User Manual ver 1.10
Please read carefully before using this product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the View-i HD and is the answer not in the manual?

Questions and answers

Related Manuals for Avic View-i HD

Summary of Contents for Avic View-i HD

  • Page 1 User Manual ver 1.10 Please read carefully before using this product.

  • Page 2: Table Of Contents

    Table of Contents Liability Precautions Components Functions Features Installation Product Manual PC Player Manual Product Trouble-Shooting 10. Specifications and Certifications 11. Warranty...

  • Page 3: Liability

    1. Liability 1. This product was designed to assist you in driving safely by recording driving information and data for by recording driving information and data for driver reference. 2. This product does not guaranteed to record information on every accident. - A minor force will not trigger the G-Force sensor to activate Event Recording.

  • Page 4: Precautions

    2. Precautions (Device) Do not open/fix/alter this device Do not spray automobile cleaning products Any customer alterations will void the directly to product warranty Product will be damaged if directly exposed to cleaning products Do not use any accessories other then those included with the recorder Do not operate product while driving The use of any additional accessories will...
  • Page 5 2. Precautions (Micro SD Card) Only use MicroSD memory card from the manufacturer Product may not function correctly if un-tested MicroSD memory cards is used Do not open/fix/modify MicroSD memory card Do not open/fix/modify MicroSD memory card Product could be damaged and warranty does not cover such damage. MicroSD memory card need to be replaced with a new product after 6month use or more Product might malfunction if MicroSD card’s writing speed decreases.

  • Page 6: Components

    3. Product Package Please contact your sales vendor if your are missing any components or components are at fault Manual MicroSD Card + Adopter Cigar jack Device User Manual (Include PC Player) Power Cable Rear View Camera IR Lighting Mount & Wire Clip (Include in Certain (Include in Certain...

  • Page 7: Functions

    4. Functions Function Description Records everything during device power on status [NOTE] If memory exceeds its capacity, device deletes oldest file to make Normal Recording room for new recordings. Therefore, if user wants to keep the old recordings, user must backup the recordings before they are automatically deleted When device detects exceeded force in the device, device automatically saves Event 10 seconds before and after of the triggered event.
  • Page 8 4. Functions Function Description Additional camera can be connected via “Video-in” port to enable 2 camera Additional recording Wire Camera (for device including 2 cameras, 2 camera can be toggled between on-device and wire input camera) Status LED Blinking status LED is positioned in front of the device to alert other as a warning Sound Device will guide users via sound communication for easier product experience Guidance...

  • Page 9: Features T

    5. Features Name Description ① Power Port DC 12V~24V ② Internal GPS Detect GPS info, time, and speed ③ Front Camera 2M Pixel CMOS Image Sensor ④ Mini USB Port 5V 400mA power input ⑤ Video-in Port Connect wire camera for rear view or other angles Preview/Replay recorded files to ⑥...

  • Page 10: Installation

    6. Installation 6.1 Recommendation Place device near rear view mirror to the driver side where GPS and Camera does not have physical interrupts (sedan standard) d d) [Caution] Placing device other then recommended area may cause foul recording or GPS reception problem.
  • Page 11 6. Installation 6.4 Attaching Device to the Window • Attach Device to h D i • Connect power plug to the device t th d i • Organize power cable with recommended area and plug in cigar jack power wire clip IR LED Attachment (RUBY Product) •...
  • Page 12 6. Installation 6.5 Installing rear view camera • Guide cables as shown in above picture in G id • Plug in cable to device’s “Video-In” port installation [Caution #1] Do not power on the device during cable connection. Device will not recognize rear view camera if device is turned on and lead to malfunction. [Caution #2] Remove all substance from the lens, including the plastic film, that may affect the quality of the recording.

  • Page 13: Product Manual

    7. Product Manual Function Description Sound Short Push this button to trigger event recording. Event Recording Ding-dong~ Push Record each 10secconds before and after of trigger. Trigger / ① Memory Format Push over 3 seconds to start memory formatting. Long Button “Ding”...
  • Page 14 7. Product Manual 7.1 Buzzer/LED Scenario Name Name Sound Sound Red LED : On Booting Status Ding-dong Blue LED : On Yellow LED : On Red LED : On If SD card is not inserted, SD Card Device will make “Ding” Blue LED : On Insert Status sound every second...

