HD-CVI Series - User's Manual

DVR-CVI8M-1080-DH-V2

2
PTZ
yr
1080p
Control
View From
Motion
Anywhere
Resolution
Activated
Warranty
Recording

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVR-CVI8M-1080-DH-V2 and is the answer not in the manual?

Questions and answers

Related Manuals for Techpro DVR-CVI8M-1080-DH-V2

Summary of Contents for Techpro DVR-CVI8M-1080-DH-V2

  • Page 1: Dvr-Cvi8M-1080-Dh-V2

    HD-CVI Series - User's Manual DVR-CVI8M-1080-DH-V2 1080p Control View From Motion Anywhere Resolution Activated Warranty Recording...

  • Page 2: Table Of Contents

    Our units do not support PAL Table of Contents FEATURES AND SPECIFICATIONS ............1 Overview ..........................1 Features ..........................1 Specifications ........................2 DVR-CVI8M-1080-DH-V2 1.3.4 ..................15 OVERVIEW AND CONTROLS ............... 28 Front Panel ........................28 DVR-CVI8M-1080-DH-V2 2.1.1 .................... 28 Rear Panel ........................
  • Page 3 INSTALLATION AND CONNECTIONS ..........51 Check Unpacked DVR ..................... 51 About Front Panel and Real Panel ................. 51 3.2.1 HDD Installation ......................51 DVR-CVI8M-1080-DH-V2 3.2.2 .................... 51 Connecting Power Supply ....................54 Connecting Video Input and Output Devices ..............54 3.4.1...
  • Page 4 Other Interfaces ........................ 59 OVERVIEW OF NAVIGATION AND CONTROLS ........60 Boot up and Shutdown ....................60 4.1.1 Boot up ......................... 60 4.1.2 Shutdown ........................60 4.1.3 Auto Resume after Power Failure ................60 4.1.4 Replace Button Battery ....................60 Startup Wizard ........................
  • Page 5 USB Device Auto Pop-up ....................76 Main Menu ........................76 Operation .......................... 77 4.8.1 Search .......................... 77 4.8.2 Backup .......................... 85 4.8.3 Shut Down ........................87 Information ........................87 4.9.1 System Info ........................87 4.9.2 Event..........................91 4.9.3 Network ........................91 4.9.4 Log ..........................
  • Page 6 5.6.1 Image .......................... 167 5.6.2 Relay output ....................... 167 WAN Login ........................168 Setup ..........................169 5.8.1 Camera ........................169 5.8.2 Network ........................174 5.8.3 Event........................... 190 5.8.4 Storage ........................198 5.8.5 Setting ........................203 Information ........................216 5.9.1 Version ........................216 5.9.2 Log ..........................
  • Page 7 Appendix B-1 Compatible USB list ..................233 Appendix B-2 Compatible SD Card list ................... 234 Appendix B-3 Compatible Portable HDD list ................234 Appendix B-4 Compatible USB DVD List ................234 Appendix B-5 Compatible SATA DVD List ................234 Appendix B-6 Compatible SATA HDD List ................
  • Page 8 Welcome Thank you for purchasing our HDCVI DVR! This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about this series hybrid standalone DVR features and functions, as well as a detailed menu tree. Before installation and operation please read the following safeguards and warnings carefully!

  • Page 9: Important Safeguards And Warnings

    Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation. 2．Transportation security Heavy stress, violent vibration or water splash are not allowed during transportation, storage and installation.

  • Page 10: Features And Specifications

    FEATURES AND SPECIFICATIONS 1.1 Overview The hybrid standalone series DVR is an excellent digital monitor product designed for security field. It adopts embedded Linux OS to maintain reliable operation. Popular H.264 compression algorithm and G.711 audio compression technology realize high quality, low bit stream. Unique frame by frame play function is suitable for detailed analysis.
  • Page 11 Support each channel real-time record independently, and at the same time it can support search, forward play, network monitor, record search, download and etc. Support various playback modes: slow play, fast play, backward play and frame by frame play. Support time title overlay so that you can view event accurate occurred time Support customized zoom function during the preview.

  • Page 12: Dvr-Cvi8M-1080-Dh-V2

    DVR-CVI8M-1080-DH-V2 1.3.4 Parameter 8-ch High-performance industrial embedded micro controller Main Processor System Embedded LINUX System Multiplex operations: Multiple-channel record, multiple-channel Resources playback and network operation simultaneously Interface User-friendly graphical user interface Input Devices USB mouse Arabic number, English character, donation and extension Chinese...
  • Page 13 Support dual streams: extra stream resolution 704×576/704×480 352×288/ 352×240, QCIF 176×144/176×120 Image Quality 6-level image quality (Adjustable) Privacy mask Support one privacy mask of user-defined size in full screen. Support max 4 zones. Image Channel information, time information and privacy mask zone. Information TV Adjust Adjust TV output zone suitable to anamorphic video.
  • Page 14 Various File Can switch to previous or next file or any file in current play list. Switch Ways Can switch to file on other channel of the same time. (If there is a file) Support file continuous play, when file is end system auto plays the next file in the current channel Playback Way Support mark playback...
  • Page 15 Interface Network 1 RJ45 10M/100M/1000M self-adaptable Ethernet port connection 1 RS485 port. PTZ control port RS485 Support various PTZ control protocols. RS232 port. Ordinary COM (Debug),keyboard connection and RS232 transparent serial port(COM input and output via network ) System Hard Disk Display HDD current status Information...

  • Page 16: Overview And Controls

    This section provides information about front panel and rear panel. When you install this series DVR for the first time, please refer to this part first. 2.1 Front Panel DVR-CVI8M-1080-DH-V2 2.1.1 The front panel is shown as below. See Figure 2-1.
  • Page 17 Multiple slow play speeds or normal playback. Slow play/8 In text mode, input number 8 (English character T/U/V). One-window monitor mode, click this button to display assistant function: PTZ control and image color. Backspace function: in numeral control or text control, press it for 1.5seconds to delete the previous character before the cursor.

  • Page 18: Rear Panel

    2.2 Rear Panel DVR-CVI8M-1080-DH-V2 2.2.1 Figure 2-5 Please refer to the following sheet for detailed information. Icon Name Function VIDEO IN Video input port Connect to analog camera, video input signal. AUDIO IN Audio input port Connect to microphone and etc to input signal.
  • Page 19 are to receive the signal from external alarm source. There are two types; (normal open)/NC (normal close).  When your alarm input device is using external power, please make sure the device and the NVR have the same ground. C1 ～ ...

  • Page 20: Dvr-Cvi8M-1080-Dh-V2

    DVR-CVI8M-1080-DH-V2 2.3.1 Please refer to the following figure for detailed information. See Figure 2-8. The following interface is based on the 8-channel series product.

  • Page 21: Remote Control

    2.4 Remote Control The remote control interface is shown as in Figure 2-12. Please note remote control is not our standard accessory and it is not included in the accessory bag. Figure 2-12 Serial Number Name Function Power button Click it to boot up or shut down the device.

  • Page 22: Mouse Control

    click this button to realize normal playback. In reverse playback click this button to pause playback. Esc. Go back to previous menu or cancel current operation (close upper interface or control) Record Start or stop record manually In record interface, working with the direction buttons to select the record channel.
  • Page 23 When you have selected one menu item, left click mouse to view menu content. Implement the control operation. Modify checkbox or motion detection status. Click combo box to pop up drop down list In input box, you can select input methods. Left click the corresponding button on the panel you can input numeral/English character (small/capitalized).

  • Page 24: Virtual Keyboard & Front Panel

    Right click In real-time monitor mode, pops up shortcut menu: one-window, mouse four-window, nine-window and sixteen-window, Pan/Tilt/Zoom, color setting, search, record, alarm input, alarm output, main menu. Among which, Pan/Tilt/Zoom and color setting applies for current selected channel. If you are in multiple-window mode, system automatically switches to the corresponding channel.

