  • Page 1 Please read carefully before using this product.

  • Page 2: Table Of Contents

    Contents 1. Package Contents Page 4 2. Quick Start Guide - Installing the Camera Page 5 - Installing the Infrared Module Page 6 - Setting Up GPS Connection Page 7 - Installing the View-I PC Player Page 8 - PC Player Password Page 9 - Set Time and Date on the PC Player Page 10...
  • Page 3 Contents 13. PC Player and Camera Settings Page 23 14. Search List Screen Page 26 15. PC Player Search Engine Page 27 16. Google Maps Page 28 17. Speed and G-Sensor Reports Page 29 18. Screen Capture Page 30 19. ECO Driver Report Page 31 20.

  • Page 4: Package Contents

    1. Package Contents Please confirm below package list in the box * HD-SL-Ruby-Wired & Power Cable HD-SL-Ruby & Cigar Power cable Infrared Module Wire Clip x 4 Cradle & Double Side Tape Soft Copy SD Card Key x 1 User Manual ( Sales Option) * Product specification and package may change for product enhancement without any notification in advance.

  • Page 5: Quick Start Guide

    2. Quick Start Guide WARNING! When installing the camera and PC Player for the first time, the following steps MUST be performed with the SD card supplied with your product. If installing with a larger card, SD card must be formatted before use (see page 12) Ensure the camera has completely turned off during all movements of the SD Card.

  • Page 6: Installing The Infrared Module

    Setting Up the Camera Quick Start Guide Continued... 2.5 Remove the second plastic cover from the sticky pad. 2.6 Carefully position and firmly place the camera on the window. 2.7 Connect the fused Red wire to 12v ignition feed and the Black earth wire to a chassis earth.

  • Page 7: Setting Up Gps Connection

    Setting Up GPS Quick Start Guide Step 2 – Setting Up GPS Connection Important: For the initial GPS lock on, the camera must be powered for approx 5 minutes. The vehicle must be in an open clear area. Not inside a garage or an area where GPS connection will be affected.

  • Page 8: Installing The View-I Pc Player

    - Installing the PC Player Quick Start Guide Step 3 – Installing the PC Player 2.20 Insert the card into the SD card slot in a PC or laptop. 2.21 If AutoPlay box opens, double click on Open Folder To View Files. If not, left click Start - Computer then double click on the SD card drive.

  • Page 9: Pc Player Password

    Installing the PC Player Quick Start Guide Continued... 2.25 Left click Next on the Wizard Setup. 2.26 Left click Next again. 2.27 Left click on box next to the Create a Desktop Icon if not already ticked, then left click Next. 2.28 Left click Install then Finish.

  • Page 10: Set Time And Date On The Pc Player

    Set Time and Date Quick Start Guide Step 4 – Set Time and Date on the PC Player 2.30 Left click on the Settings button, bottom right hand corner of player. 2.31 The Open box will appear. Double click on the SD card drive. 2.32 Double click on System folder.
  • Page 11 Set Time and Date Quick Start Guide Continued.. 2.36 To save the changes, left click Apply and repeat step.2.31 - 2.33 then click Save 2.37 Left click the red cross in top right hand corner of player to close the Player. 2.38 Safely remove the SD card from the SD card slot in the PC and insert the card into the camera.

  • Page 12: Formatting Sd Cards

    3. How To Format SD Cards Important: Formatting SD cards will delete all data on the card. Data must be backed up onto another device if the data is to be used for future reference. Recommended - Format SD card at least once every 4 weeks for optimal performance.

  • Page 13: View Recordings From Sd Cards

    4. View Recordings Saved on SD Cards How to Watch Footage Saved on the SD Card Important: The HD PC Player software must be installed to Desktop to watch any recorded data. If the PC Player has not been installed, see page 8, Installing the PC Player.
  • Page 14 4. View Recordings Saved on SD Cards Continued... 4.4 A list of recordings will appear. To play the recordings the list must be highlighted. Always tick the box in the top left hand side of the list, next to “No”, to highlight t he recordings.

  • Page 15: Camera Features

    5. Camera Features Function Description Records everything when camera is powered on. [NOTE] When the SD card is full of data, the camera deletes the oldest Constant INI file to make room for new recordings. Therefore, if the user needs to Recording keep the old recordings, the user must backup the recordings before they are automatically overwritten.

  • Page 16: Camera Functions

    6. Camera Functions Name Description 1 Power Feed DC 12/24v 2 SD Lock Key lock 3 SD Cart Slot SD card slot 4 GPS Internal GPS Antenna 5 Front Camera 2.0 mega pixel CMOS lens View real-time footage on an 6 TV-Out Port external display.

