Soyal AR-821EF-V5 Installation Manual

SOYAL
ACCESS CONTROL SYSTEM
Contents
AR-821EF-V5
1 Products
AR-821EV-V5
1 Products 2
Installation
A.
Notice
1.Tubing: The communication wires and power line should NOT be bound in the same conduit or tubing.
2.Wire selection: Use AWG 22-24 Shielded Twist Pair to avoid star wiring ,CAT 5 cable for TCP/IP connection
3.Power supply: Don't equip reader and lock with the same power supply. The power for reader may be unstable when the lock is activating, that may make the
reader malfunction.
The standard installation: Door relay and lock use the same power supply, and reader use independent power supply.
Connector Table (1)
Cable:
P1
Wire Application Wire
Lock Relay 1 Blue White (N.O.)DC24V1Amp
2 Purple White (N.C.)DC24V1Amp
Lock Relay COM 3
Door Contact 4 Orange
Exit Switch 5
Alarm Relay 6
Power 7 Thick Red
8 Thick Black DC 0V
®
AR-821EF-V5 / AR-821EV-V5
2 User Guide 3
User Guide 3 Terminal Cables
B.
1
2
P3 P2 P4
8 2
7
1
7
6
6
5
P6
5
4
4
3 4
3 3
2
2 2
1
1 1
P5
P1
3 2 1 8 7 6 5 4 3 2 1
Color Description
White (COM)DC24V1Amp
Negative Trigger Input
Purple Negative Trigger Input
Gray N.O./N.C. Optional (by jumper)
DC 12V
Terminal Cables
P1 P2
P4 P5 P6
P1 P2 P3
P4 P5 P6
Use a screwdriver to screw the mounting plate to the wall.
Pull cables ends through the access hole in the mounting plate.
Attach AR-821EF-V5 or AR-821EV-V5 to the mounting plate and install screws (supplied)
into the holes at the bottom with the allen key.
Apply power. LED (green) will light up with one beep.
Cable:
P2
Wire Application
Beeper
LED
Door Output
Wiegand
WG Door Contact
WG Exit Switch
Cable:
P3
Wire Application
TCP/IP Output
Cable: P4
Wire Application
RS-485 for Lift
Controller
Copyright by SOYAL Technology Co., Ltd.. All rights reserved.
4 Tools 5 Optional
P3
AR-821RB
4 Tools 5 Optional
AR-821RB
Wire Color Description
1 Pink Beeper Output 5V/100mA, Low
2 Yellow Red LED Output 5V/20mA, Max
3 Brown Green LED Output 5V/20mA, Max
Transistor Output Max. 12V/100mA
4 Blue White
(Open Collector Active Low)
5 Thin Green Wiegand DAT: 0 Input
6 Thin Blue Wiegand DAT: 1 Input
7 Orange Negative Trigger Input
8 Purple Negative Trigger Input
Wire Color Description
1 --- ---
2 --- ---
3 Orange White Net - TX+
4 Orange Net - TX-
5 Green White Net - RX+
6 Green Net - RX-
7 --- ---
Wire Color Description
1 Thick Green RS-485(B-)
2 Thick Blue RS-485(A+)
V120508
AR-721RB
Digital Relay
AR-721RB
Digital Relay
