- Page 1 English SXGA B/W Camera 72MHz Pixel Clock Camera Link VCC-G32S21CL Product Specification & Operation Manual CIS Corporation 900-525-31-00 ...
-
Page 2: Table Of Contents
Table of Contents 1. Scope of Application ........................3 2. Notice ............................3 3. Product Outline ..........................3 4. System Connection Diagram......................4 5. Specification ..........................5 5.1. General Specification ......................5 5.2. Camera Output Signal Specification ..................6 5.3. Camera Link Connector Bit Assignment (Base Configuration)............. 8 5.4. -
Page 3: Scope Of Application
Clause 13. Handling Precautions. 3. Product Outline VCC-G32S21CL is a high-resolution industrial B/W digital video camera module utilizing a 1/2 inch PS IT CCD. 1450K pixels CCD image sensor with on-chip micro-lenses realizes high sensitivity and high resolution. -
Page 4: System Connection Diagram
4. System Connection Diagram Camera Power Supply OUT PUT：DC12.0V ＊Recommended Ripple Voltage ： under ±500ｍV (Same ripple voltage applies when supplying power to frame grabber board.) Camera Link Camera ＊ Camera Output : 26pin Camera Link Connector Camera Power Supply : 6pin or 12pin Circular Connector ... -
Page 5: Specification
5. Specification 5.1. General Specification Item Specification Remarks Power consumption 3.7W DC +12V ± 10% (Max voltage not to exceed 15V) Power requirements (Performance Guaranteed) 0℃〜+40℃ with RH 20〜80% Operation (Operation Guaranteed) –5℃〜+45℃ with RH 20〜80% environment Note: No condensation -25℃〜+60℃... -
Page 6: Camera Output Signal Specification
Item Specification Remarks 1/38sec Progressive Scan (Normal Operation) Scanning system Horizontal frequency 40.22 KHz 1790 CLK Non-Interlaced Vertical frequency 37.66 Hz 1068 HD Pixel clock 72 MHz Partial Scan V Scanning Rate Effective V line Refer to OFF Progressive 1068 lines 38 fps 1024 lines 7.1.3 for the... - Page 7 Item Specification Remarks Setup level : 4 ± 2 (Hex) to Video Output Signal 8 bit video output (00 – FF Hex) (1) Normal Operation Mode OFF(1/38), 1/76, 1/114, 1/152, 1/500, 1/1000, (Normal operation) 1/5000, 1/10000 sec OFF(1/73), 1/76, 1/114, 1/152, 1/500, 1/1000, (Partial operation) 1/5000, 1/10000 sec (2) Standard Trigger Operation Mode...
-
Page 8: Camera Link Connector Bit Assignment (Base Configuration)
5.3. Camera Link Connector Bit Assignment (Base Configuration) 8 bit Data output (Rear switch 8:OFF, 9:OFF) Port/bit Data bit Port/bit Data bit Port/bit Data bit Port A0 Port B0 Port C0 Port A1 Port B1 Port C1 Port A2 Port B2 Port C2 Port A3 Port B3... -
Page 9: Function Setting
5.4. Function Setting Camera functions can be set with serial data communications. Function Address Data Remarks LOC/REM 0: Local (Camera SW) Control 1: Remote Control F, G Gain 0: - 1 dB F, G 1: 0 dB 2: + 6 dB 3: +12 dB 4: Manual Gain (Refer to address 008.) 0 〜... - Page 10 Function Address Data Remarks Trigger Polarity 0: Trigger Positive Input F, G Neg/Pos 1: Trigger Negative Input Initial setting (0) Input Trigger 0: Camera Link F, G Port Select 1: 12pin Circular connector Initial setting (0) 8 bit / 10 bit 0: 8bit Output Data F (RAW), G 1: 10bit Output Data...
- Page 11 Function Address Data Remarks Partial Scan 052 & 053 Partial Scan Total Line number (052: V Byte, 053: L Byte) F, G Total line 548 line +2 * (address 048 & 049 value) Read Only : min 548 lines 〜 max 832 lines number Initial value: 2, 38 (550lines) Note: Read only...
