Page 9 Welcome Thank you for purchasing our DVR! This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about this series hybrid standalone DVR features and functions, as well as a detailed menu tree. Before installation and operation please read the following safeguards and warnings carefully! viii...
Page 10: Important Safeguards And Warnings
Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. The product must be grounded to reduce the risk of electric shock. We assume no liability or responsibility for all the fires or electric shock caused by improper handling or installation.
Page 11: Features And Specifications
FEATURES AND SPECIFICATIONS 1.1 Overview The hybrid standalone series DVR is an excellent digital monitor product designed for security field. It adopts embedded Linux OS to maintain reliable operation. Popular H.264 compression algorithm and G.711 audio compression technology realize high quality, low bit stream. Unique frame by frame play function is suitable for detailed analysis.
Page 12: Specifications
 Backup function Support backup operation via USB port (such as U disk, portable HDD, burner) Client-end user can download the file to local HDD to backup via network. Support eSATA, SATA port backup (eSATA port can connect to burner or HDD, SATA port can connect to burner.) ...
Page 13: Advanced 960H Series
1.3.4 Advanced 960H Series 4-ch 8-ch 16-ch Parameter High-performance industrial embedded micro controller Main Processor System Embedded LINUX System Multiplex operations: Multiple-channel record, multiple-channel Resources playback and network operation simultaneously Interface User-friendly graphical user interface Input Devices Front panel, USB mouse, remote control Arabic number, English character, donation and extension Chinese Input Method (optional)
Page 14 4-CH composite 8-CH composite video 16-CH composite video input: input: (NTSC/PAL) video input: 75Ω) Video Input (NTSC/PAL) BNC (1.0V (NTSC/PAL) P- P, 75Ω) 75Ω) (1.0V (1.0V P- P, P- P, Video monitor Total 8 channels (4 Total 16 channels (8 IP Total 32 channels (16 channels+4 channels+8...
Page 15 Zone setup: support max 396(22×18) zones. Motion Support various sensitivities. Detection Image Quality 6-level image quality (Adjustable) Privacy mask Support one privacy mask of user-defined size in full screen. Support max 4 zones. Image Channel information, time information and privacy mask zone. Information TV Adjust Adjust TV output zone suitable to anamorphic video.
Page 16 Various File Can switch to previous or next file or any file in current play list. Switch Ways Can switch to file on other channel of the same time. (If there is a file) Support file continuous play, when file is end system auto plays the next file in the current channel Playback Way Support mark playback...
Page 17 Manual Alarm Enable or disable alarm input channel Control Support analog alarm signal to specific alarm output channel. 8-ch alarm input （ You can 4-ch alarm input（You 16-ch alarm input （ You can set can set normal open normal open or normal close type normal close...
Page 18: Series
User-friendly interface when login. Provide the following options: Logout /shutdown/ restart. Right authentication when shut down to make sure only those proper people can turn off DVR Power AC90~264V 50+2% Hz(Max. 220W) Power General Consumption 25W (Exclude HDD) Parameter Working -10℃－＋55℃...
Page 19 1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output. Video monitor 1-ch VGA output. 2-ch HDMI output. Output the same video sources as the VGA/TV. Video Output Support mouse operation. 1-ch matrix output 4/8/16-ch loop output Support TV/VGA/HDMI/SPOT OUT/loop output at the same time. Video Standard Support PAL /NTSC Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s...
Page 20 Network Total 32 channels. Channel 16 IP channels+16 analog channels. Amount Network 160Mbps Bandwidth 16-ch 200-2000mv 10KΩ (BNC) Audio Audio Input 1-ch audio output 200-3000mv 5KΩ(BNC) Audio Output Bidirectional 1-ch audio input 200-3000mv 10KΩ(BNC) Audio 1-ch audio output 200-3000mv 5KΩ(BNC) Hard Disk 16 built-in SATA port.
Page 21 function Support peripheral USB backup device. (Flash disk, portable disk, USB burner and etc.) Support external eSATA device backup Support network download and save View monitor channel remotely. DVR configuration through client-end and web browser Upgrade via client or browser to realize remote maintenance. Network View alarm information such as external alarm, motion detection and Function...
Page 22: Raid Series
Data Stream Data stream statistics for each channel (in wave mode) Statistics Backup to 1024 log files. Log statistics Support various search engines such as time and type. Display version information: channel amount, alarm input and output Version amount, system version and release date. Display current on-line user On-line user Remote device...
Page 23 High-performance industrial embedded micro controller Main Processor System Embedded LINUX System Multiplex operations: Multiple-channel record, multiple-channel Resources playback and network operation simultaneously Interface User-friendly graphical user interface Input Devices Front panel, USB mouse, remote control Arabic number, English character, donation and extension Chinese Input Method (optional) Shortcut...
Page 24 Playback 1/16-ch: 960H 960×576/960×480, 704×576/704×480, HD1 352×576/352×480, 2CIF 704×288/704×240, 352×288/ 352×240, QCIF 176×144/176×120 Support dual streams: extra stream resolution CIF 352×288/ 352×240 , QCIF 176×144/176×120 Zone setup: support max 396(22×18) zones. Motion Support various sensitivities. Detection Image Quality 6-level image quality (Adjustable) Privacy mask Support one privacy mask of user-defined size in full screen.
Page 25 Playback Repeat Way When hard disk is full, system can overwrite previous video file. Record Search Various search engines such as time, type and channel. Playback Mode Various fast play, slow play speeds, manual frame by frame playback and reverse play mode. Various File Can switch to previous or next file or any file in current play list.
Page 26 Motion 4 zone setups: support 396((PAL 22×18, NTSC 22×15)) detection Motion Detection zones. Detection and Various sensitivity levels and threshold setups. Alarm Alarm can activate record or external alarm or screen message prompt. Once any of the four zones is triggered, the motion detect of current channel is valid now.
Page 27 Password modification Administrator can modify other user’s password. Password Authentication Account lock strategy Five times login failure in thirty minutes may result in account lock. Upgrade Web browser, client-end and update tool. Password login protection to guarantee safety User-friendly interface when login. Provide the following options: Login, Logout and Shutdown Logout /shutdown/ restart.
Page 28: Overview And Controls
2 Overview and Controls This section provides information about front panel and rear panel. When you install this series DVR for the first time, please refer to this part first. 2.1 Front Panel 2.1.1 2U Series This series products’ front panel is shown as below. See Figure 2-1. Figure 2-1 Please refer to the following sheet for front panel button information.
Page 29 Activate current control, modify setup, and then move up and down. 、 Increase/decrease numeral. Down Assistant function such as PTZ menu. Shift current activated control, and then move left and right. Left/   Right When playback, click these buttons to control playback bar. Go to previous menu, or cancel current operation.
Page 30 For 4/8/16 channel device: indication light on means that the channel is in recording. For 32 channel device: Record light 1-32 Indication Light on: 1-16 channel is in recording Indication Light flashes: 17-32 channel is in recording Indication Light normally on: the corresponding channels are in recording Remote control...
Page 31: Connection Sample
2.2.6 Figure 2-9 Please refer to the following sheet for detailed information. Power on-off button Loop output Video input port Power input socket Audio input (The 1 to the 4 channel) DB25 port (The 5 to the 16 Audio output port channel audio input port) Bidirectional talk input port Bidirectional talk output port...
Page 32 General Series...
Page 33 HD-SDI Series...
Page 34 960H Series...
Page 35: Remote Control
2U RAID Series Figure 2-10 2.4 Remote Control The remote control interface is shown as in Figure 2-11. Please note remote control is not our standard accessory and it is not included in the accessory bag.
Page 36 Figure 2-11 Serial Number Name Function Power button Click it to boot up or shut down the device. Address Click it to input device number, so that you can control it. Forward Various forward speeds normal speed playback. Slow play Multiple slow play speeds or normal playback.
Page 37: Mouse Control
click this button to realize normal playback. In reverse playback click this button to pause playback. Esc. Go back to previous menu or cancel current operation (close upper interface or control) Record Start or stop record manually In record interface, working with the direction buttons to select the record channel.
Page 38 When you have selected one menu item, left click mouse to view menu content. Implement the control operation. Modify checkbox or motion detection status. Click combo box to pop up drop down list In input box, you can select input methods. Left click the corresponding button on the panel you can input numeral/English character (small/capitalized).
Page 39: Virtual Keyboard & Front Panel
Right click In real-time monitor mode, pops up shortcut menu: one-window, mouse four-window, nine-window and sixteen-window, Pan/Tilt/Zoom, color setting, search, record, alarm input, alarm output, main menu. Among which, Pan/Tilt/Zoom and color setting applies for current selected channel. If you are in multiple-window mode, system automatically switches to the corresponding channel.
