the LCD projector is switched on. Provided that the power cord is connected, the fan continues to run for 2 minutes even after the unit has been switched off. - Page 24 USER GUIDE 9.1.3 CONTRAST The contrast of an image is defined as the relation between dark and light colors. An image of high contrast is often regarded as ‘ hard’ , as compared to the ‘ soft’ feeling of a low contrast image. Low contrast is recommended for long term viewing, while high contrast is used to enhance details.
- Page 25 USER GUIDE 9.1.8 SOURCE 1/2/3 These keys select between the 3 analog RGB inputs. Only one input can be active at a time. All three inputs have the same properties and can be used for either computer/workstation or RGB video sources. The Projector defaults to input source 1 at power on.
- Page 26 USER GUIDE 9.1.14 SCALE Scaling is applicable to images that have a lower or higher resolution than the 1024x768 active LCD area. Pressing SCALE toggles between direct mapping (1:1) and compression of oversized images (1280x1024 or 1152x900), or expansion of undersized images (640x480 or 800x600). Default power on setting for oversized images is to view the image in 1:1, undersized images are expanded.
-
Page 27: Trouble-Shooting
USER GUIDE 10 TROUBLE-SHOOTING This is a check-list to help you pinpoint any problem. Check the symptoms carefully if you experience any problem. The cure may be at hand. Before you start toggle the OSD-button. If response on the screen this indicates that the LCD projector receives signals from the remote control. - Page 28 USER GUIDE The cooling fan is not working - Is the unit switched on? - If the fan is defective, turn off the unit immediately. A return for repair is then necessary The remote control is not working - Check if the batteries need replacement - Be sure to point at the projection screen or directly at the IR eye in the front of the LCD projector - You may be too far away from the projector (max.
-
Page 29: Maintenance
USER GUIDE 11 MAINTENANCE From time to time, the housing and lens may be cleaned with a dampened, non-abrasive cloth, using a mild detergent (dish washing soap, etc.) to remove spots. Always be careful with the lens surface and use the lens cap for added protection when the projector is not in use. -
Page 30: Service
USER GUIDE 12 SERVICE This product contains no user serviceable parts, other than the projection lamp and the fuse. Attempts to modify other mechanics or electronics inside the housing will violate any warranties, and may be hazardous. If for any reason the product fails to work properly, first check the previous chapter on hints and tips. - Page 31 USER GUIDE The lamp has only 50 hours burning time left, and should be changed. Remember that you can check accumulated lamp usage each time the lamp is activated. A message appears in the lower left hand corner of the screen stating software revision and lamp hours used.
- Page 32 USER GUIDE LCD PROJECTOR If you did not intend to reset the lamp timer, this message confirms that you have corrected your mistake by pressing any other key to continue. INFO! The lamp timer has not been changed...
-
Page 33: Technical Data
USER GUIDE 13 TECHNICAL DATA The technical data may change without prior notice in order to improve the product performance. The LCD projector is designed for indoor use and should not be operated outside the general environmental limits, as this may lead to permanent damage and violation of any warranties. -
Page 34: Display Unit
USER GUIDE 13.1.2 DISPLAY UNIT SIZE WEIGHT PROJECTION LENS ANTI KEYSTONE PROJECTION LAMP LCD CELL COLOR RESOLUTION RESPONSE TIME CONTRAST RATIO PIXEL RESOLUTION LCD DIAGONAL MOUSE COMPATIBILITY VIDEO FREQUENCY HORIZONTAL SYNC VERTICAL SYNC RGB INPUT DEFECTIVE PIXELS 13.1.3 REMOTE CONTROL Infrared wireless remote control. - Page 35 USER GUIDE 13.1.4 COMPATIBILITY The unit is compatible with the following interfaces. Some sources are predefined, but as different varieties of these exist (especially in workstations), a frequency adjustment may be needed. MODE RESOLUTION GENERIC 640x350 640x400 640x480 720x480 800x600 1024x768 1152x900 1280x1024...
-
Page 36: Connectors
USER GUIDE 14 CONNECTORS The pinouts of all external connectors are described. 14.1.1 MOUSE This connector is used for mouse control. 14.1.2 SOURCE 1/2/3 These connectors relay all sync and video signals from the computer to the projector and back again to the optional local CRT monitor. ANALOG R IN ANALOG G IN ANALOG B IN... -
Page 37: Fcc Statement
USER GUIDE 15 FCC STATEMENT This equipment has been certified to comply with the limits for a Class A computing device, pursuant to Subpart J of Part 15 of FCC rules. Only peripherals (computer input/output devices, terminals, printers, etc.) certified to comply with the Class A limits may be attached to a computer that complies with Class A limits. -
Page 38: Environmental Statement
USER GUIDE 16 ENVIRONMENTAL STATEMENT This product is manufactured to minimize the stress and pollution of the surroundings. Where possible, recyclable materials are used. ITEM PACKAGING MECHANICS ELECTRONICS LCD MODULE RECYCLING / HANDLING Only recyclable materials are used Only recyclable plastics and metal are used. Metal parts are painted aluminium and steel. -
Page 39: Service Information
USER GUIDE 17 SERVICE INFORMATION In cases where a problem cannot be solved by your dealer, please call the number below to get assistance. Please have the part number, serial number and the name of the dealer where you purchased the unit, ready when you call. -
Page 40: Connection Layout
USER GUIDE 18 CONNECTION LAYOUT The foldout shows how to connect the LCD projector to the different computer sources. 1. BNC V-Split Cable 1A. BNC Cable - Monitor End 1B. BNC Cable - Computer End 2. VGA/XGA V-Split Cable 2A. VGA/XGA Cable - Monitor End 2B.