  • Page 25: Installation And Connections

    3 Installation and Connections Note: All the installation and operations here should conform to your local electric safety rules. 3.1 Check Unpacked DVR When you receive the DVR from the forwarding agent, please check whether there is any visible damage. The protective materials used for the package of the DVR can protect most accidental clashes during transportation.
  • Page 26 4. Turn the device upside down 6. Connect the HDD cable and Fix the HDD firmly. and then turn the screws in power cable. firmly. in the chassis. 7. Put the cover in accordance Secure the screws in the with the clip and then place the rear panel and the side panel.

  • Page 27: Connecting Power Supply

    3.2.5 Rack Installation The DVR occupies 1.5U/2U rack units of vertical rack space.  Use twelve screws to fix the unit  Please make sure the indoor temperature is below 35℃ (95° f).  Please make sure there is 15cm (6 inches) space around the device to guarantee sound ventilation.

  • Page 28: Connecting Video Output

    The camera shall be installed in a cool, dry place away from direct sunlight, inflammable, explosive substances and etc. The camera and the DVR should have the same grounding to ensure the normal operation of the camera. Guarantee stability and reliability of the transmission line BTT TB Please use high quality, sound shielded BNC.

  • Page 29: Alarm Input And Output Connection

    3.6 Alarm Input and Output Connection Please read the followings before connecting. 1. Alarm input a. Please make sure alarm input mode is grounding alarm input. b. Grounding signal is needed for alarm input. c. Alarm input needs the low level voltage signal. d.

  • Page 30: Alarm Input Port

    Figure 3-1 In the first line, from ALARM 1 to ALARM 16. The alarm becomes active in low voltage. the left to the right,: 1，2，3，4，5，6， 7，8，9，10，11， 12，13，14，15，16 In the second line, The first four are four groups of normal open activation output (on/off from the left to the button) right:...

  • Page 31: Alarm Output Port

    Figure 3-2 3.6.3 Alarm Output Port  Provide external power to external alarm device.  To avoid overloading, please read the following relay parameters sheet carefully.  RS485 A/B cable is for the A/B cable of the PTZ decoder.  T+,T-,R+,R- are four-wire double duplex RS485 port.

  • Page 32: Other Interfaces

    3.7 RS485 When the DVR receives a camera control command, it transmits that command up the coaxial cable to the PTZ device. RS485 is a single-direction protocol; the PTZ device can’t return any data to the unit. To enable the operation, connect the PTZ device to the RS485 (A,B) input on the DVR.

  • Page 33: Overview Of Navigation And Controls

    4 Overview of Navigation and Controls 4.1 Boot up and Shutdown 4.1.1 Boot up Before the boot up, please make sure:  The rated input voltage matches the device power on-off button. Please make sure the power wire connection is OK. Then click the power on-off button. ...

  • Page 34: Startup Wizard

    4.2 Startup Wizard After device successfully booted up, it goes to startup wizard. Click Cancel/Next button, you can see system goes to login interface. Tips Check the box Startup button here, system goes to startup wizard again when it boots up the next time.
  • Page 35 Note: For security reason, please modify password after you first login. Within 30 minutes, three times login failure will result in system alarm and five times login failure will result in account lock! Click OK button, you can go to General interface. See Figure 4-3. For detailed information, please refer to chapter 4.10.5.1.
  • Page 36 Figure 4-4 Click Next button, you can go to Schedule interface. See Figure 4-5. For detailed information, please refer to chapter 4.10.4.1.1. Figure 4-5 Click Finish button, system pops up a dialogue box. Click the OK button, the startup...

  • Page 37: Manual Record

    wizard is complete. See Figure 4-6. Figure 4-6 4.3 Manual Record 4.3.1 Live Viewing After you logged in, the system is in live viewing mode. You can see system date, time, channel name and window No. If you want to change system date and time, you can refer to general settings (Main Menu->Setting->System->General).
  • Page 38  Right now, system does not support slow playback and backward playback function.  Support digital zoom function.  Support real-time backup function. You can follow the contents listed below for the operation instruction. Preview control interface Move you mouse to the top centre of the video of current channel, you can see system pops up the preview control interface.

  • Page 39: Right-Click Menu

    Figure 4-9 Right click mouse to cancel zoom and go back to the original interface. Manual record function It is to backup the video of current channel to the USB device. System can not backup the video of multiple-channel at the same time. Click button , system begins recording.

  • Page 40: Window Switch

    4.4.1 Window Switch System supports 1/4/8/9-window. You can select from the dropdown list. See Figure 4-11. Figure 4-11 4.4.2 PTZ Control The PTZ setup is shown as in See Figure 4-12. Please note the commend name is grey once device does not support this function. The PTZ operation is only valid in one-window mode.
  • Page 41 Click this key, system goes back to the single screen mode. Drag the mouse in the screen to adjust section size. The dragged zone supports 4X to 16X speeds. It can realize PTZ automatically. The smaller zone you dragged, the higher the speed. Figure 4-13 Name Function...
  • Page 42 Scan on-off button Rotate Go to menu 4.4.2.1 PTZ Function Setup Click , you can go to the following interface to set preset, tour, pattern, and scan. See Figure 4-15. Figure 4-15 Preset Setup In Figure 4-15, click preset button and use eight direction arrows to adjust camera to the proper position.
  • Page 43 Input tour value and preset No. Click Add preset button to add current preset to the tour. See Figure 4-17. Tips Repeat the above steps to add more presets to the tour. Click Del preset button to remove it from the tour. Please note some protocols do not support delete preset function. Figure 4-17 Pattern Setup In Figure 4-15, click Pattern button and input pattern number.
  • Page 44 Figure 4-19 4.4.2.2 Call PTZ Function Call Preset In Figure 4-14, input preset value and then click to call a preset. Click again to stop call. Call Pattern In Figure 4-14, input pattern value and then click to call a pattern. Click again to stop call.

  • Page 45: Color

    Click , system goes to the following interface. The options here are defined by the protocol. The aux number is corresponding to the aux on-off button of the decoder. See Figure 4-20. Figure 4-20 4.4.3 Color Here you can set hue, brightness, contrast, saturation, gain, white level, color mode and etc.
  • Page 46 Item Note period time. The value here is to adjust the edge of the video. The value ranges from 0 to 100. The larger the value is, the clear the edge is and vice versa. Please note there is Sharpness noise if the value here is too high.

  • Page 47: Search

    Item Note corresponding setup. 4.4.4 Search Please refer to chapter 4.4.4 for detailed information. 4.4.5 Record Control Please refer to chapter 4.4.5 for detailed information. 4.4.6 Manual Record Please refer to chapter 4.4.6 for detailed information. 4.4.7 Alarm Output Please refer to chapter 4.10.3.4 for detailed information. 4.4.8 Video Matrix Please refer to chapter 4.10.5.3 for detailed information.

  • Page 48: Search

    4.5.6 Search Click button , system goes to search interface. Please refer to chapter 4.8.1 4.5.7 Alarm Status Click button , system goes to alarm status interface. It is to view device status and channel status. Please refer to chapter 4.10.3. 4.5.8 Channel Info Click button , system goes to the channel information setup interface.

  • Page 49: Usb Device Auto Pop-Up

    ， system goes to the USB Manager interface. It is to view USB information, Click backup and update. Please refer to chapter 4.8.2, chapter 4.9.4, chapter 4.10.5.9, and chapter 4.10.5.11 for detailed information. 4.6 USB Device Auto Pop-up After you inserted the USB device, system can auto detect it and pop up the following dialogue box.