Page 40: Installation And Connections
3 Installation and Connections Note: All the installation and operations here should conform to your local electric safety rules. 3.1 Check Unpacked DVR When you receive the DVR from the forwarding agent, please check whether there is any visible damage. The protective materials used for the package of the DVR can protect most accidental clashes during transportation.
Page 41: Rack Installation
8. Insert the power wire 7.Loosen the HDD power wire 9. Connect HDD to SATA port with inside the DVR. specified data line, then put the cover on the box and fix it firmly. Note:  You can connect the HDD data cable and the power cable first and then fix the HDD in the device.
Page 42: Connecting Video Output
Guarantee the stability and reliability of the camera signal: The camera shall be installed in a cool, dry place away from direct sunlight, inflammable, explosive substances and etc. The camera and the DVR should have the same grounding to ensure the normal operation of the camera.
Page 43: Alarm Input And Output Connection
 Adjust the layout to reduce happening of the squeaking. 3.6 Alarm Input and Output Connection Please read the followings before connecting. 1. Alarm input a. Please make sure alarm input mode is grounding alarm input. b. Grounding signal is needed for alarm input. c.
Page 44: Alarm Input Port
Figure 3-1 In the first line, from ALARM 1 to ALARM 16. The alarm becomes active in low voltage. the left to the right,: 1，2，3，4，5，6， 7，8，9，10，11， 12，13，14，15，16 In the second line, The first four are four groups of normal open activation output (on/off from the left to the button) right:...
Page 45: Alarm Output Port
Figure 3-2 3.6.3 Alarm Output Port  Provide external power to external alarm device.  To avoid overloading, please read the following relay parameters sheet carefully.  RS485 A/B cable is for the A/B cable of the PTZ decoder.  T+,T-,R+,R- are four-wire double duplex RS485 port.
Page 46: Rs485
3.7 RS485 When the DVR receives a camera control command, it transmits that command up the coaxial cable to the PTZ device. RS485 is a single-direction protocol; the PTZ device can’t return any data to the unit. To enable the operation, connect the PTZ device to the RS485 (A,B) input on the DVR.
Page 47: Overview Of Navigation And Controls
4 Overview of Navigation and Controls 4.1 Boot up and Shutdown 4.1.1 Boot up Before the boot up, please make sure:  The rated input voltage matches the device power on-off button. Please make sure the power wire connection is OK. Then click the power on-off button. ...
Page 48: Startup Wizard
4.2 Startup Wizard After device successfully booted up, it goes to startup wizard. Click Cancel/Next button, you can see system goes to login interface. Tips Check the box Startup button here, system goes to startup wizard again when it boots up the next time.
Page 49 Note: For security reason, please modify password after you first login. Within 30 minutes, three times login failure will result in system alarm and five times login failure will result in account lock! Click OK button, you can go to General interface. See Figure 4-3. For detailed information, please refer to chapter 4.10.5.1.
Page 50 Figure 4-4 Click Next button, you can go to remote device interface. See Figure 4-5 For detailed information, please refer to chapter 4.10.1.1. Figure 4-5 Click Next button, you can go to Schedule interface. See Figure 4-6.
Page 51: Manual Record
For detailed information, please refer to chapter 4.10.4.1.1. Figure 4-6 Click Finish button, system pops up a dialogue box. Click the OK button, the startup wizard is complete. See Figure 4-7. Figure 4-7 4.3 Manual Record 4.3.1 Live Viewing After you logged in, the system is in live viewing mode. You can see system date, time, channel name and window No.
Page 52 Recording status Video loss Motion detection Camera lock Tips  Preview drag: If you want to change position of channel 1 and channel 2 when you are previewing, you can left click mouse in the channel 1 and then drag to channel 2, release mouse you can switch channel 1 and channel 2 positions.
Page 53 Realtime playback It is to playback the previous 5-60 minutes record of current channel. Please go to the Main menu->Setting->->System->General to set real-time playback time. System may pop up a dialogue box if there is no such record in current channel. Digital zoom It is to zoom in specified zone of current channel.
Page 54: Right-Click Menu
Please note this function is for one-window mode only. Bidirectional talk (For digital channel only) If the connected front-end device supports bidirectional talk function, you can click this button. Click button to start bidirectional talk function the icon now is shown as Now the rest bidirectional talk buttons of digital channel becomes null too.
Page 55: Pip
Figure 4-13 4.4.2 PIP It is to realize picture in picture function in 1-window mode. The small window supports instance playback, digital zoom and etc.  Window switch: Double click the small window, you can switch the position of the large window and the small window.
Page 56: Ptz Control
Figure 4-14 Figure 4-15 Go to the 1-winode mode, on the navigation bar, click , you can see the video on the large window and the video from the next channel is the default video on the small window. If you have set PIP function, you can click to view the last edited PIP video.
Page 57 The PTZ operation is only valid in one-window mode. Here you can control PTZ direction, speed, zoom, focus, iris, preset, tour, scan, pattern aux function, light and wiper, rotation and etc. Speed is to control PTZ movement speed. The value ranges from 1 to 8.The speed 8 is faster than speed 1.
Page 58 Figure 4-18 Please refer to the following sheet for detailed information. Please note the above interface may vary due to different protocols. The button is grey and can not be selected once the current function is null. Right click mouse or click the ESC button at the front panel to go back to the Figure 4-16.
Page 59 Figure 4-19 Preset Setup In Figure 4-19, click preset button and use eight direction arrows to adjust camera to the proper position. The interface is shown as in Figure 4-20. Click Set button and then input preset number. Click Set button to save current preset. Figure 4-20 Tour Setup In Figure 4-19, click tour button.
Page 60 Figure 4-21 Pattern Setup In Figure 4-19, click Pattern button and input pattern number. Click Begin button to start direction operation. Or you can go back to Figure 4-16 to operate zoom/focus/iris/direction operation. In Figure 4-19, click End button. Figure 4-22 Scan Setup In Figure 4-19, click Scan button.
Page 61 Figure 4-23 4.4.3.2 Call PTZ Function Call Preset In Figure 4-18, input preset value and then click to call a preset. Click again to stop call. Call Pattern In Figure 4-18, input pattern value and then click to call a pattern. Click again to stop call.
Page 62: Auto Focus
Click , system goes to the following interface. The options here are defined by the protocol. The aux number is corresponding to the aux on-off button of the decoder. See Figure 4-24. Figure 4-24 4.4.4 Auto Focus It is to set auto focus function. Please make sure the camera supports this function. 4.4.5 Color Here you can set hue, brightness, contrast, saturation, gain, white level, color mode and etc.
Page 63 Item Note Period There are two periods in one day. You can set different sharpness, brightness, and contrast setup for different periods. Effective Time Check the box here to enable this function and then set period time. The value here is to adjust the edge of the video. The value ranges from 0 to 100.
Page 64: Search
Item Note noise may become too clear. Color mode It includes several modes such as standard, color, bright, gentle. Select a color mode, the sharpness, brightness, contrast automatically switch corresponding setup. 4.4.6 Search Please refer to chapter 4.8.1 for detailed information. 4.4.7 Record Control Please refer to chapter 4.10.4.3 for detailed information.
Page 65: Favorites
Go to the 1-winode mode, click , you can see the video on the large window and the video from the next channel is the default video on the small window. If you have set PIP function, you can click to view the last edited PIP video.
Page 66: Channel Tree
Figure 4-29 Double click a name; you can change its name. See Figure 4-30. Input a new name and then click OK button. Figure 4-30 4.5.5 Channel Tree It is to set channel setup. The interface is shown as below. See Figure 4-31.
Page 67: Tour
Figure 4-31 The one level includes 16 channels. See Figure 4-32. You can left click to select a channel on the tree and then drag it to the preview window on the left pane. Once the channel is on the preview window, the channel number on the channel tree becomes grey and it is null now (can not be selected).
Page 68: Search
4.5.9 Search Click button , system goes to search interface. Please refer to chapter 4.8.1 4.5.10 Alarm Status Click button , system goes to alarm status interface. It is to view device status and channel status. Please refer to chapter 4.10.3. 4.5.11 Channel Info Click button , system goes to the channel information setup interface.
Page 69: Usb Device Auto Pop-Up
， system goes to the USB Manager interface. It is to view USB information, Click backup and update. Please refer to chapter 4.8.2, chapter 4.9.4, chapter 4.10.5.10, and chapter 4.10.5.12 for detailed information. 4.6 USB Device Auto Pop-up After you inserted the USB device, system can auto detect it and pop up the following dialogue box.
Page 70: Operation
