  • Page 1 3 7 63 1515 0 XR-M70 MD / CD STEREO SYSTEM • BASIC MD MECHANISM 7ZG-9 A1 • TYPE L 13942296513 SIMPLE MANUAL Replace this Service Manual with "Revision Publishing" when it is issued. u163 S/M Code No 09-987-270-4T3...

  • Page 2: Specifications

    http://www.xiaoyu163.com SPECIFICATIONS 3 7 63 1515 0 • Design and specifications are subject to change without notice. • The word “BBE” and the “BBE symbol” are trademarks of BBE Sound,Inc. Under license from BBE Sound,Inc. L 13942296513 u163 http://www.xiaoyu163.com...

  • Page 3: Speaker Parts List

    http://www.xiaoyu163.com SPEAKER PARTS LIST 1/1 3 7 63 1515 0 REF. NO PART NO. KANRI DESCRIPTION 1 88-CLB-941-010 PANEL,FR W 2 88-CL1-953-010 SPKR,100 3 88-CL1-954-010 SPKR,60 4 88-CL1-943-010 COVER,TOP 5 88-CLB-959-010 GRILLE,FRAME B ASSY 6 88-CLB-958-010 GRILLE,FRAME T ASSY 7 88-CLB-957-010 GRILLE,FRAME W ASSY L 13942296513 u163...

  • Page 4: Accessories/Package List

    http://www.xiaoyu163.com ACCESSORIES/PACKAGE LIST 3 7 63 1515 0 REF. NO PART NO. KANRI DESCRIPTION 1 S8-CLB-910-400 INSTRUCTION BOOK(70EZS) 2 S8-CLR-EMB-000 RC,RC-M70(EX) 3 S0-27N-F90-000 ANT,LOOP AM L 13942296513 u163 http://www.xiaoyu163.com...

  • Page 5: Mechanical Parts List

    DOOR,CD 22 S8-CL1-480-000 LENS,SENSOR REMOTE 3 S8-CL1-090-000 WINDOW,CD 23 S8-CLB-010-100 PLATE COVER FRONT CD 4 S8-CLB-030-100 CAB,TOP CD 24 S8-CL1-800-000 BADGE AIWA 5 S8-CL1-150-000 GEAR,DOOR CD A 87-081-438-010 FW,3-6-0.4 6 S8-CL1-160-000 GEAR,DOOR CD B 87-352-095-010 SCREW,ST3-8 7 S8-CL1-170-000 GEAR,DOOR CD...
  • Page 6 6 S8-CL1-660-000 BRACKET CORD AC 29 S8-CL1-620-000 BELT,PULLEY AMP 5 S8-CL1-370-100 KEY,SET-CD(GRY) 30 S8-CL1-420-000 GEAR,TRAY 7 S8-CL1-800-000 BADGE AIWA 31 S8-CL1-430-000 CENTER GEAR TRAY 8 S8-CL1-200-020 PANEL CONTROL TOP 32 S8-CL1-890-000 PLATE SUPPOTR X`FORMER 9 S8-CLB-710-100 PLATE PANEL CONTROL A 87-357-036-010...

  • Page 7: Electrical Main Parts List

    http://www.xiaoyu163.com ELECTRICAL MAIN PARTS LIST 3 7 63 1515 0 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION L101 87-003-098-080 INDUCTOR,2.2UH L112 87-003-147-010 COIL,22UH S8-320-570-000 IC,TA2057N L113 87-005-196-080 INDUCTOR,10UH S8-492-570-000 IC,TC9257F L281 87-005-696-080 INDUCTOR,100UH S9-187-230-010 IC,TMP87CM23F-2336 PT281 S1-667-260-000 PT,EL EI-16...
  • Page 8 http://www.xiaoyu163.com 3 7 63 1515 0 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION C205 87-010-079-010 CAP,E 100-6.3V C569 87-010-248-080 ELECT CAP 220-10V C207 87-010-071-040 CAP,E 1-50V C574 87-010-047-010 CAP,E 100-50V C208 87-010-071-040 CAP,E 1-50V C575 87-010-047-010 CAP,E 100-50V S0-702-501-000...

  • Page 9: Transistor Illustration

    http://www.xiaoyu163.com 3 7 63 1515 0 REF. NO PART NO. KANRI DESCRIPTION OPTICAL C.B C801 87-010-263-080 ELECT CAP 100-10V 87-010-400-010 CAP,E 0.47-50V LED801 87-A40-123-010 LED,SLZ-8128A-01-B 87-005-696-080 COIL,100UH 87-005-366-010 COIL,FM 1UH S0-091-340-070 IFT A7BRRCS-A9134 S5-030-650-000 SFR,50K 87-NF4-651-010 IFT AM PACK(RF BLOCK) SO-020-160-000 TERMINAL PUSH 2P S5-866-361-400...
  • Page 10 http://www.xiaoyu163.com SCHEMATIC DIAGRAM-4 (CD MAIN) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 http://www.xiaoyu163.com...
  • Page 11 http://www.xiaoyu163.com SCHEMATIC DIAGRAM-3 (DISPLAY) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 http://www.xiaoyu163.com...
  • Page 12 http://www.xiaoyu163.com SCHEMATIC DIAGRAM-5 (FUNCTION/PANEL) 3 7 6 3 1 5 1 5 0 SW607 OPEN/CLOSE 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 http://www.xiaoyu163.com...
  • Page 13 http://www.xiaoyu163.com SCHEMATIC DIAGRAM-2 (AMP/POWER) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 D804-807 IN 5401 AC 230V 500 250V w w w u 1 6 3 http://www.xiaoyu163.com...
  • Page 14 http://www.xiaoyu163.com SCHEMATIC DIAGRAM-1 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 http://www.xiaoyu163.com...
