Page 1: Product Specification
English SXGA B/W Camera 49MHz Pixel Clock Camera Link VCC-G22S21CL Product Specification & Operation Manual CIS Corporation 900-548-30-00... -
Page 2: Table Of Contents
Table of Contents 1. Scope of Application ........................3 2. Notice ............................3 3. Product Outline ..........................3 4. System Connection Diagram......................4 5. Specification ..........................5 5.1. General Specification ......................5 5.2. Camera Output Signal Specification ..................6 5.3. Camera Link Connector Bit Assignment (Base Configuration)............. 7 5.4. -
Page 3: Scope Of Application
Clause 13. Handling Precautions. 3. Product Outline VCC-G22S21CL is a high-resolution industrial B/W digital video camera module utilizing a 1/2 inch PS IT CCD. 1450K CCD image sensor with on-chip micro-lenses realizes high sensitivity and high resolution. Key Features. -
Page 4: System Connection Diagram
4. System Connection Diagram Camera Power Supply OUT PUT：DC12.0V ＊Recommended Ripple Voltage ： under ±500ｍV (Same ripple voltage applies when supplying power to frame grabber board.) Camera Link Camera ＊ Camera Output : 26pin Camera Link Connector Camera Power Supply : 6pin or 12pin Circular Connector Camera Link Cable Frame Grabber Board For Camera Link... -
Page 5: Specification
5. Specification 5.1. General Specification Item Specification Remarks Power consumption 2.7W DC +12V ± 10% (Max voltage not to exceed 15V) Power requirements (Performance Guaranteed) 0℃∼+40℃ with RH 20∼80% Operation (Operation Guaranteed) –5℃∼+45℃ with RH 20∼80% environment Note: No condensation -25℃∼+60℃... -
Page 6: Camera Output Signal Specification
5.2. Camera Output Signal Specification Item Specification Remarks Horizontal resolution 1024 TV lines LVAL output LVDS (Camera Link) Camera Link Sync. FVAL output LVDS (Camera Link) connector Signal I/O DVAL output LVDS (Camera Link) HD/VD input None Option Polarity POSI/NEGA Selectable LVDS (Camera Link) CC１... -
Page 7: Camera Link Connector Bit Assignment (Base Configuration)
5.3. Camera Link Connector Bit Assignment (Base Configuration) 8 bit Data output Port/bit Data bit Port/bit Data bit Port/bit Data bit Port A0 Port B0 No Data Port C0 No Data Port A1 Port B1 No Data Port C1 No Data Port A2 Port B2 No Data... -
Page 8: Function Setting
5.4. Function Setting Camera functions can be set with serial data communications. Function Address Data Remarks No Function No Function Gain 0: - 1 dB 1: 0 dB 2: + 6 dB 3: +12 dB 4: Manual Gain (Refer to address 008.) 0: 1/25ｓ（OFF）... -
Page 9: Remote Interface Function
Pulse Width Trigger Mode Shutter value can be set by trigger pulse width. Trigger pulse width shall be within over 1HD to 1/2 sec. When V-Sync reset operation, it can be controlled 1HD basis. Approximate exposure time Exposure Time = Trigger Pulse Width (nHD) + 1.6 HD (HD = 39.11μs) Note: Please note the followings when using trigger shutter mode. - Page 10 Camera No. shall consist of 6 bytes of characters/numeric strings. Send the individual camera number code or common number code, “000000”. The reply data from the camera shall contain the registered number for that camera. Process code Input any one of R, W, or C to the process code. R (read mode) is to read the data of remote controller address.
-
Page 11: External Connector Pin Assignment
6. External Connector Pin Assignment 6.1. 6 pins Circular Connector HR10-7R-6PA (HIROSE) Pin No. Power IN +12V TTL Trigger IN RS-232C RXD RS-232C TXD Do not connect ※ Be sure not to connect pin no. 5. This pin will be assigned to successor models. 6.2. -
Page 12: Safety/Quality Standards
7. Safety/Quality Standards ・ UL Standard Conform to UL Standard including materials and others. ・ CE Marking (to be acquired) Conform to EN50081-2 (Emission) Conform to EN50082-2 (Immunity) ・ RoHS Conform to RoHS Restricted Items. ・ FCC Compliance Conform to FCC Class A Digital Device This device complies with Part 15 of the FCC Rules. -
Page 13: Timing Chart
9. Timing Chart 9.1. Horizontal Synchronous Signal Timing 9. Timing chart 9.1 Horizontal synchronous signal timing LVAL OUT Video signal output 16CLK Active Area 1360CLK 16CLK 192CLK 206CLK 1392CLK Read out signal 872CLK Discharge signal 328CLK DVAL out FVAL out 1790CLK 9.2. -
Page 14: Random Trigger Shutter Timing Of The Normal Frame Rate Scan
9.3. Random Trigger Shutter Timing of the Normal Frame Rate Scan 9.3 Random trigger shutter timing of the Nomal frame rate scan(25ps non interlace) Fixed switch shutter ※Trigger width = 2H min Triggger input signal 1057 LVAL OUT Jitter 1H max Discharge signal Exposure Time Read out signal... -
Page 15: H & V - Sync Reset
9.4. H & V – SYNC Reset When trigger reset type H&V-Sync reset is selected, horizontal frequency will be reset at the 38 CLK after recognizing trigger pulse. Exposure will be started from the 428 CLK. Trigger input signal LVAL out Discharge sinal 38CLK START EXPOSURE... -
Page 16: Ccd Optical Axis Accuracy
10. CCD Optical Axis Accuracy Inclination of optical axis to datum plane. 6±0.3 6±0.3 Datum Plane 6±0.3 6±0.3 10±0.3 10±0.3 Datum Plane Product Name Plate Position（凹） Inclination of effective pixels θ to datum plane shall be The center of effective pixels shall be within Φ0.6 to the center of θ≦±0.5°... -
Page 17: Dimensions
11. Dimensions 2-M3 Depth DC IN SXGA G22S21CL 3-M3 23.7 4-M2 Depth 3 (M3) Depth 3 Model Name Plate Position (M2) 999-427-00-00 900-548-30-00... -
Page 18: Cases For Indemnity (Limited Warranty)
12. Cases for Indemnity (Limited Warranty) We shall be exempted from taking responsibility and held harmless for damage or losses incurred by the user in the following cases. In case damage or losses are caused by fire, earthquake, or other acts of God, acts by third party, deliberate or accidental misuse by the user, or use under extreme operating conditions. -
Page 19: Handling Precautions
Especially in INT/EXT sync signal settings, improper connection may cause damages to the camera and the connected devices. VCC-G22S21CL can be connected to a capture board for Camera Link by use of dedicated cable. In case of abnormal operation, contact the distributor from whom you purchased the product.