Figure 4-35 4.8 Operation 4.8.1 Search Click search button in the main menu, search interface is shown as below. See Figure 4-36. Usually there are three file types:  R: Regular recording file.  A: External alarm recording file.  M: Motion detection recording file...
Page 71 Figure 4-36 Please refer to the following sheet for more information. Name Function  Display Here is to display the searched picture or file.  window Support 1/4/9/16-window playback.  Here you can select to search the picture or the recorded file. ...
Page 72  pane. In 16-window playback mode, you can switch between1-16 and 17-32 channels.  The time bar will change once you modify the playback mode or the channel option. The card number search interface is shown as below. Here you can view card Card number/field setup bar.
Page 73 In playback mode, click it to realize various slow play modes such as slow play 1, slow play 2, and etc. Fast forward  In playback mode, click to realize various fast play modes such as fast play 1,fast play 2 and etc. Note: The actual play speed has relationship with the software version.
Page 74  For one device, if there is a backup in process, you can not start a new backup operation.  It is to edit the file. ●Please play the file you want to edit and then click this button when you want to edit.
Page 75 channel This function is null if there is no record file or system is in smart search process. when playback 4.8.1.1 Smart Search During the multiple-channel playback mode, double click one channel and then click the button, system begins smart search. System supports 396(22*18 PAL) and 330(22*15 NTSC) zones.
Page 76 Note  After you searched files, system implement accurate playback once you click Play for the first time.  System does not support accurate playback for picture.  System supports synchronization playback and non-synchronous playback. The synchronization playback supports all channels and non-synchronous playback only supports accurately playback of current select channel.
Page 77: Backup
 Play before mark time Here you can set to begin playback from previous N seconds of the mark time. Note Usually, system can playbacks previous N seconds record if there is such kind of record file. Otherwise, system playbacks from the previous X seconds when there is such as kind of record.
Page 78 eSATA. Here we introduce USB, eSATA backup. You can refer to Chapter 7 Web Client Operation for network download backup operation. Click backup button, you can see an interface is shown as in Figure 4-41. Here is for you to view devices information. You can view backup device name and its total space and free space.
Page 79 Figure 4-42 √ before channel name. You can use Fn or cancel System only backup files with a button to delete √ after file serial number. Click Start button, system begins copy. At the same time, the backup button becomes stop button.
Page 80: Shut Down
When the system completes backup, you can see a dialogue box prompting successful backup.  File format: Click the file format; you can see there are two options: DAV/ASF. The file name format usually is: Channel number+Record type+Time. In the file name, the YDM format is Y+M+D+H+M+S.
Page 81 Figure 4-45 4.9.1.1 HDD Information Here is to list hard disk type, total space, free space, video start time and status. See Figure 4-46.  SATA: 1-8 here means system max supports 8 HDDS. ○ means current HDD is normal. X means there is error. - means there is no HDD. If disk is damaged, system shows as “?”.
Page 82 Figure 4-46 Double click one HDD information; you can see the HDD SMART information. See Figure 4-47. Figure 4-47 4.9.1.2 Record Info It is to view record start time and end time. See Figure 4-48.
Page 83 Figure 4-48 4.9.1.3 BPS Here is for you to view current video data stream (KB/s) and occupied hard disk storage (MB/h). See Figure 4-49. Figure 4-49 4.9.1.4 Version Here is for you to view some version information such as version number, built date, serial number and etc.
Page 84: Event
Figure 4-50 4.9.2 Event It is to display device status and channel status. See Figure 4-51. Figure 4-51 4.9.3 Network 4.9.3.1 Online Users Here is for you to manage online users. See Figure 4-52.
Page 85: Figure
You can disconnect one user or block one user if you have proper system right. Max disconnection setup is 65535 seconds. System detects there is any newly added or deleted user in each five seconds and refresh the list automatically. Figure 4-52 4.9.3.2 Network Load Network load is shown as in Figure 4-53.
Page 86: Figure
Figure 4-53 4.9.3.3 Network Test Network test interface is shown as in Figure 4-54.  Destination IP: Please input valid IPV4 address or domain name.  Test: Click it to test the connection with the destination IP address. The test results can display average delay and packet loss rate and you can also view the network status as OK, bad, no connection and etc.
Page 87: Log
Figure 4-54 4.9.4 Log Here is for you to view system log file. System lists the following information. See Figure 4-55. Log types include system operation, configuration operation, data management, alarm event, record operation, account manager, log clear, file operation and etc. It optimized reboot log.
Page 88: Setting
Figure 4-55 Select an item on the list and then click the Details button or double click the log item, you can view the detailed information such as log time, log type, log user, IP address and etc. See Figure 4-56. Figure 4-56 4.10 Setting 4.10.1 Camera...
Page 89 4-57. Here you can add/delete remote device and view its corresponding information.  Device search: Click it to search IP address. It includes device IP address, port, device name, manufacturer, type. Use your mouse to click the item name, you can refresh display order.
Page 90 Click the Manual Add button; you can go to the following interface. See Figure 4-58. Channel number：The dropdown list here displays unconnected channel number. You can go to Figure 4-57 to set remote channel connection. Please note:  This series product supports the IPC from many popular manufactures such as Sony, Hitachi, Axis, Samsung, Dynacolor, Arecont, Onvif and Dahua.
Page 91 Figure 4-59 4.10.1.1.3 Firmware It is to view channel, IP address, manufacturer, type, system version, SN, video input, audio input, external alarm and etc. See Figure 4-60. Figure 4-60 4.10.1.1.4 Remote Upgrade It is to update the camera. From main menu->setting->camera->remote, the interface is shown as below. See Figure 4-61.
Page 92 upgrade is finish. Figure 4-61 4.10.1.2 Image The image interface is shown as below. See Figure 4-62 (analog channel) and Figure 4-63 (digital channel).  Channel: Select a channel from the dropdown list.  Saturation: It is to adjust monitor window saturation. The value ranges from 0 to 100. The default value is 50.
Page 93 is noise if the value here is too high. The default value is 50 and the recommended value ranges from 40 to 60.  Mirror: It is to switch video up and bottom limit. This function is disabled by default. ...
Page 94 Figure 4-62 Figure 4-63 4.10.1.3 Encode It is to set video bit stream, picture bit stream, video overlay parameter and etc. 4.10.1.3.1 Video...
Page 95 Video setting includes the following items. See Figure 4-64.  Channel: Select the channel you want.  Type: Please select from the dropdown list. There are three options: regular/motion detect/alarm. You can set the various encode parameters for different record types. ...
Page 96 Figure 4-65 4.10.1.3.3 Overlay Overlay interface is shown as in Figure 4-66.  Cover area: Here is for you to set cover area. You can drag you mouse to set proper section size. In one channel video, system max supports 4 zones in one channel. ...
Page 97 Figure 4-66 Figure 4-67 4.10.1.3.4 Channel Name It is to modify channel name. It max supports 31-character. See Figure 4-68. Please note for digital channel, you can only modify the channel name of the connected network camera.
Page 98 Figure 4-68 4.10.1.3.5 Channel Type This function is for some series product only. It is to set channel type. Each channel supports analog connection/analog HD connection/network camera connection (Slight function difference may be found). The network camera connection shall begin with the last channel. Please note DVR needs to restart to activate new setup.
Page 99: Network
4.10.2 Network 4.10.2.1 TCP/IP The single network adapter interface is shown as in Figure 4-70 and the dual network adapters interface is shown as in Figure 4-71  Network Mode : Includes multiple access, fault tolerance, and load balancing  Multiple-address mode: eth0 and eth1 operate separately.
Page 100  MTU: It is to set MTU value of the network adapter. The value ranges from 1280-7200 bytes. The default setup is 1500 bytes. Please note MTU modification may result in network adapter reboot and network becomes off. That is to say, MTU modification can affect current network service.
Page 101 Figure 4-71 4.10.2.2 Connection The connection setup interface is shown as in Figure 4-72.  Max connection: system support maximal 128 users. 0 means there is no connection limit.  TCP port: Default value is 37777.  UDP port: Default value is 37778. ...
Page 102 Figure 4-72 4.10.2.3 WIFI The WIFI interface is shown as below. See Figure 4-73.  Auto connect WIFI: Check the box here, system automatically connects to the previous WIFI hotspot.  Refresh: You can click it to search the hotspot list again. It can automatically add the information such as the password if you have set it before.
Page 103  WIFI working status: Here you can view current connection status. Please note:  After successful connection, you can see WIFI connection icon at the top right corner of the preview interface.  When the hotspot verification type is WEP, system displays as AUTO since the device can not detect its encryption type.