  • Page 50: Operation

    Figure 4-25 4.8 Operation 4.8.1 Search Click search button in the main menu, search interface is shown as below. See Figure 4-26. Usually there are three file types:  R: Regular recording file.  A: External alarm recording file.  M: Motion detection recording file...
  • Page 51 Figure 4-26 Please refer to the following sheet for more information. Name Function  Display Here is to display the searched picture or file.  window Support 1/4/9/16-window playback.  Here you can select to search the picture or the recorded file. ...
  • Page 52  In 4-window playback mode: you can select 4 channels according to your channel requirement.  selection In 9-window playback mode, you can switch between 1-8 and 9-16 channels.  pane. In 16-window playback mode, you can switch between1-16 and 17-32 channels.
  • Page 53 │ to begin frame by frame playback. In frame by frame playback mode, click ►/ to restore normal playback. ► Slow play In playback mode, click it to realize various slow play modes such as slow play 1, slow play 2, and etc. Fast forward ...
  • Page 54  Check the file again you can cancel current selection. System max supports to display 32 files from one channel.  After you clip on record file, click Backup button you can save it.  For one device, if there is a backup in process, you can not start a new backup operation.
  • Page 55 When the system is in full-screen playback mode, left click the mouse in the Digital screen. Drag your mouse in the screen to select a section and then left click zoom mouse to realize digital zoom. You can right click mouse to exit. Manually switch During the file playback process, you can switch to other channel via the...
  • Page 56 input time at the top right corner to search records by time. See image on the left side of the Figure 4-28 For example, input time 11:00.00 and then click Search button you can view all the record files after 11:00.00 (The records includes current time.). See image on the right side of the Figure 4-28 Double click a file name to playback.
  • Page 57 During 1-window playback mode, click mark file list button in Figure 4-26, you can go to mark file list interface. Double click one mark file, you can begin playback from the mark time.  Play before mark time Here you can set to begin playback from previous N seconds of the mark time. Note Usually, system can playbacks previous N seconds record if there is such kind of record file.

  • Page 58: Backup

     If the mark file you want to playback has been removed, system begin playbacking from the first file in the list. 4.8.2 Backup DVR support CD-RW, DVD burner, USB device backup, network download and eSATA. Here we introduce USB, eSATA backup. You can refer to Chapter 7 Web Client Operation for network download backup operation.
  • Page 59 Figure 4-32 √ before channel name. You can use Fn or cancel System only backup files with a button to delete √ after file serial number. Click Start button, system begins copy. At the same time, the backup button becomes stop button.

  • Page 60: Shut Down

    When the system completes backup, you can see a dialogue box prompting successful backup.  File format: Click the file format; you can see there are two options: DAV/ASF. The file name format usually is: Channel number+Record type+Time. In the file name, the YDM format is Y+M+D+H+M+S.
  • Page 61 Figure 4-35 4.9.1.1 HDD Information Here is to list hard disk type, total space, free space, video start time and status. See Figure 4-36.  SATA: 1-8 here means system max supports 8 HDDS. ○ means current HDD is normal. X means there is error. - means there is no HDD. If disk is damaged, system shows as “?”.
  • Page 62 Figure 4-36 Double click one HDD information; you can see the HDD SMART information. See Figure 4-37. Figure 4-37 4.9.1.2 Record Info It is to view record start time and end time. See Figure 4-38.
  • Page 63 Figure 4-38 4.9.1.3 BPS Here is for you to view current video data stream (KB/s) and occupied hard disk storage (MB/h). See Figure 4-39. Figure 4-39 4.9.1.4 Version Here is for you to view some version information such as version number, built date, serial number and etc.

  • Page 64: Event

    Figure 4-40 4.9.2 Event It is to display device status and channel status. See Figure 4-41. Figure 4-41 4.9.3 Network 4.9.3.1 Online Users...
  • Page 65 Here is for you to manage online users. See Figure 4-42. You can disconnect one user or block one user if you have proper system right. Max disconnection setup is 65535 seconds. System detects there is any newly added or deleted user in each five seconds and refresh the list automatically.
  • Page 66 Figure 4-43 4.9.3.3 Network Test Network test interface is shown as in Figure 4-44.  Destination IP: Please input valid IPV4 address or domain name.  Test: Click it to test the connection with the destination IP address. The test results can display average delay and packet loss rate and you can also view the network status as OK, bad, no connection and etc.

  • Page 67: Log

    Figure 4-44 4.9.4 Log 4.9.4.1 Local Log Here is for you to view system log file. System lists the following information. See Figure 4-45. Log types include system operation, configuration operation, data management, alarm event, record operation, account manager, log clear, file operation and etc. It optimized reboot log.
  • Page 68 Figure 4-45 Select an item on the list and then click the Details button or double click the log item, you can view the detailed information such as log time, log type, log user, IP address and etc. See Figure 4-46. Figure 4-46 4.9.4.2 Remote Log In this interface, you can search the IPC log information of the corresponding channel.

  • Page 69: Setting

    Click search button, you can view the remote connection log of current channel. You can select another channel (doe not need to click Search button again), you can view remote connection log. Figure 4-47 4.10 Setting 4.10.1 Camera 4.10.1.1 Camera The camera interface is shown as below.
  • Page 70 dark section may lack brightness while the bright section may over exposure .The recommended value ranges from 40 to 60.  Sharpness: The value here is to adjust the edge of the video. The value ranges from 0 to 100. The larger the value is, the clear the edge is and vice versa. Please note there is noise if the value here is too high.
  • Page 71  Quality: There are six levels ranging from 1 to 6. The sixth level has the highest image quality.  Video/audio: You can enable or disable the video/audio.  Audio: Please select from the dropdown list. Figure 4-49 4.10.1.2.2 Snapshot Here you can set snapshot mode, picture size, quality and frequency.
  • Page 72 Figure 4-50 4.10.1.2.3 Overlay Overlay interface is shown as in Figure 4-51.  Cover area: Here is for you to set cover area. You can drag you mouse to set proper section size. In one channel video, system max supports 4 zones in one channel. ...
  • Page 73 Please highlight icon to select the corresponding function. Figure 4-51 Figure 4-52 4.10.1.2.4 Channel Name It is to modify channel name. It max supports 31-character. See Figure 4-53. Please note for digital channel, you can only modify the channel name of the connected network camera.

