QT-80W
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
General
Power source
Power consumption
Output power
Speakers
Output terminal
Input terminals
Dimensions
Weight
Radio
Frequency range
Tape recorder
Frequency response
Signal/noise ratio
Wow and flutter
Motor
Bias system
Erase system
Specifications for this model are subject to change without prior notice.
Before operating the unit on mains, check the preset voltage. If the voltage is different from your local voltage, adjust the voltage
as follows. Slide the selector with a screwdriver to the appropriate voltage number. (AC 110 - 127 V or AC 220 - 240 V)

AC POWER SUPPLY CORD AND AC PLUG ADAPTOR

92L3404-074001
QACCB0012AW00
QACCE0007AW00
QACCL0002AW00/QACCL0008AW00

SPECIFICATIONS

AC 110-127/220-240 V, 50/60 Hz
DC 12 V ["D" size (UM/SUM-1, R20 or HP-2) battery x 8]
20 W
MPO: 18 W (9 W + 9 W) (AC operation, 10 % T.H.D)
RMS: 10 W (5 W + 5 W) (DC operation, 10 % T.H.D)
8 cm (3-1/8") full range speaker x 4
Headphones: 16-50 ohms (recommended: 32 ohms)
Mixing microphone: 600 ohms
Line input: 350 mV/47 kohms
Width: 520 mm (20-1/2")
Height: 191 mm (7-1/2")
Depth: 216 mm (8-1/2")
4.2 kg (9.3 lbs.) without batteries
FM: 88 - 108 MHz
SW1: 2.3 - 7.3 MHz
SW2: 7.3 - 22 MHz
MW: 526.5 - 1,606.5 kHz
60 - 12,000 Hz (Normal tape)
40 dB
0.3 % (WRMS)
DC 9 V electric governor
AC bias
Magnet erase

VOLTAGE SELECTION

QPLGA0003AWZZ
QPLGA0004AWZZ
– 2 –