  • Page 17: Camera Button & Lights

    7. Camera Button & Lights Name Recording Mode Manually start Event recording if button is pressed, camera Manual will make “tic-tic” sound and blue and orange LED will flash Recording quickly. These clips will be saved as an Emergency file. Button Push the button over 5seconds, toggle Mic on/off Power LED...

  • Page 18: Software Features

    8. Software Features Features Description HD PC Software to view recordings. Player View GPS data, generate reports can be done through the dedicated player. View driver’s route via Google Map through the PC Player. Google Map [NOTE] GPS needs to be connected to the satellites in order to sync data Sync with Google Maps.

  • Page 19: Pc Requirements

    9. PC Requirements System Requirement Item Description Window XP, Windows Vista, Windows 7 & 8, Operating System (English version) Pentium 4 / 1.8Ghz Processor or above More than 512MB Free HDD Space More than 200MB Display More than 1024 x 768 pixels...

  • Page 20: Password Settings

    10. PC Player Password Settings Encryption PC Player only(Password Settings) In order to protect the recorded data being accessed by an unauthorised user, the PC Player has a password protection function. To enter and change passwords, please follow the below. 12.1 When entering the HD SCE 1.7 Player for the first time, leave the entry blank and click OK.

  • Page 21: Pc Player Playback Screen

    8. View-i PC Player Manual 11. Playback Screen PC Player Playback Screen Name Description Front Video Screen Front video play screen of designated video file Rear Video Screen Interior/Second Camera screen of selected video file File Information Displays file name, time and date, longitude and latitude. G-Sensor Graph G-sensor data of video screen for user analysis Displays current position of the video on Goggle Maps...

  • Page 22: Pc Player - Buttons Functions

    12. PC Player Button Functions Buttons Functions on PC Player Software Button Description Button Description Previous File Open 1 file Rewind Print Screen Play Settings Pause ECO-Drive Report Stop Event Report Fast-forward Volume Control : Video volume control with mute Next File function...

  • Page 23: Pc Player And Camera Settings

    13. PC Player and Camera Settings Open /Change Player and Camera Settings Important: Check/set the Time and Date Settings during initial install to ensure recorded data is accurate. Any changes made on the Settings in the software must be saved in the camera. Ensure the SD card is inserted into the camera after changes have been made and power the camera for at least 3 minutes.
  • Page 24 13. PC Player Settings - Express Express Settings Adjust camera and PC Player settings. Important: Any adjustments made must be saved on the SD card and camera. Click “Apply” button save Settings to the card. Re-insert SD Card into the camera to upload the changes Name Description...
  • Page 25 13. PC Player Settings - Expert Expert Settings Only use Expert setting if you are an advanced user. Click “Apply” button and re-insert SD Card to the device to save the changes Name Description Best: 2M@VGA 30fps / Good: 2M@VGA 25fps Video Quality Normal: 2M@VGA 15fps / Compact: 2M@QVGA10fps Brightness...

  • Page 26: Search List Screen

    14. PC Player – Search List Screen Search and Play List Screen The Search List screen is the main navigation screen. Upload data from SD cards, select files to view Name Description recordings. Open recorded clips on Folder Open SD card Play button for continual Chain Play...

  • Page 27: Pc Player Search Engine

    15. PC Player – Search Engine Create and Search Database The in-built search engine can catagorise the recorded data to allow users search specific criteria such as Speed, G-Senor etc, saving time filtering through hours of data. 17.1 Import data from the SD card to the Search List screen.

  • Page 28: Google Maps

    16. PC Player – Google Map Google Map Interface The PC Player supports Google Map interface. User must have internet connection to view Google map data. Number Description Adjust Map size: + : Zoom in - : Zoom out View Mode: Map View Mode: Satellite View Mode: Street Current Position...

  • Page 29: Speed And G-Sensor Reports

    17. PC Player – Speed / G-Sensor Speed and G-Sensor Reports HD PC Player can generate detailed reports of recorded speed and G-Force impact data. These reports can be used for analyzing the driver’s driving patterns. 20.1 Click on “Big Chart” button in the G sensor screen to display below screens. Speed (MPH) G sensor Play Time...

  • Page 30: Screen Capture

    18. PC Player – Screen Capture Screen Capture Print/Save This function allows users to take screenshots of a incident or e.g. a number plate. The data can be easily be emailed as a detailed report along with location and G-Force data 21.1 Click on Screen Print to capture the picture.