-
Page 12: External Connector Pin Assignment
6. External Connector Pin Assignment 6.1. 12 pins Circular Connector HR10-10R-12PA (73) (HIROSE) Pin No. POWER IN DC +12V HD IN/OUT (RS232C RXD) VD IN/OUT (RS232C TXD) WEN OUT TRG IN It is possible to change the HD, VD I/O p ins into port ※... -
Page 13: Switch Settings, Adjustment Potentiometer Specifications
7. Switch Settings, Adjustment Potentiometer Specifications 7.1. Rear Panel Switch Function 10bit DIP-SW （● indicates initial setting position） OFF ● ● ● ● ● ● ● ● ● ● ... -
Page 14: Operation Mode Settings （Rear Panel Sw4: Mode0, Sw5: Mode1
(3) Standard trigger mode (Slow shutter) （Standard scan mode） （Partial scan mode） Shutter speed Real time Shutter speed Real time 1/38 sec 26.54 ms 1/73 sec... -
Page 15: Partial Scan Setting Switch (Rear Panel Sw: 6 Scan)
HD sync input is enabled. Jitter between Int. HD and Trigger will cause 1HD fluctuation in exposure time. To avoid this fluctuation, please synchronize with EXT. HD. Note that the trigger pulse width must be over 1 HD. 7.1.3. Partial Scan Setting Switch (Rear Panel SW: 6 SCAN) SCAN Scanning mode V Scanning lines... - Page 16 900-525-31-00 ...
-
Page 17: Rear Panel Sw7: - )
7.1.4. (Rear Panel SW7: - ) 7.1.5. (Rear Panel SW8: -) 7.1.6. 8 bit / 10bit Selection Switch （Rear Panel SW9: 8Bit/10Bit） 8bit/10bit 8 bit / 10 bit output selection 8 bit output 10 bit output 7.1.7. HD / VD Input / Output Selection Switch (Rear panel SW10: IN/OUT) IN/OUT ... -
Page 18: Internal Adjustment Switches And Potentiometer Information
7.3. Internal Adjustment Switches and Potentiometer Information VCC-F32/G32 series Internal Switch (Position C) (Position C) SW104 (Position B) (Position B) (Position A) (Position A) SW101 SW100 (GAIN) (WHITE BALANCE) RV102 RV101 (B-GAIN) (R-GAIN) -
Page 19: Hd/Vd Trigger Input/Output Circuit Of 12Pin Circular Connector
7.4. HD/VD Trigger Input/Output Circuit of 12pin Circular Connector 12 pins Circular connector HR10-10R-12PA(73) NM ʼ T HD out 470p 10 K HD in HD 74 LV1GT126A Vih min 2.0V / Vil max 0 .8 V Voh min 3. 8V / Vol max 0.55V NM ʼ... -
Page 20: Remote Interface Function
7.5. Remote Interface Function Through RS-232C interface, the camera can be controlled by external PC. (1) The settings for RS-232C are as follows. Baud rate: 9600bps Data: 8 bits Stop bit: 1bit Parity: None XON/XOFF: Not controlled (2) Control code ･... -
Page 21: Safety/Quality Standards
Remote controller address Note; Do not save the data into the address other than specified, since it may cause the damages or malfunction of the camera. Remote controller data Set the decimal number (000〜255) for the remote controller data. Please be noted to set any dummy data in read control mode. -
Page 22: Durability
9. Durability Item Specification Remarks Vibration Acceleration 7.0 m/s Vibration frequency 11〜200 Hz resistance Sweep interval 300 sec Direction XYZ 3 directions Testing time 10 min for each direction No malfunction shall occur after testing the above. Shock resistance Acceleration 490 m/s (50G) Without... -
Page 23: Timing Chart
10. Timing Chart 10.1. Horizontal Synchronous Signal Timing 900-525-31-00 ... -
Page 24: Vertical Synchronous Timing
10.2. Vertical Synchronous Timing 900-525-31-00 ... -
Page 25: Vertical Synchronous Timing (73 Fps Partial Scan Mode)
10.3. Vertical Synchronous Timing (73 fps Partial Scan Mode) 900-525-31-00 ... -
Page 26: Standard Trigger Timing
10.4. Standard Trigger Timing 900-525-31-00 ... -
Page 27: Pulse Width Trigger Timing
10.5. Pulse Width Trigger Timing 900-525 -31-00 ... -
Page 28: Dimensions
11. Dimensions 2-Mφ2.6 Depth 3.5 6-Mφ2.6 Depth 3.5 Product Label Position (凹 0.2) 900-525-31-00 ... -
Page 29: Cases For Indemnity (Limited Warranty)
12. Cases for Indemnity (Limited Warranty) We shall be exempted from taking responsibility and held harmless for damage or losses incurred by the user in the following cases. In case damage or losses are caused by fire, earthquake, or other acts of God, acts by third party, deliberate or accidental misuse by the user, or use under extreme operating conditions. -
Page 30: Handling Precautions
Especially in INT/EXT sync signal settings, improper connection may cause damages to the camera and the connected devices. VCC-G32S21CL can be connected to a capture board for Camera Link by use of dedicated cable. In case of abnormal operation, contact the distributor from whom you purchased the product.