  • Page 74: Network

    Figure 4-53 4.10.2 Network 4.10.2.1 TCP/IP The single network adapter interface is shown as in Figure 4-54 and the dual network adapters interface is shown as in Figure 4-55  Network Mode : Includes multiple access, fault tolerance, and load balancing ...
  • Page 75  Main Network Card: Please select eth0/eth1 (optional).after enable multiple access function. Note: Some series support the above three configurations and supports functions as multiple-access, fault-tolerance and load balancing.  IP Version: There are two options: IPv4 and IPv6. Right now, system supports these two IP address format and you can access via them.
  • Page 76 Figure 4-54 Figure 4-55 4.10.2.2 Connection The connection setup interface is shown as in Figure 4-56.  Max connection: system support maximal 128 users. 0 means there is no connection limit.  TCP port: Default value is 37777.  UDP port: Default value is 37778.
  • Page 77  HTTP port: Default value is 80.  HTTPS port: Default value is 443.  RTSP port: Default value is 554. Important: System needs to reboot after you changed and saved any setup of the above four ports. Please make sure the port values here do not conflict. Figure 4-56 4.10.2.3 WIFI The WIFI interface is shown as below.
  • Page 78 Figure 4-57  WIFI working status: Here you can view current connection status. Please note:  After successful connection, you can see WIFI connection icon at the top right corner of the preview interface.  When the hotspot verification type is WEP, system displays as AUTO since the device can not detect its encryption type.
  • Page 79  AUTH: It is the authentication mode. It supports PAP/CHAP.  Dial number: Please input 3G network dialup number you got from your ISP.  User name: It is the user name for you to login the 3G network.  Password: It is the password for you to login the 3G network.
  • Page 80 Figure 4-59 4.10.2.6 DDNS Setup DDNS setup interface is shown as in Figure 4-60. You need a PC of fixed IP in the internet and there is the DDNS software running in this PC. In other words, this PC is a DNS (domain name server). In network DDNS, please select DDNS type and highlight enable item.
  • Page 81 Figure 4-60 Please note NNDS type includes: CN99 DDNS, NO-IP DDNS, Quick DDNS, Dyndns DDNS and sysdns DDNS. All the DDNS can be valid at the same time, you can select as you requirement. Private DDNS function shall work with special DDNS server and special Professional Surveillance Software (PSS).
  • Page 82  Domain name：There are two modes: Default domain name and customized domain name. Except default domain name registration, you can also use customized domain name (You can input your self-defined domain name.) After successful registration, you can use domain name to login installed of the device IP. ...
  • Page 83  Default: Click it to restore default setup. In this case, the trusted sites and blocked sites are both null. Note:  If you enabled trusted sites, only the IP in the trusted sites list can access the device.  If you enabled blocked sites, the IP in the blocked sites can not access the device.
  • Page 84  Title: Please input email subject here. System support English character and Arabic number. Max 32-digit.  Receiver: Please input receiver email address here. System max supports 3 email boxes. System automatically filters same addresses if you input one receiver repeatedly.
  • Page 85 -> Serv-U Administator. Now you can set user password and FTP folder. Please note you need to grant write right to FTP upload user. See Figure 4-64. Figure 4-64 You can use a PC or FTP login tool to test setup is right or not. For example, you can login user ZHY to FTP://10.10.7.7 and then test it can modify...
  • Page 86 After completed channel and weekday setup, you can set two periods for one each channel. Click the Test button, you can see the corresponding dialogue box to see the FTP connection is OK or not. Figure 4-66 4.10.2.10 UPnP The UPNP protocol is to establish a mapping relationship between the LAN and the WAN. Please input the router IP address in the LAN in Figure 4-54.
  • Page 87 Important: When you are setting the router external port, please use 1024~5000 port. Do not use well-known port 1~255 and the system port 256~1023 to avoid conflict. For the TCP and UDP, please make sure the internal port and external port are the same to guarantee the proper data transmission.
  • Page 88 You can set in the following interface. See Figure 4-69. Figure 4-69 Please enable the SNMP function. Use the corresponding software tool (MIB Builder and MG-SOFT MIB Browser. You still need two MIB file: BASE-SNMP-MIB, DVR-SNMP-MIB) to connect to the device. You can get the device corresponding configuration information after successfully connection.
  • Page 89 Figure 4-70 Here you can set a multiple cast group. Please refer to the following sheet for detailed information.  IP multiple cast group address -224.0.0.0-239.255.255.255 -“D” address space  The higher four-bit of the first byte=”1110”  Reserved local multiple cast group address -224.0.0.0-224.0.0.255 -TTL=1 When sending out telegraph -For example...
  • Page 90 Multiple cast PORT: 3666. After you logged in the Web, the Web can automatically get multiple cast address and add it to the multiple cast groups. You can enable real-time monitor function to view the view. Please note multiple cast function applies to special series only. 4.10.2.13 Alarm Centre This interface is reserved for you to develop.

  • Page 91: Event

    Figure 4-72 2) The proxy server software developed from the SDK. Please open the software and input the global setup. Please make sure the auto connection port here is the same as the port you set in the previous step. 3) Now you can add device.
  • Page 92 front-end and support local activation function. The front-end can get enable/disable status, sensitivity and region setup. You can get corresponding prompt if front-end can not get the above information. You can change front-end setup if it can get. 4.10.3.1.1 Motion Detect After analysis video, system can generate a video loss alarm when the detected moving signal reached the sensitivity you set here.
  • Page 93  In Figure 4-76. Click button after one date or a holiday, you can see an interface shown as in Figure 4-77. There are four record types: regular, motion detection (MD), Alarm, MD & alarm.  Alarm output: when an alarm occurs, system enables peripheral alarm devices. ...
  • Page 94 Figure 4-73 Figure 4-74...
  • Page 95 Figure 4-75 Figure 4-76...
  • Page 96 Figure 4-77 Motion detect here only has relationship with the sensitivity and region setup. It has no relationship with other setups. 4.10.3.1.2 Video Loss In Figure 4-73, select video loss from the type list. You can see the interface is shown as in Figure 4-78.This function allows you to be informed when video loss phenomenon occurred.
  • Page 97 Figure 4-78 4.10.3.1.3 Tampering When someone viciously masks the lens, or the output video is in one-color due to the environments light change, the system can alert you to guarantee video continuity. Tampering interface is shown as in Figure 4-79. You can enable “Alarm output “or “Show message”...
  • Page 98 Figure 4-79 4.10.3.2 Alarm Before operation, please make sure you have properly connected alarm devices such as buzzer. In the main menu, from Setting->Event->Alarm, you can see alarm setup interface. See Figure 4-80. There are two alarm types. See Figure 4-80 to Figure 4-81. ...
  • Page 99  In Figure 4-83. Click button after one date or a holiday, you can see an interface shown as in Figure 4-84. There are four record types: regular, motion detection (MD), Alarm, MD & alarm.  Anti-dither: Here you can set anti-dither time. Here you can set anti-dither time. The value ranges from 5 to 600s.
  • Page 100 Please note, network alarm means the alarm signal from the TCP/IP. You can use NET SDK to activate network alarm. Comparing with the local alarm, there is no type, anti-dither, alarm upload function. Please highlight icon to select the corresponding function. After setting all the setups please click save button, system goes back to the previous menu.
  • Page 101 Figure 4-81 Figure 4-82...
  • Page 102 Figure 4-83 Figure 4-84 4.10.3.3 Abnormality There are two types: HDD/Network.  HDD: HDD error, no disk, no space. See Figure 4-85 and Figure 4-86.  Network: Disconnection, IP conflict, MAC conflict. See Figure 4-87.  Alarm output: Please select alarm activation output port (multiple choices). ...
  • Page 103  Latch: Here you can set corresponding delaying time. The value ranges from 1s-300s. System automatically delays specified seconds in turning off alarm and activated output after external alarm cancelled.  Show message: system can pop up the message in the local screen to alert you when alarm occurs.
  • Page 104 Figure 4-86 Figure 4-87 4.10.3.4 Alarm Output Here is for you to set proper alarm output such as schedule, manual.