Page 104 Figure 4-74 4.10.2.5 PPPoE PPPoE interface is shown as in Figure 4-75. Input “PPPoE name” and “PPPoE password” you get from your ISP (Internet service provider). Click save button, you need to restart to activate your configuration. After rebooting, DVR will connect to internet automatically. The IP in the PPPoE is the DVR dynamic value.
Page 105 4.10.2.6 DDNS Setup DDNS setup interface is shown as in Figure 4-76. You need a PC of fixed IP in the internet and there is the DDNS software running in this PC. In other words, this PC is a DNS (domain name server). In network DDNS, please select DDNS type and highlight enable item.
Page 106 The quick DDNS client has the same function as other DDNS client end. It realizes the bonding of the domain name and the IP address. Right now, current DDNS server is for our own devices only. You need to refresh the bonding relationship of the domain and the IP regularly.
Page 107 00aa: 00aa as aa:: aa: aa: aa: aa: aa: aa. System automatically removes space if there is any space before or after the newly added IP address. System only checks start address if you add IP address. System check start address and end address if you add IP section and the end address shall be larger than the start address.
Page 108 Figure 4-78 4.10.2.8 Email The email interface is shown as below. See Figure 4-79.  SMTP server: Please input your email SMTP server IP here.  Port: Please input corresponding port value here.  User name: Please input the user name to login the sender email box. ...
Page 109 Figure 4-79 4.10.2.9 FTP You need to download or buy FTP service tool (such as Ser-U FTP SERVER) to establish FTP service. Please install Ser-U FTP SERVER first. From “start” -> “program” -> Serv-U FTP Server -> Serv-U Administator. Now you can set user password and FTP folder. Please note you need to grant write right to FTP upload user.
Page 110 For example, you can login user ZHY to FTP://10.10.7.7 and then test it can modify H140H140H140 HTU or delete folder or not. See Figure 4-81. Figure 4-81 System also supports upload multiple DVRs to one FTP server. You can create multiple folders under this FTP.
Page 111: Figure
Figure 4-82 4.10.2.10 UPnP The UPNP protocol is to establish a mapping relationship between the LAN and the WAN. Please input the router IP address in the LAN in Figure 4-70. See Figure 4-83.  UPNP on/off ：Turn on or off the UPNP function of the device. ...
Page 112: Figure
same to guarantee the proper data transmission. Figure 4-83 Figure 4-84 4.10.2.11 SNMP SNMP is an abbreviation of Simple Network Management Protocol. It provides the basic network management frame of the network management system. The SNMP widely used in many environments. It is used in many network device, software and system. You can set in the following interface.
Page 113 Figure 4-85 Please enable the SNMP function. Use the corresponding software tool (MIB Builder and MG-SOFT MIB Browser. You still need two MIB file: BASE-SNMP-MIB, DVR-SNMP-MIB) to connect to the device. You can get the device corresponding configuration information after successfully connection. Please follow the steps listed below to configure.
Page 114 Figure 4-86 Here you can set a multiple cast group. Please refer to the following sheet for detailed information.  IP multiple cast group address -224.0.0.0-239.255.255.255 -“D” address space  The higher four-bit of the first byte=”1110”  Reserved local multiple cast group address -224.0.0.0-224.0.0.255 -TTL=1 When sending out telegraph -For example...
Page 115 Multiple cast PORT: 3666. After you logged in the Web, the Web can automatically get multiple cast address and add it to the multiple cast groups. You can enable real-time monitor function to view the view. Please note multiple cast function applies to special series only. 4.10.2.13 Alarm Centre This interface is reserved for you to develop.
Page 116 Figure 4-88 2) The proxy server software developed from the SDK. Please open the software and input the global setup. Please make sure the auto connection port here is the same as the port you set in the previous step. 3) Now you can add device.
Page 117: Event
Figure 4-89 4.10.3 Event 4.10.3.1 Detect In the main menu, from Setting->Event->Detect, you can see motion detect interface. See Figure 4-90. There are three detection types: motion detection, video loss, tampering.  The video loss has no detection region and sensitivity setup and tampering has no detection region setup.
Page 118  Region: Click select button, the interface is shown as in Figure 4-91. Here you can set motion detection zone. There are four zones for you to set. Please select a zone first and then left drag the mouse to select a zone. The corresponding color zone displays different detection zone.
Page 119  Record channel: System auto activates motion detection channel(s) to record once an alarm occurs. Please make sure you have set MD record in Schedule interface(Main Menu->Setting->Schedule) and schedule record in manual record interface(Main Menu->Advanced->Manual Record)  PTZ activation: Here you can set PTZ movement when an alarm occurs. Such as go to preset, tour &pattern when there is an alarm.
Page 120 Figure 4-90 Figure 4-91...
Page 121 Figure 4-92 Figure 4-93...
Page 122 Figure 4-94 Motion detect here only has relationship with the sensitivity and region setup. It has no relationship with other setups. 4.10.3.1.2 Video Loss In Figure 4-90, select video loss from the type list. You can see the interface is shown as in Figure 4-95.This function allows you to be informed when video loss phenomenon occurred.
Page 123 Figure 4-95 4.10.3.1.3 Tampering When someone viciously masks the lens, or the output video is in one-color due to the environments light change, the system can alert you to guarantee video continuity. Tampering interface is shown as in Figure 4-96. You can enable “Alarm output “or “Show message”...
Page 124 Figure 4-96 4.10.3.2 Alarm Before operation, please make sure you have properly connected alarm devices such as buzzer. In the main menu, from Setting->Event->Alarm, you can see alarm setup interface. See Figure 4-97. There are four alarm types. See Figure 4-97 to Figure 4-100. ...
Page 125  PTZ activation: Here you can set PTZ movement when alarm occurs. Such as go to preset, tour& pattern when there is an alarm. Click “select” button, you can see an interface is shown as in Figure 4-101.  Period: Click set button, you can see an interface is shown as in Figure 4-102. There are two ways for you to set periods.
Page 126  Snapshot: System can snapshot corresponding channel when an alarm occurs. Please note the activation snapshot has the higher priority than schedule snapshot. If you have enabled these two types at the same time, system can activate the activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot.
Page 127 Figure 4-98 . Figure 4-99...
Page 128: Figure
Figure 4-100 Figure 4-101...
Page 129: Figure
Figure 4-102 Figure 4-103 4.10.3.3 Abnormality There are two types: HDD/Network.  HDD: HDD error, no disk, no space. See Figure 4-104 and Figure 4-105.  Network: Disconnection, IP conflict, MAC conflict. See Figure 4-106.  Alarm output: Please select alarm activation output port (multiple choices). ...
Page 130: Figure
 Latch: Here you can set corresponding delaying time. The value ranges from 1s-300s. System automatically delays specified seconds in turning off alarm and activated output after external alarm cancelled.  Show message: system can pop up the message in the local screen to alert you when alarm occurs.
Page 131: Figure
Figure 4-105 Figure 4-106...
Page 132: Storage
4.10.3.4 Alarm Output Here is for you to set proper alarm output such as schedule, manual. Please highlight icon to select the corresponding alarm output. After all the setups please click OK button, system goes back to the previous menu. See Figure 4-107.
Page 133: Figure
 : Click it to delete a record type from one period.  Record Type: Please check the box to select corresponding record type. There are four types: Regular/MD (motion detect)/Alarm/MD&Alarm.  Week day: There are eight options: ranges from Saturday to Sunday and all. ...
Page 134 Figure 4-110 Please highlight icon to select the corresponding function. After completing all the setups please click save button, system goes back to the previous menu. There are color bars for your reference. Green color stands for regular recording, yellow color stands for motion detection and red color stands for alarm recording. The white means the MD and alarm record is valid.
Page 135 Figure 4-111 Figure 4-112 4.10.4.1.1.1 Quick Setup Copy function allows you to copy one channel setup to another. After setting in channel 1, click Copy button, you can go to interface Figure 4-113. You can see current channel name is grey such as channel 1. Now you can select the channel you wan to paste such as channel 5/6/7.
Page 136 Figure 4-113 4.10.4.1.1.2 Redundancy Redundancy function allows you to memorize record file in several disks. When there is file damage occurred in one disk, there is a spare one in the other disk. You can use this function to maintain data reliability and safety. ...
Page 137  In main menu, from Setting->Camera->Encode->Snapshot interface, here you can input snapshot mode as regular, size, quality and frequency. See Figure 4-115.  In main menu, from Setting->Camera->Encode->Schedule interface, please enable snapshot function. See interface on the right of Figure 4-116. Please refer to the following figure for detailed information.
Page 138 Figure 4-116 4.10.4.1.2.2 Trigger Snapshot Please follow the steps listed below to enable the activation snapshot function. After you enabled this function, system can snapshot when the corresponding alarm occurred.  In main menu, from Setting->Camera->Encode->Snapshot interface, here you can input snapshot mode as trigger, size, quality and frequency.
