Page 1: User Manual
SoundScape Player User Manual Exstreamer SoundScape User Manual v1.0 October 2015 SOUNDSCAPE PLAYER USER MANUAL ... -
Page 2: Table Of Contents
1. INTRODUCTION ................3 2. SOUNDSCAPE PORTAL SETUP ............3 3. SOUNDSCAPE PLAYER WEB USER INTERFACE ......4 4. HOME TAB .................. 5 5. NETWORK TAB ................6 6. SYSTEM TAB ................8 7. FILES TAB ................... 9 Pre-loading content on devices ............9 8. -
Page 3: Introduction
SoundScape Portal account or configuration. In this document, we assume that the SoundScape Portal is accessible for the user and its entire configuration has already been done. SOUNDSCAPE PLAYER USER MANUAL... -
Page 4: Soundscape Player Web User Interface
IP address of the device. This is how the login page of the SoundScape Player looks like: There are 2 types of users that can access the web UI of a SoundScape Player: 1. User (default password: Ubarix) 2. -
Page 5: Home Tab
4. Home tab The first tab that will open when accessing the web UI of a SoundScape player is the Home tab, with a PLAYER section displaying information about the status of the player and some basic commands that allow the user to change the Master Volume or skip Tracks from a Playlist. -
Page 6: Network Tab
IP address or Name to which the device should be calling in. By default it is directed to the production SoundScape Portal http://soundscape.barix.com. TIP: In order to use the device for a trial in the SoundScape DEMO Portal, this address has to be set to http://soundscapedemo.barix.com... - Page 7 Portal with the “Call-In Now” button. Additionally, the user can save a text file with “Export Network Text”. Exstreamer SoundScape users can make network configuration changes directly from the Keypad without having to access the web UI.
-
Page 8: System Tab
NOTE: Please be very careful when formatting the MicroSD since all of the Content (including the Tracks) will need to be re-downloaded from the Portal. For Exstreamer SoundScape players, the formatting action can also be triggered from the Keypad in the Media menu (press OK to enter Menu, click 2x Arrow down to select “Media”, select it with OK and press OK again to “Format SD card”). -
Page 9: Files Tab
7. Files tab The Files tab provides the user information about the files being stored in the internal MicroSD card of the SoundScape Player device. For each sub-tab, the device shows the File Name with the ID number that is used in the Portal, the Size and the last modified timestamp. - Page 10 Portal. For Exstreamer SoundScape users, the cloning functionality is also available from the Keypad, so it’s not necessary to access the web UI of the device to trigger this action (devices don’t even need to be connected to any network!).
-
Page 11: Logs Tab
The “Refresh Logs” button updates the view with the latest logs (that appear at the end of the page) and the “Latest Entries” button brings the user to the end of the page without having to manually scroll down. SOUNDSCAPE PLAYER USER MANUAL ... -
Page 12: Security Tab
The CUSTOMER USER PERMISSIONS lists all the actions and action buttons that will be available for a normal User of the web UI. NOTE: For Exstreamer SoundScape users it is possible to disable the operation of the Physical Keypad to avoid undesired manipulation of the device in the deployed Location. -
Page 13: Update Tab
The Update tab allows users to update devices via web UI and to change the web UI Language (and add new languages!). In order to update the firmware version of the SoundScape application please read the “SoundScape Update Readme.pdf” file that comes with the zipped file containing the update PKG and other necessary files. -
Page 14: Legal Information
All mentioned trademarks belong to their respective owners and are used for reference only. Barix, Exstreamer, Instreamer, SonicIP and IPzator are trademarks of Barix AG, Switzerland and are registered in certain countries. For information about our devices and the latest version of this manual please visit www.barix.com.