  • Page 105: Storage

    Please highlight icon to select the corresponding alarm output. After all the setups please click OK button, system goes back to the previous menu. See Figure 4-88. Figure 4-88 4.10.4 Storage 4.10.4.1 Schedule 4.10.4.1.1 Record Note: You need to have proper rights to implement the following operations. Please make sure the HDDs have been properly installed.
  • Page 106  Record Type: Please check the box to select corresponding record type. There are four types: Regular/MD (motion detect)/Alarm/MD&Alarm.  Week day: There are eight options: ranges from Saturday to Sunday and all.  Holiday: It is to set holiday setup. Please note you need to go to the General interface (Main Menu->System->General) to add holiday first.
  • Page 107 Figure 4-91 Please highlight icon to select the corresponding function. After completing all the setups please click save button, system goes back to the previous menu. There are color bars for your reference. Green color stands for regular recording, yellow color stands for motion detection and red color stands for alarm recording. The white means the MD and alarm record is valid.
  • Page 108 Figure 4-92 Figure 4-93 4.10.4.1.1.1 Quick Setup Copy function allows you to copy one channel setup to another. After setting in channel 1, click Copy button, you can go to interface Figure 4-94. You can see current channel name is grey such as channel 1. Now you can select the channel you wan to paste such as channel 5/6/7.
  • Page 109 Figure 4-94 4.10.4.1.1.2 Redundancy Redundancy function allows you to memorize record file in several disks. When there is file damage occurred in one disk, there is a spare one in the other disk. You can use this function to maintain data reliability and safety. ...
  • Page 110  In main menu, from Setting->Camera->Encode->Snapshot interface, here you can input snapshot mode as regular, size, quality and frequency. See Figure 4-96.  In main menu, from Setting->Camera->Encode->Schedule interface, please enable snapshot function. See interface on the right of Figure 4-97. Please refer to the following figure for detailed information.
  • Page 111 Figure 4-97 4.10.4.1.2.2 Trigger Snapshot Please follow the steps listed below to enable the activation snapshot function. After you enabled this function, system can snapshot when the corresponding alarm occurred.  In main menu, from Setting->Camera->Encode->Snapshot interface, here you can input snapshot mode as trigger, size, quality and frequency.
  • Page 112 Figure 4-98 Figure 4-99...
  • Page 113 Figure 4-100 4.10.4.1.2.3 Priority Please note the activation snapshot has the higher priority than schedule snapshot. If you have enabled these two types at the same time, system can activate the activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot.
  • Page 114 Please input corresponding information here, if you just upload the image FTP. Figure 4-101 4.10.4.2 HDD Manager Here is for you to view and implement hard disk management. See Figure 4-102. You can see current HDD type, status, capacity and etc. The operation includes format HDD, and change HDD property (read and write/read-only/redundancy).
  • Page 115 4.10.4.3.1 Record Control Note: You need to have proper rights to implement the following operations. Please make sure the HDD has been properly installed. There are three ways for you to go to manual record menu.  Right click mouse and then select Manual->Record. ...

  • Page 116: System

    Figure 4-104 Tips You can check All button after the corresponding status to enable/disable all-channel snapshot function. 4.10.5 System 4.10.5.1 General 4.10.5.1.1 Device General setting includes the following items. See Figure 4-105.  Device ID: Please input a corresponding device name here. ...
  • Page 117  Navigation bar: Check the box here, system displays the navigation bar on the interface.  Startup wizard: Once you check the box here, system will go to the startup wizard directly when the system restarts the next time. Otherwise, it will go to the login interface.
  • Page 118 Figure 4-106 4.10.5.1.3 Holiday Holiday setup interface is shown as in Figure 4-107. Click Add new holiday button, you can input new holiday information. See Figure 4-108. Here you can set holiday name, repeat mode and start/end time. Note  When you enable Holiday settings and schedule setup at the same time, holiday setting has the priority.
  • Page 119 Figure 4-107 Figure 4-108 4.10.5.2 Display 4.10.5.2.1 Display Display setup interface is shown as below. See Figure 4-109.  Transparency: Here is for you to adjust transparency. The value ranges from 128 to 255.
  • Page 120  Channel name: Here is for you to modify channel name. System max support 25-digit (The value may vary due to different series). Please note all your modification here only applies to DVR local end. You need to open web or client end to refresh channel name.
  • Page 121 Figure 4-110 4.10.5.2.3 Tour Here you can activate tour function. Click Setup button, you can see an interface shown as in Figure 4-111  Enable tour: Highlight box here to enable this function.  Interval: System supports 1/8/-window tour. Input proper interval value here. The value ranges from 5-120 seconds.
  • Page 122 Figure 4-111 4.10.5.2.4 Favorites Click Favorites button you can go to the following interface. See Figure 4-112. It is for you to set and save favorites preview setup. You can select different wiindow display modes and then select corresponding channel(s). Please note for one mode, one channel can only be selected once.
  • Page 123  Default: it is to restore factory default setup. Figure 4-112 4.10.5.3 Video Matrix Here you can set matrix output channel and its interval. System supports 1/4-window (and etc) SPOT tour. See Figure 4-113.
  • Page 124 Figure 4-113 4.10.5.4 RS232 RS232 interface is shown as below. There are five items. See Figure 4-114.  Function: There are various devices for you to select. Console is for you to use the COM or mini-end software to upgrade or debug the program. The control keyboard is for you to control the device via the special keyboard.
  • Page 125 Figure 4-114 4.10.5.5 PTZ The pan/tilt/zoom setup includes the following items. Please select channel first. See Figure 4-115.  Control mode: You can select control mode from the dropdown list. There are two options: Serial/HDCVI. For HDCVI series product, please select HDCVI. The control signal is sent to the PTZ via the coaxial cable.
  • Page 126 Figure 4-115 4.10.5.6 ATM/POS The ATM/POS function is for financial areas. It includes Sniffer, information analysis and title overlay function. The Sniffer mode includes COM and network. 4.10.5.6.1 COM Type The COM interface is shown as below. See Figure 4-116. ...
  • Page 127 Figure 4-116 4.10.5.6.2 Network Type The network type interface is shown as below. See Figure 4-117. Here we take the ATM/POS protocol to continue. There are two types: with or without the protocol according to client’s requirements. With the protocol For ATM/POS with the protocol, you just need to set the source IP, destination IP (sometimes you need to input corresponding port number).
  • Page 128 Without the protocol For the ATM/POS without the protocol, the interface is shown as in Figure 4-118. Source IP refers to host IP address that sends out information (usually it is the device host.) Destination IP refers to other systems that receive information. Usually you do not need to set source port and target port.
  • Page 129  The user name and group name can consist of eight bytes. One name can only be used once. There are four default users: admin/888888/666666 and hidden user “default”. Except user 6666, other users have administrator right.  Hidden user “default” is for system interior use only and can not be deleted. When there is no login user, hidden user “default”...
  • Page 130 4.10.5.7.1 Add/Modify Group Click add group button, the interface is shown as below. See Figure 4-120. Here you can input group name and then input some memo information if necessary. There are total 98 rights such as control panel, shut down, real-time monitor, playback, record, record file backup, PTZ, user account, system information view, alarm input/output setup, system setup, log view, clear log, upgrade system, control device and etc.
  • Page 131 Click add user button, the interface is shown as in Figure 4-121. Please input the user name, password, select the group it belongs to from the dropdown list. Then you can check the corresponding rights for current user. For convenient user management, usually we recommend the general user right is lower than the admin account.
  • Page 132 Figure 4-122 4.10.5.9 Config Backup The configuration file backup interface is shown as below. See Figure 4-123. This function allows you to import/export system configuration. You can use this function when there are several devices need the same setup.  Export: Please connect the peripheral device first and then go to the following interface.
  • Page 133 Figure 4-123 4.10.5.10 Default Click default icon, system pops up a dialogue box. You can highlight to restore default factory setup. See Figure 5-26.  Camera  Network  Event  Storage  System Please highlight icon to select the corresponding function. After all the setups please click save button, system goes back to the previ ous menu.
  • Page 134 Figure 4-124 4.10.5.11 Update Here is for you to view hardware features, software version, built date, release SN information and etc. You can also update system here. See Figure 4-40.  Start: Please insert the USB device that have the update file to the device and then click the Start button to begin the update.

  • Page 135: Web Operation

    5 WEB OPERATION Slightly difference may be found in the interface due to different series. 5.1 Network Connection Before web client operation, please check the following items:  Network connection is right  DVR and PC network setup is right. Please refer to network setup(main menu->Setting->Network) ...

  • Page 136: Lan Mode

    Figure 5-2 5.3 LAN Mode For the LAN mode, after you logged in, you can see the main window. See Figure 5-3. Figure 5-3 This main window can be divided into the following sections.  Section 1: there are five function buttons: Live（chapter 5.4）, setup (chapter 5.8), search (chapter 5.10), alarm (chapter 5.11), and logout (chapter 5.12).
  • Page 137  Section 2: There are channel number and one button: Start all. Start all button is to enable/disable all-channel real-time monitor. Click it the button becomes yellow. See Figure 5-4. Figure 5-4 Please refer to Figure 5-5 for main stream and extra stream switch information. Figure 5-5 ...