Page 139 Figure 4-118 Figure 4-119 4.10.4.1.2.3 Priority Please note the activation snapshot has the higher priority than schedule snapshot. If you have enabled these two types at the same time, system can activate the activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot.
Page 140 4.10.4.1.2.4 Image FTP In the main menu, from Setting->Network->FTP, you can set FTP server information. Please enable FTP function and then click save button. See Figure 4-120. Please boot up corresponding FTP server. Please enable schedule snapshot (Chapter 4.10.4.1.2.1) or activation snapshot (Chapter 4.10.4.1.2.2) first, now system can upload the image file to the FTP server.
Page 141 Figure 4-121 4.10.4.3 Record 4.10.4.3.1 Record Control Note: You need to have proper rights to implement the following operations. Please make sure the HDD has been properly installed. There are three ways for you to go to manual record menu. ...
Page 142 Figure 4-122 4.10.4.3.2 Snapshot Operation Check the corresponding box to enable/disable schedule snapshot function. See Figure 4-123. Figure 4-123 Tips You can check All button after the corresponding status to enable/disable all-channel snapshot function.
Page 143 4.10.4.4 Advanced It is to set HDD group, and HDD group setup for main stream, sub stream and snapshot operation 4.10.4.4.1 HDD Important HDD group and quota mode can not be valid at the same time. System needs to restart once you change the mode here. The HDD group mode is shown as in Figure 4-124.
Page 144 Figure 4-125 Figure 4-126...
Page 145 Figure 4-127 4.10.4.5 Quota Here you can set channel storage capacity. See Figure 4-128. Select a channel from the dropdown list and then select corresponding HDD quota. Figure 4-128...
Page 146 Click Quota Statistics, you can go to the following interface. You can view HDD capacity you set for each channel. See Figure 4-129. Figure 4-129 4.10.4.6 HDD Detect The HDD detect function is to detect HDD current status so that you can clearly understand the HDD performance and replace the malfunction HDD.
Page 147 Figure 4-130 4.10.4.6.2 Detect Report After the detect operation, you can go to the detect report to view corresponding information. The detect report interface is shown as below. See Figure 4-131. Figure 4-131...
Page 148 Click View, you can see the detailed information such as detect result, backup and S.M.A.R.T. See Figure 4-132 and Figure 4-133. Figure 4-132 Figure 4-133 4.10.4.7 RAID RAID function is for some series product such as 2U RAID series only.
Page 149 Right now system supports RAID0/RAID1/RAID5/RAID10. Please refer to Appendix H for detailed information. 4.10.4.7.1 RAID Config The RAID configuration interface is shown as in Figure 4-134. In this interface, you can set RAID type and settings.  Create manually: Check HDD manually to crate RAID. ...
Page 150: System
Figure 4-135 4.10.4.7.3 Hotspare Disk In this interface you can add/delete hotspare HDD. See Figure 4-136. Figure 4-136 4.10.5 System 4.10.5.1 General 4.10.5.1.1 Device General setting includes the following items. See Figure 4-137.
Page 151  Device ID: Please input a corresponding device name here.  Device No: Here you can set device number.  Language: System supports various languages: Chinese (simplified), Chinese (Traditional), English, Italian, Japanese, French, Spanish (All languages listed here are optional. Slight difference maybe found in various series.) ...
Page 152 Figure 4-137 4.10.5.1.2 Date and Time The interface is shown as in Figure 4-138.  Date format: There are three types: YYYYY-MM-DD: MM-DD-YYYYY or DD-MM-YYYY.  Date separator: There are three denotations to separate date: dot, beeline and solidus.  DST: Here you can set DST time and date.
Page 153 Figure 4-139 Figure 4-140 4.10.5.2 Display 4.10.5.2.1 Display Display setup interface is shown as below. See Figure 4-141.  Transparency: Here is for you to adjust transparency. The value ranges from 128 to 255.
Page 154  Channel name: Here is for you to modify channel name. System max support 25-digit (The value may vary due to different series). Please note all your modification here only applies to DVR local end. You need to open web or client end to refresh channel name.
Page 155 Figure 4-142 4.10.5.2.3 Tour Here you can activate tour function. Click Setup button, you can see an interface shown as in Figure 4-143  Enable tour: Highlight box here to enable this function.  Interval: System supports 1/8/-window tour. Input proper interval value here. The value ranges from 5-120 seconds.
Page 156  On the navigation bar, click to enable/disable tour function. Figure 4-143 4.10.5.2.4 Zero-channel Encoding Zero-Channel Encoding: Click Setup button, you can go to the following interface. See Figure 4-144.Here you can enable and set zero-channel encoding function so that you can view several video sources at one channel.
Page 157 Figure 4-144 4.10.5.3 Video Matrix Here you can set BNC/HDMI (HDMI port 2) output channel and its interval. See Figure 4-145 and Figure 4-146. Please note the HDMI port2 tour function is for some series product only.  Enable tour: Highlight box here to enable this function. ...
Page 158 Figure 4-145 Figure 4-146 4.10.5.4 RS232 RS232 interface is shown as below. There are five items. See Figure 4-147.
Page 159  Function: There are various devices for you to select. Console is for you to use the COM or mini-end software to upgrade or debug the program. The control keyboard is for you to control the device via the special keyboard. Transparent COM (adapter) is to connect to the PC to transfer data directly.
Page 160  Address: input corresponding PTZ address.  Baud rate: Select baud rate.  Data bit: Select data bit.  Stop bit: Select stop bit.  Parity: There are three choices: none/odd/even. After completed all the setups please click save button, system goes back to the previous menu.
Page 161 4.10.5.6 ATM/POS The ATM/POS function is for financial areas. It includes Sniffer, information analysis and title overlay function. The Sniffer mode includes COM and network. 4.10.5.6.1 COM Type The COM interface is shown as below. See Figure 4-150.  Protocol: Please select from the dropdown list. ...
Page 162 Figure 4-151 Without the protocol For the ATM/POS without the protocol, the interface is shown as in Figure 4-152. Source IP refers to host IP address that sends out information (usually it is the device host.) Destination IP refers to other systems that receive information. Usually you do not need to set source port and target port.
Page 163 4.10.5.7 Voice The audio function is to manage audio files and set schedule play function. It is to realize audio broadcast activation function. 4.10.5.7.1 File List Here you can add audio file, listen to the audio file, or rename/delete audio file. Here you can also set audio volume.
Page 164 4.10.5.7.2 Schedule It is to set schedule broadcast function. You can play the different audio files in the specified periods. See Figure 4-155. Figure 4-155 4.10.5.8 Account Here is for you to implement account management. See Figure 4-156. Here you can: ...
Page 165 rights such as monitor for this user so that you can view some channel view without login.  One user should belong to one group. User right can not exceed group right.  About reusable function: this function allows multiple users use the same account to login.
Page 166 4.10.5.8.1 Add/Modify Group Click add group button, the interface is shown as below. See Figure 4-157. Here you can input group name and then input some memo information if necessary. There are total 98 rights such as control panel, shut down, real-time monitor, playback, record, record file backup, PTZ, user account, system information view, alarm input/output setup, system setup, log view, clear log, upgrade system, control device and etc.
Page 167 Click add user button, the interface is shown as in Figure 4-158. Please input the user name, password, select the group it belongs to from the dropdown list. Then you can check the corresponding rights for current user. For convenient user management, usually we recommend the general user right is lower than the admin account.
Page 168 Figure 4-159 4.10.5.10 Config Backup The configuration file backup interface is shown as below. See Figure 4-160. This function allows you to import/export system configuration. You can use this function when there are several devices need the same setup.  Export: Please connect the peripheral device first and then go to the following interface.
Page 169 Figure 4-160 4.10.5.11 Default Click default icon, system pops up a dialogue box. You can highlight to restore default factory setup. See Figure 5-26.  Camera  Network  Event  Storage  System Please highlight icon to select the corresponding function. After all the setups please click save button, system goes back to the previous menu.
Page 170 Figure 4-161 4.10.5.12 Update Here is for you to view hardware features, software version, built date, release SN information and etc. You can also update system here. See Figure 4-50.  Start: Please insert the USB device that have the update file to the device and then click the Start button to begin the update.
Page 171: Web Operation
5 WEB OPERATION Slightly difference may be found in the interface due to different series. 5.1 Network Connection Before web client operation, please check the following items:  Network connection is right  DVR and PC network setup is right. Please refer to network setup(main menu->Setting->Network) ...
Page 172: Lan Mode
Figure 5-2 5.3 LAN Mode For the LAN mode, after you logged in, you can see the main window. See Figure 5-8. This main window can be divided into the following sections.  Section 1: there are five function buttons: Live（chapter 5.4）, setup (chapter 5.8), search (chapter 5.10), alarm (chapter 5.11), and logout (chapter 5.12).
