INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
WARNING:
If the information in these
instructions is not followed exactly a fire or
explosion may result causing property
damage, personal injury or death.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapours and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier
from a neighbour's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas supplier
call the fire department.
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
This appliance may be installed in an
aftermarket permanently located,
manufacture home (USA only) or mobile
home, where not prohibited by local codes.
This appliance is only for use with the type of
gas indicated on the rating plate. This
appliance is not convertible for use with
other gases unless a certified kit is used.
This appliance is suitable for installation in a
bedroom or bed sitting room.
270215-32
G963
INSTALLATION AND
OPERATING INSTRUCTIONS
MODEL: G963
SERIES: A
DIRECT VENT GAS HEATER
PZPE.G963BODYA
POWERED BY PACIFIC ENERGY
5055.963-A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Piazzetta G963
Summary of Contents for Piazzetta G963
-
Page 1: Operating Instructions
This appliance is not convertible for use with other gases unless a certified kit is used. This appliance is suitable for installation in a MODEL: G963 bedroom or bed sitting room. SERIES: A DIRECT VENT GAS HEATER 270215-32 PZPE.G963BODYA... -
Page 2: Note For Massachusetts
Important Note for the Commonwealth of Massachusetts: From Massachusetts Rules and Regulations 248 CMR 5.08: For all side wall horizontally vented gas fuelled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied. -
Page 3: Table Of Contents
Table of Contents Note for Massachusetts .......... 2 Caution ..............4 Safety ..............5 Owners Information First Fire ..............6 Remote Control Operation ........7 IFC Module ............. 8 Operating Procedure ..........8 Maintenance ............13 Warnings and Cautions .......... 12 Lighting Instructions.......... -
Page 4: Caution
Caution FOR YOUR SAFETY - Do not install or operate your Pacific Energy gas heater without first reading and understanding this manual. Any installation or operational deviation from the following instructions voids the Pacific Energy Fireplace Products Warranty and may prove hazardous. This heater and its individual shut off valve must be disconnected from gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psi (3.5 kPa). -
Page 5: Safety
Safety • Due to high temperatures, this gas heater should be located out of traffic and away from furniture and draperies. • Children and adults should be alerted to the hazards of high surface temperatures and should stay away to avoid burns or clothing ignition. •... -
Page 6: Owners Information
OWNER’S INFORMATION Congratulations on your purchase of a Pacific Energy Gas Heater. Your heater has been professionally installed by: Dealer name: ___________________________________ Phone Number: _________________________________ If you discover any problems with your gas heater contact your dealer immediately to have the unit repaired. -
Page 7: Remote Control Operation
OWNER’S Remote Control Operation INFORMATION System Description The Proflame2 Remote Control System consists of two elements: 1. Proflame2 Transmitter. 2. Proflame Integrated Fireplace Control (IFC) board and a wiring harness to connect the IFC to the gas valve and stepper motor. Transmitter (Remote Control with LCD Display) The Proflame2 Transmitter uses a streamline design with a simple button layout and informative LCD display (Figure 1). -
Page 8: Ifc Module
OWNER’S INFORMATION IFC Module The Proflame2 Integrated Fireplace Control (IFC) module is a device that allows automatic ignition and pilot flame supervision, and commands the functions of the hearth Heater. It’s configured to control the ON/OFF main burner operation, giving the choice of both IPI (intermittent pilot ignition), and CPI (continuous pilot ignition) modes. - Page 9 OWNER’S INFORMATION Temperature indication Display With the remote transmitter in the “OFF” position, press the thermostat key and the mode key at the same time. Look at the LCD screen on the remote transmitter to (Figure 6 verify that a C or F is visible to the right of the room temperature display. &...
- Page 10 OWNER’S INFORMATION Remote Flame Control The Proflame2 has six (6) flame levels. With the system turned on, and the flame level at maximum in the Heater, press the down arrow key once to reduce the flame height by one step until the flame is turned off.
- Page 11 OWNER’S INFORMATION Comfort Fan Speed Control If the Heater is equipped with a hot air circulating fan, the speed of the fan can be controlled by the Proflame2 System. The fan speed can be adjusted through six (6) speeds. To activate this function use the Mode Key (Fig.
-
Page 12: Warnings And Cautions
OWNER’S INFORMATION Low Battery Power Detection Transmitter The life span of the remote control batteries depends on various factors: quality of the batteries used, the number of ignitions of the Heater, the number of changes to the room thermostat set point, etc. When the remote batteries are low, an icon will appear on the LCD display of the remote (Fig. -
Page 13: Maintenance
OWNER’S Maintenance INFORMATION Turn off gas and electrical power supply (if applicable) and allow ample time for unit to cool before servicing heater. It is recommended that the heater and its venting should be inspected at least once a year by a qualified service person. Glass Door: Warning: Do not operate heater with glass door removed, cracked or broken. -
Page 14: Lighting Instructions
OWNER’S Lighting Instructions INFORMATION 270215-32 G963_5055.963-A... -
Page 15: Installer Information
INSTALLER Heater Dimensions INFORMATION G963 Figure 16: G963 Heater Dimensions G963_5055.963-A 27215-32... -
Page 16: Clearances To Combustibles
INSTALLER Clearances to Combustibles INFORMATION Minimum Clearance to Combustible Materials G963 INTERIOR SIDE WALL 4” INTERIOR BACK WALL 4 “ INTERIOR CEILING 36” IN FRONT OF HEATER 36” EXTERIOR SIDE WALL 8” VENTING CLEARANCE 1” EXTERIOR SOFFIT 30” *NCR STANDS FOR NO CLEARANCE REQUIRED; YOU MAY USE COMBUSTIBLE CONSTRUCTION MATERIALS IN DIRECT CONTACT WITH THE HEATER ON THESE SURFACES. -
Page 17: Venting
INSTALLER Venting INFORMATION Note: The vent must not exceed a total length of 28 feet. Any combination of rise and run may be used but must be constrained to the boundaries of this chart. A Maximum of three (3) 90° elbows may be used. - Page 18 INSTALLER INFORMATION Figure 17: Venting This heater is certified for use with 4” x 6-5/8”coaxial venting components only. It is permitted to only use certified venting for this heater. See charts on page 29 for a list of approved venting components. 270215-32 G963_5055.963-A...