  • Page 31: Eco Driver Report

    19. PC Player – ECO Driver Report ECO-Driver Report This report can provide information on the drivers driving behavior and bad habits. It can advise on how good or bad a driver is by scoring the recorded data. 21.1 Import data from the SD card to the Search List screen.

  • Page 32: Event Report

    20. PC Player – Event Report Create an Event Report This function allow users to take 4 screenshots of the build up to the incident. The data can be easily be emailed as a detailed report along with location and G- Force data.

  • Page 33: Gps Data Report

    21. PC Player – GPS Data Report GPS and G-Sensor Data Export This function will export the recorded GPS and G-Sensor shock data into Excel format. 23.1 Import data from the SD card to the Search List screen. (See pages 13 & 14, 4.3 onward) 23.2 Click on “Create DB”.

  • Page 34: Buzzer/Led Alert Warning

    22. Buzzer/LED Alert Warnings Warning LED Alert Buzzer Alert Red LED : On Booting Status Blue LED : Flash for apprx 10secs “beep, beep” sound Orange LED : Flash for apprx 10secs Red LED : On If SD card is not SD Card Insert inserted: Constant Blue LED : Constant Flashing...

  • Page 35: Sd Card Recording Times

    23. SD Card Recording Times H = Hour / M = Minutes Best High Normal Compact QUALITY (Default) PIXELS 1280x720 1280x720 1280x720 1280x720 Frame Per Sec. 30fps/30fps 25fps/25fps 15fps/15fps 10fps/10fps 1H20M 1H32M 2H00M 2H41M 2H41M 3H06M 4H00M 5H23M Memory 16GB 5H23M 6H12M 8H00M...

  • Page 36: Liability

    24. Liability Please read the follow liability information: 26.1 This product is offered for use on the provision that all guidelines, advice and recommendations are followed, and the device is used for its intended Purpose only. 26.2 You may not modify, reproduce, create derivative works from, transfer or sell , any information, software, products or services without the express permission of the manufacturer.

  • Page 37: Camera Precautions

    25. Camera Precautions Please read the camera precaution information below: 27.1 Do not open/fix/alter this device. Any customer alterations will void the warranty. 27.2 Do not use any accessories other than those provided with the product. The use of any additional accessories will void the product warranty. 27.3 Do not connect the device directly to car’s battery.
  • Page 38 25. Camera Precautions Continued... 27.8 Check the product regularly to ensure that the camera lens angle is properly adjusted. Always check when replacing the camera into the bracket. After violent force is applied to the vehicle or product, the camera angle may be altered resulting in poor picture quality.

  • Page 39: Sd Card Precautions

    26. SD Card Precautions IMPORTANT: Format the SD card at least once every 2-4 weeks for optimal performance. See page 12 for How to Format a SD Card) 28.1 Check SD card’s data regularly to ensure the camera is recording correctly. 28.2 Backup the data regularly if any data needs to be saved for future reference or as evidence.

  • Page 40: Trouble Shooting

    27. Trouble Shooting Problem Solution - Check the power cable connection to the camera. - Check the power cable fuse. - Check the power cable connection to vehicle power source. Camera has - If all power connections are correct then remove SD Card, re-insert and No Power turn the ignition on.
  • Page 41 27. Trouble Shooting Problem Solution - Check the correct and latest PC Player version is being used. - Open a single clip by File Open button instead of Folder Open button. - If videos are too dark, please raise the brightness in the setting configuration Recorded - Back up any data required, format the SD card and continue to record.
  • Page 42 27. Trouble Shooting Problem Solution - Check event recording settings in the PC Player setting menu. Sensitivity might be to low. Event recordings will not be triggered by small or minor impact. Press Manual button to trigger a Event recording. Event - Back up any data required, format the SD card and continue to record.

  • Page 43: Specification

    28. Specification and Accreditations List Description Camera 2M Pixel CMOS Image Sensors Front View: 120 ° view / Internal View: 149 ° view View-Angle Internal GPS G-Sensor Internal 3G Sensor (X, Y & Z) Forward: MPEG4 - 2M Pixel 20 fps at 1280x720 (HD) resolution Video Internal: MPEG4 –...

  • Page 44: Warranty

    3. Warranty: one year 4. Life time of SD Card: 6 months. AVIC WILL NOT BE HELD LIABLE FOR ANY INDIRECT OR CONSEQUENTIAL LOSS OR DAMAGE (WHETHER FOR LOSS OR BUSINESS OR OTHERWISE) COSTS, EXPENSES OR OTHER CLAIMS, WHICH ARISE OUT OF OR IN CONNECTION WITH THE USE OF THE DEVICE.