  • Page 138: Real-Time Monitor

    Figure 5-8  Section 6: From the left to the right ,you can see video quality/fluency/ full screen/1-window/4-window/6-window/8-window/9-window/13-window/16-window/20- window/25-window/36-window.. You can set video fluency and real-time feature priority.  Section 7: PTZ operation panel. Please refer to chapter 5.5 for detailed information. ...

  • Page 139: Ptz

     1: Digital zoom: Click this button and then left drag the mouse in the zone to zoom in. right click mouse system restores original status.  2: Local record. When you click local record button, the system begins recording and this button becomes highlighted.

  • Page 140: Image/Relay-Out

    Parameter Function You can turn on or turn off the light/wiper. Light and wiper 3D Intelligent Positioning You can click this icon to display or hide the PTZ control platform. Figure 5-11 5.6 Image/Relay-out Select one monitor channel video and then click Image button in section 8, the interface is shown as Figure 5-12.

  • Page 141: Wan Login

    Figure 5-13 5.7 WAN Login In WAN mode, after you logged in, the interface is shown as below. See Figure 5-14. Figure 5-14 Please refer to the following contents for LAN and WAN login difference. 1) In the WAN mode, system opens the main stream of the first channel to monitor by default.

  • Page 142: Setup

    Figure 5-15 Important The window display mode and the channel number are by default. For example, for the 16-channel, the max window split mode is 16. 3) Multiple-channel monitor, system adopts extra stream to monitor by default. Double click one channel, system switches to single channel and system uses main stream to monitor.
  • Page 143 after you set. See Figure 5-16. Figure 5-16 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Period It divides one day (24 hours) to two periods. You can set different hue, brightness, and contrast for different periods.
  • Page 144 from 40 to 60. Color mode It includes several modes such as standard, color. You can select corresponding color mode here, you can see hue, brightness, and contrast and etc will adjust accordingly. 5.8.1.2 Encode 5.8.1.2.1 Encode The encode interface is shown as below. See Figure 5-17. Figure 5-17 Please refer to the following sheet for detailed information.
  • Page 145 here refers to the capability of the network camera. Frame Rate PAL：1～25f/s；NTSC：1～30f/s.  Bit Rate Main stream: You can set bit rate here to change video quality. The large the bit rate is , the better the quality is. Please refer to recommend bit rate for the detailed information.
  • Page 146 It is to set snapshot frequency. The value ranges from 1s to 7s. Interval Or you can set customized value. The max setup is 3600s/picture. Click it; you can copy current channel setup to other channel(s). Copy 5.8.1.2.3 Video Overlay The video overlay interface is shown as in Figure 5-19.

  • Page 147: Network

    storage path ( in the preview interface).The default setup is C:\PictureDownload and C:\RecordDownload. Please click the Save button to save current setup. Figure 5-20 5.8.1.3 Channel Name Here you can set channel name. See Figure 5-21. Please note this function is for analog channel only. The digital channel name here is read-only.
  • Page 148 Parameter Function Mode There are two modes: static mode and the DHCP mode.  The IP/submask/gateway are null when you select the DHCP mode to auto search the IP.  If you select the static mode, you need to set the IP/submask/gateway manually.
  • Page 149 TCP port The default value is 37777. You can input the actual port number if necessary. UDP port The default value is 37778. You can input the actual port number if necessary. HTTP port The default value is 80. You can input the actual port number if necessary.
  • Page 150 Figure 5-25 Please refer to the following sheet for detailed information. Parameter Function WLAN type Here you can select 3G network type to distinguish the 3G module from different ISP. The types include WCDMA， CDMA1x and etc. APN/Dial No. Here is the important parameter of PPP. Authorization It includes PAP,CHAP,NO_AUTH.
  • Page 151 Figure 5-26 5.8.2.5 PPPoE The PPPoE interface is shown as in Figure 5-27. Input the PPPoE user name and password you get from the IPS (internet service provider) and enable PPPoE function. Please save current setup and then reboot the device to get the setup activated.
  • Page 152 Figure 5-28 Please refer to the following sheet for detailed information. Parameter Function Server Type You can select DDNS protocol from the dropdown list and then enable DDNS function. Server IP DDNS server IP address Server Port DDNS server port. Domain Name Your self-defined domain name.
  • Page 153 Except default domain name registration, you can also use customized domain name (You can input your self-defined domain name.) After successful registration, you can use domain name to login installed of the device IP.  User name: It is optional. You can input your commonly used email address. Important ...
  • Page 154 Figure 5-30 Please refer to the following sheet for detailed information. Parameter Function Please check the box here to enable email function. Enable Input server address and then enable this function. SMTP Server Port Default value is 25. You can modify it if necessary. Anonymity For the server supports the anonymity function.
  • Page 155 Parameter Function Please check the box here to enable this function. Health mail enable This function allows the system to send out the test email to Update period check the connection is OK or not. (interval) Please check the box to enable this function and then set the corresponding interval.
  • Page 156 Figure 5-32 5.8.2.11 SNMP The SNMP interface is shown as in Figure 5-33. The SNMP allows the communication between the network management work station software and the proxy of the managed device. It is reserved for the 3 party to develop. Figure 5-33 Please refer to the following sheet for detailed information.
  • Page 157 Parameter Function and one group of the managers. Please make sure the device and the proxy are the same. The read community will read/write/access all the objects the SNMP supported in the specified name. The default setup is write. The destination address of the Trap information from the proxy Trap address program of the device.
  • Page 158 5.8.2.14 Alarm Centre The alarm centre interface is shown as below. See Figure 5-36. This interface is reserved for you to develop. System can upload alarm signal to the alarm centre when local alarm occurs. Before you use alarm centre, please set server IP, port and etc. When an alarm occurs, system can send out data as the protocol defined, so the client-end can get the data.
  • Page 159 Figure 5-38 You can see the corresponding prompt. See Figure 5-39. Now the server certificate is successfully created. Figure 5-39 5.8.2.15.2 Download root certificate In Figure 5-37, click button, system pops up a dialogue box. See Figure 5-40. Figure 5-40 Click Open button, you can go to the following interface.
  • Page 160 Figure 5-41 Click Install certificate button, you can go to certificate wizard. See Figure 5-42. Figure 5-42 Click Next button to continue. Now you can select a location for the certificate. See Figure 5-43.
  • Page 161 Figure 5-43 Click Next button, you can see the certificate import process is complete. See Figure 5-44. Figure 5-44 Click Finish button, you can see system pops up a security warning dialogue box. See Figure 5-45.
  • Page 162 Figure 5-45 Click Yes button, system pops up the following dialogue box, you can see the certificate download is complete. See Figure 5-46. Figure 5-46 5.8.2.15.3 View and set HTTPS port From Setup->Network->Connection, you can see the following interface. See Figure 5-47. You can see HTTPS default value is 443.