Page 173 Please note, if audio input port from the device to the client-end is using the first channel audio input port. During the bidirectional talk process, system will not encode the audio data from the 1-channel. Figure 5-5  Section 4: Instant record button. Click it, the button becomes yellow and system begins manual record.
Page 174: Real-Time Monitor
Figure 5-8 5.4 Real-time Monitor In section 2, left click the channel name you want to view, you can see the corresponding video in current window. On the top left corner, you can view device IP, channel number, network monitor bit stream. See Figure 5-9.
Page 175: Ptz
 1: Digital zoom: Click this button and then left drag the mouse in the zone to zoom in. right click mouse system restores original status.  2: Local record. When you click local record button, the system begins recording and this button becomes highlighted.
Page 176: Image/Relay-Out
Parameter Function You can turn on or turn off the light/wiper. Light and wiper 3D Intelligent Positioning You can click this icon to display or hide the PTZ control platform. Figure 5-11 5.6 Image/Relay-out Select one monitor channel video and then click Image button in section 8, the interface is shown as Figure 5-12.
Page 177: Wan Login
Figure 5-13 5.7 WAN Login In WAN mode, after you logged in, the interface is shown as below. See Figure 5-14. Figure 5-14 Please refer to the following contents for LAN and WAN login difference. 1) In the WAN mode, system opens the main stream of the first channel to monitor by default.
Page 178: Setup
Figure 5-15 Important The window display mode and the channel number are by default. For example, for the 16-channel, the max window split mode is 16. 3) Multiple-channel monitor, system adopts extra stream to monitor by default. Double click one channel, system switches to single channel and system uses main stream to monitor.
Page 179 Figure 5-16 Figure 5-17 Please refer to the following sheet for log parameter information. Parameter Function Click Device search button, you can view the searched device Device search information on the list. It includes device IP address, port, device name, manufacturer and type. Select a device in the list and then click Add button, system can connect the device automatically and add it to the Added device list.
Page 180 Parameter Function Delete Click , you can delete the remote connection of the corresponding channel. : Connection succeeded. Connection status : Connection failed. Delete Select a device in the Added device list and then click Delete button, system can disconnect the device and remove it from the Added device list.
Page 181 Figure 5-19 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Period It divides one day (24 hours) to two periods. You can set different hue, brightness, and contrast for different periods. It is to adjust monitor video brightness and darkness level.
Page 182 Gain The gain adjust is to set the gain value. The smaller the value is, the low the noise is. But the brightness is also too low in the dark environments. It can enhance the video brightness if the value is high.
Page 183 video according to the device feature (The general bright of the video or there is IR light or not.)  B/W: The device outputs the black and white video.  Sensor: It is to set when there is peripheral connected IR light.
Page 184 Frame Rate PAL：1～25f/s；NTSC：1～30f/s.  Bit Rate Main stream: You can set bit rate here to change video quality. The large the bit rate is , the better the quality is. Please refer to recommend bit rate for the detailed information. ...
Page 185 The video overlay interface is shown as in Figure 5-22. Figure 5-22 Please refer to the following sheet for detailed information. Parameter Function Cover-area Check Preview or Monitor first. Click Set button, you can privacy mask the specified video in the preview or monitor video.
Page 186: Network
Figure 5-23 5.8.1.4 Channel Name Here you can set channel name. See Figure 5-24. Please note this function is for analog channel only. The digital channel name here is read-only. Figure 5-24 5.8.2 Network 5.8.2.1 TCP/IP The TCP/IP interface is shown as in Figure 5-25. Figure 5-25 Please refer to the following sheet for detailed information.
Page 187 DHCP mode to auto search the IP.  If you select the static mode, you need to set the IP/submask/gateway manually.  If you select the DHCP mode, you can view the IP/submask/gateway from the DHCP.  If you switch from the DHCP mode to the static mode, you need to reset the IP parameters.
Page 188 number if necessary. HTTP port The default value is 80. You can input the actual port number if necessary. HTTPS The default value is 443. You can input the actual port number if necessary. RTSP port The default value is 554. 5.8.2.3 WIFI Please note this function is for the device of WIFI module.
Page 189 Please refer to the following sheet for detailed information. Parameter Function WLAN type Here you can select 3G network type to distinguish the 3G module from different ISP. The types include WCDMA， CDMA1x and etc. APN/Dial No. Here is the important parameter of PPP. Authorization It includes PAP,CHAP,NO_AUTH.
Page 190 Figure 5-30 5.8.2.6 DDNS The DDNS interface is shown as in Figure 5-31. The DDNS is to set to connect the various servers so that you can access the system via the server. Please go to the corresponding service website to apply a domain name and then access the system via the domain.
Page 191 2) Function Introduction The quick DDNS client has the same function as other DDNS client end. It realizes the bonding of the domain name and the IP address. Right now, current DDNS server is for our own devices only. You need to refresh the bonding relationship of the domain and the IP regularly.
Page 192 5.8.2.8 Email The email interface is shown as in Figure 5-33. Figure 5-33 Please refer to the following sheet for detailed information. Parameter Function Please check the box here to enable email function. Enable Input server address and then enable this function. SMTP Server Port Default value is 25.
Page 193 Parameter Function function is very useful when there are too many emails activated by the abnormity events, which may result in heavy load for the email server. Please check the box here to enable this function. Health mail enable This function allows the system to send out the test email to Update period check the connection is OK or not.
Page 194 Figure 5-35 5.8.2.11 SNMP The SNMP interface is shown as in Figure 5-36. The SNMP allows the communication between the network management work station software and the proxy of the managed device. It is reserved for the 3 party to develop. Figure 5-36 Please refer to the following sheet for detailed information.
Page 195 Parameter Function and one group of the managers. Please make sure the device and the proxy are the same. The read community will read/write/access all the objects the SNMP supported in the specified name. The default setup is write. The destination address of the Trap information from the proxy Trap address program of the device.
Page 196 5.8.2.14 Alarm Centre The alarm centre interface is shown as below. See Figure 5-39. This interface is reserved for you to develop. System can upload alarm signal to the alarm centre when local alarm occurs. Before you use alarm centre, please set server IP, port and etc. When an alarm occurs, system can send out data as the protocol defined, so the client-end can get the data.
Page 197 Figure 5-41 You can see the corresponding prompt. See Figure 5-42. Now the server certificate is successfully created. Figure 5-42 5.8.2.15.2 Download root certificate In Figure 5-40, click button, system pops up a dialogue box. See Figure 5-43. Figure 5-43 Click Open button, you can go to the following interface.
Page 198 Figure 5-44 Click Install certificate button, you can go to certificate wizard. See Figure 5-45. Figure 5-45 Click Next button to continue. Now you can select a location for the certificate. See Figure 5-46.
Page 199 Figure 5-46 Click Next button, you can see the certificate import process is complete. See Figure 5-47. Figure 5-47 Click Finish button, you can see system pops up a security warning dialogue box. See Figure 5-48.
Page 200 Figure 5-48 Click Yes button, system pops up the following dialogue box, you can see the certificate download is complete. See Figure 5-49. Figure 5-49 5.8.2.15.3 View and set HTTPS port From Setup->Network->Connection, you can see the following interface. See Figure 5-50. You can see HTTPS default value is 443.
Page 201: Event
5.8.3 Event 5.8.3.1 Video detect 5.8.3.1.1 Motion Detect The motion detect interface is shown as in Figure 5-51. Figure 5-51 Figure 5-52...
Page 202 Figure 5-53 Figure 5-54 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable motion detection function. Please select a channel from the dropdown list.
Page 203 Parameter Function Period Motion detection function becomes activated in the specified periods. See Figure 5-52. There are six periods in one day. Please draw a circle to enable corresponding period. Click OK button, system goes back to motion detection interface, please click save button to exit.
Page 204 Here you can set PTZ movement when alarm occurs. Such as go Activation to preset X. See Figure 5-54. Video Matrix This function is for motion detect only. Check the box here to enable video matrix function. Right now system supports one-channel tour function.
Page 205 Figure 5-56 5.8.3.2 Alarm 5.8.3.3 Alarm Before operation, please make sure you have properly connected alarm devices such as buzzer. The input mode includes local alarm and network alarm. 5.8.3.3.1 Local Alarm The local alarm interface is shown as in Figure 5-57. It refers to alarm from the local device.
Page 206 Figure 5-58 Figure 5-59 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable this function. Please select a channel from the dropdown list. Period This function becomes activated in the specified periods. There are six periods in one day.