  • Page 15: Pc Player Manual Y

    8. PC Player Manual This part of the manual explains the use of PC Player, video and utility player. With PC Player, user may view the contents of products. * Windows Media Player and other player may show videos but G-Sensor, GPS, MAP, Report functions can only be used in PC Player.
  • Page 16 8. PC Player Manual 8.3 PC Player Double click on “icon” to view the below screen. Name Description ① Front Video Screen Display front video recordings ② Second Video Screen Display second video recordings ③ Search Search recorded files based on user preference Speed-o-meter / Display driving speed ④...
  • Page 17 8. PC Player Manual 8.4 Buttons Button Button Description Description Button Button Description Description Previous File Open 1 file Rewind Print Screen Play ECO-Drive Report Pause Event Report Stop Setting Fast-forward Next File 8.5 Control Bar Front video brightness adjustment Second video brightness adjustment Volume Control : Video volume control with mute function...
  • Page 18 8. PC Player Manual 8.6 Open File / Play • Recorded contents can be found inside device’s SD card. Constant files can be found under “NORMAL” folder / folder name under date/hour Constant files can be found under NORMAL folder / folder name under date/hour. •...
  • Page 19 8. PC Player Manual 8.7 File List Screen Name Description Folder Open a folder with recorded ① Open videos Chain Play button for continual playing of ② Play checked listed files File name consist of date/hour of recordings. EVT121019 113241 1 EVT121019_113241_1.mp4 File ③...
  • Page 20 8. PC Player Manual 8.8 Search - DB 1. Import play list to the Search screen (Reference : 8.6 Open File / Play) 2. Click on “Create DB” to make database *Database must be created before searching 3. Select search option and click “Search” button 4.
  • Page 21 8. PC Player Manual 8.9 Screen Composition Name Description ① Video Screen Video play screen of designated video file ② G-Sensor Screen G-sensor data of video screen for user analysis Speed-o-Meter / Display driving speed ③ Menu Menu Button listing for video and menu control Button listing for video and menu control Displays file name and recording type ④...
  • Page 22 8. PC Player Manual 8.10 Google Map Interface 1. PC Player supports Google Map interface Internet must be connected for Google map interface 2. Navigate through Goggle Map with mouse cursor Number Description Adjust Map size ① + : Zoom in - : Zoom out View Mode ②...
  • Page 23 8. PC Player Manual 8.11 Road Track® 1. Road Track™ shows driving path of selected files. In order to use this function, user must first call in the video files and create a database first. 2. After creating the database, click on button 3.
  • Page 24 8. PC Player Manual 8.12 Speed/G-Sensor 1. PC Player supports detailed view of speed and G-Sensor data 2. Click on “Big Chart” button in the G-sensor screen to display below pop-up screens Speed (Km/H) G sensor Play Time Play Time Play Time Play Time G-Sensor...
  • Page 25 8. PC Player Manual 8.13 Screen Capture Print/Save 1. PC Player supports screen capture function which can print / save specific screen of user choice 2. Click on button to view the screen below Description Description ① ③ G Sensor Data PRINT button for image print SAVE button for create JPEG image ②...
  • Page 26 8. PC Player Manual 8.14 ECO-Driver Report 1. Create database from user selected video files 2. Click “ECO-Drive Report” button 3. Input basic user information and click “Make Report” button to create a report 4. Use “Excel” and “Preview” button to save the report to a file or print...
  • Page 27 8. PC Player Manual 8.15 Event Report 1. Click on “Event Report” button to retrieve the image capture screen 2. Click on the “Add” button to save 4 different video screen and click on “Next” button 3. Use “Clear” button to remove selected screens 4.
  • Page 28 8. PC Player Manual 8.16 Setting - Open 1 Click on 1. Click on button button 2. Select “system/user_setup.cfg” file in your SD Card 3. Click on “Open” button. 1. Express setting allows for quick and easy 8.16.1 Setting - Express device configuration Name Name...
  • Page 29 8. PC Player Manual 8.16.2 Setting - Expert Name Description Best : ① Use 1CH 1280X720P@30fps Video Quality Use 2CH 1280X720P@15fps ② Brightness (Dark)-4 ~ +4(Bright) G Sensor G-Sensor 0 1 2 0 0.1~2.0 ③ Sensitivity (Low=sensitive / High=dull) Event 5~10 sec for before and after ④...

  • Page 30: Product Trouble-Shooting

    9. Product Trouble-Shooting Symptom Solution Please check power cable connection to the device Please check power cable connection to vehicle power source Please check power switch on the device No Power If all power connections are correct then remove MicroSD Card and re-insert and try again If you have attempted the above remedies, and the device is still not working properly, please contact your dealer Please check to see if MicroSD card is correctly inserted...

  • Page 31: Specifications And Certifications

    MicroSD Card (Max 32GB) PC Viewer HD PC Player, Windows Media Player, and more 12V~24V DC ±10% Voltage Size 52(W) x 94(H) x 18(D)mm Weight Less than 68g Manufacturer AVIC Imaging Inc. / Manufactured in South Korea Certification KCC / FCC / CE...

  • Page 32: Warranty

    Name Serial Number Phone Email Address Purchase Dealer Date Guarantee 1. AVIC Imaging Inc. grants the following warranty period on the product commencing on the date of purchase on the date of purchase. 2. Warranty Period : see store policy...
  • Page 33 Screens and pictures may differ in product use View-i® HD...