  • Page 163: Event

    5.8.3 Event 5.8.3.1 Video detect 5.8.3.1.1 Motion Detect The motion detect interface is shown as in Figure 5-48. Figure 5-48 Figure 5-49...
  • Page 164 Figure 5-50 Figure 5-51 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable motion detection function. Please select a channel from the dropdown list.
  • Page 165 Parameter Function Period Motion detection function becomes activated in the specified periods. See Figure 5-49. There are six periods in one day. Please draw a circle to enable corresponding period. Click OK button, system goes back to motion detection interface, please click save button to exit.
  • Page 166 Here you can set PTZ movement when alarm occurs. Such as go Activation to preset X. See Figure 5-51. Video Matrix This function is for motion detect only. Check the box here to enable video matrix function. Right now system supports one-channel tour function.
  • Page 167 Figure 5-53 5.8.3.2 Alarm Before operation, please make sure you have properly connected alarm devices such as buzzer. The input mode includes local alarm and network alarm. 5.8.3.2.1 Local Alarm The local alarm interface is shown as in Figure 5-54. It refers to alarm from the local device.
  • Page 168 Figure 5-55 Figure 5-56 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable this function. Please select a channel from the dropdown list. Period This function becomes activated in the specified periods. There are six periods in one day.
  • Page 169 Parameter Function whole week. Click OK button, system goes back to local alarm interface, please click save button to exit. System only memorizes one event during the anti-dither Anti-dither period. The value ranges from 5s to 600s. There are two options: NO/NC. Sensor type Record channel System auto activates motion detection channel(s) to...
  • Page 170 Figure 5-57 5.8.3.3 Alarm Output It is to set alarm output mode. See Figure 5-58. Figure 5-58 5.8.3.4 Abnormality It includes two types: No disk, disk error, disk no space, net disconnection, IP conflict and MAC conflict. See Figure 5-59 and Figure 5-60. Figure 5-59...

  • Page 171: Storage

    Figure 5-60 Please refer to the following sheet for detailed information. Parameter Function Event The abnormal events include: No disk, disk error, disk no space, net Type disconnection, IP conflict and MAC conflict. You can set one or more items here. Less than: You can set the minimum percentage value here (For disk not space only).
  • Page 172 Figure 5-61 Figure 5-62...
  • Page 173 Figure 5-63 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Pre-record Please input pre-record time here. The value ranges from 0 to 30. Redundancy Check the box here to enable redundancy function. Please note this function is null if there is only one HDD.
  • Page 174 Parameter Function Now you can select the channel you wan to paste such as channel 5/6/7. If you wan to save current setup of channel 1 to all channels, you can click the first box “ALL”. Click the OK button to save current copy setup.
  • Page 175 Figure 5-66 Please refer to the following sheet for detailed information. Parameter Function Here you can view channel number. Channel The number displayed here is the max channel amount of your device. Status There are three statuses: schedule, manual and stop. System enables auto record function as you set in record schedule Schedule setup (general, motion detect and alarm).

  • Page 176: Setting

    Figure 5-67 5.8.4.4.2 Sub Stream The sub stream interface is shown as in Figure 5-68. Here you can set corresponding HDD group to save sub stream. Figure 5-68 5.8.4.4.3 Snapshot The snapshot interface is shown as in Figure 5-69. Here you can set corresponding HDD group to save snapshot picture.
  • Page 177 The general interface is shown as in Figure 5-70. Figure 5-70 Please refer to the following sheet for detailed information. Parameter Function It is to set device name. Device ID Device No. It is device channel number. Language You can select the language from the dropdown list. Please note the device needs to reboot to get the modification activated.
  • Page 178 Figure 5-71 Please refer to the following sheet for detailed information. Parameter Function Here you can select date format from the dropdown list. Date format There are two options: 24-H and 12-H. Time Format The time zone of the device. Time zone It is to set system time.
  • Page 179 Figure 5-73 Please refer to the following sheet for detailed information. Parameter Function There are four options: 1920× 1080,1280 × 1024(default),1280 × Resolution 720,1024×768. Please note the system needs to reboot to activate current setup. Here is for you to adjust transparency. The value ranges from 128 Transparency to 255.
  • Page 180 Figure 5-75 Please refer to the following sheet for detailed information. Parameter Function Check the box here to enable tour function. Enable tour Here is for you to adjust transparency. The value ranges from 5 to Interval 120s. The default setup is 5s. Here you can set window mode and channel group.
  • Page 181 The RS232 interface is shown as in Figure 5-77. Figure 5-77 Please refer to the following sheet for detailed information. Parameter Function Select the corresponding dome protocol. Protocol Default setup is console. Select the baud rate. Baud Rate Default setup is 115200. Data Bit The value ranges from 5 to 8.
  • Page 182 Parameter Function Select speed dome connected channel. Channel You can select control mode from the dropdown list. There are two Control mode options: Serial/HDCVI. For HDCVI series product, please select HDCVI. The control signal is sent to the PTZ via the coaxial cable. For the serial mode, the control signal is sent to the PTZ via the RS485 port.
  • Page 183 The network type interface is shown as below. See Figure 5-80. Here we take the ATM/POS protocol to continue. There are two types: with or without the protocol according to client’s requirements. With the protocol For ATM/POS with the protocol, you just need to set the source IP, destination IP (sometimes you need to input corresponding port number).
  • Page 184 5.8.5.7 Account Note:  For the character in the following user name or the user group name, system max supports 6-digits. The space in the front or at the end of the string is null. The valid string includes: character, number, and underline. ...
  • Page 185 Figure 5-83 Modify user It is to modify the user property, belonging group, password and rights. See Figure 5-84. Modify password It is to modify the user password. You need to input the old password and then input the new password twice to confirm the new setup. Please click the OK button to save. Please note, the password ranges from 1-digit to 6-digit.
  • Page 186 Figure 5-84 5.8.5.7.2 Group The group management interface can add/remove group, modify group password and etc. The interface is shown as in Figure 5-85. Figure 5-85 Add group: It is to add group and set its corresponding rights. See Figure 5-86. Please input the group name and then check the box to select the corresponding rights.
  • Page 187 includes: shutdown/reboot device, live view, record control, PTZ control and etc. Figure 5-86 Modify group Click the modify group button, you can see an interface is shown as in Figure 5-87. Here you can modify group information such as remarks and rights. Figure 5-87...
  • Page 188 5.8.5.8 Auto maintain The auto maintain interface is shown as in Figure 5-88. Here you can select auto reboot and auto delete old files interval from the dropdown list. If you want to use the auto delete old files function, you need to set the file period. Click Manual reboot button, you can restart device manually.

  • Page 189: Information

    5.8.5.11 Upgrade The upgrade interface is shown as in Figure 5-91. Please select the upgrade file and then click the update button to begin update. Please note the file name shall be as *.bin. During the upgrade process, do not unplug the power cable, network cable, or shutdown the device.

  • Page 190: Connection Log

    Figure 5-93 Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, data Type operation, event operation, record operation, user management, log clear. Set the start time of the requested log. Start time Set the end time of the requested log.

  • Page 191: Online User

    Figure 5-94 5.9.4 Online User The online user interface is shown as in Figure 5-95. Figure 5-95 5.10 Playback Click Playback button, you can see an interface is shown as in Figure 5-96. Please set record type, record date, window display mode and channel name. You can click the date on the right pane to select the date.
  • Page 192 Figure 5-96 Then please click File list button, you can see the corresponding files in the list. See Figure 5-97. Figure 5-97 Select a file you want to play and then click Play button, system can begin playback. You can select to playback in full-screen. Please note for one channel, system can not playback and download at the same time.
  • Page 193 Figure 5-98 Select the file(s) you want to download and then click download button, you can see an interface shown as in Figure 5-99. The Download button becomes Stop button and there is a process bar for your reference. Please go to you default file saved path to view the files.
  • Page 194 Load more It is for you to search record or picture. You can select record channel, record type and record time to download. There are two download types. The download by file interface is shown as in Figure 5-100 and the download by time interface is shown as in Figure 5-101. Figure 5-100 Figure 5-101 Watermark...

  • Page 195: Alarm

    Figure 5-102 5.11 Alarm Click alarm function, you can see an interface is shown as Figure 5-103. Here you can set device alarm type and alarm sound setup (Please make sure you have enabled audio function of corresponding alarm events.). Figure 5-103 Please refer to the following sheet for detailed information.

  • Page 196: Log Out

    Type Parameter Function Disk error System alarms when disk error occurs. External alarm Alarm input device sends out alarm. Operation Prompt Check the box here, system can automatically pops up an alarm icon on the Alarm button in the main interface when there is an alarm.