Page 207 Parameter Function whole week. Click OK button, system goes back to local alarm interface, please click save button to exit. System only memorizes one event during the anti-dither Anti-dither period. The value ranges from 5s to 600s. There are two options: NO/NC. Sensor type Record channel System auto activates motion detection channel(s) to...
Page 208 Figure 5-60 5.8.3.3.3 IPC External Alarm IPC external alarm interface is shown as below. See Figure 5-61. For setup information, please refer to chapter 5.8.3.3.1. Figure 5-61 5.8.3.3.4 IPC Offline Alarm IPC offline alarm is shown as in Figure 5-62 . For setup information, please refer to chapter 5.8.3.3.1.
Page 209 Figure 5-62 5.8.3.4 Abnormality It includes two types: HDD error/Network error. HDD error: No disk, disk error, disk no space. See Figure 5-63 and Figure 5-64. Network error: Net disconnection, IP conflict and MAC conflict. See Figure 5-65. Figure 5-63 Figure 5-64...
Page 210 Figure 5-65 Please refer to the following sheet for detailed information. Parameter Function Event The abnormal events include: No disk, disk error, disk no space, net Type disconnection, IP conflict and MAC conflict. You can set one or more items here. Less than: You can set the minimum percentage value here (For disk not space only).
Page 211: Storage
Figure 5-66 5.8.4 Storage 5.8.4.1 Schedule In this interfaces, you can add or remove the schedule record setup. See Figure 5-67. There are three record modes: general (auto), motion detect and alarm. There are six periods in one day. You can view the current time period setup from the color bar. ...
Page 212 Figure 5-68 Figure 5-69 Please refer to the following sheet for detailed information.
Page 213 Parameter Function Channel Please select a channel from the dropdown list. Pre-record Please input pre-record time here. The value ranges from 0 to 30. Redundancy Check the box here to enable redundancy function. Please note this function is null if there is only one HDD. Snapshot Check the box here to enable snapshot function.
Page 214 Figure 5-71 Please refer to the following sheet for detailed information. Parameter Function Here you can view channel number. Channel The number displayed here is the max channel amount of your device. Status There are three statuses: schedule, manual and stop. System enables auto record function as you set in record schedule Schedule setup (general, motion detect and alarm).
Page 215 Figure 5-72 5.8.4.4.2 Main Stream The main stream interface is shown as in Figure 5-73. Here you can set corresponding HDD group to save main stream. Figure 5-73 5.8.4.4.3 Sub Stream The sub stream interface is shown as in Figure 5-74. Here you can set corresponding HDD group to save sub stream.
Page 216 Figure 5-75 5.8.4.5 Quota It is to set channel storage capacity. See Figure 5-76. Select a channel from the dropdown list and then select corresponding HDD quota. Figure 5-76 5.8.4.6 RAID RAID function is for some series product such as 2U RAID series only. Right now system supports RAID0/RAID1/RAID5/RAID10.
Page 217 Figure 5-77 5.8.4.6.2 RAID Info It is to display RAID name, space, type, member HDD, hotspare HDD, status and etc. Here you can delete RAID. See Figure 5-78. Figure 5-78 5.8.4.6.3 Hotspare HDD In this interface you can add/delete hotspare HDD. See Figure 5-79. Figure 5-79...
Page 218: Setting
5.8.5 Setting 5.8.5.1 General The general interface includes general, date/time and holiday setup. 5.8.5.1.1 General The general interface is shown as in Figure 5-80. Figure 5-80 Please refer to the following sheet for detailed information. Parameter Function It is to set device name. Device ID Device No.
Page 219 Figure 5-81 Please refer to the following sheet for detailed information. Parameter Function Here you can select date format from the dropdown list. Date format There are two options: 24-H and 12-H. Time Format The time zone of the device. Time zone It is to set system time.
Page 220 Figure 5-82 5.8.5.2 Display Display interface includes GUI, TV adjust, Tour and zero-channel encoding. 5.8.5.2.1 GUI Here you can set background color and transparency level. See Figure 5-83. Figure 5-83 Please refer to the following sheet for detailed information. Parameter Function There are four options: 1920×...
Page 221 Figure 5-84 5.8.5.2.3 Tour The tour interface is shown as in Figure 5-85. Here you can set tour interval, split mode, motion detect tour and alarm tour mode. Figure 5-85 Please refer to the following sheet for detailed information. Parameter Function Check the box here to enable tour function.
Page 222 Figure 5-86 Please refer to the following sheet for detailed information. Parameter Function This function is disabled by default. Check the box here to enable Enable this function so that you can control the zero-channel encoding function at the WEB. Compression System default setup is H.264.
Page 223 Figure 5-87 Figure 5-88 5.8.5.4 RS232 The RS232 interface is shown as in Figure 5-89. Figure 5-89 Please refer to the following sheet for detailed information. Parameter Function Select the corresponding dome protocol. Protocol Default setup is console. Select the baud rate. Baud Rate Default setup is 115200.
Page 224 Parameter Function Data Bit The value ranges from 5 to 8. Default setup is 8. There are two options: 1/2. Stop bit Default setup is 1. Parity There are five options: none/odd/even/space/mark. Default setup is none. 5.8.5.5 PTZ The PTZ interface is shown as in Figure 5-90 (analog channel) and Figure 5-91 (digital channel).
Page 225 Parameter Function Set corresponding dome address. Default value is 1. Please note Address your setup here shall comply with your dome address; otherwise you can not control the speed dome. Select the dome baud rate. Default setup is 9600. Baud Rate Data Bit Default setup is 8.
Page 226 Figure 5-93 Without the protocol For the ATM/POS without the protocol, the interface is shown as in Figure 5-94. Source IP refers to host IP address that sends out information (usually it is the device host.) Destination IP refers to other systems that receive information. Usually you do not need to set source port and target port.
Page 227 Figure 5-95 Click Add button, you can add audio file and import the audio file via the local computer. See Figure 5-96. Figure 5-96 5.8.5.7.2 Schedule It is to set schedule broadcast function. You can play the different audio files in the specified periods.
Page 228 Figure 5-97 5.8.5.8 Account Note:  For the character in the following user name or the user group name, system max supports 6-digits. The space in the front or at the end of the string is null. The valid string includes: character, number, and underline. ...
Page 229 monitor rights,. Hidden user “default” is for system interior use only and can not be deleted. When there is no login user, hidden user “default” automatically login. You can set some rights such as monitor for this user so that you can view some channel view without login. Here you can input the user name and password and then select one group for current user.
Page 230 Figure 5-100 5.8.5.8.2 Group The group management interface can add/remove group, modify group password and etc. The interface is shown as in Figure 5-101. Figure 5-101 Add group: It is to add group and set its corresponding rights. See Figure 5-102. Please input the group name and then check the box to select the corresponding rights.
Page 231 includes: shutdown/reboot device, live view, record control, PTZ control and etc. Figure 5-102 Modify group Click the modify group button, you can see an interface is shown as in Figure 5-103. Here you can modify group information such as remarks and rights. Figure 5-103...
Page 232 5.8.5.9 Auto maintain The auto maintain interface is shown as in Figure 5-104. Here you can select auto reboot and auto delete old files interval from the dropdown list. If you want to use the auto delete old files function, you need to set the file period. Click Manual reboot button, you can restart device manually.
Page 233: Information
5.8.5.12 Upgrade The upgrade interface is shown as in Figure 5-107. Please select the upgrade file and then click the update button to begin update. Please note the file name shall be as *.bin. During the upgrade process, do not unplug the power cable, network cable, or shutdown the device.
Page 234: Connection Log
Figure 5-109 Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, data Type operation, event operation, record operation, user management, log clear. Set the start time of the requested log. Start time Set the end time of the requested log.
Page 235: Online User
Figure 5-110 5.9.4 Online User The online user interface is shown as in Figure 5-111. Figure 5-111 5.10 Playback Click Playback button, you can see an interface is shown as in Figure 5-112. Please set record type, record date, window display mode and channel name. You can click the date on the right pane to select the date.
Page 236 Figure 5-112 Then please click File list button, you can see the corresponding files in the list. See Figure 5-113. Figure 5-113 Select a file you want to play and then click Play button, system can begin playback. You can select to playback in full-screen. Please note for one channel, system can not playback and download at the same time.
Page 237 Figure 5-114. Figure 5-114 Select the file(s) you want to download and then click download button, you can see an interface shown as in Figure 5-115. The Download button becomes Stop button and there is a process bar for your reference. Please go to you default file saved path to view the files.