-
Page 19: Plumbing And Electrical
INSTALLER Plumbing and Electrical INFORMATION Figure 19: Gas and Electrical Connections Gas connection To make the required electrical and gas connections, start by positioning the gas heater. Connect the gas supply line to the 1/2” flare fitting at the rear of the unit as seen in Figure . Please see the gas supply section of the manual for requirements of the gas supply. -
Page 20: Gas Supply
Turn on the gas supply and check that all connections are tight and leak free. WARNING: The gas tray including gasket must be reinstalled after conversion/installation or servicing has been completed. Gas Pressure Check Please refer to following page for gas pressure testing procedure. G963 Gas pressure requirements Orifice Output AFUE 2.55mm... -
Page 21: Gas Pressure Testing Procedure
INSTALLER Gas Pressure Testing Procedure INFORMATION Note: To test the gas pressure, turn off the gas supply to the heater before loosening test point screws. Verify gas pressures with the heater lit and at the highest setting. 1. Remove switch cover and back panel and locate the valve as seen in Figure . 2. -
Page 22: Propane Conversion
INSTALLER Propane Conversion INFORMATION Before starting the conversion make sure to shut off the gas supply to the unit and allow heater to cool to room temperature. To convert the gas heater insert from natural gas to propane the (GASC.LPKIT) kit is required. This kit comes with new pilot and burner orifices as well as a new pressure modulator for the valve. -
Page 23: Door Installation/Removal
INSTALLER Door Installation/Removal INFORMATION Installation 1. Position the glass retainer’s frame so that the studs on unit align with holes in frame. Secure using 12 11/32” nuts as shown in Figure 25. CAUTION: Over tightening of nuts could result in glass fracturing. 2. -
Page 24: Panel Installation/Removal
INSTALLER Panel Installation / Removal INFORMATION Note: The burner tray needs to be removed before installation or removal of panels, see page Installation 1. Insert lower back panel so that it is sitting on the ledge at the back of the firebox as shown in Figure 28. -
Page 25: Burner Kit Installation/Removal
INSTALLER Burner Kit Installation / Removal INFORMATION Burner Tray Installation / Removal Installation Place the burner tray in the firebox so that the venturi is over top of the orifice. To secure the burner tray, insert the 4 screws using a screwdriver, as seen in Figure . -
Page 26: Cladding Installation/Removal
INSTALLER Cladding Installation / Removal INFORMATION Installation 1. Slide back the top cladding piece into the top of the heater as seen in 35. Fasten using screws on front of heater as shown in 36. 2. Place metal grill onto lower front cladding as seen in Figure 37 3. -
Page 27: Venturi Adjustment
INSTALLER INFORMATION Figure 40: Side Cladding Stand Figure 39: Front Cladding Securement Figure 41: Side Cladding Figure 42: Side Cladding Securement Venturi Adjustment To adjust the venturi the lower front piece of cladding needs to be removed, please refer to appropriate section of manual for removal instructions. -
Page 28: Replacement Parts
Replacement Door Screen PZPE.5002.963 Replacement Aluker Panel Set PZPE.5099.G963 Aesthetic Components Description Order Number Exterior Ceramic Panels by Piazzetta Mirage Surround Classic Bordeaux PZSY.P963CBX Mirage Surround Classic Oriental Sand PZSY.P963COS Mirage Surround Classic Off White PZSY.P963CWH Mirage Surround Modern Stone PZSY.P963MST... -
Page 29: Venting Components
INSTALLER Venting Components INFORMATION NOTE: Mixing venting components from different manufacturers is inadvisable. Figure 44: 4”x6-5/8" Rigid Piping Cross Reference Chart Figure 45: 4”x6-5/8" Rigid Pipe Components Cross Reference Chart G963_5055.963-A 27215-32... -
Page 30: Wiring Diagram
INSTALLER Wiring Diagram INFORMATION Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. 270215-32 G963_5055.963-A... - Page 31 INSTALLER INFORMATION G963_5055.963-A 27215-32...
-
Page 32: Installation Notes
© 2015 Copyright Pacific Energy Fireplace Products LTD. Reproduction, adaptation, or translation without prior written permission is prohibited except as allowed under the copyright laws. For technical support, please contact your retailer. Web site: www. pacificenergy.net 2975 Allenby Rd., Duncan, BC V9l 6V8...