  • Page 197: Professional Surveillance System

    6 Professional Surveillance System Besides Web, you can use our Professional Surveillance Software (PSS) to login the device. For detailed information, please refer to PSS user’s manual.

  • Page 198: Faq

    7 FAQ 1. DVR can not boot up properly. There are following possibilities:  Input power is not correct.  Power connection is not correct.  Power switch button is damaged.  Program upgrade is wrong.  HDD malfunction or something wrong with HDD ribbon. ...
  • Page 199  DVR and monitor resistance is not compatible.  Video transmission is too long or degrading is too huge.  DVR color or brightness setup is not correct. 6. Can not search local records. There are following possibilities:  HDD ribbon is damaged. ...
  • Page 200  PTZ decoder setup, connection or installation is not correct.  Cable connection is not correct.  PTZ setup is not correct.  PTZ decoder and DVR protocol is not compatible.  PTZ decoder and DVR address is not compatible. ...
  • Page 201  MAC address conflict.  PC or DVR network card is not good. 16. Burn error /USB back error. There are following possibilities:  Burner and DVR are in the same data cable.  System uses too much CPU resources. Please stop record first and then begin backup.
  • Page 202  Camera quality is too low. Lens is dirty. Camera is installed against the light. Camera aperture setup is not correct.  HDD capacity is not enough.  HDD is damaged. 22. Can not playback the downloaded file. There are following possibilities: ...
  • Page 203  Please check and maintain the device regularly.

  • Page 204: Appendix A Hdd Capacity Calculation

    Appendix A HDD Capacity Calculation Calculate total capacity needed by each DVR according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte. ...
  • Page 205 448K 196M 512K 225M 640K 281M 768K 337M 896K 393M 1024K 450M 1280K 562M 1536K 675M 1792K 787M 2048K 900M...

  • Page 206: Appendix B Compatible Backup Devices

    Appendix B Compatible backup devices Appendix B-1 Compatible USB list Manu factor Model Capacity Sandisk Cruzer Micro 512M Sandisk Cruzer Micro Sandisk Cruzer Micro Sandisk Cruzer Freedom 256M Sandisk Cruzer Freedom 512M Sandisk Cruzer Freedom Sandisk Cruzer Freedom DataTraveler Ⅱ Kingston DataTraveler Ⅱ...

  • Page 207: Appendix B-2 Compatible Sd Card List

    Kingston Data Traveler 32GB Aigo L8315 16GB Sandisk 16GB Kingston Data Traveler Locker+ 32GB Netac U228 Appendix B-2 Compatible SD Card list Brand Standard Capacity Card type Transcend SDHC6 16GB Kingston SDHC4 Kingston Kingston Sandisk SDHC2 Small Sandisk Small Appendix B-3 Compatible Portable HDD list Brand Model Capacity...

  • Page 208: Appendix B-6 Compatible Sata Hdd List

    Samsung TS-H653 Ver.F Samsung SH-224BB/CHXH SONY DRU-V200S SONY DRU-845S SONY AW-G170S Pioneer DVR-217CH Appendix B-6 Compatible SATA HDD List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. Here we recommend HDD of 500G to 4T capacity. Port Manufacturer Series...
  • Page 209 Seagate Seagate Pipeline HD2 ST31000322CS SATA Seagate Seagate Pipeline HD2 ST1000VM002 SATA Seagate Seagate Pipeline HD2 ST1500VM002 SATA Seagate Seagate Pipeline HD2 ST2000VM002 SATA Seagate Seagate Pipeline HD2 ST2000VM003 SATA Seagate Seagate Constellation ST3500514NS 500G SATA Seagate Seagate Constellation ST31000524NS SATA Seagate Seagate Constellation...
  • Page 210 Westem Digital Cariar SE WD2500JS 250G SATA Westem Digital Cariar SE16 WD7500KS 750G SATA Westem Digital Cariar SE16 WD5000KS 500G SATA Westem Digital Cariar SE16 WD4000KD 400G SATA Westem Digital Cariar SE16 WD3200KS 320G SATA Westem Digital Cariar SE16 WD2500KS 250G SATA Westem Digital...
  • Page 211 Hitachi HitachiCinemaStar™ HCP725050GLA380 500G SATA 5K500 Hitachi HitachiCinemaStar™ HCT721050SLA360 500G SATA 7K1000.B Hitachi HitachiCinemaStar™ HCT721075SLA360 750G SATA 7K1000.B Hitachi HitachiCinemaStar™ HCT721010SLA360 SATA 7K1000.B Maxtor DiamondMax 20 STM3320820AS 320G SATA Maxtor DiamondMax 20 STM3250820AS 250G SATA...

  • Page 212: Appendix Ccompatible Cd/Dvd Burner List

    Appendix C Compatible CD/DVD Burner List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. And you can use the USB cable with the model recommended to set USB burner. Manufacturer Model Port Type Type Sony...

  • Page 213: Appendix D Compatible Displayer List

    Appendix D Compatible Displayer List Please refer to the following sheet form compatible displayer list. Brand Model Dimension (Unit: inch) BENQ（LCD） ET-0007-TA 19-inch (wide screen) DELL（LCD） E178FPc 17-inch BENQ（LCD） Q7T4 17-inch BENQ（LCD） Q7T3 17-inch HFNOVO（LCD） LXB-L17C 17-inch 22 寸(wide screen) SANGSUNG（LCD）...

  • Page 214: Appendix E Compatible Switcher

    Appendix E Compatible Switcher Brand Model network working mode D-LinK DES-1016D 10/100M self-adaptive D-LinK DES-1008D 10/100M self-adaptive Five network modes 1. AUTO 2. HALF-10M Ruijie RG-S1926S 3. FULL-10M 4 .HALF-100M 5. FULL-100M H3C-S1024 10/100M self-adaptive TP-LINK TL-SF1016 10/100M self-adaptive TP-LINK TL-SF1008+ 10/100M self-adaptive...

  • Page 215: Appendix Fcompatible Wireless Mouse List

    Appendix F Compatible Wireless Mouse List Please refer to the following sheet for compatible SD card brand. Brand Model Rapoo 3500 Logitech M215 Shuangfeiyan Tianyao G7-630...

  • Page 216: Appendix G Earthing

    Appendix G Earthing 1. What is the surge? Surge is a short current or voltage change during a very short time. In the circuit, it lasts for microsecond. In a 220V circuit, the 5KV or 10KV voltage change during a very short time (about microseconds) can be called a surge.
  • Page 217  Signal lightning arrester: This device is mainly used in the PC network, communication system. The connection type is serial connection. Once you connected the signal lightning arrestor with the signal port, it can cut the channel of the thunderstorm to the device, and on the other hand, it can discharge the current to the ground to guarantee the device proper work.
  • Page 218 conductance of the ground conductor. In the high-frequency circuit, you need to use the multiple-point ground mode and each cable needs to connect to the ground. The length shall be less than the 1/20 of the signal wavelength. Mixed ground: The mix ground consists of the feature of the one-point ground and multiple-point ground.
  • Page 219  The thunder proof ground shall adopt the special ground cable from the monitor control room to the ground object. The ground cable adopts copper insulation cable or wire and its ground section shall be more than 20mm2.  The ground cable of the monitor system can not short circuit or mixed connected with the strong alternative current cable.
  • Page 220 For L (live cable) Turn the digital multimeter to 750V AC, use your one hand to hold the metal end, and then the other hand insert the pen to the L port of the socket. See the following figure. If the multimeter shows 120, then you can see current live cable connection is standard.

  • Page 222: Appendix H Toxic Or Hazardous Materials Or Elements

    Appendix H Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Sheet ○ ○ ○ ○ ○ ○ Metal(Case) Plastic Parts ○ ○ ○ ○ ○ ○ （Panel） ○ ○ ○ ○ ○...

Table of Contents