Page 238 HD Transcoding When the bandwidth is limited, you can use this function to transfer the HD bit stream to the specified lower resolution and then playback. It is to reduce network load. In Figure 5-112, select the playback period and then select playback mode and channel(s). Check the box to enable HD transcoding function and then click the Set button;...
Page 239: Alarm
Figure 5-118 Watermark Watermark interface is shown as In Figure 5-117. Please select a file and then click Verify button to see the file has been tampered with or not Figure 5-119 5.11 Alarm Click alarm function, you can see an interface is shown as Figure 5-120. Here you can set device alarm type and alarm sound setup (Please make sure you have enabled audio function of corresponding alarm events.).
Page 240: Log Out
Figure 5-120 Please refer to the following sheet for detailed information. Type Parameter Function Alarm Video loss System alarms when video loss occurs. Type Motion detection System alarms when motion detection alarm occurs. Tampering System alarms when camera is viciously masking. Disk full System alarms when disk is full.
Page 241: Un-Install Web Control
Figure 5-121 5.13 Un-install Web Control You can use web un-install tool “uninstall web.bat” to un-install web control. Please note, before you un-installation, please close all web pages, otherwise the un-installation might result in error.
Page 242: Professional Surveillance System
6 Professional Surveillance System Besides Web, you can use our Professional Surveillance Software (PSS) to login the device. For detailed information, please refer to PSS user’s manual.
Page 243: Faq
7 FAQ 1. DVR can not boot up properly. There are following possibilities:  Input power is not correct.  Power connection is not correct.  Power switch button is damaged.  Program upgrade is wrong.  HDD malfunction or something wrong with HDD ribbon. ...
Page 244  DVR and monitor resistance is not compatible.  Video transmission is too long or degrading is too huge.  DVR color or brightness setup is not correct. 6. Can not search local records. There are following possibilities:  HDD ribbon is damaged. ...
Page 245  PTZ decoder setup, connection or installation is not correct.  Cable connection is not correct.  PTZ setup is not correct.  PTZ decoder and DVR protocol is not compatible.  PTZ decoder and DVR address is not compatible. ...
Page 246  MAC address conflict.  PC or DVR network card is not good. 16. Burn error /USB back error. There are following possibilities:  Burner and DVR are in the same data cable.  System uses too much CPU resources. Please stop record first and then begin backup.
Page 247  Camera quality is too low. Lens is dirty. Camera is installed against the light. Camera aperture setup is not correct.  HDD capacity is not enough.  HDD is damaged. 22. Can not playback the downloaded file. There are following possibilities: ...
Page 248 29. After I connected to the IP channel, there multiple-window output is OK, but there is no one-window output. There are following possibilities:  Check there is video from the IP channel or not. Please go to the main menu->info->System->BPS to view bit stream real-time information. ...
Page 249: Appendix A Hdd Capacity Calculation
Appendix A HDD Capacity Calculation Calculate total capacity needed by each DVR according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte. ...
Page 250 448K 196M 512K 225M 640K 281M 768K 337M 896K 393M 1024K 450M 1280K 562M 1536K 675M 1792K 787M 2048K 900M...
Page 251: Appendix B Compatible Backup Devices
Appendix B Compatible backup devices Appendix B-1 Compatible USB list Manu factor Model Capacity Sandisk Cruzer Micro 512M Sandisk Cruzer Micro Sandisk Cruzer Micro Sandisk Cruzer Freedom 256M Sandisk Cruzer Freedom 512M Sandisk Cruzer Freedom Sandisk Cruzer Freedom DataTraveler Ⅱ Kingston DataTraveler Ⅱ...
Page 252 Kingston Data Traveler 32GB Aigo L8315 16GB Sandisk 16GB Kingston Data Traveler Locker+ 32GB Netac U228 Appendix B-2 Compatible SD Card list Brand Standard Capacity Card type Transcend SDHC6 16GB Kingston SDHC4 Kingston Kingston Sandisk SDHC2 Small Sandisk Small Appendix B-3 Compatible Portable HDD list Brand Model Capacity...
Page 253 Samsung TS-H653 Ver.F Samsung SH-224BB/CHXH SONY DRU-V200S SONY DRU-845S SONY AW-G170S Pioneer DVR-217CH Appendix B-6 Compatible SATA HDD List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. Here we recommend HDD of 500G to 4T capacity. Port Manufacturer Series...
Page 254 Seagate Seagate Pipeline HD2 ST31000322CS SATA Seagate Seagate Pipeline HD2 ST1000VM002 SATA Seagate Seagate Pipeline HD2 ST1500VM002 SATA Seagate Seagate Pipeline HD2 ST2000VM002 SATA Seagate Seagate Pipeline HD2 ST2000VM003 SATA Seagate Seagate Constellation ST3500514NS 500G SATA Seagate Seagate Constellation ST31000524NS SATA Seagate Seagate Constellation...
Page 255 Westem Digital Cariar SE WD2500JS 250G SATA Westem Digital Cariar SE16 WD7500KS 750G SATA Westem Digital Cariar SE16 WD5000KS 500G SATA Westem Digital Cariar SE16 WD4000KD 400G SATA Westem Digital Cariar SE16 WD3200KS 320G SATA Westem Digital Cariar SE16 WD2500KS 250G SATA Westem Digital...
Page 256 Hitachi HitachiCinemaStar™ HCP725050GLA380 500G SATA 5K500 Hitachi HitachiCinemaStar™ HCT721050SLA360 500G SATA 7K1000.B Hitachi HitachiCinemaStar™ HCT721075SLA360 750G SATA 7K1000.B Hitachi HitachiCinemaStar™ HCT721010SLA360 SATA 7K1000.B Maxtor DiamondMax 20 STM3320820AS 320G SATA Maxtor DiamondMax 20 STM3250820AS 250G SATA...
Page 257 Appendix C Compatible CD/DVD Burner List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. And you can use the USB cable with the model recommended to set USB burner. Manufacturer Model Port Type Type Sony...
Page 258: Appendix D Compatible Displayer List
Appendix D Compatible Displayer List Please refer to the following sheet form compatible displayer list. Brand Model Dimension (Unit: inch) BENQ（LCD） ET-0007-TA 19-inch (wide screen) DELL（LCD） E178FPc 17-inch BENQ（LCD） Q7T4 17-inch BENQ（LCD） Q7T3 17-inch HFNOVO（LCD） LXB-L17C 17-inch 22 寸(wide screen) SANGSUNG（LCD）...
Page 259: Appendix E Compatible Switcher
Appendix E Compatible Switcher Brand Model network working mode D-LinK DES-1016D 10/100M self-adaptive D-LinK DES-1008D 10/100M self-adaptive Five network modes 1. AUTO 2. HALF-10M Ruijie RG-S1926S 3. FULL-10M 4 .HALF-100M 5. FULL-100M H3C-S1024 10/100M self-adaptive TP-LINK TL-SF1016 10/100M self-adaptive TP-LINK TL-SF1008+ 10/100M self-adaptive...
Page 260: Appendix F Compatible Wireless Mouse List
Appendix F Compatible Wireless Mouse List Please refer to the following sheet for compatible SD card brand. Brand Model Rapoo 3500 Logitech M215 Shuangfeiyan Tianyao G7-630...
Page 261: Appendix G Earthing
Appendix G Earthing 1. What is the surge? Surge is a short current or voltage change during a very short time. In the circuit, it lasts for microsecond. In a 220V circuit, the 5KV or 10KV voltage change during a very short time (about microseconds) can be called a surge.
Page 262  Signal lightning arrester: This device is mainly used in the PC network, communication system. The connection type is serial connection. Once you connected the signal lightning arrestor with the signal port, it can cut the channel of the thunderstorm to the device, and on the other hand, it can discharge the current to the ground to guarantee the device proper work.
Page 263 conductance of the ground conductor. In the high-frequency circuit, you need to use the multiple-point ground mode and each cable needs to connect to the ground. The length shall be less than the 1/20 of the signal wavelength. Mixed ground: The mix ground consists of the feature of the one-point ground and multiple-point ground.
Page 264  The thunder proof ground shall adopt the special ground cable from the monitor control room to the ground object. The ground cable adopts copper insulation cable or wire and its ground section shall be more than 20mm2.  The ground cable of the monitor system can not short circuit or mixed connected with the strong alternative current cable.
Page 265 For L (live cable) Turn the digital multimeter to 750V AC, use your one hand to hold the metal end, and then the other hand insert the pen to the L port of the socket. See the following figure. If the multimeter shows 120, then you can see current live cable connection is standard.
Page 267 Appendix H RAID Introduction Appendix H-1 About RAID RAID is an abbreviation for Redundant Array of Independent Disks. It is to combine several independent HDDs (physical HDD) to form a HDD group (logic HDD) to provide more storage capacity and data redundancy. Right now system supports RAID0/RAID1/RAID5/RAID10.
Page 268 RAID Note Min HDD Level Needed the data in the first malfunction HDD is not complete, system can not rebuild the data based on the first damaged HDD. Now you need to use the second malfunction HDD, usually you can get the all data again. ...
Page 269 Appendix H-3 RAID Capacity Calculation RAID Name Total Space of the N disks. RAID0 The total amount of N*HDD=HDD space *HDD amount. RAID1 Min(capacityN) （N-1）× min(capacityN) RAID5 （N/2）× min(capacityN) RAID10 Note capacityN refers to the disk of mini space among all the member HDDs. Appendix H-4 RAID Usage Suggestions ...
Page 270 Appendix I Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Sheet ○ ○ ○ ○ ○ ○ Metal(Case) Plastic Parts ○ ○ ○ ○ ○ ○ （Panel） ○ ○ ○ ○ ○...

Techpro HYBDVR-FEO8 User Manual

1 Features and Specifications

2 Overview and Controls

3 Installation and Connections

4 Overview of Navigation and Controls

5 Web Operation

6 Professional Surveillance System

7 Faq

Appendix A Hdd Capacity Calculation

Appendix B Compatible Backup Devices

Appendix D Compatible Displayer List

Appendix E Compatible Switcher

Appendix F Compatible Wireless Mouse List

Appendix G Earthing

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Techpro HYBDVR-FEO8

Summary of Contents for Techpro HYBDVR-FEO8

Table of Contents
